NST CPT2IP User manual

IP Wireless / Wired Camera
H
H.
.2
26
64
4I
IP
P
C
Ca
am
me
er
ra
aUser Manual
(For Windows OS)
1-512-756-1678
CPT2IP

IPCAM User Manual
2
Content
1Product Overview.....................................................................................................4
1.1 Product package ................................................................................................4
1.2 Product Characteristics......................................................................................4
2Device apprearance and interface installation.............................................................5
2.1 Device apprearance............................................................................................5
2.2 Interface installation..........................................................................................6
3Device installation.....................................................................................................6
3.1 Hardware installation.........................................................................................7
3.2 Software installation......................................................................................... 10
4Visit IP Camera in LAN ..............................................................................................11
4.1 Connect in LAN................................................................................................11
4.2 Search and set device IPaddress........................................................................11
4.3 LOGIN IP Camera........................................................................................... 12
4.4 IPcamera operation......................................................................................... 16
4.4.1 Menu bar........................................................................................................ 16
4.4.2 Video playing area........................................................................................... 17
4.4.3 Control area.................................................................................................... 17
4.4.4 Functions and setting area................................................................................ 18
5 Visit IPCamera in internet...................................................................................... 19
5.1 Connect in the Internet..................................................................................... 19
5.2 Related setiing and visit IPcamera.................................................................... 19
6 The device like Mobile phone , PAD Etc. visit IP Camera.......................................... 23
6.1 Visit ip camera via Android app........................................................................ 23
6.2 Visit ip camera via Iphone app.......................................................................... 25
7 An introduction to centralized monitoring software.................................................. 28
8 Othersetting........................................................................................................... 29
8.1 System............................................................................................................. 29
8.1.1 System status................................................................................................ 29
8.1.2 Device time Setting....................................................................................... 29
8.1.3 User management......................................................................................... 30
8.1.4 Other options setting..................................................................................... 30
8.1.5 Firmware upgrade and reset......................................................................... 31
8.2 Network setting................................................................................................ 31
8.2.1 Network parameters .................................................................................. 31
8.2.2 wireless fidelity(WIFI)setting.................................................................... 32
8.2.3 DDNS setting................................................................................................ 33
8.2.4 MSTPsetting................................................................................................ 34
8.2.5 PTZsetting................................................................................................... 35
8.3 Audio and video setting.................................................................................... 35

IPCAM User Manual
3
8.4 Alarm setting................................................................................................... 37
9 APPENDIX............................................................................................................. 38
9.1 Register and apply for DDNS Service ................................................................ 38
9.2 Frequently Asked Questions ............................................................................. 43
9.2.1 I have forgetten the username and / or password............................................ 43
9.2.2 IPAddress configuration............................................................................... 43
9.2.3 Network configuration.................................................................................. 43
9.2.4 No pictures show........................................................................................... 44
9.2.5 Network bandwidth problems ....................................................................... 44
9.2.6 IPcamera has connected with internet, why can't visit though IP camera........ 44
9.3 The solution for common operation problems.................................................... 61
9.4 The default Parameters.................................................................................... 45
9.5 Technical parameters ....................................................................................... 46

IPCAM User Manual
4
1Products overview
CPT2IP is a IP integrated camera solution. For the user based on the local network
( LAN ) and wide area network ( WAN ) remote video surveillance products provides a clear,
high integration, low cost solution. Integrated network and web service function, the shooting of
the video can be transmitted through the network to any place, through a web browser you can
readily access live video. It can be applied in large stores, schools, factories, families and a
many other places. Easy to install, easy to operate.
1.1 Product package list
Remark:if you choose Wifi fuction device, You will need to connect the included Wi-Fi antenna.
Before you install the IP camera, please check that all accessories are
included. If it lacks something, please contact an agent.
1.2 Product Features
●Powerful high-speed video protocol processor
●High-sensitivity 1/4" CMOS sensor, support 720P (1280*720) video coding of various video
parameter adjustments, meet all kinds of user browser demands. Industrial quality
CMOS camera, achieves a good lowillumination effect.
●It uses advanced H264 video Compression, supports H264MainProfile@Level3.0coding,H.264
Baseline Profile@Level3.0coding and MJPEG/JPEG Baseline coding, and it can easily
transmit HD image with low bandwidth and save storage space.
●It supports complete SIP function, Inner microphone can achieve audio collection and two
ways audio function;And have clear voice, small delay and no dropping frames of the audio.
●IR night vision to support long distance night vision scope and achieve 24/7 monitoring
●Embedded Linux operating system, inner WEB SERVER supports direct Web browser access,
The system is stable, powerful, safe and reliable.
●Multi-level users management and passwords definition
●Support wifi network (Wi-Fi/802.11/b/g),Inner Wifi module can flexibly create wifi monitoring
environment.;
●Supportsmotion detection which can achieve 24/7 monitoring. It can e-mail, FTP and send
alarm message though alarm server etcs. To achieve many kinds of alarm function.;
●Pan/Tilt Pan 330°、Tilt 90° Unit is tiny and convenient to install, which is suitable for all
kinds of places;
●Support UPNP. It can support to achieve auto port map in the router;
●With SD card slot, makes it convenient for users to store images;
●Supportsremote upgrade;Supportsmobile phone viewing
●Factory set every device to a unique device serial number, unique factory DDNS, and burn
it to device and when it connects with public internet, then it can visit though DDNS.

IPCAM User Manual
5
2Device appearance and interface
2.1 Device appearance
Picture 1 Device appearance
1. Photo Sensor: Senses outside light conditons to decide whether to turn on/off infrared LED
2. Infrared LED
3. Lens :CMOS Sensor .You can turn around the lens manually to adjust the focus range
4. Build-in Microphone
Phote Sensor
HD Glass Lens
Built in sound
Infrared LED
WIFI antenna
Build-in Microphone

IPCAM User Manual
6
2.2Device interface
Picture 2 Device interface
LAN : RJ-45/10-100 Base T
DC5V : 5V/2APower supply
I/O PINS: 1)Output(GND) 2)Output (+5V) 3)Alarm input 4)Input (GND)
Picture 3 Reset Button
RESET BUTTON: Press and hold down the RESET BUTTON for 5 seconds. IP camera will
be reset back to the factory default parameter
3 Device installation
System configuration requirements:
CPU:P4 2.0GHZ or above Memory: 512M or above
Network Card: 10M or above Display Card: Microsoft DirectX 9 Picture device or above
memory
Recommended Operating System: WindowsXP.Vista. Windows 7
Support web browser: IE .Firefox 、Safari 、Chrome etc .
RESET BUTTON
I/O Alarm input/output
DC5V Power adapter
WIFI antenna
RJ-45 Ethernet Port
Audio output
SD Card Slot

IPCAM User Manual
7
3.1 Hardware installation
You should install your IP Camera's hardware according to the following step in order to
make sure the IP camera worksproperly. Especially, pay attention to IP camera's installation
environment.
1) IPCAM. Plug DC adapter with IP camera
I.Note: Please use supplied or approved DCadapteron of IP camera. Using DC
adapter without any certificate, may destroy IP camera.
2) Plug cable from IP camera, and the other end of cable should connect with DSL or router. In
addition, make sure power of IP camera worksproperly and IP camera and PC are in the same
Subnet Mask
Picture 4 Network connection sketch map
3) When you use the CPT2IP for the first time, Unit should be set for DHCP
automatically. (Before using, please make sure " DHCP" Server function in LAN's
router has been opened, or Server system open " DHCP" Server function) It is very

IPCAM User Manual
8
convenient for users to use because it is suitable for different LAN NETWORK
environment.
Picture 5
4) You can search PC IP and DNS Server as belows:
Picture 6
users can click the ―start‖menu, choose‖run‖, then try‖command ‖or‖cmd‖(for windows
xp,2000),then confirm it. And type ―ipconfig‖and press (ENTER). Then user can check the network
settings as below.
This is the server which provide
the service of DNS

IPCAM User Manual
9
5)The ip address of the device can be changed, but the subnet of device and PC should be the
same as eachothe. Please check the ip address,subnet mask and default gateway
Picture 7
To test CPT2IP whether it starts smoothly or it connects properly, we can operate
in the Windows(START- RUN-CMD), and then input :ping 192.168.1.111
Picture 8 ping IP Camera
To check whether you can "Ping" CPT2IP, If 4 packets received and sent , then it means IP
Camera has been networked properly to LAN.
Network server provide DNS
server Address
User can change the IP address

IPCAM User Manual
10
3.2 Software installation
Software installation
●It is very easy to install software. You just need to run installation program then
follow on screen directions.
·Please put CD into PC and the CD will automatically run to the software
installation interface:
If no such an interface, please click “autorun.exe”in the CD
●And then find“search.exe”Clink and install LAN Tool to PC system,then
you can view " IP Camera Tool" in Computer desktop for LAN Search tool.“IP
Camera Tool”
G
Picture9 Software installation interface
Min
User manual Open user manual Exit
Search tool in LAN Application Tool box Open CD
Client instructions

