Numark cdmix usb User manual

SPECIFICATION
CD FUNCTION
PITCH ＆ PITCH BEND---------------- ± 4%,±8%,±16%,±100% Speed Control, PITCH BEND ±16% Speed Control.
SEARCH-------------------------------------Pressing this button to turn on the SEARCH function.
CUE-------------------------------------------Press the button will retun to the cue point. Holding down the button will start playback from this point.
TIME-----------------------------------------Switches the display between elapsed time/remaining time/total remaining time.
SINGLE--------------------------------------Press this button to toggle between Single Play or Continuous Play.
PROGRAM----------------------------------Helps you create a program – a sequence of tracks to play continuously.
CUE-------------------------------------------Returns and pauses the music at the last set cue point.
PLAY/PAUSE-------------------------------Plays or pauses the track.
LOOP IN/OUT/RELOOP-----------------These buttons are used to define your beginning and ending loop points (LOOP IN and LOOP OUT)
or to replay or restart your loop (RELOOP).
TRACK---------------------------------------Turn this knob to select a track to play.
TAP--------------------------------------------Press the button once to activate Auto BPM mode. Press the TAP button repeatedly in time with the
beats of the music on that deck to enter Manual BPM mode. To go back to AUTO BPM mode, hold the
button for 2 seconds.
SCRATCH-----------------------------------Activates or deactivates Scratch Mode.
SEARCH-------------------------------------Activates or deactivates Search Mode.
REVERSE-----------------------------------Press this button to reverse playback of the track.
BRAK----------------------------------------Press this button to activate braking.
SOURCE-------------------------------------Press to select USB A, USB B, or CD audio source.
EJECT----------------------------------------Press this button to open or close the CD disc tray.
SERVICE MANUAL
MODEL:CDMIX USB

MIXER FUNCTION
1.INPUT--------------------------------------RCA (LINE/PHONO Unbalance) x 2 pair
1/4" TRS JACK (MIC) x 1 pair
2.OUTPUT-----------------------------------RCA (MASTER/MASTER1) x 2 pair
1/4" TRS JACK (MASTER Balance) x 1 pair
1/4" TRS JACK (PHONE) x 1 pair
1/8" JACK (PHONE) x 1 pai r
3.GAIN,LINE FADER,MASTER---------CONTROL VOLUME
4.CROSS FADER----------------------------CONTROL CH1 OR CH3 OUTPUT
5.CUE,CUE GAIN,CUE MIX--------------SELECT CUE FORM CH1.2.3,CUE VOLUME,CONTROL CUE OR MASTER
6.TREBLE,MID,BASS----------------------CONTROL EQ +12~ -28Db
7.7 segment meter LED's for each channel and separate 2x7 segment for master
STANDARD
OUTPUT LEVEL-----------------------------7.0±0.5 Vrms (1KHz 0dB)
S/N RATIO------------------------------------MORE THAN 70dB
FREQUENCY RESPONSE-----------------20Hz~20KHz±2 dB
CHANNEL BALANCE---------------------- ± 2dB
HARMONIC DISTORTION----------------LESS THAN 0.09%

DISASSEMBLY PROCEDURES
1. REMOVAL OF KNOB AND VR CAP AND PANEL ASSEMBLY. (Fig1)
(A) REMOVE THE 18 PCS KNOB AND 6 PCS VR CAP FROM OF PANEL.
(B) REMOVE THE 13 PCS SCREWS FROM OF BOTTOM CHASSIS.
(C) REMOVE THE 3 PCS CONNECTORS BEFORE REMOVAL OF PANEL ASSEMBLY.
Fig.1

2.REMOVAL OF CROSS FADER PCB AND HEADPHONE PCB AND MIXER PCB ASSEMBLY. (Fig.2)
(A) REMOVE THE 2 PCS SCREWS AND 1 PC CONNECTOR BEFORE REMOVAL OF CROSS FADER PCB
ASSEMBLY.
(B) REMOVE THE 2 PCS SCREWS AND 1 PC CONNECTOR BEFORE REMOVAL OF HEADPHONE PCB
ASSEMBLY.
(C) REMOVE THE 13 PCS SCREWS BEFORE REMOVAL OF MIXER PCB ASSEMBLY.
Fig.2
3.MOVAL OF LCM PCB AND FUNCTION PCB ASSEMBLY.(Fig.3)
(A) REMOVE THE 6 PCS SCREWS AND 2 PCS CONNECTORS BEFORE REMOVAL OF LCM ASSEMBLY.
(B) REMOVE THE 11 PCS SCREWS BEFORE REMOVAL OF FUNCTION PCB ASSEMBLY.
Fig.3

4.REMOVAL OF S ITCHING PO ER PCB AND MAIN PCB ASSEMBLY .(Fig4)
(A) REMOVE THE 15 PCS SCREWS AND 5 PCS CONNECTORS BEFORE REMOVAL OF MAIN PCB ASSEMBLY.
(B) REMOVE THE 3 PCS SCREWS BEFORE REMOVAL SWITCHING POWER PCB ASSEMBLY.
Fig.4

5.REMOVAL OF SERVO PCB AND CM-H12 ASSEMBLY.(Fig5)
(A) REMOVE THE 8 PCS SCREWS AND 6 PCS CONNECTORS BEFORE REMOVAL 2 PCS SERVO PCB
ASSEMBLY.
(B) REMOVE THE 2 PCS FRONT PANEL FROM THE BOTTOM CHASSIS.
(C) REMOVE THE 8 PCS SCREWS BEFORE REMOVAL CM-H12
Fig.5

LEVEL
P/N DESCRIPTION QTY REF
0.1 BAGL-55A CABLE CLIP 55L 3 56
0.1 BASV-N019 VR Cap 6 2
0.1 BAW-0348 Washer 2 16
0.1 BAW-1065 WASHER 2 13
0.1 CMH12YAH01 CM-H12 2 33
0.1 CN0100001013 Flat Cable GND Wire Black φ3. 2
0.1 CN0520002501 Flat Cable Multicolored 5P Pit 2 53
0.1 CN0620001001 Flat Cable 6Pin Pitch 2.0mm Si 2 54
0.1 CN0639602001 Flat Cable 6Pin Pitch 3.96mm S 1 55
0.1 ERE73 E Ring 3mm 2 17
0.1 EVA0104406 EVA 1 62
0.1 EVA0604404 EVA 2 34
0.1 FFC1410002001 FFC 14Pin Pitch:1.0mm Length:2 1 50
0.1 FFC1610002001 CONNECTOR 2 51
0.1 FFC3010001011 FFC 30Pin Pitch:1.0mm Length:1 2 57
0.1 FFC3010003001 FFC 30Pin Pitch:1.0mm Length:3 1 52
0.1 K46-1 Cable Tie 1 60
0.1 LAC22MAR1042 Serial Number Label 1 49
0.1 LAC32MAR252 INDICATEN LABEL(CS) (05) 1 65
0.1 LAC42MAR350 LABEL (05) 1 64
0.1 LAP62MAR342 Label (07) 1 64
0.1 LAC53MAR1061 Warning Label 1 48
0.1 LAC62MAR1043 Bar Code Label 2
0.1 LAC62MAR1044 Bar Code Label(CODE 39) (01) 1
0.1 LAC63MAR1059 TUV SUD Label (01) 1 63
0.1 LAC52MAR254 WARNING LABEL (05) 1 63
0.1 LAC67MAR303 SAFETY LABEL (06) 1 63
0.1 LAC51MAR1065 PSE Warning Label (07) 1 63
0.1 LAC67MAR681 Label(Circle Limpid) 2
0.1 LAC67YAH261 Label φ8mm Green 1
0.1 LCMWDH0078-TMI Liquid Crystel Display Module 2 21
0.1 MT0605507 BRASS 2 15
0.1 MT11044191 Fixed Holder 4 30
0.1 MT1105555 Copper 2 39
0.1 MT1105584 Copper 5 24
0.1 MT11300147101 Panel(Printing & Painting) 1 9
0.1 MT1130015101 Plate(CROSS FADER)Painting 1 6
..2 MT11300151 Plate(CROSS FADER) 1
0.1 NM1104412 VELVET CARPET 19 25
0.1 NM1106118 Velvet Carpet 3 12
0.1 NM1106125 Velvet Carpet 3 61
0.1 NP206YAH124 NAME PLATE 2 4
0.1 NP211MAR177 Isolate Plate 1 38
0.1 PNC20MAR01 Pack Assembly (01) 1
PNC20MAR02 Pack Assembly (02) 1
PNC20MAR03 Pack Assembly (03) 1
PNC20MAR04 Pack Assembly (04) 1
PNC20MAR05 Pack Assembly (05) 1
PNC20MAR06 Pack Assembly (06) 1
PNC20MAR07 Pack Assembly (07) 1
PNC20MAR08 Pack Assembly (08) 1
PNC20MAR09 Pack Assembly (09) 1
..2 BC1015025000 Bubble Pad 1
..2 CB313S036 Separate Wall 1
..2 CGNC20310MAR01 Inner Box 1
..2 CTNC20513MAR01 Carton 1
..2 GEMAR59 CARD (05) 1
..2 GEMAR90 Ouarantee Card (09) 1
..2 GEMAR91 Ouarantee Card (09) 1
..2 OPNC20MAR01 Instruction Book 1
..2 OPNK14MAR07
Operation Manual(V17.9) (01)(02)(03)(05)(06)(07)(08)
1
NC20MAR01~09 BOM

