NURSAL N6039 User manual

RECHARGEABLE SHIATSU
NECK AND SHOULDER HEATED
MASSAGER
MANUAL
Model: N6039

English.................................................................................
German...............................................................................
French...................................................................................
Italian....................................................................................
Spanish...............................................................................
02
12
24
36
48
Contents

Thank you for choosing N6039
rechargeable neck and shoulder
massager. Please read this manual
carefully before use, especially the
precautions and using methods. Please
keep this manual properly and check it
whenever you need it.
01

Product Features
Product Parts and Function
Operation Instruction
Attention and Maintenance Matters
Simple Product Failure Analysis and Processing
Product Specifications
Ingredient and Content of Hazardous Substances in Products
03
04
05
07
09
10
11
Contents
02

03
Perfect stylish appearance and streamlined design;
Built-in 8 kneading nodes, a new design for relaxing shoulder and
neck at the same time;
A hand-held strap fixed the massager well which make you more
convenient and comfortable;
Clockwise and Anticlockwise massage function are available to you;
It can be used for the neck, shoulder, waist, back, legs and other
parts of your body;
15 minutes timer function;
Heating function for your tired muscle and promote the blood
circulation.
Note: Surfaces will be heated, not sensitive person must be used
with attention.
Product Features

04
Product Parts and Function
Introduction to Control Panel:
ON/OFF Switch:
start the massager by press and hold for
3 seconds, and press it shortly for stop.
Massage Balls
Cover
Control Panel
DC Plug
Direction Switch:
control the rotation direction of the
massage ball (forward and reverse).
Speed Switch:
adjust the speed of the massage ball.
Heating Switch:
turn on and off the heating function.

05
Operation Instruction
Insert the DC plug into the DC socket, then insert the power plug
into the AC power socket. When the product does not work, the
battery is charging. And the battery is not charged when the
product is working.
Press the ON/OFF Switch (kneading forward and heating
simultaneously)
After you press the switch, the automatic mode is turn on, which
changed per 20 seconds:
forward slow speed - forward fast - forward slow speed - reverse
slow - reverse slow - reverse fast - reverse fast, move in endless
cycles;
Note: The automatic mode only exist when you press the ON/OFF
switch. If you press other switch during the machine working, the
automatic mode will disappear. If you need the automatic mode,
the only way is to re-open the machine.
The Direction Switch: press once, it will change the direction.
The Speed Switch: press once, it will change the speed, fast / slow
adjustment.
The Heating Switch: When the massager start working, the heating
is turn on. If you do not need it, just need to press the heating switch.
When you are finished, unplug the AC power connector.
The Purple LED light on, indicating the heating function work. The
Blue LED light on, indicating the heating function does not work.
The Red LED flashes, indicating low power ( below 9.5V).
Security Warning:
1. The massager is not intended to be provided to persons with
physical disability, sensory or neurological deficiencies, lack of
experience and common sense (including children), unless they
are supervised and guided by those who are responsible for their
safety.
2. Children must be supervised by their parents to ensure that they
do not play with the equipment.

06
Operation Instruction
Insert the DC plug into the DC socket, then insert the power plug
into the AC power socket. When the product does not work, the
battery is charging. And the battery is not charged when the
product is working.
Press the ON/OFF Switch (kneading forward and heating
simultaneously)
After you press the switch, the automatic mode is turn on, which
changed per 20 seconds:
forward slow speed - forward fast - forward slow speed - reverse
slow - reverse slow - reverse fast - reverse fast, move in endless
cycles;
Note: The automatic mode only exist when you press the ON/OFF
switch. If you press other switch during the machine working, the
automatic mode will disappear. If you need the automatic mode,
the only way is to re-open the machine.
The Direction Switch: press once, it will change the direction.
The Speed Switch: press once, it will change the speed, fast / slow
adjustment.
The Heating Switch: When the massager start working, the heating
is turn on. If you do not need it, just need to press the heating switch.
When you are finished, unplug the AC power connector.
The Purple LED light on, indicating the heating function work. The
Blue LED light on, indicating the heating function does not work.
The Red LED flashes, indicating low power ( below 9.5V).
Security Warning:
1. The massager is not intended to be provided to persons with
physical disability, sensory or neurological deficiencies, lack of
experience and common sense (including children), unless they
are supervised and guided by those who are responsible for their
safety.
2. Children must be supervised by their parents to ensure that they
do not play with the equipment.

