NuTone RM604201 User manual

RMP Series
Backsplash
(Optional)
SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted By Date
70D 99043133D
RM60000 SERIES
PRO-STYLE
RANGE HOOD
(Original Rangemaster)
Provides high ventilation and durable construction
to meet the needs of professional-quality residential
cooktops.
A complete installation requires several optional compo-
nents. Refer to page 2 when planning your installation
FEATURES
HOOD:
•Widths - 30” to 72” in 6” increments
•Finishes - Stainless Steel*, White**, and Black** appli-
ance colors
•Appliance colors in 54”, 60”, 66” & 72” widths are Spe-
cial Orders
•Grease lters are dishwasher safe
•Dual food warming lamps (BR40 Size, 250W, Infrared
- purchase separately)
•Three-level cooktop lighting (Uses three, 50W,
PAR 20 halogen lamps - purchase separately)
•Solid-State, innite speed blower control with speed
memory
•Exclusive, Broan Heat Sentry™ turns blower ON to
HIGH speed when excess heat is detected
BAFFLE FILTER KIT:
RBF Series (Optional)
•Available for all hood widths
BACKSPLASH:
RMP Series (Optional)
•Widths - 30” to 72” in 6” increments
•Stainless Steel* construction - protects back wall and
wipes clean easily
•Two, removable, dual-position food warming / condi-
ment storage shelves
SOFFIT CHIMNEY:
RMN Series (Optional)
•Widths - 30” to 72” in 6” increments
•Finishes - Stainless Steel*, White**, and Black** appli-
ance colors
•Appliance colors in 54”, 60”, 66” and 72” widths are
Special Orders
•Recommended for use when installation location has no
soft
RM60000 Series
Hood
RMN Series Sof-
fit Chimney
(Optional)
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
NuTone, Inc., 4820 Red Bank Road, Cincinnati, OH 45227 (1-800-543-8687)
Broan-NuTone Canada, Inc., 1140 Tristar Drive, Mississauga, Ontario L5T 1H9 (1-888-882-7626)
Intended for
domestic
cooking only.
* 22 gauge, type 430
stainless steel
** 22 gauge, painted
galvanneal

HL0075
- 4 -
RMP SERIES BACKSPLASH
(Stainless steel wall covering
with warming shelves. Optional)
Model 415
(7” round adjustable elbow)
Model 427
(4
1
/ 2 ” x 18
1
/ 2 ”
to 10” Round,
6” high - lateral
Model 423
(4
1
/ 2 ” x 18
1
/ 2 ” to
10” Round - vertical
Model 424
(4
1
/ 2 ” x 18
1
/ 2 ” to
10” Round - horiz.
front/rear
Model 454
(4
1
/ 2 ” x 18
1
/ 2 ”
to 10” Round -
horiz. /right
Model 453
(4
1
/ 2 ” x 18
1
/ 2 ”
to 10” Round -
horiz. /left
RM60000
SERIES HOOD
(Canopy with
blower controls
& lighting.
Required for all
installations.)
OPTIONAL
SOFFIT CHIMNEY
RMN SERIES
-RM60000 SERIES RANGE HOOD SYSTEM -
INTERNAL BLOWERS
Model 437
(High capacity roof cap)
Model 441
(10’’ Round wall cap)
Model 634 or 644
(roof cap)
Model 647
(7” Round wall cap)
Model 407
(7” round duct—2 ft. sections)
Model 410
(10” round duct—2 ft. sections)
MODEL RM325H
BLOWER/ROUGH-IN KIT
(600 cfm interior blower &
rough-in plate)
MODEL RM326H
BLOWER/ROUGH-IN KIT
(1200 cfm interior blower
& rough-in plate)
Model 418
(10” round adjustable elbow)
OPTIONAL
BAFFLE FILTERS
RBF SERIES
NOTE: In addition to the blower models shown, the
RM60000 Series Hood is also compatible with older
internal blowers Models 325H & 326H. Discard the
installation instructions for those blowers, and contact
Technical Support to obtain replacement instructions.

- 5 -
HL0076
RMP SERIES
BACKSPLASH
(Stainless steel wall
covering with warming
shelves. Optional.)
-RM60000 SERIES RANGE HOOD SYSTEM -
EXTERNAL BLOWERS
332KR in-line and exterior blower
rough-in kit - Purchase separately.
Model 418
10” Round
adjustable elbow
(optional)
Model HLB3 (280 cfm)
in-line blower
(includes one 8” to 10”
round transition)
Model 331H (600 cfm)
or 332H (900 cfm)
exterior blower
Model 335 (1200 cfm)
or 336 (1500 cfm)
exterior blower
Model 441
(10” Round
wall cap)
Model 437
(High capacity roof cap)
Model 441
(10” Round wall cap)
Model 421
(10” Round vert.
in-line damper)
Recommended
for use with
exterior blowers
Model 410
(10” Round duct
—2ft. sections)
Model HLB6 (600 cfm)
in-line blower
(includes two 4½” x 18½”
to 10’’ round transitions)
Model HLB9 (800 cfm)
or HLB11 (1100 cfm)
in-line blower
(includes two 8” x 12” to
10’’ round transitions)
RM60000
SERIES HOOD
(Canopy with
blower controls
& lighting.
required for all
installations.)
OPTIONAL
SOFFIT CHIMNEY
RMN SERIES
OPTIONAL
BAFFLE FILTERS
RBF SERIES