OPNK14MAR08 Operation Manual (09) 1
..2 PE230370402B07 Poly Bag 230*370mm 1
..2 PLNC2001 Polyfoam(Left) 1
..2 PLNC2002 Polyfoam(Right) 1
..2 SD650490RJP Soft Sheet 1
0.1 PT060290216 Panel-Printing(Painting) 2 35
..2 PT0602902 DECK FRONT PANEL 2
0.1 PT061074303 Wheel(Painting) 2 11
..2 PT0610743 ROTATE KNOB 2
...3 MT0605501 Jog Axis 2
0.1 PT11044310 Fixed Holder(Button) 4 28
0.1 PT11044311 Fixed Holder(Lid) 1 26
0.1 PT11044312 Fixed Holder 2 14
0.1 PT1110613701 KNOB 2 1
0.1 PT1110631102 Button(Headphone)Printing 4 29
..2 PT11106311 Button (CUE) 4
0.1 PT11106555 Light Pipe(5) 2 27
0.1 PT1130311401 Bottom Chassis(Printing & Pain 1 46
..2 PT11303114 Bottom Chassis 1
0.1 PW63200UC01 Ac Power Supply Cord Long 2.0m UL+CSA (01) 1
UP301-104 AC Power Supply Cord Long 1.83m EU (02)
PW53200UK03 AC Power Supply Cord Long 2.0m UK (03)
PW43200SAA01 AC Power Supply Cord Long 2.0m SAA (04)
PW43200AR01 AC Power Supply Cord Long 2.0m AR (05)
PW33200KS01 AC Power Supply Cord Long 2.0m KS (06)
PW22200JIS02 AC Power Supply Cord Long 2.0m JIS (07)
PW43200SAA01 AC Power Supply Cord Long 2.0m SAA(08)
PW33150BRA01 AC Power Supply Cord Long 1.5M BRA(09)
0.1 RU0610621401 RUBBER KNOB (EJECT) 2 19
0.1 RU0610622401 Rubber Button(FUNCTION KEY) 2 20
0.1 RU06106227 Rubber Button 2 18
0.1 RU1130734 Rubber Foot 4 47
0.1 SC0306FIBI SCREW M3X6 PFB 19 5
0.1 SC0308FBBI Screw M3X8 PFB Tapping 13 7
0.1 SC0308RBNI Screw M3X8 PRN Tapping 36 22
0.1 SC0308RIBI Screw M3X8 PPB 2 59
0.1 SC0308RINI SCREW M3X8 PPN 13 32
0.1 SC0310PBBI SCREW M3X10 PPB TAPPING 7 43
0.1 SC0314PBNI Screw M3X14 PPN Tapping 2 36
0.1 SC0408PBBI SCREW M4X08 PPB TAPPING 5 58
0.1 SPSSNPY041 SWITCHING POWER(INTERNAL) 5V/3 1 37
0.1 TWPT1110650201 Knob(STDV)Assembly 16 3
..2 PT11106502 Knob(STDV) 16
..2 PT11106503 Decoretive(STDV) 16
..2 PT1130042 Knob Deck(STDV) 16
0.1 TWSWR19A-201 Power switch ASS'Y 1 45
..2 DWLN2008502 BROWN WIRE 1
..2 K46-1 Cable Tie 1
..2 SWR19A-2 Power Switch 1
0.1 TWPC15C01801 Main PCB Assembly 1
..2 PC15C018 Main PCB 1
..2 TWPC15C018A01 Main PCB Assembly 1 44
...3 AL4-05-0028 JACK XLR 3-PIN FEM STEREO-COMB 1 MIC500
...3 CN0100002501 Flat Cable GND Wire Y/G φ4.3 1 CN400
...3 CS100J5003NPO CCAP SMD 10pF/50V 5% 0603 NPO 2 C514,554
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 8 C500,506,526,530,541,550~552
...3 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 10 C414A,414B,415A,415B,510,519,524,536,543
,555
...3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 15 C226,228,237~242,244,306~311

...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 83
C101,103~111,113~129,200~214,217~225,22
7,229~236,243,245,303~305,401A,401B,402A
,402B,420,432,433,509,515,517,518,529,532,
537,545,547,553,CC01
...3 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 14 C400~403,403A,403B,407A,407B,408A,408B,
409A,409B,413A,413B
...3 CS106K1003X5R CCAP SMD 10uF 10% 10V 0603 X5R 1 C246
...3 CS150J5003NPO CCAP SMD 15pF/50V 5% 0603 NPO 9 C130,405A,405B,406A,406B,410A,410B,411A
,411B
...3 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 3 C102,215,216
...3 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 10 C301,302,421~428
...3 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO 1 C100
...3 CS331J5003NPO CCAP SMD 330pF/50V 5% 0603 NPO 6 C512,513,504,507,558,559
...3 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 4 C404A,404B,412A,412B
...3 DIEN1N4148WSM Diode SMD 6 D404,405,501~504
...3 DIEN1SR154400SM Rectifier Diode 1SR154-400 SOD 4 D400~403
...3 DWR202201 Red Wire 220mm 1 TE400
...3 EC10825 Capacitor Electrolytic 1000uF/25V 3 EC402~404
...3 EC33725TLE Capacitor Electrolytic low ESR 330uF/25V 4 EC400,401,405,406
...3 EC47616T Capacitor Electrolytic 47uF/16V 4 EC500~502,504
...3 EC47716T Capacitor Electrolytic 470uF/16V 1 EC100
...3 ECS10616B Capacitor Electrolytic 10uF/16V 8 EC103,200,205,206,403A,403B,516,517
...3 ECS10625BLE ECAP Low ESR 10UF/25V 4*5.4mm 3 EC514,518,519
...3 ECS10716D Capacitor Electrolytic 100uF/16V 4 EC300,302,420,429
...3 ECS22616C Capacitor Electrolytic 22uF/16V 4 EC401A,401B,402A,402B
...3 ECS22725F E CAP 220UF/25V 8*10MM SMD 1 EC515
...3 ECS47550B ECAP 4.7UF/50V 4*5.3MM SMD 1 EC301
...3 ECS47616D Capacitor Electrolytic 47uF/16V 15 EC101,102,202~204,503,505~513
...3 FCN1T1001402 FCN DOWN Touch ZIF SMD Pitch=1.0mm 1 FCN400
...3 FCN1T1003001 FCN Down Touch ZIF SMD Pitch=1.0mm 3 FCN300,301,500
...3 FSMSMD200 Fuse PTC MSMD200 8V/2A SMD 1 FS100
...3 ICAIC1117-18PY IC AIC1117-18PY 1 IC100
...3 ICAIC809N46PU IC AIC809N46PU 1 IC302
...3 ICAP7165SPG IC AP7165-SPG-13 1 IC205
...3 ICBA033FP IC BA033FP 1 IC204
...3 ICBA05FP IC BA05FP 1 U421
...3 ICBA4558F IC BA4558F 4 IC502~505
...3 ICDA1191F IC DA1191F 2 IC401A,401B
...3 ICDRV602 IC DRV602 2 IC402A,402B
...3 ICDSPB56724AG IC DSPB56724AG 1 IC201
...3 ICK4S281632I IC K4S281632I 1 IC206
...3 ICKIA7808API IC KIA7808API 2 IC400,401
...3 ICSN74LV373APWR IC SN74LV373APWR 2 IC202,203
...3 ICSN74LVC3G14 IC SN74LVC3G14 4 IC303~306
...3 ICTL072CPWR IC TL072CPWR 1 IC500
...3 ICXCBDSP56367 IC XCBDSP56367 1 IC101
...3 ICYH104C13 IC YH104C13 (MX25L8006EM2I+Program) 1 IC200
....4 ICMX25L8006EM2I IC MX25L8006EM2I-12G 1 -
...3 ICYH2K09C01M IC YH2K09C01M
(MASK ET5126-YA+PROGRAM LQFP)
1 U100
...3 ICYH2K270 IC YH2K270 (TMP86FS49BFG+Program) 1 IC301
....4 ICMP86FS49BFG-1 IC TMP86FS49BFG Blank 1 -
...3 JK292336-1 USB A TYPE Jack 90° 1 USB100
...3 JK40861323322 RCA JACK 4Pin 90° 1 J501
...3 JK6L0670CBKA6A 6.4φPhone JACK 7PIN 90°Fem 1 MIC501
...3 JK7TU-301-AP AC JACK 3P 90°PIN 1 JK400
...3 JKLX-1601HR-3 XLR JACK 3PIN 90°MALE 2 J502,504
...3 RS000004J06 RESISTOR 0Ω5% SMD 1206 1 R400
...3 RS000010J03 RESISTOR 0Ω5% SMD 0603 13 R134,139,147,148,151~154,157,502,510,569,
576
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 8 R252,512,519,530,543,555,564,584
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603 3 R117,248,320
...3 RS002710F03 RESISTOR 27Ω1% SMD 0603 4 R119,120,123,124
...3 RS002K10F03 RESISTOR 2K 1% SMD 0603 1 R253

