Ntron 709FX Series Installation and operating instructions

709FX
Managed Industrial
Ethernet Switch
User Manual &
Installation
Guide

(Revised 2012-05-01) Page 2 of 196
709FX Industrial Ethernet Switch Installation Guide...............................................................................................5
709FX Industrial Ethernet Switch Accessories........................................................................................................7
SAFETY WARNINGS...........................................................................................................................................9
SUPPORT:.............................................................................................................................................................9
Installation ...........................................................................................................................................................10
DIN RAIL MOUNTING......................................................................................................................................12
FRONT PANEL (709FX).....................................................................................................................................14
APPLYING POWER (Top View).........................................................................................................................16
Connecting the Unit..............................................................................................................................................17
Overview of Advanced Features...........................................................................................................................22
Mode of Operation..................................................................................................................................................................22
Port Mirroring .........................................................................................................................................................................22
Port Trunking ..........................................................................................................................................................................22
Quality of Service (QoS).........................................................................................................................................................22
Virtual LAN............................................................................................................................................................................23
Rapid Spanning Tree Protocol ................................................................................................................................................24
SNMP Traps............................................................................................................................................................................24
IGMP Snooping ......................................................................................................................................................................24
N-Ring.....................................................................................................................................................................................25
N-Link.....................................................................................................................................................................................25
CIP ..........................................................................................................................................................................................25
DHCP......................................................................................................................................................................................25
DHCP Client ...........................................................................................................................................................................26
DHCP Relay Agent.................................................................................................................................................................26
DHCP Server...........................................................................................................................................................................26
LLDP.......................................................................................................................................................................................26
Port Security—MAC Address Based......................................................................................................................................26
TROUBLESHOOTING..........................................................................................................................................................27
Web Software Configuration ................................................................................................................................29
Web Management ...................................................................................................................................................................29
Web Management - Home ......................................................................................................................................................30
Administration – System.........................................................................................................................................................33
Administration – SNMP..........................................................................................................................................................38
Administration – Fault ............................................................................................................................................................40
DHCP – Server – Setup Profiles .............................................................................................................................................42
DHCP – Server – Setup IP Maps ............................................................................................................................................46
DHCP – Server – View Bindings............................................................................................................................................52
DHCP – Relay & Local IP - Setup..........................................................................................................................................53
LLDP - Configuration.............................................................................................................................................................56
LLDP - Ports ...........................................................................................................................................................................57
LLDP - Status..........................................................................................................................................................................58
LLDP - Statistics.....................................................................................................................................................................59
Ports – MAC Security – Learning...........................................................................................................................................64
Ports – MAC Security – Authorization List............................................................................................................................67
Ports – MAC Security – Intruder Log.....................................................................................................................................69
Ports – Mirroring.....................................................................................................................................................................70
Ports – Mirroring, Continued … .............................................................................................................................................71
Ports – Mirroring, Continued… ..............................................................................................................................................72
Ports – QOS.............................................................................................................................................................................74
Statistics – Port Statistics ........................................................................................................................................................76
Statistics – Port Utilization......................................................................................................................................................78
VLAN – Configuration ...........................................................................................................................................................79
Bridging – Aging Time...........................................................................................................................................................83
Bridging – Unicast Addresses.................................................................................................................................................84
Bridging – Multicast Addresses ..............................................................................................................................................86

