Numark X5 User manual

SPECIFICATIONS
MIC – AUX GAIN” (Microphone –Auxiliary Gain): This knob
adjusts the volume of both the main microphone and auxiliary
inputs.
“Treble “ (Microphone –Auxiliary High EQ):This knob adjusts
the high-tone input sound of the microphone.
“Bass” (Microphone – Auxiliary Low EQ): This knob adjusts
the low-tone input sound of the microphone.
“Gain knob” (Input Level Trim): This rotary control adjusts the
pre - fader input signal levels of the inputs.
EQ:
“Treble” (Input Level High EQ): This rotary control adjusts the
high – tone sound of the inputs.
“Middle” (Input Level Midrange EQ): This rotary control adjusts
the high-tone sound of the inputs.
“Bass” (Input Level Low EQ): This rotary control adjusts the
high – tone sound of the inputs.
“Phono(AUX)/Line Switch” (Input Selector Switch): These
three – position toggles select what input source is engaged among
the connected units and a flash position to allow rapid transforming
effect.
“Input Level Slider” (VCA Fader): These slide faders adjust the level
for CH-1 or CH-2 respectively.
“Slope knob” (Input Fader Curve Style Control): The position of this
knob determines the rate of volume level increase of the fader.
“Reverse Button” (Input Fader Reverse Control): Activation of this
switch can reveres the fader direction.
“Program/PFL Level Meter and Button”: Press to alternate display
modes.
“Cue Gain Knob”(Headphone Level): This rotary control adjusts
the levels of the headphones connected to the front panel input.
“Cue Tone Knob” (Headphone Tone Control): This rotary knob
adjusts the tone of the headphone output.
“Channel Cue Slider”: Channels 1 and 2 can be previewed using this
mini – crossfader.
“Cue Button” (MIC and MASTER Cue Buttons): When pressed,
the CUE button illuminates green indicating that the source is
being cued to the headphones.
“Crossfader Slider” (Digital VCA Crossfader): This slide fader
blends audio between CH-1 and CH-2.
SERVICE MANUAL
MODEL:X5
“Contour Knob” (Crossfader Rate/Slope Control): The position of this switch
determines how quickly or intensely the crossfader will act depending upon mode
setting.
“Direction Button” (Crossfader Reverse Control): Activation of this switch
reverses the assignment of CH-1 and CH-2 on the crossfader.
“Master Knob” (Main Output Level Control): This rotary control adjusts the main
output volume.
“Booth Knob” (Master/Split Style Headphone Cueing Switch): This rotary control
adjusts the auxiliary (AKA booth) output volume.
“Digital Output” (Optical): 48kHz, 24-bit S/PDIF output.
“Digital Output” (Coax): 48kHz, 24-bit S/PDIF output.

DISASSEMBLY PROCEDURES
1. REMOVING OF THE TOP PANELS (Fig1)
(A) REMOVE 4 CAPS.
(B) REMOVE 17 SCREWS BEFORE REMOVING OF THE TOP PANELS, INCLUDED UPPER, MIDDLE AND
LOWER PANEL.
(Fig1)

2. REMOVING OF THE BOTTOM CHASSIS (Fig2).
(A) REMOVE 12 SCREWS BEFORE REMOVING OF THE BOTTOM CHASSIS.
(Fig.2)
3. REMOVING OF THE REAR PANEL AND DISASSEMBLE THE I/O PCB
ASSEMBLY. (Fig3).
(A) REMOVE 13 SCREWS.
(B) REMOVE 2 NUTS TO DISSEMBLING THE REAR PANEL AND THE I/O PCB ASSEMBLY.
(Fig.3)

3-1.DISASSEMBLE THE I/O PCB ASSEMBLY . (Fig.3-1)
(A)(B)(C)(D)(E)(F)(G)(H)REMOVE 9 CABLES.
(Fig.3-1)
4. REMOVING OF THE FRONT PANEL (Fig4).
(A) REMOVE 1 KNOB.
(B) REMOVE 2 SCREWS BEFORE MOVING OF THE FRONT PANEL..
(Fig.4)