...3 RS010010F03 RESISTOR 100Ω1% SMD 0603 48
R127,132,133,135~138,141,146,158,200,213,
216~223,225,230,246,321,322,327,329,330,3
32,344,348,349,402A,402B,412A,412B,413A,
413B,501,505,508,515~517,520,522,560,562
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 88
R100~115,126,128~131,150,155,156,201~21
2,224,226,233,243~245,247,250,301~306,309
,310,313~319,323,325,326,328,331,333~343,
345~347,500,507,518,526,532,535,552,556,5
59,567
...3 RS015010F03 RESISTOR 150Ω1% SMD 0603 16 R227~229,231,239~242,401A,401B,403A,403
B,404A,404B,405A,405B
...3 RS015K10F03 RESISTOR 15K 1% SMD 0603 4 R116,118,121,122
...3 RS018010F03 RESISTOR 180Ω1% SMD 0603 1 R140
...3 RS022010F03 RESISTOR 220Ω1% SMD 0603 8 R214,215,234,235,420~423
...3 RS027010F03 RESISTOR 270Ω1% SMD 0603 1 R324
...3 RS02K710F03 RESISTOR 2.7K 1% SMD 0603 2 R557,563
...3 RS036K10F03 RESISTOR 36K 1% SMD 0603 4 R407A,407B,410A,410B
...3 RS047010F03 RESISTOR 470Ω1% SMD 0603 1 R125
...3 RS047K10F03 RESISTOR 47K 1% SMD 0603 8 R504,511,534,545,561,571,577,580
...3 RS056010F03 RESISTOR 560Ω1% SMD 0603 2 R149,300
...3 RS05K110F03 RESISTOR 5.1K 1% SMD 0603 2 R521,568
...3 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 6 R513,523,528,548,554,565
...3 RS062K10F03 RESISTOR 62K 1% SMD 0603 4 R406A,406B,411A,411B
...3 RS068K10F03 RESISTOR 68K 1% SMD 0603 4 R408A,408B,409A,409B
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 12 R251,503,506,509,514,524,533,549,558,566,5
70,573
...3 RS560K10F03 RESISTOR 560K 1% SMD 0603 1 R585
...3 TE613960601 6P CONNECTOR 1 (TE402)
...3 TE617920201 2P CONNECTOR 1 (TE401)
...3 TR2SA1037ASM TRANSISTOR 2SA1037AKR PNP 1 Q509
...3 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 6 Q502~507
...3 WRUSB05200015W4 Shielding Cable USB2.0 5Pin 1 TE100
...3 XTM06000X6 Crystal 6MHZ 49US SMD Fundamen 1 X100
...3 XTM11289X6 Crystal 11.2896MHz 49US SMD Fu 1 X200
...3 XTM16000X8 CRYSTAL 16MHz S3225A Fundament 1 X301
..2 TWPC15C018B01 HeadPhone PCB Assembly 1 10
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 4 C735,736,738,739
...3 JK-3537 3.5mm Phone Jack 9P 90°DIP 1 JK710
...3 JK6L0670CBKA6A 6.4φPhone JACK 7PIN 90°Fem 1 JK711
...3 MT1104484 Fixed Plate 2 -
...3 SC0308RINI SCREW M3X8 PPN 2 -
...3 TE10200601 6P CONNECTOR 1 (TE710)
0.1 TWPC15C01901 Function PCB Assembly 1
..2 PC15C019 Function PCB 1
..2 TWPC15C019A01 Function PCB Assembly 1 23
...3 BALE48212-0A LED 14 (LED5~9,18,19,30~34,43,44)
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 8 C3,8,11,12,14,15,21,24
...3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 2 C19,20
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 14 C1,4~6,13,16,18,22,25,27~31
...3 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 1 C23
...3 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 2 C7,9
...3 CS475K1605X5R CCAP SMD 4.7uF/16V 10% 0805 X5R 1 C17
...3 DIRPI-352 Diode 4 S1~4
...3 EC10716TS Capacitor Electrolytic 100uF/16V 1 EC26
...3 FCN1R1001605 FCN UP Touch smd Pitch 1.0mm 2 FCN1,2
...3 FCN1T1001401 FCN Up Touch ZIF SMD Pitch=1.0mm 1 FCN3
...3 IC74HC595 IC 74HC595 4 IC2~4,6
...3 ICAIC809N46PU IC AIC809N46PU 1 IC1
...3 ICSN74LVC3G14 IC SN74LVC3G14 2 IC7,8
...3 ICYH2K269 IC YH2K269 (TMP86FS49BFG+Program) 1 IC5
....4 ICMP86FS49BFG-1 IC TMP86FS49BFG Blank 1 -
...3 JK0CU4P04A USB Jack A-TPYE USB 180° 1 USB1

...3 LDAPHK1608CGCK Liquid-emitting Diode Green SM 4 LED20,21,45,46
...3 LDIFR324HD LED Red 3M/M 14 LED5~9,18,19,30~34,43,44
...3 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 32 LED1~4,10~17,22~29,35~42,47~50
...3 RS000010J03 RESISTOR 0Ω5% SMD 0603 4 R136~139
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603 1 R18
...3 RS002210F03 RESISTOR 22Ω1% SMD 0603 4 R59,133~135
...3 RS010010F03 RESISTOR 100Ω1% SMD 0603 1 R29
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 19 R11~13,23,25,27,30~38,40,56,57,60
...3 RS012K10F03 RESISTOR 12K 1% SMD 0603 4 R123,125,127,129
...3 RS015K10F03 RESISTOR 15K 1% SMD 0603 4 R116,119,121,122
...3 RS018010F03 RESISTOR 180Ω1% SMD 0603 36 R1,3~5,15~17,19~21,24,26,41~46,48~51,63,6
4~70,73~78
...3 RS01K510F03 RESISTOR 1.5K 1% SMD 0603 4 R85~88
...3 RS020K10F03 RESISTOR 20K 1% SMD 0603 2 R109,112
...3 RS022K10F03 RESISTOR 22K 1% SMD 0603 4 R83,84,113,114
...3 RS027010F03 RESISTOR 270Ω1% SMD 0603 1 R6
...3 RS033010F03 RESISTOR 330Ω1% SMD 0603 4 R97,98,131,132
...3 RS036010F03 RESISTOR 360Ω1% SMD 0603 14 R7~10,14,28,39,54,55,58,61,62,71,72
...3 RS03K310F03 RESISTOR 3.3K 1% SMD 0603 4 R89~92
...3 RS03K910F03 RESISTOR 3.9K 1% SMD 0603 8 R93~96,99~102
...3 RS047K10F03 RESISTOR 47K 1% SMD 0603 4 R79~82
...3 RS056010F03 RESISTOR 560Ω1% SMD 0603 1 R22
...3 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 4 R103~106
...3 RS06K810F03 RESISTOR 6.8K 1% SMD 0603 4 R107,108,110,111
...3 RS07K510F03 RESISTOR 7.5K 1% SMD 0603 4 R115,117,118,120
...3 RS08K210F03 RESISTOR 8.2K 1% SMD0603 4 R124,126,128,130
...3 SWDC11G Switch Rotational Encode 20Pul 2 ENC1,2
...3 SWEVQ11L05R Switch Tact 5mm 160g Horizonta 40 SW2~10,12,14~43
...3 TE10200502 5P CONNECTOR 1 (TE1)
...3 VRS10306010 Potentiometer Slide 10KB2 20X6 2 VR1,2
...3 XTM16000X6 Crystal 16MHZ 49US SMD Fundame 1 X1
..2 TWPC15C019B01 Spare PCB Assembly 1 42
..2 TWPC15C019C01 Mixer PCB Assembly 1 31
...3 AL2-71-0074 IC TL074 QUAD OPAMP 7 IC402,403,502,503,602,603,710
...3 AL2-72-0339 IC LM339 ANALOG COMP 4 IC802,803,805,806
...3 CN0720001004 Flat Cable 7Pin Pitch 2.0mm Single Row 1 TE501
...3 CS100J5003NPO CCAP SMD 10pF/50V 5% 0603 NPO 8 C401,402,501,502,601,602,701,702
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 14 C419,420,519,520,619,620,719~722,901,902,
907,908
...3 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 6 C414,416,514,516,614,616
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 59
C403,404,413,415,421~424,503,504,513,515,
521~524,603,604,613,615,621~624,703,704,7
18,723~727,732,733,801,802,805~810,903,90
4,909,910,915~927
...3 CS123K5003X7R CCAP SMD 0.012UF/50V 10% 0603 X7R 4 C417,418,617,618
...3 CS183K5003X7R CCAP SMD 0.018UF/50V 10% 0603 X7R 6 C408,410,508,510,608,610
...3 CS184K1603X7R CCAP SMD 0.18UF/16V 10% 0603 X7R 4 C407,409,607,609
...3 CS272K5003X7R CCAP SMD 2.7nF/50V 10% 0603 X7R 1 C717
...3 DIEN1N4148WSM Diode SMD 8 D710~713,801~804
...3 EC10550TS Capacitor Electrolytic 1uF/50V 4 C803,804,811,812
...3 EC10616TS Capacitor Electrolytic 10uF/16V 8 C405,406,505,506,605,606,705,706
...3 EC10625TL Capacitor Electrolytic low-lea 10uF/25V 1 C740
...3 EC10716TS Capacitor Electrolytic 100uF/16V 4 C728~731
...3 EC22616TS Capacitor Electrolytic 22uF/16V 14 C425,426,525,526,625,626,734,737,905,906,9
11~914
...3 EC22725T Capacitor Electrolytic 220uF/25V 1 C741
...3 EC33550TS Capacitor Electrolytic 3.3uF/50V 6 C411,412,511,512,611,612
...3 FCN1T1003001 FCN Down Touch ZIF SMD Pitch=1.0mm 1 FCN401
...3 ICBA4558F IC BA4558F 7 IC401,501,601,701,801,901,902
...3 ICNJM4556AM IC NJM4556AM 2 IC711,712
...3 LD-005HLV Red LED 8 LED901~908
...3 LDAPHK1608CGCK Liquid-emitting Diode Green SMD 6 LED803~805,810~812
...3 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 2 LED801,808