(Revised 2012-05-01) Page 3 of 196
Bridging – Show MAC by Port...............................................................................................................................................88
RSTP – Configuration.............................................................................................................................................................90
IGMP – Configuration ............................................................................................................................................................94
IGMP – Show Group and Show Router..................................................................................................................................99
IGMP – RFilter .....................................................................................................................................................................101
N-View – Configuration........................................................................................................................................................103
N-View – Ports......................................................................................................................................................................104
N-Ring – Configuration ........................................................................................................................................................106
N-Ring – Advanced Configuration .......................................................................................................................................109
N-Ring – Status.....................................................................................................................................................................112
N-Link – Configuration.........................................................................................................................................................117
N-Link – Status .....................................................................................................................................................................121
CIP – Configuration..............................................................................................................................................................129
CIP – Status...........................................................................................................................................................................130
Firmware/Config – TFTP......................................................................................................................................................132
Firmware/Config – TFTP, Continued ...................................................................................................................................134
Support – Web Site and E-mail.............................................................................................................................................135
Rate Limiting – Broadcast Rate Limit Configuration ...........................................................................................................137
Rate Limiting – Multicast Rate Limit Configuration............................................................................................................138
User Management – Adding Users .......................................................................................................................................140
User Management – Removing Users...................................................................................................................................141
LogicalView..........................................................................................................................................................................143
Configuration – Save or Reset...............................................................................................................................................144
Help – Overview ...................................................................................................................................................................146
Help – Administration...........................................................................................................................................................147
Help – DHCP ........................................................................................................................................................................148
Help – LLDP.........................................................................................................................................................................149
Help – Ports...........................................................................................................................................................................150
Help – Statistics.....................................................................................................................................................................151
Help – VLAN........................................................................................................................................................................152
Help – Bridging.....................................................................................................................................................................153
Help – RSTP .........................................................................................................................................................................154
Help – IGMP.........................................................................................................................................................................155
Help – N-View......................................................................................................................................................................156
Help – N-Ring.......................................................................................................................................................................157
Help – N-Link.......................................................................................................................................................................158
Help – CIP.............................................................................................................................................................................159
Help – Firmware/Config .......................................................................................................................................................160
Help – Rate Limiting.............................................................................................................................................................161
Help – User Management......................................................................................................................................................162
Help – Other..........................................................................................................................................................................163
CLI Commands..................................................................................................................................................164
“?” (Help)..............................................................................................................................................................................164
Logout...................................................................................................................................................................................164
Show, Add, or Delete ARL Entries.......................................................................................................................................165
Configuration Device Operations..........................................................................................................................................166
Show or Set CIP Configuration.............................................................................................................................................167
Save or Reset the Configuration Settings..............................................................................................................................168
Show or Set IGMP Configuration.........................................................................................................................................168
Show or Set Mirror Configuration ........................................................................................................................................169
Show or Set N-Ring Configuration.......................................................................................................................................170
Show or Set N-View Configuration......................................................................................................................................170
Ping a Host............................................................................................................................................................................171
Show or Set Port Configuration ............................................................................................................................................172
Reset the Switch....................................................................................................................................................................173
Show or Set SNMP Configuration........................................................................................................................................173
Show or Clear the Last System Error....................................................................................................................................174

(Revised 2012-05-01) Page 4 of 196
Show System Information.....................................................................................................................................................174
Set or Show the System IP Configuration.............................................................................................................................175
Show or Set System Configuration .......................................................................................................................................176
VLAN Addition and Deletion Example ..............................................................................................................177
VLAN Configuration Examples..........................................................................................................................183
Example 1 – Basic understanding of port-based VLANs......................................................................................................183
Example 2 – Basic understanding of tagged VLANs (Admit – Tagged Only).....................................................................184
Example 3 – Basic understanding of tagged VLANs (Admit – All).....................................................................................185
Example 4 – Basic understanding of Hybrid VLANs ...........................................................................................................186
Example 5 – Basic understanding of Overlapping VLANs...................................................................................................187
Example 6 – Basic understanding of VLANs with Multicast Filtering.................................................................................188
KEY SPECIFICATIONS (709FX) .....................................................................................................................189
KEY SPECIFICATIONS (709FX-HV)...............................................................................................................191
Appendix A. XML Settings File Example..........................................................................................................193
N-TRON Limited Warranty................................................................................................................................196

(Revised 2012-05-01) Page 5 of 196
709FX Industrial Ethernet Switch Installation Guide
The N-TRON 709FX Industrial Ethernet Switch offers outstanding performance and ease of use. It is ideally
suited for connecting Ethernet enabled industrial and or security equipment and is a fully managed switch.

