NuTone 690NT User manual

NuTone, Inc., 4820 Red Bank Road, Cincinnai, OH 45227 (1-800-543-8687)
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
Architectural & Engineering Specications
February 2007
Bath Fan
Upgrade Kit
MODEL 690NT
70B 99043834A
DESCRIPTION
INSTALLATION
Complete installation instructions are included with each kit.
Nautilus N671, N688 The kit will work if your
housing measures 7½” x 7¼”.
Broan 670, 671, 688, 689 The kit will work if your
housing measures 7½” x 7¼”.
NuTone 693, 695, 696N The kit will work if your
housing measures either
7½” x 7¼” or 8” x 7¼”.
Reducesthesoundlevelofyourexistingbathfanbyupto50%whileincreasing
air movement by up to 20%. No rewiring or new ductwork required.
GRILLE:
•White polymeric - blends well with any decor
•Torsion spring grille mounting - no tools required
FAN ASSEMBLY:
•Plug-in, permanently lubricated motor
•Polymeric blower wheel
•Galvanized steel motor bracket and motor plate
•Fits into your existing bath fan housing
•Two motor plate sizes included - to accomodate a variety of economy fan
models
ACCESSORIES:
•Wrench and hardware included - no additional tools required
•Polymeric scroll band included - enhances performance of existing bath
fan housings
SPECIFICATIONS
VOLTS AMPS CFM SONES
120 1.2 60 3.0 ARCHITECT’S SPECIFICATION
• Bath Fan Upgrade Kit shall be NuTone Model 690NT.
• Bath Fan Upgrade Kit shall include two galvanized
steel motor plates designed to accommodate a variety
of economy fan models.
• Motor shall be removable and permanently lubricated.
• Air delivery shall be no less than 60 cfm and sound
level no greater than 3.0 Sones. All air and sound
ratings shall be certied by HVI. Unit shall be U.L.
Listed.
HVI-2100 CERTIFIED RATINGS comply with new testing technologies and
procedures prescribed by the Home Ventilating Institute, for off-the-shelf
products, as they are available to consumers. Product performance is rated
at 0.1 in. static pressure, based on tests conducted in AMCA’s state-of-the-art
test laboratory. Sones are a measure of humanly-perceived loudness, based
on laboratory measurements.
For use only with these bath fan models:
