NuTone IMA-4406 Series Installation instructions

IMA4406 Radio
Intercom with CD P layer
The IMA4406 radio-intercom with CD player provides total
home communications and superb music distribution. An
excellent way to add value and convenience to any home.
Model No. Overall Size
IMA4406 173⁄4" x 101⁄8" x 31⁄2"
F E AT U R E S :
• Step saving room-to-room intercom
• Door-answering security
• Monitoring feature for checking on baby or person
confined to bed
• “Hands Free” answering at all stations
• Control CD/Radio from remote stations
• Powerful 20 watt amplifier for excellent fidelity
• Separate bass and treble controls
• Smoked window allows view of CD in player
•C D pauses when intercom or chime is used
• FM/AM Radio features 12 station memory
• “Wake to Music” feature functions as alarm clock
• Use with up to 9 remote stations and 3 door speakers
(Can be increased to a maximum of 15 stations and 3
door speakers with the use of optional Expansion
Module IAA-440)
• Optional chime module or external electronic chime,
audio wall plate
• Available in three colors:
White (IMA4406WH)
Biscuit (IMA4406L)
Black (IMA4406BL)
S P E C I F I C ATIONS:
Rough - i n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IR-10 5
Panel Projection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17⁄8"
Max. No. of remote speakers . . . . . . . . . . . . . . . . .15 speakers
Max. No. of door speakers . . . . . . . . . . . . . . . . . . . .3 speakers
Remote speaker wire . . . . . .NuTone IW-6 or IW-6UL (6) wire
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(3) twisted pair cable
Max. wire length of (1) remote speaker/control . . . . . . . .750 ft.
Max. wire length of all remote speakers/controls wire .4000 ft.
Door speaker wire . . . . . . . . . . . . . . . .NuTone IW-2 or IW-2UL
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(2) wire twisted cable
Max. wire length of (1) door speaker wire . . . . . . . . . . . . .300 ft.
Max. wire length of all door speaker wires . . . . . . . . . . . .750 ft.
Warra n t y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Year
Product specifications subject to change without notice. BROAN-NUTONE GROUP, INC.
I M A 4 4 0 6
INTERCOM SYSTEMS