IPCAM User Manual
11
4 Visit Ip Camera in LAN
4.1 Connect in LAN
Picture 10 Connection between Several IP camera and router
4.2 Search and set device IP address
Please note before searching IP camera:
1:Make sure IP camera has a good connection with power and network.
2:The router should be opened DHCP(Dynamic host configuration protocol) because the factorysetting
status of IPcamera is to obtain automatically IP camera.
3:When powering CPT2IP, expect to wait 20 secondsfor unit to power up
Search IP camera
When we run Search tool" IP camera Tool", we can find the IP camera showing IP
address, Port, Name. If we use Wi-fi connection, we will find Wi-fi IP address. For
the details, we can view the following picture.
Picture 11
Note:(“IP Camera Tool.exe”Program is for use to search IP camera address and port in
the LAN. The tool can't search IP camera IP address and port in the WAN.
There are 3 situations:
1Can not find the device and (re-search) can not locate it in the LAN, please check whether the power
and network cable are working properly.
2Searching for the device in LAN, all the devices will be listed as shown in Picture 12.
3Devices installed in the LAN, but not in the same network segment where the computer and the
IPCamera are in. The device's IP address will be listed, but you can not turn the camera on, just change
the

IPCAM User Manual
12
network parameter in accordance with the computer, and it will be ok.
Network parameters configuration instructions::
Please review the upper left corner of the computer, if the computer has multiple network cards,
select the card that is being used, while ensuring that the IP Camera is in the corresponding network.
Modify the last octet of the CPT2IP IP Address, and ensure that the gateway and subnet are the same
as in the LAN and the CPT2IP.
If you are not sure exactly how to change the IP Address, you can also check the "automatically
obtain an IP address", the IP Camera will then obtain an IP address directly from the router (If you
can not obtain an IP address from the router, you need to check the "specify an IP address
manually", then fill in an available IP Address, Subnet Mask and Gatway for your LAN).
The Administrator password must be correct, (Factory default user name is: admin; password:
admin), click on the "save your settings" button, setting will take effect. Next, select the device in
the device list box. Double-click it, it will automatically open the browser and a pop-up dialog box
to access the device's user name and password promts, you can then enter into the main page of the
CPT2IP IP Camera, as shown in Picture 16
Note: If your computer is equipped with firewall software, when running IPCamera.exe,
you will be prompted whether to block the program, please choose Allow access for connection.
3. To manually modify the name of the camera, the HTTP port, IP address, subnet mask, gateway, DNS
servers, etc., please click the Save Settings after modifying.
4.3 Login ip camera
●The computer will open the device according to its default browser. Running ActiveX mode in Internet
Explorer (IE) to access for example. Double-click the selected IP devices with the left mousebutton
Picture 12
Or enter the IP address of the device in the browser directly, you can enter into the landing of the
verification page of the device in both twoways (for example: http://192.168.1.111:8999). As shown
in picture 13:
2. Computer has a fixed IP(ie, non-DHCP-IP), the first time you use the networkcamera, click.
,So that the network camera’s IP address, gateway and DNS synchronize with computer.
1. Camera information means the network camera information

IPCAM User Manual
13
Picture 13
The first time you use IE or a compatible browser to access the IP Camera, you may need to install plug-ins
before being able to watch the video. In picture 13, click ―Download Activex for IE‖(initial use), it will
pop-up a dialog box as in picture 14. Click on Run, it will automatically download the player controls and
install.
Click Run to begin the installation
Picture 14
Default username:admin
Default password
:admin
Need to install AtiveX for the
first time use

IPCAM User Manual
14
First time using the network camera you will automatically use the corresponding language
version of your currentweb browser and language. You can also select other languages.
Picture 15
Click Login to enter the monitoring screen after the authentication page, to enter the UI for access,
enter user name and password (default user name and password are admin).
Picture 16
●CPT2IP default username: admin, password: admin, after entering the correct username and
password, click "Login" to open the monitoring screen.
●If you are using Firefox or Safari as a browser to watch video you need to install the Quicktime plug-
in, users can follow the prompts of the content to complete the plug-in installation.
The IPCAM using Firefox and Safari browser to access as follows:
Language options:you can choose
languages listed according to your
demand

IPCAM User Manual
15
Picture 17
Picture 18

IPCAM User Manual
16
4.4 Ip Camera Operation
User interface
The interface is divided into four parts: the menu bar, the video playback area, control areas and
functions and the setting area.
Picture 19
4.4.1 menu bar
The shortcut menu bar located at the top of the page Live Video, Audio, Talkback, Snapshot, View
Photos, Record, Playback, and Reboot the device and Exit:
『Audio』click button to enter the audio mode, the icon becomes you can now monitor the
audio, click once more to exit audio..
『 Talkback』click button to enter the dialogue mode, the icon becomes the operator can talk
with people at the monitoring location through the cameras MIC.
『Snapshot] click button to capture video images.
『Record』Click button "record" to record active video and Audio and
stream to the default path in the local computer. in the active video region, the flashing prompt
suggests that that the video is being recorded, click on the video button again, and it will stop recording.
『 Live Video』is to display the cameras images with in the GUI
『 Playback』click button to display the location where the video files a located querry by, recording time,
file length and size, to play select file and double-click!