(Revised 2012-05-01) Page 6 of 196
PRODUCT FEATURES
• Full IEEE 802.3 Compliance
• Eight 10/100 BaseTX RJ-45 Ports
• One 100BaseFX(E) Port
• Extended Environmental Specifications (Surrounding
Air): -40 to 70 °C Operating temperature
• ESD and Surge Protection Diodes on all Ports
• Auto Sensing 10/100BaseTX, Duplex, and MDIX
• Offers Rapid Spanning Tree Protocol
• Store & Forward Technology
• Rugged Din-Rail Enclosure
• Onboard Temperature Sensor
• Configuration Backup via optional SD Card
(NTCD-128)
• Redundant Power Inputs
PRODUCT CONFIGURATIONS
• 709FX-XX-VV and 709FXE-XX-YY-VV
– Eight 10/100 Base-TX RJ45 Copper Ports,
one 100BaseFX Port,
Where: XX = ST or SC
YY = 10, 40 or 80 for Singlemode, Blank for Multimode
VV = HV for High voltage, Blank for Standard voltage
E = Singlemode, Blank Otherwise
MANAGEMENT FEATURES
• SNMP v1, v2, v3 and Web Browser Management
• SNMP based image or config download and config upload
• Configuration backup via Optional Configuration Device (NTCD)
• EtherNet/IP™ CIP Messaging
• Detailed Ring Map and Fault Location Charting
• N-Ring™ Technology with ~30ms Healing
• Web Browser Management with detailed ring map and
fault location charting.
• N-View™ OPC Monitoring
• N-Link™ Redundant N-Ring Coupling
• IGMP Auto Configuration and Plug and Play Support
• 802.1Q tag VLAN and Port VLAN
• 802.1p QoS, Port QoS, and DSCP
• LLDP (Link Layer Discovery Protocol)
• Trunk with other N-Tron trunking capable switches over two ports
• Port Mirroring
• 802.1D RSTP (Rapid Spanning Tree Protocol)
• DHCP Client, Server, Option 82 relay, Option 61
• Local Port IP Addressing
• Port Security—MAC Address Based
Copyright, © N-Tron Corp., 2008-2012

(Revised 2012-05-01) Page 7 of 196
709FX Industrial Ethernet Switch Accessories
The SD and USB connectors are for temporary connection only. Do not use, connect, or disconnect unless
area is known to be non-hazardous. Connection or disconnection in an explosive atmosphere could result in
an explosion.
NTCD-128
Configuration Device
Ideal for saving, or restoring switch configuration
parameters quickly without the need for a computer or
software. One configuration device per switch is
recommended.
The configuration device is inserted in the back of the 709FX.

(Revised 2012-05-01) Page 8 of 196
Copyright, © N-Tron Corp., 2008-2012
820 S. University Blvd., Suite 4E
Mobile, AL 36609 USA
All rights reserved. Reproduction, adaptation, or translation without prior written permission from N-Tron
Corp. is prohibited, except as allowed under copyright laws.
Ethernet is a registered trademark of Xerox Corporation. All other product names, company names, logos
or other designations mentioned herein are trademarks of their respective owners.
The information contained in this document is subject to change without notice. N-Tron Corp. makes no
warranty of any kind with regard to this material, including, but not limited to, the implied warranties of
merchantability or fitness for a particular purpose. In no event shall N-Tron Corp. be liable for any
incidental, special, indirect, or consequential damages whatsoever included but not limited to lost profits
arising out of errors or omissions in this manual or the information contained herein.
Warning
Do not perform any services on the unit unless qualified to do so. Do not substitute unauthorized parts or
make unauthorized modifications to the unit.
Do not operate the unit with the top cover removed, as this could create a shock or fire hazard.
Do not block the air vents on the sides or the top of the unit.
Do not operate the equipment in the presence of flammable gasses or fumes. Operating electrical equipment
in such an environment constitutes a definite safety hazard.
Do not operate the equipment in a manner not specified by this manual.

(Revised 2012-05-01) Page 9 of 196
SAFETY WARNINGS
GENERAL SAFETY WARNINGS
WARNING: If the equipment is used in the manner not specified by N-Tron Corp., the protection
provided by the equipment may be impaired.
LASER SAFETY (Single Mode Fiber Models -40 and -80)
CAUTION: CLASS 1 LASER PRODUCT. Do not stare into the laser!
SUPPORT:
Contact Information
N-Tron Corp.
820 South University Blvd. Suite 4E
Mobile, AL 36609
TEL: [phone]
FAX: [phone]
WEBSITE: www.n-tron.com
E-MAIL: [email protected]
ENVIRONMENTAL SAFETY
WARNING: The unit may become very hot to the touch in high temperature environments, so extreme
caution should be exercised in handling when energized. The unit should be disconnected from power and
allowed to cool for approximately 5 minutes before touching in high temperature applications.
ELECTRICAL SAFETY
Must be powered by a Class 2 source only.
WARNING: Disconnect the power cable before removing the top cover.
WARNING: Do not operate the unit with the any cover removed.

(Revised 2012-05-01) Page 10 of 196
WARNING: Properly ground the unit before connecting anything else to the unit. Units not properly
grounded may result in a safety risk and could be hazardous and may void the warranty. See the grounding
technique section of this user manual for proper ways to ground the unit.
WARNING: Do not work on equipment or cables during periods of lightning activity.
WARNING: Do not perform any services on the unit unless qualified to do so.
WARNING: Do not block the air vents.
WARNING: Observe proper DC Voltage polarity when installing power input cables. Reversing voltage
polarity can cause permanent damage to the unit and void the warranty.
Hazardous Location Installation Requirements
1.
This equipment is suitable for use in Class I, Div. 2, Groups A, B, C, D or non-hazardous locations
only.
2. WARNING: Explosion Hazard – Substitution of components may impair suitability for Div. 2.
3. WARNING: Explosion Hazard - do not disconnect while circuit is live, unless area is known to be
non-hazardous.
4. WARNING: Explosion Hazard – do not replace the device unless power has been switched off or
the area is known to be non-hazardous.
5. Use 90°C or higher rated Copper wire, (0.22Nm) 2lb/in Tightening torque for field installed
conductors.
Please make sure the 709FX Series Ethernet Switch package contains the following items:
1. 709FX Series Switch
2. Product CD
Contact your carrier if any items are damaged.
Installation
Read the following warning before beginning the installation:
WARNING
Never install or work on electrical equipment or cabling during periods of lightning activity. Never connect
or disconnect power when hazardous gasses are present.

(Revised 2012-05-01) Page 11 of 196
Disconnect the power cable before removing any enclosure panel.
UNPACKING
Remove all the equipment from the packaging, and store the packaging in a safe place. File any damage
claims with the carrier.
CLEANING
Clean only with a damp cloth.

(Revised 2012-05-01) Page 12 of 196
DIN RAIL MOUNTING
Install the unit on a standard 35mm Din-Rail. Recess the unit to allow at least 3” of horizontal clearance for
copper cable bend radius. Recess the unit to allow at least 5” of horizontal clearance for fiber cable bend
radius. There should be at least 3” of clearance on both the top and bottom of the unit to allow proper
ventilation.
To install the unit to 35mm industrial DIN rail,
place the top edge of the included mounting
bracket on the back of the unit against the DIN rail
at a 15° angle as shown. Rotate the bottom of the
unit to the back (away from you) until it snaps into
place.
To remove the unit from the 35mm industrial
DIN rail, pull forward on the unit until it disengages
from the bottom of the DIN rail. Rotate the bottom
of the unit towards you and up at an approximate
15° upward angle to completely remove the unit.
URMK CPMA
Most N-Tron™ products are designed to be mounted on industry standard 35mm DIN rail. However, DIN
rail mounting may not be suitable for all applications. Our Optional Universal Rack Mount Kit (P/N:

(Revised 2012-05-01) Page 13 of 196
URMK) may be used to mount the enclosure to standard 19" racks, and our Optional Factory Installed Panel
Mount Assembly may be used to mount the enclosure to a panel or any other flat surface.

(Revised 2012-05-01) Page 14 of 196
FRONT PANEL (709FX)
From Top to Left:
RJ45 Ports Auto Sensing 10/100 Base-TX Connections
Fiber Port 100 Base-FX Connection
LED lights when Power is supplied to the unit
NOTE: The RJ45 data port has two LEDs located on each connector. The left LED indicates LINK status,
and the right LED indicates ACTIVITY.
LEDs: The table below describes the operating modes:
LED Color Description
GREEN Power is ON
RED Power is ON and a fault condition exists
OFF Power is OFF
LNK GREEN 10/100Mb Link between ports
OFF No Link between ports

(Revised 2012-05-01) Page 15 of 196
ACT GREEN Data is active between ports
OFF Data is inactive between ports

(Revised 2012-05-01) Page 16 of 196
APPLYING POWER (Top View)
•Unscrew & Remove the DC Voltage Input
Plug from the Power Input Header
•Install the DC Power Cables into the Plug
(observing polarity).
•Plug the Voltage Input Plug back into the
Power Input Header.
•Tightening torque for the terminal block
power plug is 0.5 Nm/0.368 Pound Foot.
•Verify the Power LED stays ON (GREEN).
Notes:
•Only 1 power supply must be connected to power for minimal operation. For redundant power
operation, V
1
and V
2
inputs must be connected to separate DC Voltage sources. This device will
draw current from both sources simultaneously. Use 16-28 gauge wire when connecting to the
power supply.
•The Fault pins on the power connector can be used for an alarm contact. The current carrying
capacity is 1A at 24VDC. It is normally open and the relay closes when a fault condition occurs.
These pins can be used to connect an external warning device such as a light in order to provide an
external alarm. The conditions for generating a fault condition (closing the relay) can be configured
through software.
Recommended 24V DC Power Supplies, similar to: N-Tron’s P/N NTPS-24-1.3 (NOTE: Not appropriate
for use with M12, POE, and HV models.):
•
Input AC 115/230V
•Output DC 24-28V
•Output Current 1.3A @ 24V
1.0A @ 28V
•
Power 30W
•35 mm DIN-Rail Mountable
•Dimensions: 45X75X91 mm