...3 LDLTST-C190KSKT Liquid-emitting Diode Amber SMD 2 LED802,809
...3 PT111048005 Fixed Base,LED 8 (LED901~908)
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 13 R740,805,806,813,821,901~903,924~926,929,
930
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603 6 R403,404,503,504,603,604
...3 RS002710F03 RESISTOR 27Ω1% SMD 0603 2 R817,825
...3 RS006810F03 RESISTOR 68Ω1% SMD 0603 8 R727~734
...3 RS010010F03 RESISTOR 100Ω1% SMD 0603 12 R437~442,703,704,744,745,810,811
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 22 R405,406,431,432,435,436,505,506,531,532,5
35,536,605,606,631,632,635,636,910~913
...3 RS015K10F03 RESISTOR 15K 1% SMD 0603 7 R401,402,501,502,601,602,725
...3 RS016K10F03 RESISTOR 16K 1% SMD 0603 2 R537,538
...3 RS01K310F03 RESISTOR 1.3K 1% SMD 0603 4 R716~719
...3 RS01K810F03 RESISTOR 1.8K 1% SMD 0603 4 R814,815,822,823
...3 RS020K10F03 RESISTOR 20K 1% SMD 0603 12 R701,702,904~909,920,921,927,928
...3 RS024010F03 RESISTOR 240Ω1% SMD 0603 16 R414,417,420,423,426,429,517,520,526,529,6
14,617,620,623,626,629
...3 RS024K10F03 RESISTOR 24K 1% SMD 0603 2 R801,802
...3 RS02K710F03 RESISTOR 2.7K 1% SMD 0603 18 R413,416,419,422,425,428,513,519,522,528,6
13,616,619,622,625,628,715,726
...3 RS033K10F03 RESISTOR 33K 1% SMD 0603 2 R742,743
...3 RS03K310F03 RESISTOR 3.3K 1% SMD 0603 1 R724
...3 RS043K10F03 RESISTOR 43K 1% SMD 0603 4 R916~919
...3 RS047K10F03 RESISTOR 47K 1% SMD 0603 3 R739,922,923
...3 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 6 R433,434,533,534,633,634
...3 RS051010F03 RESISTOR 510Ω1% SMD 0603 2 R816,824
...3 RS056K10F03 RESISTOR 56K 1% SMD 0603 10 R415,418,424,427,518,527,615,618,624,627
...3 RS05K110F03 RESISTOR 5.1K 1% SMD 0603 4 R720~723
...3 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 4 R735~738
...3 RS062K10F03 RESISTOR 62K 1% SMD 0603 6 R421,430,521,530,621,630
...3 RS068010F03 RESISTOR 680Ω1% SMD 0603 2 R807,809
...3 RS06K810F03 RESISTOR 6.8K 1% SMD 0603 4 R812,820,914,915
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 2 R803,804
...3 RS200K10F03 RESISTOR 200K 1% SMD 0603 12 R408,409,411,412,508,509,511,512,608,609,6
11,612
...3 RS270K10F03 RESISTOR 270K 1% SMD 0603 4 R407,410,607,610
...3 RS330K10F03 RESISTOR 330K 1% SMD 0603 1 R808
...3 RS560K10F03 RESISTOR 560K 1% SMD 0603 1 R741
...3 SWSFPC14MA01 Switch Push 2P2T Dual Row Lock 4 SW901~904
...3 SWSSFUB22-10K Switch Slide Single Row 180° 3 SW501,701,702
...3 TR2SA1037ASM TRANSISTOR 2SA1037AKR PNP 1 Q714
...3 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 4 Q710~713
...3 TRBC857B TRANSISTOR BC857B PNP 3 Q801~803
...3 VRR50301704 Potentiometer Rotary Volume Sh 11 VR402~404,502,504,602~604,710,711,901
...3 VRR50301705 Potentiometer Rotary Volume Sh 3 VR501,712,902
...3 VRR50301706 Potentiometer Rotary Volume Sh 2 VR401,601
...3 VRS50304527 Potentiometer Slide 50KA Trave 2 VR405,605
...3 VRS50306001 Potentiometer Slide 50K15A 600 1 VR701
...3 WR0620001004 Shielding Cable 6Pin Single Ro 1 CN503
..2 TWPC15C019D01 Cross Fader PCB Assembly 1 8
...3 TE622000701 7P CONNECTOR 1 (TE502)
...3 VRS50304528 Potentiomeper Slide 50K3BX4 45 1 VR506
0.1 TWPC15C03701 SERVO PCB 2 Assembly 1
..2 PC15C037 SERVO PCB 1
..2 TWPC15C037A01 Server PCB Assembly 2 41
...3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 2 C2,3
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 13 C1,6~10,12~17,20
...3 CS272K5003X7R CCAP SMD 2.7nF/50V 10% 0603 X7R 1 C4
...3 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 2 C18,19
...3 CS681J5003NPO CCAP SMD 680pF/50V 5% 0603 NPO 1 C11
...3 CS682K5003X7R CCAP SMD 6.8 nF/50V 10% 0603 X7R 1 C5
...3 EC10616TS Capacitor Electrolytic 10uF/16V 1 EC10
...3 EC10716TS Capacitor Electrolytic 100uF/16V 9 EC1~3,6~9,11,12

...3 EC22450TS Capacitor Electrolytic 0.22uF/50V 1 EC4
...3 EC33550TS Capacitor Electrolytic 3.3uF/50V 1 EC5
...3 FCN1R1001605 FCN UP Touch smd Pitch 1.0mm 1 FCN1
...3 FCN1T1003001 FCN Down Touch ZIF SMD Pitch=1.0mm 1 FCN2
...3 ICBA033FP IC BA033FP 1 IC2
...3 ICBA5968FP IC BA5968FP 1 IC1
...3 ICBU9543KV IC BU9543KV 1 IC3
...3 RS001410F03 RESISTOR 14Ω1% SMD 0603 1 R28
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 2 R15,27
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603 1 R30
...3 RS002010F03 RESISTOR 20Ω1% SMD 0603 1 R31
...3 RS002210F03 RESISTOR 22Ω1% SMD 0603 1 R3
...3 RS010010F03 RESISTOR 100Ω1% SMD 0603 1 R29
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 4 R2,9,10,11
...3 RS015010F03 RESISTOR 150Ω1% SMD 0603 6 R23~25,32~34
...3 RS022K10F03 RESISTOR 22K 1% SMD 0603 5 R13,18~21
...3 RS02K210F03 RESISTOR 2.2K 1% SMD 0603 1 R4
...3 RS02K710F03 RESISTOR 2.7K 1% SMD 0603 1 R1
...3 RS033K10F03 RESISTOR 33K 1% SMD 0603 2 R16,17
...3 RS03K310F03 RESISTOR 3.3K 1% SMD 0603 1 R5
...3 RS047010F03 RESISTOR 470Ω1% SMD 0603 2 R22,156
...3 RS04R710F03 RESISTOR 4.7Ω1% SMD 0603 2 R6,7
...3 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 1 R14
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 1 R12
...3 TE10200501 5P CONNECTOR 1 (TE2)
...3 TE10200602 6P CONNECTOR 1 (TE1)
...3 TR2SA1037ASM TRANSISTOR 2SA1037AKR PNP 1 Q1
...3 XTM16934X8 CRYSTAL 16.9344MHz S3225A Fund 1 X1
..2 TWPC15C037B01 Shielding PCB Assembly 1 40

