NuTone 744SFLNT User manual

REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
Broan-NuTone LLC Hartford, Wisconsin www.nutone.com 800-558-1711
Broan-NuTone Canada Missisauga, Ontario www.nutone.ca 877-896-1119
Architectural & Engineering Specifications
October 2009
Humidity Sensing
Recessed
Fan / Fluorescent
Light
90K 99044573A
DESCRIPTION
TRIM RING BAFFLE:
• Polymeric construction with matte white finish
• Recessed styling, mounts flush with finished ceiling
• Integrated humidity sensor
LAMP:
• Uses R30-shaped, 3500K, 14W, high efficacy, compact
fluorescent lamp with GX24q-1 base (included)
• Electronic ballast
BLOWER:
• Plug-in, permanently lubricated, motor
• Dynamically balanced centrifugal blower wheel for quiet,
efficient performance
• Quiet operation
HOUSING:
• Fits in 2” x 8” construction
• Rugged, 26 gage, galvanized steel construction
• 4” round, polymeric duct connector with 2” tapered sleeve and
no metallic clatter
• Adjustable mounting brackets span up to 24”
CONTROLS: (purchase separately)
• Model VS-96 - One rocker switch with “on” indicator light
• Model VS-86SN - Two rocker switches - fits single outlet box
AUTOMATIC CONTROL:
• Humidity control automatically turns fan ON when either of
these conditions is detected:
- a rapid to moderate (user adjustable) increase of humidity
- humidity above user-adjustable set-point (50%-100% RH)
• Two wire manual operation for odor control - Turns fan ON
when power line through wall switch is cycled ON, OFF and
back ON
• Remains ON for a user-adjustable 5 to 60 minutes after
humidity has stabilized and is below set-point or after
manually initiated through power line cycling
• Saves energy because unit runs only for the time required. A
unit controlled with a wall timer may keep fan ON longer than
required or turn it OFF before room is sufficiently ventilated
U.L. Listed for use in insulated ceilings (TYPE I.C.)
U.L. Listed for use over bathtubs and showers when connected to
a GFCI protected branch circuit.
Title 24 compliant.
ENERGY STAR qualified.
MODEL 744SFLNT

Broan-NuTone LLC Hartford, Wisconsin www.nutone.com 800-558-1711
Broan-NuTone Canada Missisauga, Ontario www.nutone.ca 877-896-1119
HVI-2100 CERTIFIED RATINGS comply with new testing
technologies and procedures prescribed by the Home Ventilating
Institute, for off-the-shelf products, as they are available to
consumers. Product performance is rated at 0.1 in. static pressure,
based on tests conducted in a state-of-the-art test laboratory.
Sones are a measure of humanly-perceived loudness, based on
laboratory measurements.
SPECIFICATIONS
MODEL VOLTS AMPS*
744SFLNT 120 0.5
STATIC PRESSURE CFM SONES FAN WATTS DUCT
0.10 70 1.5 34.4 4” Round
0.25 55
* Total Connected Load
INSTALLATION
Complete installation instructions are included with each Humidity
Sensing Recessed Fan / Light.
ARCHITECT’S SPECIFICATION
Fan / Light shall be NuTone Model 744SFLNT as manufactured by
NuTone according to specifications listed:
Fan / Light shall have corrosion resistant steel housing and adjustable
mounting brackets.
Motor assembly to be removable and permanently lubricated.
Non-metallic damper/duct connector to be included.
Fan and Light to operate separately or in combination.
Fan / Light must use an R30-shaped, 3500K, 14W, high efficacy,
pin-based, compact fluorescent lamp and an electronic ballast.
Air delivery shall be no less than 70 CFM and sound level no greater
than 1.5 Sones. All air and sound ratings shall be certified by HVI.
Fan / Light must be U.L. and cU.L. Listed for use in insulated ceilings
(Type I.C.).
Fan / Light must be Title 24 compliant.
Fan / Light must be ENERGY STAR qualified.
The unit will have a control that will automatically turn fan ON
when humidity increase is rapid to moderate (user adjustable),
or when humidity is higher than user-adjustable set-point (50%-
100% Relative Humidity), or when supply power is cycled from
ON (for more than a second) to OFF (for less than a second) and
back ON. It shall be user-adjustable to turn OFF 5 to 60 minutes
after humidity has stabilized and is below user-adjustable set-
point, or after manually initiated by supply power cycling.
HUMIDITY SENSING RECESSED
FAN / FLUORESCENT LIGHT
MODEL 744SFLNT
