Ntron MINI ID User manual

MINI ID
R134a REFRIGERANT ANALYSER
OPERATION MANUAL
Manual Part Number: 5-06-4900-62-0
Manual File MN-A-0165 Rev. B
Mullaghboy Industrial Park
Navan, Co. Meath Ireland
Telephone: 00353 469071333 • Fax: 00353 469071331
www.ntron.com
EUROPE
Mini ID

The terms of these warranty provisions shall apply to all products sold by NTRON
LTD., except filters which are considered “consumable items,” and as such are not
covered by the terms of these warranties. No waiver, alteration or modification of
the terms of these provisions shall be valid unless in writing and signed by an ex-
ecutive officer of NTRON LTD..
EXCEPT AS SPECIFICALLY SET FORTH AND LIMITED IN THIS PARAGRAPH, NTRON
LTD., INC. MAKES NO WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRAN-
TIES AS TO MERCHANTABILITY, OR AS TO THE FITNESS OF THE GOODS FOR ANY
PARTICULAR USE OR PURPOSE, AND ANY WARRANTIES SET FORTH IN THIS PARA-
GRAPH ARE IN LIEU OF SUCH IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR PARTICULAR USE OR PURPOSE.
Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 13

Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 12
NTRON LTD. warrants, subject to the terms listed below, that the goods will be free
from defects in design, materials, and workmanship for a period of (1) one year
from the date that the goods are shipped to the buyer.
THE SOLE LIABILITY OF NTRON LTD. FOR ALL PURPOSES SHALL BE TO REPAIR OR
REPLACE, AT THE SOLE OPTION OF NTRON LTD. , DEFECTS APPEARING WITHIN THE
(1) ONE YEAR PERIOD. NTRON LTD. SHALL HAVE NO OBLIGATION FOR REPAIR OR
REPLACEMENT UNLESS NTRON LTD. HAS RECEIVED WRITTEN NOTICE OF THE AL-
LEGED DEFECT WITHIN THE (1) ONE YEAR PERIOD AND THE DEFECTIVE GOODS ARE
PROMPTLY RETURNED BY THE BUYER, AT THEIR EXPENSE, TO NTRON LTD. AT:
MULLAGHBOY INDUSTRIAL PARK, NAVAN, CO MEATH, IRELAND, AND THE DEFECT
OCCURS UNDER THE CIRCUMSTANCES OF PROPER USE IN ACCORDANCE WITH ALL
INSTRUCTIONS AND MANUALS PROVIDED TO THE BUYER. NTRON LTD. WILL DE-
LIVER THE REPAIRED OR NEW GOODS TO THE BUYER AT NTRON LTD. EXPENSE. IN
NO EVENT WILL NTRON LTD. BE LIABLE FOR ANY LOSS OR DAMAGE DIRECTLY OR
INDIRECTLY ARISING FROM THE DEFECTS OR FROM THE USE OF THE GOODS OR
FROM CONSEQUENTIAL OR INCIDENTAL DAMAGES, WHETHER IN CONTRACT, TORT,
OR OTHERWISE, FOR PERSONAL INJURY OR PROPERTY DAMAGE OR ANY FINANCIAL
LOSS.
Buyer shall be responsible for insuring that the goods are functioning properly at all
times and shall not use any goods which are not functioning properly. Buyer, there-
fore, agrees to indemnify NTRON LTD. from and against all losses and claims to or
by any person or property caused in any manner by the goods or the use of the
goods, including any expenses and attorney’s fees in connection with all claims,
demands, proceedings, or other expenses.
Any description of the goods contained in any documents to which these warranty
provisions relate, including any quotations or purchase orders relating to the goods
being delivered to the buyer, are for the sole purpose of identifying the goods, and
any such description, as well as any sample or model which may have been dis-
played to or seen by the buyer at any time, have not been made part of the basis of
the bargain and have not created or amounted to any express warranty that the
goods would conform to any such description or any such sample or model.
NTRON LTD. DOES NOT WARRANT THAT THE GOODS ARE FREE OF THE RIGHTFUL
CLAIM OF ANY THIRD PERSON BY THE WAY OF INFRINGEMENT OF PATENT OR
OTHER PROPRIETARY INFORMATION AND DISCLAIMS ANY WARRANTY AGAINST
SUCH INFRINGEMENT.
It shall be the responsibility of the buyer to read carefully and abide by all instruc-
tions provided to the buyer in the instruction manual or elsewhere. If the buyer, or
the employees of the buyer, did not abide by such instructions, then the alleged
defect shall not be deemed to have arisen under circumstances of proper use.
The Mini ID utilizes a disposable oil filter that
can not be cleaned.
Be sure to have spare filters available as the
instrument cannot be operated with a con-
taminated filter.
P/N 6-01-6001-23-1
When properly used, this filter will protect the
instrument from oil and sealant contamina-
tion.
See Page 10 for additional information.

Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 2
For Your Safety………………………………………………………………….. 3
General Cautions………………………………………………………………. 3
Welcome…………………………………………………………………………… 5
Introduction………………………………………………………………………. 6
Product Description…………………………………………………………… 7
Product Components…………………………………………………………. 8
Instructions For Use…………………………………………………………… 9
The Test Results………………………………………………………………… 9
Help/Troubleshooting………………………………………………………… 10
Specifications……………………………………………………………………. 11
Warranty…………………………………………………………………………… 12
Table of Contents
Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 11
SPECIFICATIONS
Refrigerant Detected: R134a
Pass/Fail Purity: 95%
Power: 12—15 VDC @ 1 amp
Sample Source: Oil Free Vapour Refrigerant
Minimum Input Pressure: 1.38 Bar (20 Psig)
Maximum Input Pressure: 20.70 Bar (300 Psig)
Operating Temperature : 10°— 45°C
Approvals (Pending): UL, CE, SAE J1771
Replacement Oil Filter P/N: 6-01-6001-23-1

Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 10
HELP / TROUBLESHOOTING
Unit Fails to Power On - Check the voltage and polarity of the power
source. Ensure that the power plug is fully inserted into the power socket on
the unit.
Excess Air / Fail—The Mini ID is equipped with a unique filter located be-
tween the coupler and hose. This is a disposable filter designed to trap oil
and sealant to prevent damage to the unit. Remove and inspect the filter for
oil etc. and replace if necessary. Remove any oil in the coupler with com-
pressed air and a dry cloth. Replacement Filter P/N 6-01-6001-23-1
The Mini ID is equipped with internal fault codes for assistance with trouble-
shooting. When the “FAULT” light is illuminated, the code is determined by
counting the number of flashes.
Code 3 = Calibration Error
Code 4 = Temperature Error
Code 5 = Calibration Compensation Error
Should one of these codes appear, take the following action prior to contact-
ing you Ntron Service Representative.
1. Disconnect the power from the instrument and verify the power source is
between 12 and 15 VDC.
2. Place the unit in a climate controlled area between 15°C and 27°C.
3. Fully Squeeze the Calibration Bulb 10 times.
4. Allow the unit to remain in the climate controlled room for 30 minutes.
5. Reconnect the unit and re-test.
If these steps fail to restore the unit to good working order, contact:
Ntron Ltd.
Mullaghboy Industrial Park
Navan, Co Meath Ireland
Telephone: 00353 469071333 • Fax: 00353 469071331
www.ntron.com
Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 3
For Your Safety:
PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE ATTEMPTING
INSTALLATION OR OPERATION! Attempting to operate the Mini ID
without fully understanding its features and functions may result in
unsafe conditions.
Always use protective eye wear and observe proper safety procedures when
working with pressurized gases.
Identifier Warnings
Sample Filter Warning: The Mini ID contains a unique filter designed to sig-
nificantly reduce the probability of oil contamination. Replace the brass oil
filter of the instrument AS SOON AS OIL IS DETECTED IN THE SAMPLE HOSE.
Failure to properly maintain and replace the oil filter may result in severe
damage.
Sample Input Warning: The instrument requires connection of the supplied
sample hose to the LOW SIDE OR VAPOUR port of refrigerant storage cylin-
ders or vehicle air conditioning systems. DO NOT attempt to introduce liquid
or samples heavily laden with oil into the instrument. DO NOT connect the
sample hose to the HIGH SIDE or LIQUID port! Liquid or oil laden samples
may cause severe damage to the instrument that will not be covered under
warranty repairs.
General Cautions
• Always inspect the sample hose before each use. Replace the hose if it
appears cracked, frayed, obstructed or fouled with oil.
• Always turn the compressor or automobile engine off before connecting
the instrument to an air conditioning system.

• Always wear eye and skin protection when working with refrigerants. Es-
caping refrigerant vapours will present a freezing danger.
• To reduce the risk of electrical shock, do not disassemble the instru-
ment; do not use the instrument in wet or damp areas.
• DO NOT direct refrigerant vapours venting from hoses towards the skin.
• DO NOT disassemble the instrument. There are no serviceable compo-
nents internal to the instrument and disassembly will void the warranty.
• Always place the Identifier on a flat and sturdy surface.
• DO NOT utilize any other hose other than those supplied with the instru-
ment. The use of other hose types will introduce errors into the refriger-
ant analysis and instrument calibration.
• Always verify that the refrigerant to be tested does not contain or will not
emit heavy loads of oil or liquid.
• NEVER admit any sample into the instrument at pressures in excess of
300 psig.
• DO NOT utilize the coupler supplied on the service end of the R134a
Sample Hose for any application other than with the instrument. The
coupler supplied is a modified version that does not contain a check
valve and is not suitable for any other refrigerant application.
• NEVER obstruct the air intake, sample exhaust or case vent ports of the
instrument during use.
• WARNING – This Identifier must not be operated in flammable atmos-
pheres.
• CAUTION – Should be operated by certified personnel.
• Avoid breathing A/C refrigerant and lubricant vapor or mist. Exposure may
irritate eyes, nose and throat. To remove HFC-134a from the A/C system,
use service equipment certified to meet the requirements of SAE J2788.
Additional health and safety information may be obtained from refrigerant
and lubricant manufacturers.
• CAUTION – Do not pressure test or leak test HFC-134a service equipment
and/or vehicle air conditioning systems with compressed air. Some mix-
tures of air and HFC-134a have been shown to be combustible at elevated
pressures. These mixtures, if ignited, may cause injury or property damage.
Additional health and safety information may be obtained from refrigerant
manufacturers.
Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 4
INSTRUCTIONS FOR USE
WARNING: Be sure to turn off the vehicle and let it rest for 3 minutes.
1) Connect the power cable to the power port located on the bottom of the
instrument.
2) Connect the power clips to the 12 VDC battery source. Be sure to ob-
serve the correct polarity.
3) The lights will sequence, press “NEXT” to begin the “WARM UP”.
4) After approximately 90 seconds, the “CALIBRATING” light will flash.
5) Fully squeeze the calibration bulb 5 times and press “NEXT”.
6) The “CALIBRATING’ light will illuminate for approximately 60 seconds.
7) When the Analysing light begin to flash, connect hose to the vehicles low
side service port and then press “NEXT”.
8) The Analysing light will illuminate for approximately 45 seconds while the
test is in progress.
9) The “PASS”/”FAIL” light will then provide the test results (See The Test
Results)
10) Disconnect the sample hose from the vehicle, press the “NEXT” button
and squeeze the calibration bulb 5 times. Remove the power and the
instrument may now be stowed.
THE TEST RESULTS
1) After the Analysis is complete, the “PASS” or “FAIL” light will flash.
a) “PASS” indicates the refrigerant tested is 95% or greater R134a and
is suitable for recovery.
b) “FAIL” indicates the refrigerant tested is less than 95% R134a and
should not be recovered without special equipment.
c) The EXCESS AIR” light will illuminate in conjunction with the “PASS”
or “FAIL” if the instrument determines that a significant amount of
air is present. (See Help/Troubleshooting) .
Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 9

