Numatics SentronicD User manual

SentronicD
Digital Electronic Pressure Regulator
Installation Manual

CAUTION! Dangerous operating conditions may occur when using the programming interface on the valve as the valve may possibly
not react to the analog setpoint any more.
Provide for protection against uncontrolled movement of equipment when putting the valve into operation and before making any
modifications to the valve settings.
NOTICE
The information in this manual is subject to change without notice.
In no event shall Numatics be liable for technical or editorial errors or omissions. Neither is any liability assumed for accidental or consequential
damages arising out of or in connection with the supply or use of the information contained herein.
THIS MANUAL CONTAINS INFORMATION PROTECTED BY COPYRIGHT. NO PART OF THIS DOCUMENT MAY BE PHOTOCOPIED OR REPRODUCED
IN ANY FORM OR MANNER WHATSOEVER WITHOUT PRIOR WRITTEN PERMISSION FROM NUMATICS.
ESD
This product complies with the essential requirements of the EMC Directive 89/336/EEC and its amendments. It is CE-approved. A separate Declaration
of Conformity is available on request.
A separate Declaration of Incorporation relating to the EU Directive 89/392/EEC Annex II B is available on request. Please provide ordering code and
serial numbers of products concerned.
DECLARATION OF INCORPORATION
according to Machinery Directive 89/392/EEC, Annex II B
We herewith declare that the version of the product described in this installation manual is intended to be incorporated into or assembled with other machinery and
that it must not be put into service until the machinery into which it is to be incorporated has been declared in conformity with the provisions of Council Directive
89/392/EEC, Annex IIB.
Handling, assembly and putting into service and all settings and adjustments must be done by qualified, authorised personnel only.
This product contains electronic components sensitive to electrostatic discharge.
An electrostatic discharge generated by a person or object coming in contact
with the electrical components can damage or destroy the product.
To avoid the risk of electrostatic discharge, please observe the handling
precautions and recommendations contained in standard EN 100015-1. Do not
connect or disconnect the device while it is energised.
CAUTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC SENSITIVE DEVICES
!
1
1.1
1.2
1.3
1.4
2
3
4
5
6
7
7.1
7.2
8
9
10
Table of Contents
SentronicD
Description 3
How To Order 3
Operating Elements 4
Manual Pressure Regulation 4
Operating Modes 4
Electrical Connection 5
Analog Setpoint - Outlet Pressure 6
Pneumatic Connection 7
Factory Settings for a Standard Valve 7
Field-programmable settings 8
Technical characteristics 8
Fluid characteristics 8
Specifications 8
Accessories 9
Maintenance and care 9
Dimensions and weights 10

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
3
SentronicD
Installation
Manual
1. Description
SentronicDis a new generation of electronic pressure regulators designed on the basis of an enhanced digital control.
SentronicDstands for:
Digital communication and control
Display (incorporated)
Direct operated valve
Dynamic behaviour (high speed)
Digital control offers many advantages during installation and start-up of the SentronicDvalve and extended possibilities
to adapt it to various applications.
The four following standard versions are available:
• With display and pushbuttons: Pressure display, manual pressure setting and diagnostic LEDs.
• Without display and pushbuttons: The economic solution.
• Nominal diameter DN 4mm: with a flow rate of 470 l/min (SRA).
• Nominal diameter DN 8mm: with a flow rate of 1300 l/min (SRA).
Various pneumatic connections: integral connections, back panel connection and subbase mount.
• All pressure and exhaust ports are the same size, which allows for short response times when the pressure is
increased or decreased.
• Digital pressure control in a closed loop: An internal pressure sensor compares the setpoint at the inlet to the outlet
pressure. The outlet pressure is adjusted in real time.
• The control parameters can be changed with the additional software called DaS. The DaS program (Data
Acquisition Software) ensures that all parameters used by the valve can be changed. This flexibility allows the valve
to be adapted to the application and enables the optimization of its response time, overshoot and precision.
• After having set the optimum parameters you can save them in a project file for your personal use or send them to
our Product Support for future production.
1.1 How to Order
608 6 C 0 1 1 1
Nominal diameter
608 = DN 4mm
609 = DN 8mm
Version (ports), body
0 = G 1/8 (DN4), G 1/4 (DN 8)
1 = G 1/4 (DN 4), G 3/8 (DN 8)
2 = Manifold version1)
G 1/8 (DN 4), G 1/4 ( DN 8)
6 = NPT 1/4 (DN 4), NPT 3/8 (DN 8)
Display
0 = without display
1 = with display
Options
A00 = Dual loop control
211 = Oxygen clean
Digital output
1 = Pressure switch output
PNP ± 5 %
Feedback
1 = Feedback output 0 -10 V
2 = Feedback output 0 - 20 mA
3 = Feedback output 4 - 20 mA
4 = Feedback input 0 ... 10 Volt2)
5 = Feedback input 0 ... 20 mA2)
6 = Feedback input 4 ... 20 mA2)
Command signal
0 = 0 - 10 V
1 = 0 - 20 mA
2 = 4 - 20 mA
1 = 0 - 10 bar
2 = 0 - 12 bar
3 = 0 - 3 bar
4 = 0 - 1 bar
5 = 0 - 15 bar
6 = 0 - 6 bar
Pressure range
A = 0 - 50 psi
B = 0 -100 psi
C = 0 -150 psi
Maximum pressure
90 psi
140 psi
190 psi
Maximum pressure
13 bar
15 bar
6 bar
4 bar
18 bar
9 bar
Notes:
1) See Accessories section for required manifold sub-base
2) Feedback input is needed for dual loop units