07
Attention and Maintenance Matters
In order to keep the massager in the best condition, please pay
attention on the following questions. The massager can only be
used in accordance with the functional description of this manual.
1. Do not massage on the surface of wounded or decayed regions.
2. Do not exert all your strength to press the machine when you are
using it standing or sit, in order to prevent the machine work
overload.
3. If you are the first time to use massager product, please do not use
it for a long time. It is better to use only 15 minutes, and you could
add the use time after you adapt it. If you feel the massager
strength is too strong, it is recommended that put a thick towel on
the kneading nodes. Therefore, a sharp weakening of the massage
intensity.
4. It is suggested that using the massager should not exceed 30 minutes.
5. You should stop using the massager and cut off the power
immediately, when the temperature is too high or bad smell
appears.
6. After using, please press the ON/OFF switch to turn off the power.
Then, pull the plug out and make sure the massager is turned off.
Do not pull the electric wire roughly.
7. Use soft cotton cloth or mild detergent to clean the massager.
8. Do not use (or store) the massager in wet or high temperature places.
9. Do not trample, throw and press the massager heavily.

08
Attention and Maintenance Matters
10. The following users must consult their doctor before use:
People with cancer or those who suffer from chronic diseases or major diseases
People with severe heart disease.
People with a pacemaker or implanted medical device.
People with other metal appliances, such as prostheses.
Pregnant women and children
Patients with mental illness
11. Do not pull the power wire of the massager.
12. Do not use this massager in water or in a wet place. If the massager
falls into the water accidentally, you should turn off the power and
unplug the power plug from the outlet immediately. Do not remove
the massager from the water immediately.
13. Do not use the massager near the electric heater and other heat
sources.
14. Do not use the massager with the accessories or parts, which are not
provided by Nursal company.
15. Do not took the machine apart or replace parts privately, otherwise,
the company does not warranty and stop the relevant after-sales
service.
16. Do not disassemble the zipper for your personal safety and the life
of the product. The Company will not be responsible for any
consequences arising from the violation.
17. Do not use the massager within 1 hour after meals.

09
Phenomenon Possible reason Solution
The machine does not
work
1. the power is not
connected;
2. poor contact between
socket and power plug;
3. the power switch is not
turn on;
4. the battery isn't
charging;
1. turn on the power;
2. plug the plug;
3. turn on the ON/OFF
switch;
4. charge the product;
creating a squeaking
sound or sneezing sound
during usage
1. it is the normal work
sound of the engine;
2. the working time of the
massager is too long;
3. mechanical parts are
damaged normally;
No need to deal with
the strength of massager
is gentle or become more
and more gentle during
the usage
1. the using position and
posture is wrong;
2. feeling strong strength,
because your body is too
close to the massager or
you have not yet
adapted;
3. feeling gentle or useless,
keep your body away
from the massger and
the intensity is not
enough;
1. adjust the placement
angle and change your
posture, until you feel
the intensity is good
enough,
2. adjust the distance
between your body and
the massager, or put a
towel on the massage
balls;
3. adjust the distance
between your body and
the massager;
Simple Product Failure Analysis and Processing

10
Product Specifications
Product Name:
Rechargeable Shiatsu Neck and Shoulder Heated Massager
Product Type: N6039
Voltage: AC100-240V;50/60Hz; DC 12V 2A
Rated power: 24W
Accessories
Massagerx1;
User Manualx1;
Car chargerx1;
Adapterx1;

11
Ingredient and Content of Hazardous Substances in Products
Parts Name
Adapter
Letterprint
(PB)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
chromium
(Cr(V1))
Polybrominated
biphenyls
(PBB)
Polybrominated
diphenyl
ethers
(PBDE)
Leather & cloth
Plastic parts
Hardware
Circuit board
PU
Ingredient and Content of
Hazardous Substances in Products
This form is prepared in accordance with SJ / T 11364.
: Indicates that the content of the substance in all the homogeneous materials is less than
the limit specified in GB / T 26572.
: indicates that the content of the hazardous substance in at least one of the homogeneous
materials of the part exceeds the limit requirement specified in GB / T 26572.
This product "environmental protection life" for 10 years, pollution
control labels as shown on the left side of the pattern. The harmful
substances in electrical and electronic products will not occur leakage
or mutation. The deadline of that the users do not cause serious
pollution or damage to their personals and property caused by the
electrical and electronic normal use.