PRODUCT COMPONENTS
Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 8
Base Module
Coupler with Filter
Calibration Bulb
Battery Clips
WELCOME
Thank you for purchasing the MINI ID R134a Refrigerant Analyser.
The Mini ID is the most economical refrigerant identifier ever designed for ana-
lysing the purity of gaseous R134a automotive refrigerant. It has many features
to offer the user, which will be described in this manual. We recommend that
all personnel who use this instrument read this manual to become more famil-
iar with its proper operation.
For further information regarding the application, operation or spare parts,
please contact the Ntron Ltd. Customer Service Department. If you have ques-
tions or comments, we would like to hear from you.
Ntron Ltd.
Mullaghboy Industrial Park
Navan, Co. Meath Ireland
Telephone: 00353 469071333
Fax: 00353 469071331
Visit us at www.ntron.com
Copyright ©2008 Ntron Ltd..
This work is protected under International Code and is the sole property of Ntron
Ltd. No part of this document may be copied or otherwise reproduced, or stored in
any electronic information retrieval system, except as specifically permitted under
International copyright law, without the prior written consent of Ntron Ltd.
Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 5

INTRODUCTION AND OVERVIEW
Contamination of refrigerants in vehicle air conditioning systems can lead to
component corrosion, elevated head pressures and system failures when
utilized by unsuspecting technicians. The ability of the technician to deter-
mine refrigerant type and purity is severely hampered by the presence of air
when attempting to utilize temperature-pressure relations. The develop-
ment of various substitute refrigerants further complicates the ability of a
technician to identify refrigerant purity based upon temperature-pressure
relationships. The substitute refrigerant blends can also introduce a flam-
mability hazard to the technician and the ultimate end user of the vehicle air
conditioning system.
The Ntron Mini ID Refrigerant Identifier will provide an easy and accurate
means to determine if the R134a refrigerant in vehicle air conditioning sys-
tems is of suitable purity. The instrument utilizes non-dispersive infrared
(NDIR) technology to determine the weight concentrations of refrigerant
types R12, R134a, R22, as well as, hydrocarbons and air. Refrigerant purity
is automatically determined for refrigerant R134a by the instrument to elimi-
nate human error.
The instrument is supplied complete with a R134a sample hose, a 12 VDC
power cord and all required plumbing housed within a rugged, portable in-
strument.
Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 6
PRODUCT DESCRIPTION
The Ntron Mini ID is an economical instrument designed to provide a “PASS”
or “FAIL” indication for R134a Purity. The product will also indicate if an ex-
cess amount of non-condensable gas (air) is present in the system. Excess
“air” will cause poor cooling performance and can be easily corrected by
simply recovering the refrigerant, evacuating the system and recharging the
vehicle. The Mini ID uses a simple hand pump to purge refrigerant from the
sample cell in order to calibrate the instrument. LED’s provide the user with
easy to understand status indicators. Flashing LED’s require user action
while solid LED’s indicate the instrument is performing a task.
The unique brass filter, located between the Coupler and Sample Hose, pro-
vides excellent protection from oil contamination by trapping the oil at the
coupler and preventing it from entering the instrument. If the instrument
continually gives excess air messages, this is an indication that the filter has
been compromised by oil and the filter must be changed.
Manual Part Number:
5-06-4900-62-0
Manual File:
MN-A-0165 Rev. B
Revision Date:
Sept. 9, 2008
Page 7
Table of contents
Other Ntron Measuring Instrument manuals
Popular Measuring Instrument manuals by other brands

GeneReach
GeneReach POCKIT Central user manual

AEMC instruments
AEMC instruments 300-24-2-10 user manual

Agilent Technologies
Agilent Technologies E4418B Service guide

Hanna Instruments
Hanna Instruments C22190 reference guide

Iridex
Iridex Cyclo G6 Operator's manual

PCE Health and Fitness
PCE Health and Fitness VOC 1 user manual
