NVX XBTL6 User manual

BLUETOOTH®
WIRELESS ON-EAR
STEREO HEADPHONES
USER MANUAL
XBTL6

1
NVX HEADPHONES
THANK YOU FOR CHOOSING NVX
You have joined an elite group of audiophiles and professionals
who rely on NVX to deliver crisp and clear sound. After a long day
of listening to music on the XBTL6 Bluetooth®headphones, their
convenience and comfort will become abundantly clear. Another great
benet is they can be used as wired (3.5mm) headphones. Therefore
you can listen to them wirelessly or plugged-in to enjoy true NVX sound
and comfort built-in to each one of our products!

Visit: nvx.com | Call: 213.444.1689 |15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403 2
BLUETOOTH |XBTL6
SPECIFICATIONS
HEADPHONE XBTL6
Frequency Response 20Hz-20kHz
Impedance 32+/-15% Ω
Sensitivity @ 1kHz 110+/-5dB
Distortion ≤ 1% @ 1KHz
Rated Power Input 10mW
Driver Diameter 40mm
Net Weight ~0.35 lbs (160g)
Transmission Range 30ft (10 m)
Music Playback Time (Bluetooth®)10hrs
Stand-by Time ≤ 30 Days
Battery 380mAh Li Polymer
Charging time 2.5hrs (max)
Bluetooth Version V3.0
ACCESSORIES
•(1) USB Charging Cable
•(1) 3.5 mm Audio Cable
•(1) Instruction Manual

3
NVX HEADPHONES
1Multi-Purpose Button
•On/Off (Hold)
•Play/Pause (Tap)
•Answer/Hang Up (Tap during calls)
2Volume Down / Previous Track
• Decrease Volume (Hold)
• Re-start Track (Tap once)
•Previous Track (Tap multiple times)
3Volume Up / Next Track
•Increase Volume (Hold)
•Next Track (Tap)
4Microber Leather Headband
5ComfortMax™Cushion Earpads
• Heat-sensitive, low-rebound foam padding
• Comfortable, exible protein leather
6Micro USB Charger Port
73.5mm Audio Jack
8Microphone
9LED Indicator
• Flashing Blue (Active/Pairing)
• Red/Pink (Charging)
FEATURES
1
2
7
5
6
4
8
9
3

Visit: nvx.com | Call: 213.444.1689 |15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403 4
BLUETOOTH |XBTL6
CONTROLS
POWER ON/OFF
•POWER ON: hold (~3 seconds)
Multi-Purpose Button until LED ashes blue.
•POWER OFF: hold (~3 seconds)
Multi-Purpose Button until LED stops
ashing blue.
CHARGING*
•Connect the headphone to a PC or power
adapter using the USB charging cable.
•The LED light will alternate red and pink when on
and will remain solid red when powered off while
headphones are charging.
•The LED light will turn off when the headphones
are fully charged.
PAIRING
•Headphones will be in pairing mode while on.
•Place the headphones and the mobile phone/
music player within 3 ft. (1 Meter) of each other
when pairing.
•Open the Bluetooth® settings on your device and
select “XBTL6” from the Bluetooth®device list.
•Some devices require a pin code. If this is the
case, enter the code “0000.”
•Once your devices are successfully paired, the
LED light will ash blue at a slower pace (once
every few seconds).

5
NVX HEADPHONES
PLAYBACK**
•PLAY / PAUSE: Tap Multi-Purpose Button
•TRACK CHANGE:
- Press the Volume Down / Previous Track
Button once to re-play previous track. Press
twice to go back a track.
- Press the Volume Up / Next Track Button
to skip to the next track.
•VOLUME:
- Hold (~3 seconds or more) Volume Down /
Previous Track Button to lower the
volume level
- Hold (~3 seconds or more) Volume Up /
Next Track Button to raise the volume level.
CALL**
•ANSWER / END: Tap Multi-Purpose Button
•VOLUME:
- Hold (more than 3 seconds) Volume Down
/ Previous Track to lower the volume level
of the call.
- Hold (more than 3 seconds) Volume Up /
Next Track to raise the volume level of the call.
WIRED AUX MODE
•When the headphones are in Bluetooth mode
or powered off, plug-in the 3.5mm stereo audio
cable, to automatically enter into aux-in mode.
CONTROLS CONT.
*Controls will not function while charging.
**Controls will not function with wired aux mode.