1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
Check REV Description
Title:
Size A3 Number Revision
Date :
File Name:
Sheet of
Design By :
DATEDesignApproval
1 8
REV0
REV1
REV2
REV0_DATE
REV1_DATE
REV2_DATE
SCK
1D6 108
D3 105 D2 102
A17 99 A13 93
A8 84
ACI
28
A4 78
PB7
34
SDO0/PC11
4
SDO3/SDI2/PC8
7
SDO4/SDI1/PC7
10
FSR/PC1
13 GNDA 96
HCKT/PC5
16
GNDQ
19 GNDQ 90
PB11
22 GNDA 87
VCCS
25
GNDA 81
PB10
31
GNDA 75
TMS
142
TDO
139
D23
133
D18
124
D15
121
D14
118
D11
115
D7
109
PB1 42
AA2 51
BR 63
AA1 69
A0 72
TCK
141 TDI
140
D17
123 D16
122
D19
125
D20
128
D21
131
D13
117
D10
114
D8
110
D9
113
D12
116
SS
2
D4 106 D0 100 D5 107
A16 98
D1 101
A14 94 A10 88 A12 92 A11 89
ADO
27
PB8
33
TIO0
29
PB6
35
PB9
32
A6 82 A5 79 A2 76 A7 83 A3 77
PB3 40
PB2 41
PB0 43
CAS 52
BB 64
WR 67
AA0 70
RD 68
BG 71
TA 62
D22
132
HERQ
3
GNDS
9
SD02/SDI3/PC9
6SDO1/PC10 5
SDO5/SDI0/PC6
11
VCCS
8
VCCD 103
GNDD 104
VCCQL
18
PB12
21
SCKR/PC0
15
PB15
23
SCKT/PC3
14
HCKR/PC2
17
VCCQH
20
VCCQL 91
VCCQH 95
VCCA 86
PB13
30
GNDS
26
VCCA 80 VCCA 74
PB4 37
MODB/IRQB
136
GNDD
130
GNDQ
127
GNDD
112
GNDH 39
VCCP 45
PE6/SDO5_1/SDI0_1 48
GNDQ 54
VCCC 57
PE0/SCKR_1 60
GNDC 66
MODC/IRQC
135 MODD/IRQD
134
MOSI/HAO
143
MODA/IRQA
137
PE7/SD04_1/SDI1_1
138
VCCD
129
VCCQL
126
VCCD
111
VCCD
119
A15 97
PB5
36
VCCH 38
RESET 44
PCAP 46
GNDP 47
GNDC 58
VCCQL 56
EXTAL 55
PE1/FSR_1 59
PE3/SCK_1 53
FE4/FST_1 50
VCCC 65
A9 85 A1 73
FST/PC4
12
GNDD
120
MISO/SDA
144
PB14
24
PINIT/MMI 61
VCCQH 49
IC101
DSP56367
R134
0
SPI-CLK
R135 100
DSP-CS3
B-SERVO-SUBCLK
R115 10K
R136 100
B-SERVO-SUBDATA
DSP-PCMD1 DSP-PCMD2
DGND
R137 100
A-SERVO-SUBDATA
R138 100
A-SERVO-DOUT
DSP-LRCK
R158 100
A-SERVO-LRCK
DSP-BCK
A-SERVO-DCK
A-SERVO-SUBCLK A-SERVO-SUBSYQ
A-SERVO-WFCK
B-SERVO-SUBSYQ
B-SERVO-WFCK
OTG_RESET
OTG_CLK
R146 100
OTG_INSERT-A
OTG_DataErr
OTG_DataRdy
OTG_D7 OTG_D6 OTG_D5
OTG_D4
DSP 3.3V
DGND
OTG_D3
OTG_D2
OTG_D1
OTG_D0
+1.8V
C123 104
B-SERVO-DOUT
DSP-RDY3
DSP-INT3
DSP2-MCLK
B-SERVO-LRCK
B-SERVO-DCK
OTG_DataRdy
R128 10K
R126 10K
SPI-MOSI
SPI-MISO
1
2
3
4
5
6
7
8
9
10
11
12
13 14 15 16 17 18 19 20 21 22 23 24
25
26
27
28
29
30
31
32
33
34
35
36
37 38 39 40 41 42 43 44 45 46 47 48
ICET5126S
USB HOST Controller
U100
OTG_INSERT-A
C106
104
R127 100 OTG_RESET
C107
104
DSP 3.3V
C104 104
DSP 3.3V
OTG_D0 OTG_D1 OTG_D2 OTG_D3 OTG_D4 OTG_D5 OTG_D6
OTG_D7
C105
104
EC101
47uF/16V
DSP 3.3V
OTG_DataErr
OTG_CLK
OTG_DataRdy
DGND
X100
6MHz R117
1M
C101 104
R124 27
R123 27
R121 15K R122 15K
DSP 3.3V
+1.8V
C103
104
DGND
+1.8V
DSP 3.3V
R120 27
R119 27
DGND
R116 15K
R118 15K
OTG_INSERT-B
R130 10K
R131 10K
R129 10K
OTG_INSERT-B
C112 220P(NC)
R149 560
C129 104
DGND
DSP 3.3V
C110
104
C108
104
C111
104
C115
104
C117
104
C120
104
C128
104
C125
104
C126
104
C127
104
C122
104
C121
104
C119
104
C118
104
C113
104
C114
104
DGND
DSP 3.3V +1.8V
Vin
3
GND
1
Vout 2
IC100
AIC1117-18PY
DGND
DGND
DGND
DGND
NC20 DSP56367
DSP2-RST
C124
104
R155 10K
R156 10K
R150 10K
DGND
C116
104
C109 104
OTG_D4
OTG_D3
OTG_D2
OTG_D1
OTG_D0
OTG_D7
OTG_D6
OTG_D5
OTG_RESET
OTG_CLK
OTG_INSERT-A
OTG_DataErr
OTG_INSERT-B
R114 10K
R113 10K
R112 10K
R111 10K
R110 10K
R109 10K
R108 10K
R107 10K
R106 10K
R105 10K
R104 10K
R103 10K
DSP 3.3V
EC102
47uF/16V
R102 10K
R101 10K
R100 10K B-SERVO-SUBCLK
A-SERVO-SUBCLK
DSP2-RST
USB1_D-
USB1_D+
USB2_D-
DGND
EC100
470uF/16V
VDDUSB FS100
FSMSMD200 D+5V
DGND
EC103
10uF/16V
1
2
3
4
5
6
TE102
(NC)
Vbus 1
D- 2
D+ 3
GND 4
UGND
5
UGND
6
USB100 JK292336
1
2
3
4
5
TE100
TO USB
R140
180
R132 100
R133 100
R147
0
R139
0
R141 100 R148
0
R157
0
R151 0
R152 0
R153 0
R154 0
PC15C018
2015.12.07
100
USB2_D+
DGND
D-
D+
C100
33p
C102
22p R125 470
PIC10001 PIC10002
COC100
PIC10101 PIC10102
COC101
PIC10201 PIC10202
COC102
PIC10301
PIC10302
COC103
PIC10401 PIC10402
COC104
PIC10501
PIC10502
COC105
PIC10601
PIC10602
COC106
PIC10701
PIC10702
COC107
PIC10801 PIC10802
COC108
PIC10901 PIC10902
COC109
PIC11001 PIC11002
COC110
PIC11101 PIC11102
COC111
PIC11201 PIC11202
COC112
PIC11301
PIC11302
COC113
PIC11401
PIC11402
COC114
PIC11501
PIC11502
COC115
PIC11601
PIC11602
COC116
PIC11701
PIC11702
COC117
PIC11801
PIC11802
COC118
PIC11901
PIC11902
COC119
PIC12001
PIC12002
COC120
PIC12101
PIC12102
COC121
PIC12201
PIC12202
COC122
PIC12301 PIC12302
COC123
PIC12401 PIC12402
COC124
PIC12501 PIC12502
COC125
PIC12601 PIC12602
COC126
PIC12701 PIC12702
COC127
PIC12801 PIC12802
COC128
PIC12901 PIC12902
COC129
