NuTone 153001 User manual

SHIPPING
MODEL VOLTS AMPS SONES CFM DUCT WT.
1530 120 3.7 4.5 300 3¼" x 10" 40 Lbs.
1536 120 3.7 4.5 300 3¼" x 10" 43 Lbs.
SPECIFICATION SHEET
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
NuTone, Inc., 4820 Red Bank Road, Cincinnati, OH 45227 (1-800-543-8687)
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
TYPICALSPECIFICATION
RangeHoodshallbeBroanElite15000Series.
Unitshall beconstructed ofheavy-gauge steelfinished witha
durable,black,(white),(biscuit)paintedfinish.Itwillinstallina
standard30"(orwider)cabinetwithaflushorrecessedbottom.
Hoodtocontainaquietefficientcentrifugalblowerwithautomatic
start-upathightemperatures.Itshallbeductedverticallythrough
3¼"x10"ductwork.Blowerandfluorescentlightshallbeturned
ONandOFFusingasliding,temperedglassdrawer.Aninfinite
speedcontrol,withmemory,shallbeprovidedtoadjustblower
speed.
Airdelivery shallbe noless than300CFMandsoundlevelno
greaterthan4.5Sones.Allairandsoundratingsshall becertified
byHVI.
UnittobeU.L.listed.
50B 99041263F
SPECIFICATIONS
BROAN ELITE
15000 SERIES
(
®)
RANGE HOODS
Mounts into a full-sized cabinet above the cooktop with only a
slim,sliding glassdrawervisibletoaccent today'scontemporary
andEuropean-styledkitchens.
FEATURES
•Highefficiencydualcentrifugalblowerwithresilientanti-vibrationmotor
mounts
•BlowerturnsONwhendrawerispartiallypulledout-OFF when
closed
•Front-mountedsolidstateinfinitespeedcontrolwithmemory
•HeatSentry™ -Automaticallyturnsblower ONtoHIGHspeedwhen
excessheatis detected
•Bright,economical24"fluorescentlight(F20T12tubenotincluded)
•Prismaticglasslightlens-removeseasilyforcleaning
•LightturnsONwhendrawer ispulledoutslightly- OFFwhen closed
•Drawerhandlepermanentlybondedtotemperedglass
• Drawerglides inandoutsmoothlyandprecisely-removesfor
cleaning
• Washablefoamfilter
• Installsinstandard30"or36"wide,flushorrecessedbottom-styled
cabinets
• Compactblowerhousing-permitsuseofcabinetshelfspace
• Includesdamper/ductconnector
• Choiceof3colorsand 2 sizes:
Model15300130"White Model15360136"White
Model15302330"Black Model15362336"Black
Model15300230"Biscuit Model15360236"Biscuit
Model15300430"StainlessLook Model15360436"StainlessLook
BrushedAlluminum BrushedAlluminum
HVI-2100 CERTIFIED RATINGS comply with new testing
technologies and procedures prescribed by the Home Ventilating
Institute,foroff-the-shelfproducts,astheyareavailabletoconsumers.
Product performance is rated at 0.1 in. static pressure, based on
tests conducted in AMCA’s state-of-the-art test laboratory. Sones
areameasureofhumanly-perceivedloudness,basedonlaboratory
measurements.