4-1. DISASSEMBLE THE MIC AND PHONE PCB ASSEMBLY . (Fig.4-1)
(A) REMOVE 2 NUTS AND 2 WASHERS BEFORE REMOVING OF THE MIC AND PHONE PCB ASSEMBLY.
(B) REMOVE 2 CABLES ON THE MIC AND PHONE PCB ASSEMBLY.
(Fig.4-1)
5. REMOVING OF THE MAIN PCB ASSEMBLY.
5-1. REMOVING OF THE KNOBS, FIXED HOLDERS AND GROUND PLATES.
(Fig.5-1)
(A) REMOVE 17 KNOBS.
(B) REMOVE 5 FIXED HOLDERS.
(C) REMOVE 2 GROUND PLATES.
(Fig.5-1)

5-2. REMOVING OF THE NUTS, WASHERS AND VELVET CARPETS ON THE
CABINET . (Fig.5-2)
(A) REMOVE 14 NUTS AND 14 WASHERS.
(B) REMOVE 2 VELVET CARPET.
(C) REMOVE 10 SCREWS.
(Fig.5-2)
5-3. REMOVING OF THE VR PCB ASS’Y . (Fig.5-3)
(A) REMOVE 8 SCREWS.
(B)(C)(D)(E) REMOVE 4 CABLES BEFORE REMOVING OF THE VR PCB ASSEMBLY.
.
(Fig.5-3)

5-4. DISASSEMBLE THE SWITCH PCB ASSEMBLY AND REMOVING OF THE
FADERS . (Fig.5-4)
(A) REMOVE 2 KNOBS.
(B) REMOVE 4 SCREWS.
(C) REMOVE 2 METAL PLATE.
(D)REMOVE 2 CABLES ON SWITCH PCB ASSEMBLY.
(E)(F)(G)REMOVE 3 CABLES CONNECTED TO THE FADERS BEFORE REMOVING OF THE FADERS.
(Fig.5-4)
5-5. REMOVING OF THE MAIN PCB ASSEMBLY . (Fig.5-5)
(A) REMOVE 11 SCREWS BEFORE MOVING OF THE MAIN PCB ASSEMBLY.
(Fig.5-5)

WIRING DIAGRAM

EXPLODE DIAGRAM
NMS9MAR01/02/03/04/05/06/07
SEQUENCE NO OF EXPLODE DIAGRAM WILL BE MARKED ON REF. COLUMN OF BOM LIST

PACKING DIAGRAM
NMS9MAR01

PACKING DIAGRAM
NMS9MAR02

PACKING DIAGRAM
NMS9MAR03

PACKING DIAGRAM
NMS9MAR04/05/06/07

LEVEL P/N DESCRIPTION QTY REF
0.1 CN0820003006 Flat Cable 8Pin Pitch 2.0mm Single row length 300mm 2
0.1 K46-1 Cable Tie 5
0.1 LAC62MAR631 Date Label 1
0.1 LAC22MAR398 SERIAL LABEL 1
0.1 LAC62MAR399 BAR COADE LABEL 2
0.1 LAC62MAR492 Bar Code Label 1
0.1 LAC63MAR410 SAFETY LABEL 1
0.1 LAC67YAH261 Sticker φ8mm Green 1
0.1 MT0705517 COPPER 6 44
0.1 MT1101806 EARTHER PLATE 2 23
0.1 MT1101809 Screw Ground Assembly 2 35
0.1 MT1101840 Ground Plate 2 49
0.1 MT1103205 DISSIPATING PLATE 1 24
0.1 MT1104410 HOLDER PLATE 3 29
0.1 MT11044109 HOLDER PLATE 1 25
0.1 MT1104432 VR HOLDER PLATE 3 19
0.1 MT1104434 METAL PLATE 2 17
0.1 MT112046902 Front Panel-Printing 1 22
..2 MT112046901 Front Panel-Painting 1
...3 MT1120469 FRONT PLATE 1
0.1 MT112047002 Rear Panel-Printing 1 31
..2 MT112047001 Rear Panel-Painting 1
...3 MT1120470 BACK PLATE 1
0.1 MT113008001 TOP PANEL-TOP (PRINT) 1 6
0.1 MT113008101 TOP PANEL-MID(PRINT) 1 7
0.1 MT113008201 TOP PANEL-BELOW(PRINT) 1 8
0.1 MT113034801 BOTTOM(PRINT/PAINT) 1 45
0.1 NM1104426 VELET CARPET 1
0.1 NM1106111 VELVET CARPET 2 14
0.1 NP211MAR135 NAME PLATE 1 9
0.1 NP311MAR92 LOGO 1 39
0.1 PNMS9MAR01 PACK ASS'Y 1
..2 CGNMS9313MAR01 Inner Box 1
..2 CTNMS9513MAR01 CARTON 1
..2 OPNK14MAR05 Operation Manual 1
..2 OPNMS9MAR01 MANUAL 1
..2 PE230370402B07 Poly Bag 230*370mm 1
..2 PLNMS901 POLYFOAM(L) 1
..2 PLNMS902 POLYFOAM(R) 1
..2 PLNMS903 Polyfoam Block 1
..2 SD35055000RJP SOFT SHEET 1
0.1 PT0710621101 KNOB 11 2
0.1 PT1104416401 FIXED HOLDER PAINT 5 40
..2 PT11044164 FIXED HOLDER 5
0.1 PT1110611302 KNOB 1 3
..2 PT11106113 KNOB 1
0.1 PT11106142 KNOB 7 1
0.1 PT11106163 VR KNOB 3 4
0.1 PT111062001 KNOB 4 11
..2 PT1110620 KNOB 4
0.1 PT1110621 KNOB 5 10
0.1 PT111063702 KNOB 1 50
..2 PT1110637 KNOB 1
0.1 PT111063801 KNOB 2 13
..2 PT1110638 KNOB 2
0.1 PT1130208 CABINET 1 21
0.1 RU1104407 RUBBER 2 43
NMS9MAR01~07 BOM

