NUTRICHEF PKTWC36SL User manual

PKTWC36SL
Hot & Cold Water Cooler Dispenser System,
Thermoelectric Cooling
TopLoadingWaterCoolerDispenser

www.NutriChefKitchen.com
PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE USE
PARTS NAME
www.NutriChefKitchen.com
2
Water Tank Support
Indication Panel
Hot water faucet
Cool water faucet
Drip tray
Heating switch (red)
Cooling switch (green)
Power cord

L
E
N
cold switch
refrigeration
components
green
red
hot switch
heating thermostat
self-reset
electric heating pipe
overheat protector
hand-reset
www.NutriChefKitchen.com
CIRCUIT DIAGRAM
Attentions
1. Put the unit on the stable at surface in
the cool dry room, escape from direct
sunshine. Keep the unit at least 20 cm
away from the wall and no easy-burned
articles near the dispenser. The unit is not
t for using at outdoor or the place with
water spray.
2. Moving models with compressor can’t
be put up and down or slope to 45° for
avoiding destruction or accident happening.
3. Pull out the plug and drain out the rest water
if its not going to be used for a long time.
When the electric parts is working under
0 degree and cause ice jam, close cooling
switch for 4 hours and then it can be opened
for continuous working.
4. Do not start and stop the unit by inserting or
pulling out the plug. Don’t lengthen the
power cord to avoid re.
5. For avoiding dry operation to destroy the
parts, please push the hot water faucet till
the water ow out, then start the power
and connect the heating switch.
www.NutriChefKitchen.com
3

www.NutriChefKitchen.com
6. Use three-core outlet earthing plug and
operate reliable switch for leakage
protection.
7. If hot and cold water will not be used for
a long time, please close the heating and
cooling switch for power saving.
8. Do not clean the unit with gas oil or other
organism solvent, do not wash the unit
with water or spraying water. Please clean
the dirt timely with spring water.
9. When using purifying water tank, please check the connection between the
unit and water tank, and the sealed condition of the tank, otherwise will cause
water leakage.
10. Models with compressor shall be restarted 3 minutes later when the cooling
switch is closed or power o.
11. The cooling temperature-controller has been adjusted, please do not do
adjustment freely.
12. The power cords connected by Y frame, the cords shall be exchanged by
manufacturer or professionals appointed when destroyed.
FUNCTION INTRODUCTION
1. Cooling and heating function, manufacture cool water, it ts for 3-5 gallon
water tank and purifying tank.
2. This water dispenser installed with 20 litres large capacity storage cabinet,
and the support weight mainly reach 4 kgs.
3. With top quality stainless steel, the inner tank is long lifespan and little water
scale.
4. Integrative door design, more stable in performance.
5. Multiple zones design for storage cabinet, brings you more colorful life.
USAGE STEPS
1. Tear o the labels on the water tank cover.
2. Insert the bottle in the tank support vertically. Push red hot water faucet till
water ow out.
3. Connect with power and turn on the heating/cooling switch, the unit is on
working condition.
4. When the unit is working, (power, heating and cooling) the lights director will
www.NutriChefKitchen.com
4

www.NutriChefKitchen.com
be in corresponding conditions (please see director lights description on the
indication panel).
5. When the water is used out, please take out the tank vertically and exchange
another tank of water.
MALFUNCTION EXAMINATION
The units are working well under the following conditions, the users may use
them with no worries:
1. It is normal to have some slight noise when the unit is heating.
2. When the hot water tank is heating without water, the dry-boiling protection
device will be break and can not be reset except operated by professionals.
3. It is normal for slight noise when the compressor is working（for models with
compressor cooling only. You will hear ”kata” sound when the compressor is
turned ON or OFF.
4. The cooling speed may be slow when the ambient temperature is high.
TROUBLESHOOTING GUIDE
1. Above is the judge and examination of usual malfunctions.
2. Please do not open or maintain the unit by yourself for avoiding dangers.
www.NutriChefKitchen.com
5
No. Malfunctions Reasons Solutions
1
Unsuitable
water
temperature
1. Consume too much
water in some short
time,
2. No power
1. Wait a moment before
taking water,
2. Connect the power and
switch on
2
No water from
water faucet
1. No water in tank
2. Hole was blocked
up by tank cover
paper
1. Exchange another tank
of water
2. Ger rid of waste paper,
tear oer the label on the
tank cover and insert the
tank
3 Water-leak from
tank support
Water tank is broken Exchange water tank
4 Big noise The unit is not set at
and stable
Put the unit on the at and
stable surface
5 No water from
cool water
faucet
Ice jam Close cooling switch for
4 hours

www.NutriChefKitchen.com
CLEANING AND MAINTENANCE
Remark: Cut o the power for following operation to avoid accident happening.
1. The washing and water drainage method as:
Put the water tank into the support vertically, open the tap, ow out 1 litre
water and then take down the water tank. Take out the water stopple on the
back or bottom of the unit. And drain out all of the rest water, then screw up
the stopple, the unit may start to work.
Attention: The temperature of the hot water tank is high, so operate carefully to
avoid being burnt.
2. Use the neutral daily use solvent to clean the unit surface with no friction.
Attention to avoid water owing into the unit.
If you want to x the unit, please operate it as the following steps:
1. Please discharge the screw on the left and right bottom awarding to the
following indication.
2. Use screw to rivet the two adapter plates to the left and right bottom of the
water dispenser.
3. Use screw to rivet the adapter plate to the oor or tabletop on which the
water dispenser is placed.
CAUTIONS
1. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been supervision or instruction concerning use
of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
4. Do not damage the fridge circuit.
5. Do not store explosive substances such as aerosol cans with a ammable
propellant in this appliance.
www.NutriChefKitchen.com
6

www.NutriChefKitchen.com
FEATURES:
• Child Safe, Innovative and Stylish Glass Panel
• Time-Saving and Very Convenient To Use
• Automatic Water Dispenser System
• Simple Electric Plug-in Design
• Ability to Dispense Both Hot & Cold Water
• Simple & Hassle-Free Operation
• Universal Compatibility with 3 or 5-Gallon Bottles/Jugs
• Convenient Countertop / Tabletop Design
• Top-Loading Water Bottle Style
• LED Indicator Lights
• Ultra-Quiet Operation
• Convenient Spill Guard Drip Tray
WHAT'S IN THE BOX:
• Water Dispenser
TECHNICAL SPECS:
• Construction Material: Engineered ABS Housing + Coated Steel
• Rated Voltage/Frequency: 110V/60Hz
• Rated Heating Power: 500W
• Rated Cooling Power: 80W
• Rated Cooling Current: 0.8A
• Cold Water Temperature: 42.8-50° Fahrenheit (6 - 10° Celsius)
• Hot Water Temperature: 185-203° Fahrenheit (85 - 95° Celsius)
• Rated Cooling Capacity: 1.5L/hr (6°C-10°C) (42.8°F-50°F)
• Rated Heating Capacity: 4.5L/hr (85-95°C) (185°F-203°F)
• Cold Tank Capacity: 2L
• Hot Tank Capacity: 700ml
• Power Cable Length: 5.9’ft.
• Product Dimension (L x W x H): 12.2'' x 12.6'' x 18.9'' -inches
www.NutriChefKitchen.com
7
