Body Mate 608 User manual

OSCILLATING MASSAGE BELT
Model: 608
INSTRUCTION MANUAL
BodyMate
TABLE OF CONTENTS
Introduction..................................................................................2
Notes on Safety.............................................................................2
Names of Parts.............................................................................3
Features......................................................................................4
Method of Usage..........................................................................4
Example of Application places-......................................................5
Product Care and Storage.............................................................6
Specifications..............................................................................6
1

INTRODUCTION
Thank you for purchasing Oscillating Massage Belt which is designed
to provide effective simulating massage to eliminate excessive fat in
your body with easy-to-use-features.
Before your begin using this product, please read the instruction
manual thoroughly for the correct methods of usage, noting especially
the section on safety.
This manual should be kept on hand for future reference.
NOTES ON SAFETY
* Check that the voltage corresponds wit the specification indicated for
the massager.
* Always turn all controls to the "Off" position and remove the AC plug
from the electrical outlet after use or before cleaning the massager.
* Do not sit on or press heavily on the massager.
* Do not use the massager while having a bath or shower.
* Do not immerse the massager in water.
* Remove the AC plug from the electrical out let immediately if the
massager falls into water. Do not reach into the water immediately to
retrieve the massager.
* Do not leave the massager unattended when it is plugged into the
electrical outlet.
* Close supervision by an adult is necessary when the massager is
used by, on or near children and persons with disabilities.
* Do not use the massager in places with poor ventilation, e.g. under
blankets or Pillows. Excess heating may occur, which may cause
fire, electric shock or injury to the user.
* Never operate the massager with a damaged cord. If the massager is
damaged in any manner, stop the operation immediately. Do not
dismantle or attempt to repair the massager yourself. Please contact
the dealer agent for inspection.
* Use only attachments recommended by manufacturer.
* Stop operation immediately should you experience any discomfort
during the massage.
2
BodyMate
* Use the massager only for its intended use as described in this manual.
Do not use the massager on sensitive skin.
* Always keep the massager away from heated surfaces and areas.
* This massager is for indoor use only.
* Do not carry the massager by its electrical cord.
* Do not use the massager on any body part which is swollen or inflamed.
And do not massage any area where pain is present.
* Always avoid direct contact with eyes.
NOTE
* Please allow the massager to rest for 20 minutes before the next usage.
This will prevent the massager from overheating, which may result in
damage to massager.
NAMES OF PARTS
1. Massage Belt and Controller Unit-
a
b
cd
e
fg
a. Power Jack b. Power On/Off
c. Power/Mode indicator
(Red color-auto mode, Green-manual mode)
d. Auto/Manual
e. High (to increase oscillating speed in manual mode)
f . Low (to decrease oscillating speed in manual mode)
g. Forward/Reverse (functional in manual mode)
3

BodyMate
2. Extension belt
3. Power Adapter
hi
h. AC Power plug
i. DC output plug
(connecting to power jack on
massager belt)
FEATURES
* Auto Mode Function for Best Effectiveness of Exercise Simulation
Cycle.
* Manual Mode with 5 Rotation Strength Levels Adjustment
* Rotation Direction Option
(Clockwise and Counter-Clockwise)
* Auto off Function 10 Minutes
* Easy Operation controller device affixed
* Included one Extension Belt
* Applicable for Waist, Abdomen, Thigh, Calf, Hip and Upper Back.
* Power supply 100-240 VAC, 35W
METHOD OF USAGE
1. Connecting Power supply with
DC output plug to the Jack at
Massage belt.
4
(Fig. 1)
2. Tie up the massage belt on a proper position of your body (such as
Waist, abdomen etc., please refer to the Example of Application in
next section). Tension and adjust to comfortable. If necessary you
may extend the length of belt by attaching the extension belt.
3. Connecting Power supply another end to any AC outlet.
4. Press "Power On/Off" key to turn on the massager and enter to the
"Auto" Mode (LED in Red color). The Auto Off Timer start to count
down for 10 minutes. During the Auto Mode, device presets an
exercise program cycle alternating between different speed and
direction. So that you may just relax to enjoy the best effective of
massage.
5. Press "Auto/Manual" key to switch between Auto and Manual mode
as you like. (LED indicate Auto - Red color, Manual - Green color)
6. While in "Manual Mode", you may press "High" or "Low" to adjust the
speed from Level 1 - 5. Each press of key response with a beep tone,
when speed reached to the highest level 5 or lowest level 1,further
press the key will be silence no beep tone to indicate it reached the
end of adjustment.
7. While in "Manual Mode", you may press "Direction" key to change the
Oscillating direction from clockwise to counterclockwise or vise versa.
8. Press "Power On/Off" again to turn to device off or when Auto off 10
minutes timer time up to turn off automatically.
EXAMPLE OF APPLICATION PLACES
5
NOTE
* The speed adjustment High/Low and direction key only functional in
"Manual Mode". While in "Auto Mode" is disabled.
Photo for Calf Photo for HipPhoto for Thigh Photo for
Upper Back
(Fig. 2)
Photo for
Abdomen

PRODUCT CARE AND STORAGE
* Be sure to remove the AC plug from the electrical outlet before
cleaning the massager.
* Do not use benzene, thinner or any other solvent on your massager.
* Use a piece of dry cloth when cleaning the massager.
Never use a damp cloth to clean the massager and the controller
device.
* When not in use for a long time, it is advisable that the apparatus and
fittings stored in a dust and moisture - free environment.
* Do not store the massager near intense heat or an open flame.
Do not leave the massager under direct sunlight for a long period of
time.
SPECIFICATIONS
Model Name: Oscillating Massage Belt
Model Number: 608
Input Voltage: 100-240 VAC, 50 - 60 Hz
Output Voltage: 24V DC, 1.5A
Power Consumption: 35 W
Speed adjust: 5 Levels
Auto Timer: 10 Minutes
6
611-608000-000
VER 1.0, 10/2006