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
4
SentronicD
Installation
Manual
1.2 Operating Elements
1.3 Manual Pressure Regulation (Hand)
1 Proportional solenoid coil
2.1 Pressure supply
2.2 Pressure outlet
2.3 Exhaust
3 Power supply, M12 connector
4 Operator buttons
5 3-digit display of outlet pressure
6 Ground connection, M4
7 Threaded mounting holes M4/6 mm
8 Mounting holes for M4 screws
9.1 Green LED
OFF: Setpoint ≠feedback
ON: Setpoint = feedback
Flashing: Overtemperature
9.2 Yellow LED
OFF: Normal
ON: Manual operation
Flashing: AUTOSAFE enabled
9.3 Red LED
OFF: Normal
ON: Low voltage
Flashing: Overvoltage
10 Serial communication (PC connection)
1
8
4
82.3
9.39.1 9.2
2.1
5
6
2.2
10
1⇒
3
⇒ 3
⇒ 2
7
After an interruption in the power supply, press both arrow buttons located beneath the display during power up to
switch to the manual mode. The operating mode is indicated by the letters “H n d” in the display.
The "H n d" display disappears when the arrow buttons are released.
Press the left arrow button or DOWN arrow to reduce the outlet pressure, press the right arrow button or UP arrow to
increase the outlet pressure. The yellow LED is on permanently during manual mode.
Exit this operating mode by pressing both arrow buttons simultaneously or by turning off the power supply for a short
time.
1.4 Operating Modes
Shut-off:
If the command signal falls below 0.5 %, the coil current is switched off and the valve is fully exhausted.
Overtemperature:
If the temperature of the internal control electronics exceeds 100°C, the operating mode is switched to AUTOSAFE
and the green LED starts to flash.
Undervoltage / overvoltage:
If the supply voltage is less than 20 V or more than 30 V, the coil current is switched off and the valve is fully exhaust-
ed. The red LED lights up constantly to indicate undervoltage or flashes to indicate overvoltage.
Autosafe:
If the coil current exceeds 1000 mA (DN8) or 560 mA (DN4) for more than 20 seconds, the output current is limited to
max. 70% every 4 seconds to prevent the valve from overheating. The yellow LED flashes.

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
5
SentronicD
Installation
Manual
2. Electrical Connection 5-pin M12 female connector
(view on soldered side)
250 Ohm at cur-
rent setpoint
Valve
M12 connector
+24V supply voltage
Supply voltage GND
Setpoint GND
(only for 6-wire cable)
Setpoint
0-10V
(or 0-20 / 4-20mA)
Feedback
0-10V
(or 0-20 / 4-20mA)
Control
Analog output:
Only at current output:
max. 500 ohm
Digital output: PNP when setpoint is reached
(setpoint=feedback)
Inductive
load
M4 connection on valve body
1) The valve must only be supplied with 24V DC at a tolerance of +15%/-10% and a max. ripple of 10% (no supply via
diode bridge). Overvoltage or a ripple rate exceeding these tolerances can damage the electronics.
2) The max. current at the digital output is 200 mA/4.8W (PNP output). The output is protected against short circuit and
overload.
3) If a relay (inductive load) is connected to the digital output, a freewheel diode or a varistor must be used.
4) A shielded cable must be used for protection against interference and EMC.
5) The valve body must be grounded with the earthing terminal PE (dia. M4)
Connector housing
Shield
=200mA max./4.8W
Connector Pin Out
Command signal: View on soldered side of female connector
2
14
3
5
PIN Description
1+24 VDC Supply
2Command Signal
3+0 VDC Common (Supply)
+0 VDC Common (Command Signal)*
4Analog output (feedback)
5Digital output (pressure switch)
Body EMC shield
*A 6-wire cable with separate common for the command signal is used for cable
lengths over 2 m to minimize the voltage drop for the command signal.

