NuTone RL6200 Series User manual

REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
NuTone, Inc., 4820 Red Bank Road, Cincinnati, OH 45227 (1-800-543-8687)
Architectural & Engineering Specifications
August 2005
Two-Speed Non-Ducted
Range Hood
MODEL RL6200 SERIES
DESCRIPTION
• Rocker-type fan and light switches.
• Polymeric blade and light lens (accepts up to 75W bulb).
• Non-ducted filter – effective non-ducted filtration system removes
smoke and odors.
• Mitered sides and hemmed bottom for safety and good looks.
• Contemporary styling in White, Almond, White/White, Black (30”
and 36”) and Stainless Steel.
• Available in 24”, 30”, 36”, and 42” widths.
50H 99042972B
VOLTS AMPS RPM
120 2.0 2850
INSTALLATION
Complete installation instructions are included with each Range
Hood.
ARCHITECT’S SPECIFICATION
Non-Ducted Range Hood shall be NuTone Model RL6200 as
manufactured by NuTone according to specifications listed:
• Unit shall be non-ducted and have a non-ducted filter.
• Motor to be permanently lubricated. RPM not to exceed 2850.
• Unit shall have a two-speed fan switch and separate light switch.
• Sides shall be mitered and bottom edge hemmed – with no sharp
edges.
• Unit shall be U.L. listed.
SPECIFICATIONS
