Nugens ND-24E User manual
1
Quick Installation Guide
ND-24E
23.8” 1080P LED Monitor
2
1. Introduction
Package Contents
1. LED Monitor x1
2. Power Cable x 1
3. Power Transformers x 1
4. HDMI Cable x 1
5. Monitor Stand x 1
6. Quick Installation Guide x 1
1-2 Overview
Bottom Side
Ports/Buttons
HDMI
Insert HDMI cable to this port (*Note 1)
VGA
Insert VGA cable to this port (*Note 1)
AUDIO
3.5mm Audio Port
DC 12V
Insert power cable and transformer to this port
Power ON/OFF
Turn on or off monitor display
DOWN
Go down in Menu
UP
Go up in Menu
MENU
Press to view Menu
AUTO
Auto adjust settings and parameters
Note 1 This product comes with HDMI cable, VGA cable needs to be prepared by yourself.
Note 2 Menu contents refer to Parameter Setting.
3
1-3 Parameter Setting
1-3-1 Menu
Menu
Function Setting
Brightness: 0-100
Contrast: 0-100
Mode: Standard, Movie, Game,
Internet
DCR: On/Off
Overdrive: On/Off
HDR: On/Off
H. Position: 0-100
V.Position: 0-100
Clock: 0-100
Phase: 0-100
Image Ration: wide, 4:3
Color Temp: Normal, Warm, User,
sRGB, Cool,
Red: 0-100
Green: 0-100
Blue: 0-100
Low Blue Mode: On/Off
4
Language: Multi-Country
H.Position: 0-100
V.Position: 0-100
Timeout: 5-100
Transparent: 0-100
Auto Configure
(Press to enter auto configure)
Auto Color
(Press to enter auto color)
Reset
Black Level: 0-100
Input Select: HDMI, VGA
Mute: On/Off
Volume: 0-100
5
1-3-2 Resolution
Recommend user to choose one kind of the following schemes:
Resolution
Horizontal scan
frequency (KHz)
Frame frequency
(Hz)
640*350
31.467 (+)
70.082 (-)
720*400
31.467 (-)
70.082 (+)
640*480
31.467 (-)
59.487 (-)
640*480
31.467 (-)
72.809 (-)
640*480
31.467 (-)
75.000 (-)
800*600
35.156 (+)
56.250 (+)
800*600
37.897 (+)
60.317 (+)
800*600
48.077 (+)
72.188 (+)
800*600
46.875 (+)
75.000 (+)
1024*768
48.363 (-)
60.004 (-)
1024*768
56.476 (-)
70.069 (-)
1024*768
60.023 (+)
75.029 (+)
1-4 Specification
Parameters
Screen size
23.8-inch
Panel
TN
Resolution
1920*1080 @ 60HZ
Visible area
527.04×296.45(mm2)
Viewing angle
(horizontal/vertical)
H:170°
V:160°
Contrast
1000:1
Brightness
250cd/m2
Pixel
233.1umx233.1um
Aspect ratio
16:9
Display color
16.7M
Screen refresh rate
60Hz
Response time
5ms (MPRT)
Additional
Function
Connection ports
VGA + HDMI
VESA
100*100 mm
System
OSD
Multi-country
6
Power
Voltage
DC 12V/2.5A
Power consumption
<20W
Power consumption (Standby)
0.5W
2. Instructions
Thank you for purchasing the ND-24E 23.8” 1080P LED Monitor.
-This product equips with three cables earth-type plug, this plug only can
adapt to earth-type outlet, this is a function of taking security into account, if
unable to insert it in the socket, please consult your electrician to change old
socket, should not give up the earth type plug for the safety reason, if voltage
of use area where you locate is 220V-240V AC, should chose equipment cable
of additional ‘‘Tandem Blade’ plug as input terminal of 230V AC, and should
pay attention to this cable you choose must have passed relevant safety
certification and mechanism authentication.
2-1 Safety Instructions
Before using the product, please read these safety precautions for proper use:
Do not conceal or block the heat dissipation hole under the
machine6
Do not use sharp things, metal or liquid to stretch into or touch the signal
terminal or in the heat dissipation hole, to avoid a short circuit and product
damage.
If you have not used the product for a very long time, you shall pull out the
power cable from the wall power plug.
Do not try to resolve it by yourself or dismantle any parts of this product,
which may lead to damage to the product and injury to the human body
and make the product's guarantee void.
Do not touch the screen surface directly with the finger, may
damage the screen surface in this way, and very difficult to drive out if the
oil of the skin stays on the screen.
7
Do not exert pressure on the LCD screen, because the LCD screen is very
exquisite and fragile.
Must use the Power Supply provided by the original factory, to avoid
causing the products to be damaged.
Please pull out the Power adapter cable of this product in the
following situations:
1. If you do not use the product for some time.
2. If the cable or power plug is damaged.
Please assemble or adjust this product according to this user manual, if you meet an unexpected
condition while assembling this product, please pull out the Power Supply Cable first and contact
us or our resellers/distributor as soon as possible.
2-2 Troubleshooting
Problem
Solutions
No display
If the LED indicator light is off: Check whether the
cable is connected firmly.
If LED indicates the light is red colour: Check whether
the connection of the HDMI or VGA cable is firm at the
same time, and check whether the host computer is
turned on.
Check whether horizontal synchronization exceeds
the range if the LED indicator light shows green.
Picture unstable
(miscellaneous
wave, flickering,
blurry, etc.)
Check whether the connecting cable (HDMI or VGA
cable) is connected well with the host computer.
The rate (Hz) of monitor is compatible with host
computer.