PIEC10001
PIEC10002
COEC100
PIEC10101
PIEC10102
COEC101
PIEC10201
PIEC10202
COEC102
PIEC10301
PIEC10302
COEC103
PIFS10001 PIFS10002
COFS100
PIIC10001
PIIC10002PIIC10003
COIC100
PIIC10101 PIIC10102 PIIC10103 PIIC10104 PIIC10105 PIIC10106 PIIC10107 PIIC10108 PIIC10109 PIIC101010 PIIC101011 PIIC101012 PIIC101013 PIIC101014 PIIC101015 PIIC101016 PIIC101017 PIIC101018 PIIC101019 PIIC101020 PIIC101021 PIIC101022 PIIC101023 PIIC101024 PIIC101025 PIIC101026 PIIC101027 PIIC101028 PIIC101029 PIIC101030 PIIC101031 PIIC101032 PIIC101033 PIIC101034 PIIC101035 PIIC101036
PIIC101037
PIIC101038
PIIC101039
PIIC101040
PIIC101041
PIIC101042
PIIC101043
PIIC101044
PIIC101045
PIIC101046
PIIC101047
PIIC101048
PIIC101049
PIIC101050
PIIC101051
PIIC101052
PIIC101053
PIIC101054
PIIC101055
PIIC101056
PIIC101057
PIIC101058
PIIC101059
PIIC101060
PIIC101061
PIIC101062
PIIC101063
PIIC101064
PIIC101065
PIIC101066
PIIC101067
PIIC101068
PIIC101069
PIIC101070
PIIC101071
PIIC101072
PIIC101073PIIC101074PIIC101075PIIC101076PIIC101077PIIC101078PIIC101079PIIC101080PIIC101081PIIC101082 PIIC101083 PIIC101084PIIC101085PIIC101086PIIC101087PIIC101088PIIC101089 PIIC101090 PIIC101091PIIC101092PIIC101093PIIC101094PIIC101095PIIC101096PIIC101097PIIC101098PIIC101099 PIIC1010100 PIIC1010101 PIIC1010102PIIC1010103PIIC1010104PIIC1010105PIIC1010106PIIC1010107 PIIC1010108
PIIC1010109
PIIC1010110
PIIC1010111
PIIC1010112
PIIC1010113
PIIC1010114
PIIC1010115
PIIC1010116
PIIC1010117
PIIC1010118
PIIC1010119
PIIC1010120
PIIC1010121
PIIC1010122
PIIC1010123
PIIC1010124
PIIC1010125
PIIC1010126
PIIC1010127
PIIC1010128
PIIC1010129
PIIC1010130
PIIC1010131
PIIC1010132
PIIC1010133
PIIC1010134
PIIC1010135
PIIC1010136
PIIC1010137
PIIC1010138
PIIC1010139
PIIC1010140
PIIC1010141
PIIC1010142
PIIC1010143
PIIC1010144
COIC101
PIR10001PIR10002
COR100
PIR10101PIR10102
COR101
PIR10201PIR10202
COR102
PIR10301PIR10302
COR103
PIR10401PIR10402
COR104
PIR10501PIR10502
COR105
PIR10601PIR10602
COR106
PIR10701PIR10702
COR107
PIR10801PIR10802
COR108
PIR10901PIR10902
COR109
PIR11001PIR11002
COR110
PIR11101PIR11102
COR111
PIR11201PIR11202
COR112
PIR11301PIR11302
COR113
PIR11401PIR11402
COR114
PIR11501PIR11502
COR115
PIR11601
PIR11602
COR116
PIR11701
PIR11702
COR117
PIR11801
PIR11802
COR118
PIR11901PIR11902
COR119
PIR12001PIR12002
COR120
PIR12101
PIR12102
COR121
PIR12201
PIR12202
COR122
PIR12301 PIR12302
COR123
PIR12401 PIR12402
COR124
PIR12501PIR12502
COR125
PIR12601 PIR12602
COR126
PIR12701 PIR12702
COR127
PIR12801PIR12802
COR128
PIR12901 PIR12902
COR129
PIR13001 PIR13002
COR130
PIR13101 PIR13102
COR131
PIR13201 PIR13202
COR132
PIR13301 PIR13302
COR133
PIR13401
PIR13402
COR134
PIR13501
PIR13502
COR135
PIR13601
PIR13602
COR136
PIR13701
PIR13702
COR137
PIR13801
PIR13802
COR138
PIR13901
PIR13902
COR139
PIR14001 PIR14002
COR140
PIR14101
PIR14102
COR141
PIR14601
PIR14602
COR146
PIR14701
PIR14702
COR147
PIR14801
PIR14802
COR148
PIR14901 PIR14902
COR149
PIR15001 PIR15002
COR150
PIR15101 PIR15102
COR151
PIR15201 PIR15202
COR152
PIR15301 PIR15302
COR153
PIR15401 PIR15402
COR154
PIR15501 PIR15502
COR155
PIR15601 PIR15602
COR156
PIR15701
PIR15702
COR157
PIR15801
PIR15802
COR158
PITE10001
PITE10002
PITE10003
PITE10004
PITE10005
COTE100
PITE10201
PITE10202
PITE10203
PITE10204
PITE10205
PITE10206
COTE102
PIU10001
PIU10002
PIU10003
PIU10004
PIU10005
PIU10006
PIU10007
PIU10008
PIU10009
PIU100010
PIU100011
PIU100012
PIU100013 PIU100014 PIU100015 PIU100016 PIU100017 PIU100018 PIU100019 PIU100020 PIU100021 PIU100022 PIU100023 PIU100024
PIU100025
PIU100026
PIU100027
PIU100028
PIU100029
PIU100030
PIU100031
PIU100032
PIU100033
PIU100034
PIU100035
PIU100036
PIU100037 PIU100038PIU100039PIU100040 PIU100041 PIU100042PIU100043 PIU100044 PIU100045PIU100046PIU100047 PIU100048
COU100
PIUSB10001
PIUSB10002
PIUSB10003
PIUSB10004
PIUSB10005
PIUSB10006
COUSB100
PIX10001
PIX10002
COX100
POA0SERVO0DCK POA0SERVO0DOUT POA0SERVO0LRCK
POA0SERVO0SUBCLK POA0SERVO0SUBDATA POA0SERVO0SUBSYQ POA0SERVO0WFCK
POB0SERVO0DCK
POB0SERVO0DOUT
POB0SERVO0LRCK
POB0SERVO0SUBCLK POB0SERVO0SUBDATA POB0SERVO0SUBSYQ POB0SERVO0WFCK
PODSP20MCLK
PODSP20RST
PODSP0BCK
PODSP0CS3
PODSP0INT3
PODSP0LRCK
PODSP0PCMD1 PODSP0PCMD2
PODSP0RDY3
POOTG0CLK
POOTG0D0
POOTG0D1
POOTG0D2
POOTG0D3
POOTG0D4
POOTG0D5 POOTG0D6POOTG0D7
POOTG0DATAERR POOTG0DATARDY
POOTG0INSERT0A POOTG0INSERT0B
POOTG0RESET
POSPI0CLK
POSPI0MISO
POSPI0MOSI
POUSB10D0
POUSB20D0