IPCAM User Manual
17
『 View Photos』View stored images that were captured
click here and a pop up confirmation window appears, click OK to reboot the device
『Reboot』
immediately.
『Exit』to exit the browser page.
4.4.2 video playing area
The video play size is consistent with the video resolution, the greater the resolution, the larger size
of the playback image. Double-click the play area, the video will be shown in full screen, double-click
again, and it will then restore to the original size. You can use the user settings to show the date and
time, device name, and recording status in the video.

IPCAM User Manual
18
4.4.3 ControlArea
Adjust and controlsimage parameters and is also the contoller for PTZ functions and the cameras settings
selector buttons.
『PT Control』:click different direction, ip camera turns accordingly,automatic PT
Stop PT
『Image flip』: Image fluctuation flip(up and down). Image around flip (right and left)
『ZOOM』: /Zoom optical zoom lens.
『IO output switch』: I/O output Switch on /off..
『PTZ speed』: PTZ speed increase from left to right.
『Set Preset』: Represent which preset has been choosen、run current
preset、 Set preset, and delete current preset!
『Video resolution』: can choose from three different resolutions to watch the
video!
『Model』: Please choose 50hz/60hzaccording to the power frequency in which the
users are located. 60Hz is USA.
Regulate image effect according to the requirement
of the users desired image.
『Brightness and contrast』:
『Restore the default value』: Click here to restore to the default value.
Note:
Name formatof video file:Chn0—IP address--.the current time V264
file
4.4.4 functions and setting area
『System』: Drop down menu containing options to check system status,related settings, ,
device time, user management, miscellaneous, firmware upgrade and reset settings .
『Network functions setting』: containing network parameters, wireless network card,
DDNS, SMTP, and PT settings.
『Audio and video Settings』:containing image coding parameters, the OSD settings,
video scheduling and network storage settings.
『Alarm settings』:containing motion detection and alarm input, sound detection and
alarmoutput! For details, please refer to other settings of Part 7.

IPCAM User Manual
19
5 Visit IP Camera in internet
5.1 Connect in the internet
Picture 25
5.2 Related setting and visit IP camera
1. If your IP camera is using a static IP, you just need to input this IP address and port into
browser,address bar and press enter you will land on the cameras homepage.
2. If you are using ADSL to dial-up and surf on line, you should obtain IP Camera Current WAN
IP Address or configured DDNS.
·There are three ways for you to obtain WAN IP Address
①Using mail to send internet IP function
After setting mail successfully, your IP should send mail to your receiver e-mail box when
Internet IP or port has changed. If it is dynamic IP, users need to input this IP address into the
browser to visit theIP camera.
②Finding your IP address of your PC over the WWW.
It is very easy for you to obtain your WAN'S IP address. You can open a browser in the
computer on the condition that the IP camera and PC have the same subnet. For example::
http://www.whatismyip.com.or http://www.myip.cn etcs.,It will tell you WAN'S IP address as
shows below.
picture 26
③Obtain from router
We take" TP-Link " router as example
A.According to router's manual, we get Router's IP is 192.168.1.1 ,User name and password are
both admin.
B. Login in router,: Input 192.168.1.1 in the browser. Find the status of Router and find Router's WAN( In this
example, WAN'S IP is 116.24.235.122;As shows in Picture 27.

IPCAM User Manual
20
picture 27
Now you can visit IP Cam from Internet. What you should do is to Input correct IP address.
For example: Http:// 116.24.235.122:8999.
Note: Make sure the Port's UPnP is available. You can open UPnP via the following ways.
Enter into Routers' setting page( Details : Router's user manual) to make UPnP available.
Or enable vir tual mapping function. Add equipment IP address and por t to the virtual mapping
list.
picture 29
3. DDDNS (dynamic DNS) is the Internet domain name service and can be Static or dynamic IP address
with real-time corresponding (analysis) service. Simply said, whenever the user surfson the internet
and no matter if they have a Static or Dynamic IP or what kind of way you are using the Internet the
DDNS ensures that a fixed domain name can access the user's device.
Table of contents
Other NST IP Camera manuals