0.1 RU1330701 FOOT STAND 4 41
0.1 SC0204BIPI Screw 4 42
0.1 SC0305PIBI Screw 12 18
0.1 SC0308ABBI Screw(FLAT) 17 5
0.1 SC0308ABNI Screw 16 20
0.1 SC0308PBBI Screw M3x8mm PPB TAPPING 5 33
0.1 SC0308RBNI Screw M3*8mm Prn Tapping 21 30
0.1 SC0312RBNI Screw 1 47
0.1 SC2604RIBI SCREW 4 15
0.1 SC2606RBNI SCREW 4 16
0.1 SP1110603 SPRING 5 12
0.1 TF48093201UL ADAPTOR 9VAC 1.3A UL (01) 1
TF48093301EU ADAPTOR 9VAC 1.3A EU (02)
TF48093401UK ADAPTOR 9VAC 1.3A UK (03)
0.1 WR112645062G1 Isolation Cable 3Pin Single Row 450mm 1
0.1 WR1140052W1 WIRE 5P 400MM 1
0.1 TWSWRA19-201-1 POWER SW ASS'Y 1 46
..2 CN0220000701 Flat Cable Multicolored 2P Pitch 2.0mm 70mm 1
..2 HST050015BUL Heat-Shrinkable Tube 5X15mm 2
..2 SWR19A-2 POWER SWITCH 1
0.1 TWPC02C03502 I/O PCB ASS'Y 1 32
..2 AL2-62-0245 IC 74AHC245 2 U25,26
..2 AL2-62-1004 IC AHCU04 1 U11
..2 AL2-71-0072 IC TL072CDR 1 U1
..2 AL2-71-0074 IC TL074 9 U2~5,9,10,12~14
..2 AL2-75-1101 IC CONVERTER A/D 24BIT AL1101G 3 U15~17
..2 AL2-75-1201 IC CONVERTER D/A 24BIT AL1201G 2 U19,20
..2 AL2-77-0095 IC DSP 1KS/AL3102 1 U18
..2 AL4-02-0902 JACK 1 J5
..2 AL5-00-0021 SCREW 4 (U22,23)
..2 AL5-02-4402 NUT 4 (U22,23)
..2 CN0420000802 Flat Cable Multicolored 4P Pitch 2.0mm 80mm 2 (SW2,SW3)(SW4,SW5)
..2 CS101J5005NPO CERAMIC 100pF/50V 5% 0805 NPO 4 C5,6,10,11
..2 CS102K5005X7R CERAMIC 1nF/50V 10% 0805 X7R 4 C113,115,116,118
..2 CS104K5005X7R CERAMIC 0.1uF/50V 10% 0805 X7R 45
C4,9,19,21,22,33,39,42,47,59,84,85,95~97,100,105,11
0,114,117,119,120,122,125,128,130~142,144~147,180
,181,183
..2 CS221J5005NPO CERAMIC 220pF/50V 5% 0805 NPO 7 C20,46,48,90~93
..2 CS330J5005NPO CERAMIC 33pF/50V 5% 0805 NPO 1 C83
..2 CS331J5005NPO CERAMIC 330pF/50V 5% 0805 NPO 20 C2,3,7,8,12~18,28,34,35,62,86~89,148
..2 CS332K5005X7R CERAMIC 3.3nF/50V 10% 0805 X7R 6 C121,123,124,126,127,129
..2 CS390J5005NPO CERAMIC 39pF/50V 5% 0805 NPO 1 C94
..2 DIN4002 Diode DIN4002 5 D1~5
..2 DISDBAT54CSM Zener Diode BAST54C 1 Q1
..2 EC10835 Capacitor Electrolytic 1000uF/35V 13*21mm 4 C44,45,71,72
..2 EC22816 Capacitor Electrolytic 2200uF/16V 1 C61
..2 EC47616T Capacitor Electrolytic 47uF/16V 5*11mm 50 C1,23,36~38,40,41,43,49~58,60,63~68,70,73~82,98,9
9,101~104,106~109,111,112,143,182
..2 IC7805 IC 7805 2 U22,23
..2 IC7815 IC 7815 1 U6
..2 IC7915 IC 7915 1 U8
..2 ICBA03FP-E2 IC BA03FP 1 U7
..2 ICCS8406-CSZ IC CS8406-CSZ 1 U21
..2 JKDJ-0702B-025 JACK 1 J7
..2 JKOC0806T JACK 1 J6
..2 MC273100MM MALYER CAPACITOR 0.027UF/100V TOLERAUCE 5
%
4 C24~27
..2 MC822100MM MALYER CAPACITOR 8200P/100V TOLERAUCE 5% 4 C29~32
..2 MT1101810 Ground Contact Slice 4 (J1~4)
..2 MT1103206 DISSIPATING PLATE 1 -