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
6
SentronicD
Installation
Manual
10 V
20 mA
5 V
10 mA
3. Analog Setpoint - Outlet Pressure
CAUTION:Outlet pressures above the maximum outlet pressure (PMR) are not controlled by the valve, i.e. the max.
outlet pressure is limited to the PMR.
In order to avoid damaging the sensor, the supply pressure must always be less than the maximum inlet pressure
defined above (see table).
The span can be set to max. 100% of the maximum outlet pressure (PMR). It can only be decreased.
Setpoint offset
The pressure setpoint zero can be changed via the DaS program. Switch to "Custom" in the "Setpoint setting" section.
The zero range is max. ±50 %.
Setpoint span
The span of the output pressure can be changed via the DaS program. Switch to "Custom" in the "Setpoint setting"
section. The span is between 10 and 100%.
Offset adjustment
Factory setting
SHUT-OFF
Max. outlet
pressure
PMR
+50 % PMR
20mA
412 mA
0
50 mV
0.1 mA
4.08 mA
0
-50 % PMR
10 V
20 mA
0
Span adjustment
Max. outlet
pressure (PMR)
Max. outlet
pressure 0.5 PMR
Factory setting: 100 %
50 % setting
SHUT-OFF
20mA
4
0
50 mV
0.1 mA
4.08 mA
0
Max. Outlet Pressure PMR Max. Inlet Pressure
50 psi 90 psi
100 psi 140 psi
150 psi 190 psi
1 bar 4 bar
3 bar 6 bar
6 bar 9 bar
10 bar 13 bar
12 bar 15 bar
15 bar 18 bar

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
7
SentronicD
Installation
Manual
4. Pneumatic Connection
• 0 psi outlet pressure at a setpoint of 0 V / 0 mA / 4 mA.
• Span: 50 psi device: = 50 psi at 10 V / 20 mA
100 psi device: = 100 psi at 10 V / 20 mA
150 psi device: = 150 psi at 10 V / 20 mA
• Minimum hysteresis.
• The control parameters, setpoint offset, setpoint span and window size of the digital output (pressure switch) are
factory-programmed.
Parameter set: factory settings
Offset: 0 %
Span: 100 %
Ramp: no ramp
Shut-off: ON; the valve is exhausted at a command signal below 0.5%
Controller structure: PID
Proportional gain: 4.0
Integration time: 0.1 sec
Derivation time: 8 msec
3 bar device: = 3 bar at 10 V / 20 mA
6 bar device: = 6 bar at 10 V / 20 mA
10 bar device: = 10 bar at 10 V / 20 mA
The air flow is from port 1 to port 2.
Inch screw connections (pipe threads) must be used.
Each screw connections must be lined with a fitting synthetic sealing disc.
Do not use Teflon sealing tape or hemp as they may get inside the valve and damage it.
Use an appropriate silencer at port (3). The exhaust time may vary depending on the type of silencer used.
The diameter of the pneumatic lines must be adjusted to the nominal diameter of the valve. The diameter of outlet line (2)
must be larger or equal to that of inlet line (1).
The supply pressure must always be less than the value given in the table in section 3 and must always be above the
desired outlet pressure.
Pressure outlet 2
Exhaust 3
Pressure supply 1
5. Factory Settings for a Standard Valve