(Revised 2012-05-01) Page 17 of 196
Connecting the Unit
For FX/FXE units, remove the dust cap from the fiber optic connectors and connect the fiber optic cables.
The TX port (located on the bottom connector) on the FX/FXE models should be connected to the RX port of the
far end station. The RX port (located on the top connector) on the FX/FXE versions should be connected to the
TX port of the far end station.
For 10/100 Base-TX ports, plug a Category 5E twisted pair cable into the RJ45 connector. Connect the
other end to the far end station. Verify that the LNK LEDs are ON once the connection has been completed.
To connect any port to another device (end node, Switch or Repeater), use a standard Category 5E straight
through or crossover cable with a
minimum length of one meter and a
maximum length of 100 meters.
N-Tron recommends the use of pre-
manufactured Cat5E cables to ensure the
best performance. If this is not an option
and users must terminate their own ends
on the Cat5E cables; one of the two color
coded standards shown to the right should
be utilized. If a user does not follow one
of these two color code standards then the
performance and maximum cable distance
will be reduced significantly, and may
prevent the switch from establishing a
link.
Warning: Creating a port to port connection on the same switch (i.e. loop) is an illegal operation and
will create a broadcast storm which will crash the network!

(Revised 2012-05-01) Page 18 of 196
N-TRON SWITCH GROUNDING TECHNIQUES
The grounding philosophy of any control system is an integral part of the design. N-Tron switches are
designed to be grounded, but the user has been given the flexibility to float the switch when required. The
best noise immunity and emissions (i.e. CE) are obtained when the N-Tron switch chassis is connected to
earth ground via a drain wire. Some N-Tron switches have metal din-rail brackets that can ground the
switch if the din-rail is grounded. In some cases, N-Tron switches with metal brackets can be supplied with
optional plastic brackets if isolation is required.
Both V- legs of the power input connector are connected to chassis
internally on the PCB. Connecting a drain wire (shown in green) to
earth ground from one of the V- terminal plugs as shown here will
ground the switch and the chassis. The power leads from the power
source should be limited to 3 meters or less in length.
As an alternate, users can run a drain wire (shown in green) & lug from any
of the Din-Rail screws or empty PEM nuts on the enclosure. When using an
unused PEM nut to connect a ground lug via a machine screw, care should be
taken to limit the penetration of the outer skin by less than 1/4 in. Failure to
do so may cause irreversible damage to the internal components of the switch.
Note: Before applying power to the grounded switch, you must use a volt
meter to verify there is no voltage difference between the power supply’s
negative output terminal and the switch chassis grounding point.
If the use of shielded cables is required, it is generally recommended to only connect the shield at one end to
prevent ground loops and interfere with low level signals (i.e. thermocouples, RTD, etc.). Cat5e cables
manufactured to EIA-568A or 568B specifications are required for use with N-Tron Switches.
In the event all Cat5e patch cable distances are small (i.e. All Ethernet devices are located in the same local
cabinet and/or referenced to the same earth ground), it is permissible to use fully shielded cables terminated
to chassis ground at both ends in systems void of low level analog signals.

(Revised 2012-05-01) Page 19 of 196
RJ45 CONNECTOR CRIMP SPECIFICATIONS
Please reference the illustration below for your Cat5 cable specifications:

(Revised 2012-05-01) Page 20 of 196
USB INTERFACE
The 709FX Series switches provide a USB interface accessed via the USB connector labeled as “USB” on
the unit. This is used to access the Command Line Interpreter (CLI).
The USB connector is at the bottom of the 709FX.
USB Cable
Connect the USB port of your PC and the Switch using a standard USB cable. You will require a cable with
a Type A connector for the PC end, and a Type B connector for the Switch end.
Standard USB cables are readily available from a variety of computer stores.
HyperTerminal
The following configuration should be used in HyperTerminal:
Port Settings: 115200
Data Bits: 8
Parity: NONE
Stop bits: 1
