NWI NTS03 User manual

OWNER'S MANUAL
NTS03
TOTAL STATION

This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Caution: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
MPE caution
To satisfy FCC RF exposure requirements, a separation distance of 20 cm or more should be
maintained between the antenna of this device and persons during device operation.
To ensure compliance, operations at closer than this distance is not recommended
User Safety
WARNING:
Carefully read the Safety Instructions and Product Manual before using this
product. The person responsible for the instrument must ensure that all
users understand and adhere to these instructions.
FCC Compliance

1
Content
1. Use of instrument ..........................................................6
2. Names and functions of the components.....................9
2.1 Names of the components.............................................9
2.2 The information of the displays...................................11
2.3 Functional keys under the basic measurement mode ..15
2.3.1Angle mode (including three pages).................15
2.3.2 Distance measurement mode............................16
2.3.3 Coordinate measurement mode........................17
2.3.4 Explanation of saving data...............................18
2.4 Star key [★] mode.......................................................18
3. Initial setup..................................................................20
3.1 On & Off .....................................................................20
3.2 Set up the tilt correction of horizontal and vertical
angles ........................................................................................20
3.3 Set up the target Type..................................................20
3.4 Set up the Reflecting Prism Constant..........................20
3.5 Signal...........................................................................21
3.6 Set up theAtmospheric Correction .............................21
3.6.1 Set up theAtmospheric Correction value (ppm)
directly...............................................................................22
3.6.2 Calculate the Atmospheric Correction out with
temperature and pressure sensor........................................22
3.7 The Correction of the Atmospheric refraction and the
Earth Curvature.........................................................................23
3.8 Set up the minimum reading of the angle....................23
3.9 Set up the minimum reading of the distance...............23
3.10 Setup of Automatic Shutdown ..................................24
3.11 Set rectangle beep......................................................24
3.12 Set up theAddictive Constant and the Multiplying
Constant ....................................................................................24

2
3.13 Selecting Data File....................................................25
4. Preparations before measurements......................26
4.1 Unpacking and storing instruments.............................26
4.2 Set up the instrument...................................................26
4.2.1 Using plummets to center and level (align)......26
4.2.2 Using centering device to center ......................27
4.3 Loading and unloading of battery ...............................28
4.4 Reflecting Prism..........................................................29
4.5 Loading and unloading of the pedestal........................29
4.6 Adjusting eyepiece lens of the telescope and aiming the
target..........................................................................................29
4.7 Entering letters and numbers.......................................29
4.8 Notice for using U disk ...............................................32
5. Angle mode...................................................................33
5.1 Save.............................................................................33
5.2 0set..............................................................................34
5.3 Hset .............................................................................34
5.4 Hold.............................................................................34
5.5 Angle by repetition......................................................35
5.6 Slope (V%)..................................................................36
5.7 H-Bz............................................................................36
5.8 L/R...............................................................................37
5.9 V mode........................................................................37
6. Distance mode..............................................................38
6.1 Save.............................................................................38
6.2 Meas............................................................................38
6.3 Mode ...........................................................................38
6.4 Offset...........................................................................39
6.5 Stake out (S.O)............................................................39
7. Coordinate mode.........................................................40
8. Offset mode..................................................................43

3
8.1 Offset (Angle) .............................................................43
8.2 Offset (Dist1)...............................................................44
8.3 Offset (Dist2)...............................................................45
8.4 Offset (Plane) ..............................................................46
8.5 Offset (Column) ..........................................................47
9. Menu.............................................................................50
9.1 Surveying ....................................................................50
9.1.1 Operation..........................................................50
9.1.2 Preparation .......................................................51
9.1.3 Station and backsight........................................51
9.1.3.1 Example for set station..................................52
9.1.3.2 Example for setting angle..............................54
9.1.4Measurement.....................................................56
9.2Staking out....................................................................57
9.2.1 Staking out points.............................................58
9.2.2 Polar coordinates..............................................60
9.2.3 Resection..........................................................62
9.3File manager.................................................................65
9.3.1 File Dialogbox..................................................65
9.3.2 Import...............................................................68
9.3.2.1 Import from PC .............................................68
9.3.2.2 Import from USB ..........................................70
9.3.3 Export...............................................................71
9.3.3.1 Export to PC..................................................71
9.3.3.2 Export to USB...............................................72
9.3.3.3 Export with Mini USB port...........................73
9.3.4 Format disk.......................................................74
9.3.5 Information of disk (MenInfo) .........................74
9.3.6 Update ..............................................................74
9.4 Program.......................................................................76
9.4.1 Remote height (REM)......................................77