1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
Check REV Description
Title:
Size
A2
Number Revision
Date :
File Name:
Sheet of
Design By :
DATEDesignApproval
2 8
R243 1 0K R245 1 0K
C202 0.1uF
C220 0.1uF
C221 0.1uF
C223 0.1uF
C224 0.1uF
C222 0.1uF
R250 10K
C226 0.01uF
C228 0.01uF
R253 2 K
C232 0.1uF
C234 0.1uF
C235 0.1uF
C236 0.1uF
EC205
10uF/16V
R210
10K
DSP 3.3V
DSP 3.3V
DSP 3.3V
R224
10K
C203 0.1uF
R215 220
C201 0.1uF
R244 1 0K R247 1 0K
DSP 3.3V
R248
1M
C215 22pF
C216 22pF
C230
0.1uF
C227 0.1uF
C229 0.1uF
DSP 3.3V
C237
0.01uF
C233 0.1uF
DSP 3.3V
C239
0.01uF
C240
0.01uF
C241
0.01uF
C244
0.01uF
C243 0.1uF
C245 0.1uF
R212
10K
R201
10K
C205
0.1uF
R235 2 20
R233 10K
C207 0 .1uF C208 0 .1uF C20 9 0.1uF
C211 0 .1uF C212 0 .1uF
C213 0.1uF C210 0.1uF
C218 0 .1uF C219 0.1uF
POK
3FB 6
VIN
1VOUT 8
VIN
2
EN
4GND 5
VOUT 7
IC205
AP7165
DSP 3.3V
R226 10K
Serial (SPI) Flash Memory
EC200
10uF/16V
C200
0.1uF
DSP 3.3V
C204
0.1uF
X200
11.2896MHz
DSP 3.3V
C238
0.01uF
C242
0.01uF
WP
3SCLK 6
CS
1VCC 8
GND
4
DO
2
DIN 5
Reset 7
IC200
A25L080
C206 0.1uF
C214 0.1uF
C217 0.1uF
KEEP (LSYNC_OUT -> LSYNC_IN)
*. Q5 = A10 ,A13 NO USE LACTH.
DSP Core Power Regulator
(DSPB56724AG-1.2V)
AP7165 (Max 600mA)
FB : Vout = 0.8v(1+R78/R79)
1.2v = 0.8v(1+1K/2K)
Q2
6
D2
7
GND
10
Q1
5
D3
8
Q3
9
OE
1
Q0
2
LE 11
Q4 12
D4 13
D5 14
Q5 15
Q6 16
Q7 19
D0
3
D1
4D6 17
D7 18
VCC 20
IC203
74HC373A
Q2
6
D2
7
GND
10
Q1
5
D3
8
Q3
9
OE
1
Q0
2
LE 11
Q4 12
D4 13
D5 14
Q5 15
Q6 16
Q7 19
D0
3
D1
4D6 17
D7 18
VCC 20
IC202
74HC373A
IO_VDD 107
PINT/NMI 105
TDI 103
TMS 101
CORE_VDD 95
SCKR/PC0 93
SCKT/PC3 91
SDO3/SDI2/PC8 87 SDO5/SDI0/PC6 85
SPDIFIN1 83
IO_VDD 81
XTAL 79
PLLD_GND 77 PLLA_GND 75
PLLP_VDD 73
SDO3_1/SDI2_1/PE8 99 SDO5_1/SDI0_1/PE6 97
HCKT/STCLK/PC5 89
MODA0/IRQA
143
MODC0/PLOCK
141
FSR_3/PE1_1
139
FST_3/PE4_1
135
IO_GND
133
CORE_GND
131
MODA1/IRQC
129
MODC1/NMI
127
SS/HA2
117
SCK/SCL
115
MISO/SDA
113
RESET
111
CORD_VDD
109
CORE_VDD
1
SCAN
144
MODD0/PG1
140
MODB0/IRQB
142
MODB1/IRQD
128
CORE_VDD
130
IO_VDD
132
MODD1/PG2
126
SS_1/HA2_1
112
MOSI/HA0
114
HREQ/PH4
116
IO_GND 108
CORD_GND
110
LCS0
4
LCS1
5
LCS2
6
LCS3
7
LCS4
8
LCS5
9
TCK 102 TDO 104
WDT 106
IO_VDD
12
IO_GND
13
CORD_VDD
14
CODE_GND
15
LWE
16
LOE
17 HCKR/PC2 92
FSR/PC1 94
CORD_GND 96
LCKE
20
LCLK
21
LBCTL
22
LSDWE
23
LSDCAS
24
LGTA
25 SPDIFOUT1 84
FST/PC4 90
SDO4/SDI1/PC7 86 SDO2/SDI3/PC9 88
LA2
28
IO_VDD
29
IO_GND
30
PLLP1_VDD
32
PLLP1_GND
31
PLLD1_GND
33 PLLD_VDD 76
PLLD_GND 78
EXTAL 80
IO_GND 82
PLLA1_VDD
36
LSYNC_IN 37
LAD22 40
LAD21 41
LAD20 42
LAD19 43
LAD18 44
LAD17 45
IO_VDD 48
IO_GND 49
LAD16 50
LAD15 51
LAD14 52
LAD13 53
LAD10 56
LAD9 57
IO_VDD 58
IO_GND 59
CORE_VDD 60
CORE_GND 61
LAD6 64
LAD5 65
LAD4 66
LAD3 67
LAD2 68
LAD1 69
IO_VDD 72
PLLA_VDD 74
SDO2_1/SDI3_1/PE9 100 SDO4_1/SDI1_1/PE7 98
LSYNC_OUT 38
LAD23 39
CORE_VDD 46
CORD_GND 47
LAD12 54
LAD11 55
LAD8 62
LAD7 63
LAD0 70
IO_GND 71
CORE_GND
2
LALE
3
LCS6
10
LCS7
11
LGPL5
18
LSDA10
19
LA0
26
LA1
27
PLLD1_VDD
34
PLLA1_GND
35
HCKR_3/PE2_1
137
SDO2_2/SDI3_2/PC9_1
125
SDO4_2/SDI1_2/PC7_1
123
SDO2_3/SDI3_3/PE9_1
121
SDO4_3/SDI1_3/PE7_1
119
SCKT_3/PE3_1
136
SCKR_3/PE0_1
138
HCKT_3/PE5_1/STCLK
134
SDO3_3/SDI2_3_PE8_1
120
SDO5_2/SDI0_2/PC6_1
122
SDO3_2/SDI2_2/PC8_1
124
SDO5_3/SDI0_3/PE6_1
118
IC201
DSP56724
A3
26
A1
24
A10/AP
22
BA0
20
RAS
18
WE
16
VDD
14
VSSQ
12
DQ5
10
DQ4
8
VSSQ
6
DQ1
4
DQ0
2
A4 29
A6 31
A8 33
A11 35
CKE 37
UDQM 39
VSS 41
VDDQ 43
DQ10 45
DQ11 47
VDDQ 49
DQ14 51
DQ15 53
VDD
27
A2
25
A0
23
BA1
21
CS
19
CAS
17
LDQM
15
DQ7
13
DQ6
11
VDDQ
9
DQ3
7
DQ2
5
VDDQ
3
VDD
1
VSS 28
A5 30
A7 32
A9 34
NC 36
CLK 38
NC/RFU 40
DQ8 42
DQ9 44
VSSQ 46
DQ12 48
DQ13 50
VSSQ 52
VSS 54
IC206
K4S281632I
A0
A0
A1
A1
A11
A11
A12
A12
A14
A14
A15
A15
A2
A2
A3
A3
A4
A4
A5
A5
A6
A6
A7
A7
A8
A8
A9
A9
HREQ/PH4
LAD1
LAD1
LAD10
LAD10 LAD11
LAD11
LAD11
LAD12
LAD12
LAD12
LAD13
LAD13
LAD14
LAD14
LAD14
LAD15
LAD15
LAD15
LAD16
LAD16
LAD17
LAD17
LAD18
LAD18
LAD19
LAD19
LAD2
LAD20
LAD20
LAD21
LAD21
LAD22
LAD22
LAD23
LAD23
LAD3
LAD3 LAD4
LAD4
LAD5
LAD5
LAD6
LAD6
LAD7
LAD7
LAD8
LAD8
LAD8
LAD9
LAD9
LAD9
LALE
LALE
LALE
LCKE
LCKE LCLK
LCLK
LCS7
LCS7
LSDA10
LSDA10
LSDCAS
LSDCAS
LSDDQM
LSDDQM
LSDDQM
LSDRAS
LSDRAS
LSDWE
LSDWE
MODA0
MODA1
MODB0
MODB1
MODC0
MODC1
MODD0
MODD1
SPI-CL K
SPI-MISO
SPI-MOSI
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND DGND
DGND
DGND
DGND
Core Power
Core Power
LAD2
LAD0
LAD0
LAD[0..23]
LAD[0..23]
DSP-RST
TO MICON PIN45 (DSP RST)
DSP-CS1
TO IC301(MCU) PIN38 (TO DSP CS1)
SPI- MISO
TO IC304(74LVC3G14) PIN3 (SPI-MISO)
SPI-MOSITO IC301(MCU) PIN41 (SPI-MOSI)
SPI-CL K
DSP-CS2TO IC301(MCU) PIN39 (TO DSP CS2)
TO IC301(MCU) PIN42 (SPI-CLK)
De-Emphasis2TO DA1191 PIN12 (DM)
DAC-DIN2
TO DA1191 PIN2 (DIN)
TO SERVO BU9543KV PIN23(SUBDATA)
DSP-PCMD2TO SERVO BU9543KV PIN24(SUBCK)
JOG-A2
JOG-B2
DAC-SCK2
TO DA1191 PIN14 (SCKIN)
DAC-LRCK2TO DA1191 PIN1 (LRCKIN)
DAC-BCKIN2TO DA1191 PIN3 (BCKIN)
DSP-INT2TO IC303(74LVC3G14)PIN6
DSP-BCK
DSP-LRCK
From DSP56367 PIN14
From DSP56367 PIN12
DSP-RDY2TO MICON PIN44 (DSP READY 2)
DSP-RDY1 TO MICON PIN43 (DSP READY1)
De-Emphasis1 TO DA1191 PIN12 (DM)
DAC-DIN1 TO DA1191 PIN2 (DIN)
DAC-SCK1 TO DA1191 PIN14 (SCKIN)
DAC-LRCK1 TO DA1191 PIN1 (LRCKIN)
DAC-BCKIN1
TO IC303(74LVC3G14)PIN3
DSP-INT1
TO DA1191 PIN3 (BCKIN)
TO DSP56367 PIN14
TO DSP56367 PIN12
JOG-A1
JOG-B1
C225
0.1uF C231
0.1uF
O
G
I
IC204
BA033FP
DGND
DGND
R246
100
DSP 3.3V
R209 10K
DGND
R208 10K
DSP 3.3V
R207 10K
R206 10K
R205 10K
R204 10K
R203 10K
R202 10K
DGND
DSP 3.3V
DSP-BCK
DSP-LRCK
DSP-PCMD1 TO DSP56367 PIN7
DSP-CS3 TO DSP56367 PIN2
R234 2 20
R214 220
HREQ/PH4
DSP2-RST
DSP2-MCLK
TMS
TCK
TDI
TDO
R211
10K
DSP 3.3V
R231 150
R229 150
R228 150
R227 150
R242 1 50 R241 1 50 R240 1 50 R239 1 50
1
2
3
4
5
6
TE201
(NC)
D+5V
NC20 DSP56724
2015.12.07
PC15C018
R200
100
R219 100
R220 100
R221 100
R230
100
wire length equal ot (LCLK->CLK) +(DQ->LAD)
10uF
C246
EC202
47uF/16V
EC204
47uF/16V
EC203
47uF/16V EC206
10uF/16V
R223 100
R225 100
R222 100
R213 100
R216 100 R217 100
R218 100
R252 1K
R251 100K
LSYNC
200
C130
15p
PIC13001 PIC13002
COC130
PIC20001 PIC20002
COC200
PIC20101 PIC20102
COC201
PIC20201 PIC20202
COC202
PIC20301 PIC20302
COC203
PIC20401
PIC20402