Visit: nvx.com | Call: 213.444.1689 |15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403 6
BLUETOOTH |XBTL6
•This limited warranty does not cover failure of the product
resulting improper installation, misuse, abuse, accident,
neglect, mishandling, or wear from ordinary use or
environmental deterioration.
•This limited warranty does not cover cosmetic damage, including
paint damage, or consequential damage to ordinary use or
environmental deterioration.
•This limited warranty does not cover cosmetic damage, including
paint damage, or consequential damage to other components
or premises which may result for any reason from the failure of
the product.
•This limited warranty is null and void for products not used in
accordance with NVX instructions.
•This limited warranty is null and void for products with altered or
missing serial numbers and for products not purchased from an
authorized dealer.
•This limited warranty terminates if you sell or otherwise transfer
this product to another party.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO
STATE, JURISDICTION TO JURISDICTION, OR COUNTRY TO COUNTRY. NVX’S RESPONSIBILITY FOR MALFUNCTIONS AND DEFECTS IN
HARDWARE IS LIMITED TO REPLACEMENT OR REPAIR AS SET FORTH IN THIS WARRANTY STATEMENT.
WARRANTY
NVX warrants to the original retail purchaser that this product is to be free from defective materials and workmanship for a period of two (2) years
from the date of purchase, if it is properly used and maintained. If this product proves defective in either material or workmanship, NVX, at its
discretion, will (a) repair the product, or (b) replace the product, at no charge for parts or labor. If the product model is no longer available and
cannot be repaired effectively or replaced with an identical model, NVX at its sole option may replace the unit with a current model of equal or
greater value. To obtain a repair or replacement under the terms of this warranty, please return to dealer rst, if possible, and the dealer will direct
you accordingly for repairs or replacement. You will be required to submit a copy of the original receipt. Return shipping for exchanges/repairs is
the sole responsibility of the original retail purchaser.
LIMITATIONS:
WARRANTY CONTINUES ON NEXT PAGE

7
NVX HEADPHONES
ALL EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN TIME TO THE TERM OF THIS WARRANTY. SOME
STATES, JURISDICTIONS, OR COUNTRIES DO NOT ALLOW THE EXCLUSION OF CERTAIN IMPLIED WARRANTIES OR CONDITIONS,
OR LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THIS LIMITATION MAY NOT APPLY TO YOU.
NVX DOES NOT ACCEPT LIABILITY FOR SPECIAL, INDIRECT, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING WITHOUT
LIMITATION, ANY LIABILITY FOR THIRD PARTY CLAIMS AGAINST YOU FOR DAMAGES OR FOR PRODUCTS NOT BEING AVAILABLE FOR
USE. THE MAXIMUM LIABILITY FOR WHICH NVX MAY BE RESPONSIBLE WILL BE NO MORE THAN THE AMOUNT YOU PAID FOR THE
PRODUCT THAT IS THE SUBJECT OF THE CLAIM. SOME STATES, JURISDICTIONS, OR COUNTRIES DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION
MAY NOT APPLY TO YOU.
Warranty Outside the U.S.
The Warranty on this product shall comply with applicable law when sold to a consumer outside of the United States. To obtain any applicable warranty
service, please contact the dealer from which you purchased this product, or the distributor that supplied this product.
WARRANTY CONT.

Visit: nvx.com | Call: 213.444.1689 |15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403 8
BLUETOOTH |XBTL6
•Receive your RA Number from NVX online at nvx.com/support
•Package all defective components in the original packaging
(if available) or in a package that will prevent shipping damage.
•Package the original packaging in an additional shipping container
to avoid shipping damages and to comply with most shipping
couriers such as UPS and FedEx.
•Insure your return at the price paid as NVX is not responsible for
insurance losses or damages occurring in shipment to our facility.
•Clearly mark RA Number on the outside shipping container.
•Return only defective components as the return of functioning
items increases your return freight charges.
-Non-defective returns or products not eligible for warranty service
will be returned freight collect.
•Include a copy of the original receipt with the purchase date clearly
visible, and a “proof-of-purchase” statement listing the customer’s
name, dealer’s name and invoice number, and product purchased.
-Warranty expiration on items without proof-of-purchase will be
determined from type of sale and the manufacturing date code.
•Ship your package freight prepaid to the address below. Items
sent freight collect or COD will be refused.
NVX
Attn: Returns
10645 Freeport Dr.
Louisville, KY 40258-1873
Failure to follow the steps listed above may void your warranty. Any questions can be directed via
email to [e-mail] or via mail at the address listed above.
WHAT TO DO IF YOU NEED WARRANTY OR SERVICE
Defective products should be returned to the place of purchase. Your authorized NVX dealer is trained
to handle and expedite any warranty claim. Assistance in locating an authorized dealer can be found
at nvx.com or by contacting NVX directly.
Alternatively, if it becomes necessary for you to return defective product directly to NVX, please refer to
the following instructions for warranty service:

9
NVX HEADPHONES
NOTES

Visit: nvx.com | Call: 213.444.1689 |15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403 10
BLUETOOTH |XBTL6
Authorized Dealer’s Name:
Purchase Date:
Model Number:

Visit: nvx.com | Call: 213.444.1689 | 15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403