4
9.4.1.1 ―Input T.H‖ Mode .........................................77
9.4.1.2 ―Without T.H‖ ...............................................78
9.4.2 Resection..........................................................79
9.4.3 MLM................................................................79
9.4.4 Coord.Z ............................................................80
9.4.5Area measurement............................................82
9.4.6 Projection .........................................................83
9.4.7 Roadway...........................................................84
9.5 Options........................................................................84
9.6 Adjust ..........................................................................86
9.6.1 Calibrate I.E .....................................................86
9.6.2 Calibrate TILT:X..............................................86
9.6.3 Calibrate TILT:Y..............................................88
9.7 Config (Instrument constant).......................................89
9.8 Select code file............................................................89
9.9 Gird scale ....................................................................89
9.10 Communication.........................................................90
10. Roadway.....................................................................91
10.1 Inputting Roadway....................................................91
10.1.1 Horizontal alignment......................................91
10.1.1.1 Element method...........................................91
10.1.1.2 Intersection method.....................................93
10.1.2 Vertical alignment...........................................94
10.2 Stake out (road).........................................................95
10.2.1 Selecting Roadway File..................................96
10.2.2 Setting station and BSS(backsight point).......97
10.2.3 Stake out road.................................................97
11. Adjustments and Corrections...................................99
11.1 Tubular Level ............................................................99
11.2 Circular Level............................................................99
11.3 Reticle of the telescope............................................100

5
11.4 The Perpendicularity of Collimation axis and Cross
axis (2C)..................................................................................101
11.5 Vertical plate index zero automatic compensation ..102
11.6 Vertical index error (angle i) and set vertical index 0
.................................................................................................102
11.7 Centering device......................................................103
11.8 Addictive constant (K).............................................104
11.9 The parallelism of collimation axis and
photoelectricity axis ................................................................105
11.10 Non-prism ranging ................................................105
12. Technical parameters..............................................107
AppendixA File format introduction..........................109
Appendix B Bi-directional communication................. 110

6
1. Use of instrument
The total station is such an instrument that measures the azimuth
and distances to destination and can calculate the destination point
coordinates automatically. It plays an important role in the economic
construction and national defense construction. General Survey,
exploration and mining of minerals, the construction of railways,
roads, bridges, irrigation, urban planning and construction is driven
by electronic total station measurements. In the building of national
defense, such as battlefield preparations, harbor, forts, airfields, bases
and military construction projects, and so on, must be based on a
detailed and accurate geodetic. In recent years, electronic total station
is a large precision engineering, shipbuilding and aviation industries
and other aspects of effective tools for precise positioning and
installation.
The series total station is equipped with absolute code dial
system, integrated-circuit-control-board ranging item and
microcomputer for measurements of angle and distance and for
calculation, display, depositing and etc. It can exhibit horizontal and
vertical angle, slope and horizontal distance and altitude difference
simultaneously. Furthermore, it can be set to measure under different
mode (e.g. Angle mode, Distance mode).It is even designed for you
specializing in construction projects with non-prism ranging. The
non-prism ranging can be comprehensively used in measuring
three-dimensional coordinates, position determination, remote
elevation measurement (REM), verticality, pipeline positioning,
cross-section measurement etc. It also meets requirements for
trigonometrical control survey, topographic survey, cadastre and real
estate survey.
Standard Warranty Terms
Warranty period for NTS03 is 36 months from date of purchase. NWI
warrants this instrument made by Northwest Instrument to be free
from manufacturing defects in materials and workmanship. For

7
claims to be made under this warranty, the instrument must be
inspected by Northwest and the defect must be proven to NWI‘s
satisfaction. At the time that it is proven to the NWI‘s satisfaction that
the instrument is defective, it shall be repaired or replaced, at the
NWI‘s option and returned to the original purchaser at no cost to
them. NWI‘s sole obligation and the Buyer‘s sole remedy are limited
strictly to repair or replacement with these provisions below:
A. The instrument is returned to Northwest, properly packaged with
the transportation charges prepaid and insured and accompanied by
proof of ownership. Receipt and previous registration is required.
B. Except for ordinary wear and tear resulting from normal usage, the
instrument, upon inspection by NWI is determined to be defective in
material and/or workmanship. Under no circumstances shall NWI be
liable for any consequential, incidental or contingent damages
whatsoever.
Limitations and Exclusions
A. This warranty does not apply to instruments subject to negligence,
abuse, accident, improper operation, instruments damaged in transit
or damage due to unauthorized service repairs made by someone
other than Northwest or other Northwest authorized service personnel.
Circumstances beyond Northwest Instrument s control cannot be
warranted.
B. This warranty does not apply to regular required maintenance such
as cleaning, adjusting, lubricating or calibrating unless required as a
result of a defect in workmanship or materials. If, upon examination
of the instrument, NWI determines that additional repair services are
required and not covered under this warranty, NWI shall notify the
Buyer of such repair charges and proceed only after authorization has
been received.
C. This warranty does not apply to instruments damaged in transit to
or from Northwest Instrument or any authorized repair center.

8
Other remedies may or may not be available for transportation
damages.
These designs, figures and specifications of NTS03 are subject
to change without notice. NWI shall not be held liable for damages
resulting from errors in this instruction manual.