..2 PC02C035 I/O PCB 2Layer FR-4 1.6T 208*136.5MM 1 -
..2 RJ1106-09 RCA BASE 2P 1 J4
..2 RJ1107-09 RCA BASE 4P 3 J1~3
..2 RS000008J05 RESISTOR 0Ω5% SMD 0805 2 R149,150
..2 RS001M08F05 RESISTOR 1M 1% SMD 0805 1 R94
..2 RS002K08F05 RESISTOR 2K 1% SMD 0805 5 R74,108,110,111,113
..2 RS010008F05 RESISTOR 100Ω1% SMD 0805 13 R2,5,10,13,23,40~43,66,67,123,140
..2 RS010K08F05 RESISTOR 10K 1% SMD 0805 26 R1,24,36~39,44~49,59,60,82~93
..2 RS033008F05 RESISTOR 330Ω1% SMD 0805 35 R18~22,29~31,95~106,132,133,135~139,141~148
..2 RS039008F05 RESISTOR 390Ω1% SMD 0805 1 R81
..2 RS047008F05 RESISTOR 470Ω1% SMD 0805 1 R160
..2 RS047K08F05 RESISTOR 47K 1% SMD 0805 25 R3,4,11,12,50~58,61,68~71,75~80,134
..2 RS07K508F05 RESISTOR 7.5K 1% SMD 0805 4 R107,109,112,114
..2 RS100K08F05 RESISTOR 100K 1% SMD 0805 8 R7,8,15,16,25~28
..2 RS13K708F05 RESISTOR 13.7K 1% SMD 0805 4 R115,117,120,122
..2 RS1K6508F05 RESISTOR 1.65K 1% SMD 0805 4 R116,118,119,121
..2 RS2K2108F05 RESISTOR 2.21K 1% SMD 0805 4 R6,9,14,17
..2 RS3K7408F05 RESISTOR 3.74K 1% SMD 0805 4 R124~127
..2 RS4K5308F05 RESISTOR 4.53K 1% SMD 0805 4 R128~131
..2 RS5K1108F05 RESISTOR 5.11K 1% SMD 0805 2 R64,65
..2 RS8K2508F05 RESISTOR 8.25K 1% SMD 0805 4 R32~35
..2 RU1104407 RUBBER 2 -
..2 SC0312RBNI Screw 1 -
..2 TE10200502 5P CONNECTOR 1 (J12)
..2 TE612000202 2P CONNECTOR 1 SW1
..2 TE612000301 3P CONNECTOR 1 (J10)
..2 TE612000801 8P CONNECTOR 2 (J8,9)
..2 TE812000211 2P CONNECTOR 4 SW2~5
..2 TE962005002 50P CONNECTOR 1 J11
..2 TE962541401 14P CONNECTOR 1 (J13)
..2 WS073307IC WASHER FLAT 4 (U22,23)
..2 WS663309IC SPRING WASHER 3# 4 (U22,23)
..2 XTM12288X3 Crystal 12.288MHzMHz 49US DIP Fundamental 1 X1
0.1 TWPC02C03603 MAIN PCB ASS'Y 1
..2 PC02C036 Function PCB Single Layer 1.6T 330*197MM 1
..2 TWPC02C036A03 MAIN PCB ASS'Y 1 27
...3 AL0-17-0102 RESISTOR ARRAY 4X1K 2 R14,15
...3 AL0-17-0470 RESISTOR ARRAY 4X47 1/10W 0603 1 R12
...3 AL2-51-4403 TRANSISTOR 2N4403 PNP SOT-23 17 Q1~17
...3 AL2-62-0138 IC 74AHC138 1 U6
...3 AL2-72-0339 IC LM339 2 U3,4
...3 AL2-73-4052 IC CD4052 2 U1,2
...3 CN0320000801 Flat Cable Multicolored 3P Pitch 2.0mm 80mm 3 J2~4
...3 CN0320001501 Flat Cable Multicolored 3P Pitch 2.0mm 150mm 1 J15
...3 CN0620000701 Flat Cable 6Pin Pitch 2.0mm 70mm 3 J6,7,9
...3 CN1425403001 Flat Cable Type 7P*2 Pitch 2.54mm 300mm 1 J5
...3 CN5020001801 Flat Cable Type 25P*2 Pitch 2.0mm 180mm 1 J1
...3 CS104K5005X7R CERAMIC 0.1uF/50V 10% 0805 X7R 8 C1~4,8~10,12
...3 CS330J5005NPO CERAMIC 33pF/50V 5% 0805 NPO 2 C6,7
...3 CS474K2505X7R CERAMIC 0.47uF/25V 10% 0805 X7R 1 C11
...3 CSF104J5012P Film chip capacitor 0.1UF/50V 5% 1812 Panasonic 1 C5
...3 EC47616T Capacitor Electrolytic 47uF/16V 5*11mm 3 C13~15
...3 ICYH92M02 IC YH92M02 MICONIC 1 U5
....4 AL2-70-0008 IC P87C51RC2BBD 1 -
...3 JW5206T JUMP WIRE 101 JM1~JM100,L1
...3 LD-005HLV RED LED 7 D3~8,29
...3 LD-241E4HR26S RED LED 20 D9~28
...3 PT1104412 LED 1 (D8~29)
...3 RS000008J05 RESISTOR 0Ω5% SMD 0805 19 JS1~19