COC204
PIC20501
PIC20502
COC205
PIC20601
PIC20602
COC206
PIC20701
PIC20702
COC207
PIC20801
PIC20802
COC208
PIC20901
PIC20902
COC209
PIC21001
PIC21002
COC210
PIC21101
PIC21102
COC211
PIC21201
PIC21202
COC212
PIC21301
PIC21302
COC213
PIC21401
PIC21402
COC214
PIC21501PIC21502
COC215
PIC21601PIC21602
COC216
PIC21701
PIC21702
COC217
PIC21801
PIC21802
COC218
PIC21901
PIC21902
COC219
PIC22001PIC22002
COC220
PIC22101PIC22102
COC221
PIC22201PIC22202
COC222
PIC22301PIC22302
COC223
PIC22401PIC22402
COC224
PIC22501
PIC22502
COC225
PIC22601PIC22602
COC226
PIC22701PIC22702
COC227
PIC22801PIC22802
COC228
PIC22901PIC22902
COC229
PIC23001
PIC23002
COC230
PIC23101
PIC23102
COC231
PIC23201PIC23202
COC232
PIC23301PIC23302
COC233
PIC23401PIC23402
COC234
PIC23501PIC23502
COC235
PIC23601PIC23602
COC236
PIC23701
PIC23702
COC237
PIC23801
PIC23802
COC238
PIC23901
PIC23902
COC239
PIC24001
PIC24002
COC240
PIC24101
PIC24102
COC241
PIC24201
PIC24202
COC242
PIC24301 PIC24302
COC243
PIC24401
PIC24402
COC244
PIC24501 PIC24502
COC245
PIC24601
PIC24602
COC246
PIEC20001
PIEC20002
COEC200
PIEC20201
PIEC20202
COEC202
PIEC20301
PIEC20302
COEC203
PIEC20401
PIEC20402
COEC204
PIEC20501PIEC20502
COEC205
PIEC20601
PIEC20602
COEC206
PIIC20001
PIIC20002
PIIC20003
PIIC20004 PIIC20005
PIIC20006
PIIC20007
PIIC20008
COIC200
PIIC20101 PIIC20102 PIIC20103 PIIC20104 PIIC20105 PIIC20106 PIIC20107 PIIC20108 PIIC20109 PIIC201010 PIIC201011 PIIC201012 PIIC201013 PIIC201014 PIIC201015 PIIC201016 PIIC201017 PIIC201018 PIIC201019 PIIC201020 PIIC201021 PIIC201022 PIIC201023 PIIC201024 PIIC201025 PIIC201026 PIIC201027 PIIC201028 PIIC201029 PIIC201030 PIIC201031 PIIC201032 PIIC201033 PIIC201034 PIIC201035 PIIC201036
PIIC201037
PIIC201038
PIIC201039
PIIC201040
PIIC201041
PIIC201042
PIIC201043
PIIC201044
PIIC201045
PIIC201046
PIIC201047
PIIC201048
PIIC201049
PIIC201050
PIIC201051
PIIC201052
PIIC201053
PIIC201054
PIIC201055
PIIC201056
PIIC201057
PIIC201058
PIIC201059
PIIC201060
PIIC201061
PIIC201062
PIIC201063
PIIC201064
PIIC201065
PIIC201066
PIIC201067
PIIC201068
PIIC201069
PIIC201070
PIIC201071
PIIC201072
PIIC201073PIIC201074PIIC201075 PIIC201076 PIIC201077PIIC201078PIIC201079PIIC201080 PIIC201081 PIIC201082 PIIC201083 PIIC201084 PIIC201085 PIIC201086PIIC201087PIIC201088PIIC201089PIIC201090PIIC201091PIIC201092 PIIC201093 PIIC201094 PIIC201095 PIIC201096 PIIC201097 PIIC201098PIIC201099 PIIC2010100PIIC2010101 PIIC2010102 PIIC2010103PIIC2010104PIIC2010105PIIC2010106PIIC2010107PIIC2010108
PIIC2010109
PIIC2010110
PIIC2010111
PIIC2010112
PIIC2010113
PIIC2010114
PIIC2010115
PIIC2010116
PIIC2010117
PIIC2010118
PIIC2010119
PIIC2010120
PIIC2010121
PIIC2010122
PIIC2010123
PIIC2010124
PIIC2010125
PIIC2010126
PIIC2010127
PIIC2010128
PIIC2010129
PIIC2010130
PIIC2010131
PIIC2010132
PIIC2010133
PIIC2010134
PIIC2010135
PIIC2010136
PIIC2010137
PIIC2010138
PIIC2010139
PIIC2010140
PIIC2010141
PIIC2010142
PIIC2010143
PIIC2010144
COIC201
PIIC20201
PIIC20202
PIIC20203
PIIC20204
PIIC20205
PIIC20206
PIIC20207
PIIC20208
PIIC20209
PIIC202010 PIIC202011
PIIC202012
PIIC202013
PIIC202014
PIIC202015
PIIC202016
PIIC202017
PIIC202018
PIIC202019
PIIC202020
COIC202
PIIC20301
PIIC20302
PIIC20303
PIIC20304
PIIC20305
PIIC20306
PIIC20307
PIIC20308
PIIC20309
PIIC203010 PIIC203011
PIIC203012
PIIC203013
PIIC203014
PIIC203015
PIIC203016
PIIC203017
PIIC203018
PIIC203019
PIIC203020
COIC203
PIIC20401
PIIC20402
PIIC20403
COIC204
PIIC20501
PIIC20502
PIIC20503
PIIC20504 PIIC20505
PIIC20506
PIIC20507
PIIC20508
COIC205
PIIC20601
PIIC20602
PIIC20603
PIIC20604
PIIC20605
PIIC20606
PIIC20607
PIIC20608
PIIC20609
PIIC206010
PIIC206011
PIIC206012
PIIC206013
PIIC206014
PIIC206015
PIIC206016
PIIC206017
PIIC206018
PIIC206019
PIIC206020
PIIC206021
PIIC206022
PIIC206023
PIIC206024
PIIC206025
PIIC206026
PIIC206027 PIIC206028
PIIC206029
PIIC206030
PIIC206031
PIIC206032
PIIC206033
PIIC206034
PIIC206035
PIIC206036
PIIC206037
PIIC206038
PIIC206039
PIIC206040
PIIC206041
PIIC206042
PIIC206043
PIIC206044
PIIC206045
PIIC206046
PIIC206047
PIIC206048
PIIC206049
PIIC206050
PIIC206051
PIIC206052
PIIC206053
PIIC206054
COIC206
PIR20001 PIR20002
COR200
PIR20101
PIR20102
COR201
PIR20201PIR20202
COR202
PIR20301PIR20302
COR203
PIR20401PIR20402
COR204
PIR20501PIR20502
COR205
PIR20601 PIR20602
COR206
PIR20701 PIR20702
COR207
PIR20801 PIR20802
COR208
PIR20901 PIR20902
COR209
PIR21001 PIR21002
COR210
PIR21101
PIR21102
COR211
PIR21201
PIR21202
COR212
PIR21301
PIR21302
COR213
PIR21401PIR21402
COR214
PIR21501PIR21502
COR215
PIR21601
PIR21602
COR216
PIR21701
PIR21702
COR217
PIR21801 PIR21802
COR218
PIR21901 PIR21902
COR219
PIR22001 PIR22002
COR220
PIR22101 PIR22102
COR221
PIR22201 PIR22202
COR222
PIR22301 PIR22302
COR223
PIR22401 PIR22402
COR224
PIR22501 PIR22502
COR225
PIR22601 PIR22602
COR226
PIR22701PIR22702
COR227
PIR22801 PIR22802
COR228
PIR22901PIR22902
COR229
PIR23001PIR23002
COR230
PIR23101 PIR23102
COR231
PIR23301
PIR23302
COR233
PIR23401
PIR23402
COR234
PIR23501
PIR23502
COR235
PIR23901
PIR23902
COR239
PIR24001
PIR24002
COR240 PIR24101
PIR24102
COR241
PIR24201
PIR24202
COR242
PIR24301
PIR24302
COR243
PIR24401
PIR24402
COR244
PIR24501
PIR24502
COR245
PIR24601 PIR24602
COR246
PIR24701
PIR24702
COR247
PIR24801
PIR24802
COR248
PIR25001 PIR25002
COR250
PIR25101 PIR25102
COR251
PIR25201
PIR25202
COR252
PIR25301PIR25302
COR253
PITE20101
PITE20102
PITE20103
PITE20104
PITE20105
PITE20106
COTE201
PIX20001
PIX20002
COX200
POA0
POA1
POA2
POA3 POA4
POA5
POA6
POA7
POA8
POA9
POA11
POA12
POA14
POA15
PODAC0BCKIN1
PODAC0BCKIN2
PODAC0DIN1
PODAC0DIN2
PODAC0LRCK1
PODAC0LRCK2
PODAC0SCK1
PODAC0SCK2
PODE0EMPHASIS1
PODE0EMPHASIS2
PODSP20MCLK
PODSP20RST
PODSP0BCK
PODSP0CS1
PODSP0CS2
PODSP0CS3
PODSP0INT1
PODSP0INT2
PODSP0LRCK
PODSP0PCMD1
PODSP0PCMD2
PODSP0RDY1
PODSP0RDY2
PODSP0RST
POHREQ0PH4
POJOG0A1
POJOG0A2
POJOG0B1
POJOG0B2
POLAD0POLAD1POLAD2POLAD3POLAD4POLAD5POLAD6POLAD7POLAD8POLAD9 POLAD10POLAD11POLAD12POLAD13POLAD14POLAD15POLAD16POLAD17POLAD18POLAD19POLAD20POLAD21POLAD22POLAD23 POLAD0000230
POLALE
POLCKE
POLCLK
POLCS7
POLSDA10
POLSDCAS
POLSDDQM
POLSDRAS
POLSDWE
POLSYNC POMODA0
POMODA1
POMODB0
POMODB1
POMODC0
POMODC1
POMODD0
POMODD1
POSPI0CLK
POSPI0MISO
POSPI0MOSI