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
8
SentronicD
Installation
Manual
6 Field-Programmable Settings
Display/Pressure Readings
The actual outlet pressure is displayed during normal operation. See "Parameters/Display" section. Other displays:
Hnd indicates that the Manual mode has been selected.
SOF Internal error of pressure control. Replace valve or contact our Product Support.
Err Internal overflow.
AEr Autozero overflow. Contact our Product Support.
Push Buttons
To enter the Manual mode, press and hold both pushbuttons simultaneously during power up. "Hnd" appears in the
display.
Use the UP button to increase the outlet pressure and the DOWN button to decrease it. The actual outlet pressure is
displayed.
Quick presses on the buttons allow you to make slight changes in the pressure rating.
Longer presses allow you to make quick pressure changes.
Press both pushbuttons simultaneously to exit the manual mode.
Construction Installation
Directly operated valve Assembly position: any; for optimum performance vertically
with solenoid at the top.
Body: Aluminium Air: filtered at 50 µm, free of condensate
Internal parts: POM Connections: Hemp or Teflon tape must not be used.
Seals: NBR (nitrile), FPM (fluoroelastomer) Electrical connection: Select a wire section that will give a
voltage drop of less than 2 volts at 2A.
7.1 Fluid Characteristics
Fluids: Air or neutral gas, filtered at 50 µm, free of condensate, lubricated or not
Ports: 1/8-1/4-3/8 NPT or GTap, see section 3
Max. Inlet Pressure: see section 3
Temperature / Fluid: 32°F - 140°F (0ºC - 60ºC)
Temperature / Ambient: 32ºF - 122ºF (0°C - 50°C)
Hystersis: <1% of span
Linearity: <0.5% of span
Repeatability: <0.5% of span
Minimum Setpoint: 100mV (0.2 mA/4.2mA) with shut-off function
Minimum Outlet Pressure: <1% of span
7.2 Specifications
Nominal diameter
dn (mm)
Supply voltage
(stabilised)*
Max. Power
(W)
Max. Current
(mA)
Insulation
Class
Degree of
Protection
Flow
Electrical Connection
KvNm3/h l/min (SRA)
4 24 V = +15%/-10% 21 850 H IP 65 0.25 470 5-pin female M12
connector
8 24 V = +15%/-10% 40 1650 H IP 65 0.7 1300 5-pin female M12
connector
* Residual ripple: 10 %
Test conditions according to ISO 8778: temperature: 20 °C, relative inlet pressure: 6 bar, relative outlet pressure: 5 bar
Command signal: 0 ... 10 V (100 kOhm input resistance)
0 ... 20 mA / 4 ... 20 mA (250 Ohm input resistance)
Feedback output: 0 ... 10 V (max. 10 mA), short-circuit protected
0 ... 20 mA / 4 ... 20 mA (max. 24 VDC)
Digital output: pnp; open collector; max. 200 mA/4.8W, short-circuit protected
HIGH (24 VDC) if feedback=setpoint
LOW (open) if feedback≠setpoint
Overvoltage: Shut-off at a voltage level higher than 30 volts (+10%).
Low voltage: Shut-off at a voltage level lower than 19.5 volts (-10 %).
7. Technical Characteristics

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
9
SentronicD
Installation
Manual
No special maintenance or care required.
9. Maintenance and Care
8. Accessories
Micro Female 5 Pole 90 Degree 6 Wire 22 AWG Euro Color Code, Shielded
3 Meter TD0503MMS000671Y
5 Meter TD0505MMS000671Y
Manifold Model Number
Manifold for 608 (DN 4mm) with G3/8; common supply and exhaust 1) 35500558
Manifold for 609 (DN 8mm) with G1/2; common supply and exhaust 1) 35500559
PC Software & Cable Connectors Model Number
DaS Light: Data Acquisition Software for SentronicD- basic parameters -
free download at Numatics.com 99100110
DaS Expert: Data Acquisition Software for SentronicD- full parameters - CD-ROM 99100111
RS 232 cable converter; 2m cable with 9-pin Sub-D (plug connector) 88100732
RS 232 cable converter; 2m cable with 9-pin Sub-D (screw connector) 833-993708
5 Pin 12mm FEMALE 90 DEGREE Field Attachable Connectors
PG 9 Cable Gland TD05F20000000000
5 Pin 12mm FEMALE Straight Field Attachable Connectors Model Number
PG 9 Cable Gland TC05F20000000000
Micro Female 5 Pole Straight 6 Wire 22 AWG, Shielded
3 Meter TC0503MMS000671Y
5 Meter TC0505MMS000671Y
Micro F 90°/M Straight 22 AWG Euro Color Code
Unshielded Shielded
2 Meter - TD0403MIETA04000 3 Meter - TD0403MMETA04000
5 Meter - TD0405MIETA04000 5 Meter - TD0405MMETA04000
Micro F/M 4 Pole Straight 22 AWG Euro Color Code
Unshielded Shielded
2 Meter - TC0403MIETA04000 3 Meter - TC0403MMETA04000
5 Meter - TC0405MIETA04000 5 Meter - TC0405MMETA04000
1) Manifold ships with required hardware and gaskets for connecting manifolds together.