...3 RS004708F05 RESISTOR 47Ω1% SMD 0805 2 R6,9
...3 RS010008F05 RESISTOR 100Ω1% SMD 0805 2 R4,5
...3 RS010K08F05 RESISTOR 10K 1% SMD 0805 8 R2,7,8,10,11,13,16,17
...3 RS015008F05 RESISTOR 150Ω1% SMD 0805 1 R3
...3 RS3K3208F05 RESISTOR 3.32K 1% SMD 0805 1 R1
...3 SW-150 POWER SWITCH 5 S3~7
...3 SWSKHVBE3520 Switch Tact 1 S8
...3 TE812000311 3P CONNECTOR 4 (J2~4,15)
...3 TE812000611 6P CONNECTOR 3 (J6,7,9)
...3 VRR50202001 VARIABLE RESISTANCE 6 P1~4,7,12
...3 VRR50202003 VARIABLE RESISTANCE 8 P5,6,8~11,13,14
...3 VRS50202001 VARIABLE RESISTANCE 1 P15
...3 WCB6 WIRE 1 (A1,A2)
...3 XTM30000X3 Crystal 30MHZ 49US DIP Fundamental 1 X1
..2 TWPC02C036C01 MIC PCB ASS'Y 1 37
...3 CS103K5005X7R CERAMIC 0.01uF/50V 10% 0805 X7R 1 C202
...3 CS331J5005NPO CERAMIC 330pF/50V 5% 0805 NPO 2 C115,116
...3 JKSCJ644R5NG PHONE JACK 6.3φ6PIN 1 J11
...3 TE612000301 3P CONNECTOR 1 (J12)
..2 TWPC02C036D01 PHONE PCB ASS'Y 1 38
...3 CS103K5005X7R CERAMIC 0.01uF/50V 10% 0805 X7R 3 C109,110,201
...3 CS104K5005X7R CERAMIC 0.1uF/50V 10% 0805 X7R 2 C203,204
...3 ICNJM4556AD IC NJM4556AD 2 U24,25
...3 JKSCJ644R5NG PHONE JACK 6.3φ6PIN 1 J13
...3 JW5206T JUMP WIRE 3 JM101~103
...3 R47012 RESISTOR 47Ω1/2W 4 R151~154
...3 TE10200502 5P CONNECTOR 1 (J14)
..2 TWPC02C036E02 SWITCH PCB ASS'Y 2 36
...3 SWLBCR23M-095 SWITCH 2 S1
...3 TE622000801 8P CONNECTOR 2 (J17)
..2 TWPC02C036F01 VR PCB ASS'Y 3 28
...3 TE612000301 3P CONNECTOR 3 CN
...3 VRR50203001 VARIABLE RESISTANCE 3 POT
..2 TWPC02C036G01 PCB ASS'Y 1 34
...3 JW5206T JUMP WIRE 1 JM104
...3 SWSS70010-0202 SWITCH 2 D10,11
...3 TE622000401 4P CONNECTOR 2 (CN1,2)
..2 TWPC02C036H01 VR PCB ASS'Y 1 48
...3 TE622000302 3P CONNECTOR 1 (CN3)
...3 VRR50203001 VARIABLE RESISTANCE 1 POT1
0.1 TWPC04M00902 VR PCB ASS'Y 3 26
..2 PC04M009 VR PCB 3 -
..2 TE10200602 6P CONNECTOR 3 (TE1)
..2 VRS50304513 VARIABLE RESISTANCE 3 VR1