12
AUFLADBARES SHIATSU HALS- UND
SCHULTER MASSAGEGERÄT
BEDIENUNGSANLEITUNG

Vielen Dank für Ihren Kauf des auflafbaren
N6039 Hals- und Schulter Massagegeräts Bitte
lesen Sie sich diese Bedienungsanleitung
sorgfältig durch, bevor Sie das Gerät verwenden.
Achten Sie dabei besonders auf die Sicherheits-
und Nutzungshinweise. Bitte heben Sie diese
Anleitung gut auf.
13

Produkt Features
Produkt-Bestandteile und Funktionen
Nutzungshinweise
Wartung und Pflege
Problembehandlung
Produkteigenschaften
Materialien und gefährliche Substanzen des Produkts
15
16
17
19
21
22
23
Inhaltsangabe
14

15
Stylisches Gerät mit schlankem Design;
8 eingebaute Knetknoten – ein neues Design zum gleichzeitigen
Entspannen der Schultern und des Halses;
Trageriemen für eine noch praktischere und bequemere Anwend-
ung;
Massagefunktion im und gegen den Uhrzeigersinn;
Ideal für den Hals, die Schultern, die Hüften, den Rücken, die Beine
und andere Körperteile;
15 Minuten Timer-Funktion;
Hitzefunktion für verspannte Muskeln und zur Förderung des
Blutkreislaufs
Hinweis: Die Oberfläche wird sich erhitzen. Sensible Personen
sollten das Gerät mit Vorsicht bedienen.
Produkt Features

16
Produkt-Bestandteile und Funktionen
EInleitung in das Bedienfeld:
AN/AUS Taste:
Startet das Massagegerät, indem Sie die
Taste für 3 Sekunden gedrückt halten.
Kurz drücken, um es zu stoppen.
Massagebälle
Abdeckung
Bedienfeld
Stecker
Richtungstaste:
steuert die Richtung der Massagebälle
(vorwärts oder rückwärts).
Geschwindigkeitstaste:
passt die Geschwindigkeit der
Massagebälle an.
Hitzetaste:
schaltet die Hitzefunktion ein und aus.

17
Nutzungshinweise
Schließen Sie den Stecker an eine Steckdose an und schließen Sie
das andere Ende an das Gerät an. Wenn das Gerät nicht funktion-
iert, wird die Batterie noch aufgeladen. Während der Verwendung
wird die Batterie nicht aufgeladen.
Betätigen Sie die AN/AUS Taste (gleichzeitig Vorwärts-Kneten
und Hitzefunktion).
Nachdem Sie diese Taste gedrückt haben, wird sich der automa-
tische Modus aktivieren und die Modi alle 20 Sekunden ändern.
Langsame Vorwärts-Geschwindigkeit – schnell vorwärts – langsam
vorwärts – rückwärts langsam – rückwärts schnell – in Kreisbewe-
gungen.
Hinweis: Der automatische Modus existiert nur, wenn Sie die
AN/AUS Taste betätigen. Wenn Sie eine andere Taste während der
Verwendung drücken, wird der automatische Modus direkt
ausgeschalten. Wenn Sie den automatischen Modus möchten,
müssen Sie das Gerät neu einschalten.
Richtungstaste: einmal drücken und die Richtung ändert sich.
Geschwindigkeitstaste: einmal drücken und die Geschwindigkeit
ändert sich zwischen schnell / langsam.
Hitzetaste: Wenn das Gerät im Betrieb ist und diese Taste
eingeschaltet ist, wird sich das Gerät erhitzen. Wenn Sie diese
Funktion nicht wünschen, deaktivieren Sie einfach diese Taste.
Nach der Verwendung ziehen Sie einfach den Stecker.
Das lilafarbene LED Licht zeigt an, dass die Hitzefunktion aktiv ist.
Das blaue LED Licht zeigt an, dass die Hitzefunktion nicht aktiv ist.
Das rote LED Licht blinkt, wenn die Batterie leer ist (weniger als
9,5V).
Sicherheitshinweise:
1. Das Massagegerät ist nicht für Personen mit körperlichen,
sensorischen oder neurologischen Behinderungen geeignet.
Gleiches gilt für Personen ohne ausreichend Erfahrung (z.B.
Kinder), sofern diese nicht von anderen Erwachsenen beaufsichtigt
werden, die auch die Verantwortung übernehmen.
2. Kinder müssen von ihren Eltern beaufsichtigt werden, damit sie
nicht mit diesem Gerät spielen.