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
10
SentronicD
Installation
Manual
10. Dimensions in inches (mm), Weight in lbs (kg)
Dimensions: Inches (mm), Weight in lbs (kg)
M4 hole for
ground screw
1/8, 1/4 NPT or GTap
0.79 (20)
1.16 (29.5)
2.13 (54)
1.71 (43.55)
0.71 (18)
0.43 (11)
0.88 (22.3)
0.59 (15)
1.73 (44)
2.56 (65)
4.39 (111.5)
1.52 (38.5)
2.22 (56.3)
2.67 (67.8)
0.47 (12)
0.53 (13.5)
1.14 (29)
0.79 (20)
1.86 (47.15)
Ø 1.38 (35)
0.85 (21.5)
1.69 (43)
2.05 (52)
M12x1
Hole for
M4 screw (*)
Hole for
M4 screw (*)
1/8, 1/4 NPT or GTap
Programming
Interface
Connector
Mounting holes: M4 thread
Inline version: DN 4
Weight: 1.23 (0.56)
Mounting holes:
M4 thread
1/4, 3/8 NPT or GTap
M4 hole for
ground screw
Connector
1/4, 3/8
NPT or GTap
0.98 (25) 0.20 (5) 0.98 (25)
2.25 (57.15)
Ø 1.77 (45)
1.10 (28)
2.20 (56)
0.79 (20)
1.57 (40)
2.60 (66)
1.57 (40)
0.71 (18)
1.09 (27.6)
1.67 (42.3)
3.35 (85)
0.64 (16.3)
2.40 (61)
0.94 (24)
3.06 (77.8)
0.51 (13)
2.50 (63.55)
2.64 (67)
2.85 (72.5)
5.41 (137.5)
1.91 (48.5)
2.61 (66.3)
Programming
interface
Hole for
M4 screw
Inline version: DN 8
Weight: 2.49 (1.13)

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
11
SentronicD
Installation
Manual
Manifold version: DN 4
Weight: 1.23 (0.56)
Dimensions: Inches (mm), Weight in lbs (kg)
Manifold: DN 4
Connector
0.79 (20) 0.47 (12)
0.85 (21.5)
1.69 (43)
2.05 (52)
2.05 (52)
1.86 (47.15)
0.63 (16)
1.38 (35)
2.13 (54)
2.67 (67.8)
1.52 (38.5)
0.18 (4.5)
1.71 (43.55)
4.39 (111.5)
2.38 (60.5)
0.88 (22.3)
0.47 (12)
1.16 (29.5)
1.85 (47)
2.07 (52.5)
2.56 (65)
2.22 (56.3)
Programming
interface
Hole for
M4 screw
M4 hole for
ground screw
1/8 GTap
Hole for
M4 screw
Hole for
M4 screw
Hole for
M4 screw
3/8 GTap
1/8 GTap
1/4 GTap
3/8 GTap
3/8 GTap
3/8 GTap
0.31 (8)
1.93 (49)
0.55 (14) 1.69 (43)
1.38 (35)
1.61 (41)
0.79 (20)
0.83 (21)
2.17 (55)
1.26 (32)
2.24 (57)
0.24 (6) 1.28 (32.5)
0.45 (11.5)
3.74 (95)
3.94 (100)
2.12 (54)

Information subject to change without notice. For ordering information or regarding your local sales office visit www.numatics.com.
12
SentronicD
Installation
Manual
Manifold version: DN 8
Weight: 2.49 (1.13)
Manifold: DN 8
Dimensions: Inches (mm), Weight in lbs (kg)
Hole for
M4 screw
M4 hole for
ground screw
Connector
2.61 (66.3) 0.20 (5) 1.91 (48.5)
2.25 (57.15)
1.77 (45)
1.10 (28)
2.20 (56)
2.60 (66)
2.85 (72.5)
0.71 (18)
2.50 (63.55) 2.64 (67)
3.06 (77.8)
1.67 (42.3)
3.35 (85)
0.55 (14)
1.50 (38)
2.40 (61)
1.05 (26.6)
5.41 (137.48)
1/4 GTap
Programming
interface
Hole for
M4 screw
Hole for
M4 screw
0.83 (21)
0.20 (5)
0.45 (11.5)
1.54 (39)
4.53 (115) 4.72 (120)
0.31 (8) 1.02 (26)
2.40 (61)
0.71 (18)
2.68 (68) 2.01 (51)
1.81 (46)
2.01 (51)
2.17 (55)
1.38(35)
2.68 (68)
1/2 GTap
1/8 GTap
1/2 GTap
1/2 GTap
3/8 GTap
1/2 GTap

SentronicDManual Rev 02/12
© Numatics Inc. 2010 - 2012
World Class Supplier of Pneumatic Components
World Headquarters
USA Numatics, Incorporated
46280 Dylan Drive
Novi, Michigan 48377
P: 248-596-3200
F: 248-596-3995
Canada Numatics, Ltd
P: 519-758-2700
F: 519-452-3995
Mexico Numatics de Mexico S.A. de C.V.
P: 52-222-284-6176
F: 52-222-284-6179
Numatics, Inc. | Tel [phone] | www.numatics.com | email: [email protected]
