Nuie NSSQ7 User manual

SCREEN
BOTTOM
SEAL
VERTICAL
DOOR SEAL
WALL PROFILE
SCREEN PROFILE
SMALL FIXING SCREW,
CHROME CUP AND CAP.
SCREEN PROFILE
CAP
WALL PROFILE
CAP
WALL FIXING SCREW,
WALL PLUGS &
CHROME CUPS AND
CAPS.
AZ
TO POSITION YOUR SCREEN, PUT THE WALL PROFILE ONTO THE END OF THE
SCREEN PROFILE AND PUT THE BOTTOM SEAL ON THE BOTTOM OF THE SCREEN
GLASS.
POSITION THE SCREEN SO THAT THE BOTTOM SEAL DEFLECTION BLADE IS TO THE
INSIDE RADIUS OF THE BATH LEDGE; AS SHOWN IN THE VIEW ABOVE. CHECK
LEVEL WITH A SPIRIT LEVEL.
ONCE HAPPY, MARK THE POSITION OF THE WALL PROFILE WITH A PENCIL AND
MARK THROUGH THE WALL PROFILE FIXING HOLES WITH A PENCIL.
INSIDE BATH
RADIUS
SCREEN
GLASS
BOTTOM SEAL
DEFLECTION BLADE
8mm HINGED BATH SCREEN
UNPACK THE BOX AND ENSURE ALL COMPONENTS ARE PRESENT.
NO REFUND OR REFITTING COST WILL BE GIVEN IF INCOMPLETE OR DAMAGED
GOODS HAVE BEEN FITTED.
THE TOUGHENED SAFETY GLASS SHOULD BE HANDLED WITH CARE AS IMPACTS
WILL DAMAGE THE GLASS OR BATH.
TOOLS REQUIRED
POWER DRILL - 3mm DRILL BIT - 6mm MASONARY DRILL BIT - CROSS HEAD SCREW
DRIVER - TAPE MEASURE - PENCIL - SILICONE GUN WITH SANITARY GRADE
SEALANT - SPIRIT LEVEL.
1
2
DRILL AND PLUG THE WALL
WHERE YOU MARKED FOR
THE FIXING HOLES. THEN
FIX THE WALL PROFILE IN
PLACE USING THE LARGE
FIXING SCREWS OR
SUITABLE FIXINGS.
ENSURE YOU USE THE
SCREW CUPS AND CAPS.

BB
VIEW FROM INSIDE OF
ENCLOSURE
BC
BD
WHERE THE SCREEN
PROFILE MEETS THE
WALL PROFILE.
BF
150
3
BEFORE REPLACING THE SCREEN
ASSEMBLY, YOU WILL NEED TO SLIDE
THE VERTICAL DOOR SEAL DOWN
THE HINGE SIDE OF THE GLASS AND
PUSH ONTO THE END OF THE GLASS.
NOW SLIDE THE SCREEN ASSEMBLY
INTO THE WALL PROFILE. THE
BOTTOM EDGE OF THE GLASS MUST
BE PARALLEL TO THE BATH TOP
FACE.
POSITION THE SCREEN ASSEMBLY SO
THAT THERES AN EQUAL AMOUNT
OF SCREEN PROFILE IN THE WALL
PROFILE AND SO THERES AN
ADEQUATE AMOUNT OF MATERIAL
TO PIN THE PROFILE USING HOLES
PROVIDED.
ENSURE SQUARE AND TRUE WITH A
SPIRIT LEVEL.
4
TO PIN YOUR SCREEN IN
PLACE USE THE 3mm DRILL
BIT TO DRILL THROUGH
THE HOLES IN THE WALL
PROFILE.
ENSURE YOU ONLY DRILL
THROUGH ONE WALL
THICKNESS.
NOW PIN THE SCREEN
USING THE SMALL FIXING
SCREWS, CUPS AND CAPS.
5
FIT THE SCREEN TOP CAPS
AS SHOWN ACROSS.
6
EXTERNALLY SILICONE SEAL THE WALL PROFILE
WHERE IT MEETS THE WALL AND 150mm HIGH
AS SHOWN IN THE DEATILED VIEW BELOW. ALL
IN A CONTINUOUS BEAD.
AFTERCARE - ENSURE YOU CLEAN
YOUR PRODUCT USING A MILD
DETERGENT DILUTED IN WATER,
REMOVING ANY RESIDUE WITH A
SOFT DAMP CLOTH.
MAINTENANCE - ENSURE MOVING
PARTS ARE FREE FROM ANY DEBRIS
OR SOAP BUILD UP.