9
2. Names and functions of the components
2.1 Names of the components
Handle
Objective lens
keys
Display
Coarse sighting device
Base
SD card port
serial port
connector
Plate level
Vertical clamping
and tangent screw

10
Horizontal
axis center
Battery
Focusing knob
eyepiece
Base
Horizontal clamping
and tangent screw
Leveling screw

11
2.2 The information of the displays
Symbols on the keyboard
Keys
Name Function
ANG Angle
measurement
In the basic interface,enter the angle
measurement . Under other modes, move
the cursor up or up to select the options.
DIST Distance
measurement
In the basic interface，enter the distance
mode
In the other modes，Move the Cursor down
or down to select the options.
CORD Coordinate
measurement
In the basic interface，enter the coordinate
mode
In the other modes, move the cursor left or
page up.
MENU Menu key
Under the basic measurement
interface,down to the menu interface.
Under the other modes ,move the cursor
right or page down
Power key Power on/off

12
F1~F4 Soft Keys The characters at the bottom line of the display indicate the meaning of the soft
keys.
0~9 Number keys Input numbers or characters or choose the
menu
★Star key
In any measurement interface, you can
enter the star key interface .You can set the
contrast, lighting compensator and
parameters of distance measuring .
The side
key Enter
Receive and save the data input in the
dialogue and end the dialogue.
Save the current measurement data under
the basic measurement interface.
ESC Exit /quit End the dialogue box without saving the
input，and return to the previous step
◄► Left /right change the option in the select box
Data list page
▲▼ Up /down Move the Cursor up and down in order.
Turn the page under the basic measurement.
0～9 Number
Input number and characters and select one
of menu.
―0‖: Enter the electronic bubble interface
under the basic measurement.
·~ - Symbols Enter symbols, decimals and signs;
Enter the interface for input height.
Symbols on the display
Symbols Indication
Vz Zenith Mode
Vo The mode that the vertical is displayed as zero when the
telescope is level in normal
Vh Vertical angle Mode (it is 0°00′00″when the telescope is
level. The angle of elevation is positive and the angle of
depression is negative.)
V% Slope Mode
HR Horizontal angle (right angle). dHR means the angle
difference of setting out.
HL
Horizontal angle (anticlockwise increment)
HD Horizontal distance. dHD is to stake out horizontal
distance difference.
VD Elevation difference. dVD is to stake out difference
between elevation differences.

13
SD Slope distance. dSD is to stake out differences between
slope distances.
N Northing. dN is to stake out differences between
north-coordinates.
E Easting. dE is to stake out differences between
East-coordinates.
Z Elevation. dZ is to stake out differences between
Z-coordinates
EDM(Electronic Distance Measurement) is in progress.
m Unit in meters (metric units)
ft Units in feet
fi Units in American feet
M Units inMIL
X The magnitude of which is along the baseline in a point
projection measurement. The positive direction is from the
starting point to the
terminal.
Y The magnitude of which deviates from the base line
horizontally in a point projection measurement.
Z Altitude of the target in a point projection measurement.
MdHD Maximum error of evaluated distance
Reference functions of common soft key
Soft key
reference Functions
B.S (Backspace)Delete one last character on the left of
the inserter in the edited column.
Clear
Delete all typed in the edited column.
Enter End up the input in the current edited column and the
inserter goes to the next column. If there‘s only one
or no edited column in the dialogue box, the soft key
‗Enter‘ is also used to accept the input and exit the
dialogue box.
Input Go to Coordinate dialogue box and enter the
coordinates with keyboard
M.Pt Retrieval coordinates of points from measured file
K.Pt (Known) call coordinates of points from coordinate file
Search List the points in the current coordinate file to
provide to select the number for you.

14
View List out details of the current record
Info. Displays the name, code and coordinate of the
current station and back-sight station.
Settings Set the height of the instrument and the target
STA Enter coordinates of the station where instrument is
placed.
BSS Enter coordinates of the point where the target is.
Meas Start rangefinders to measure distance
Save Start rangefinders when being under the Coordinate
and Distance mode. Then save the result of this
measurement and name of point which is added by
one automatically. The result cannot be saved when
the compensator is over .(Tilt over)
Comp. Display the inclination (tilt) of the vertical axis
Light Turn on or off the backlight and the illuminating
brightness of reticle (at the same time).
Para. Set the atmospheric parameters, prism constant and
signals.

15
2.3 Functional keys under the basic measurement
mode
2.3.1 Angle mode (including three pages)
Vz:
HR:
Vmode
278°12′23″
159°54′05″
R/L
H-Bz 3/3
F1 3F4F2 F3
Vz:
HR:
Hset
278°12′23″
159°54′05″
0set
Save 1/3
F1 3F4F2 F3
Vz:
HR:
V%
278°12′23″
159°54′05″
Rep
Hold 2/3
F1 3F4F2 F3
[F4]
[F4]
[F4]
Page Soft key Reference Function
1
F1 Save Record the measured angle to the
selected file.
F2 0set Set the horizontal angle as 0°
F3 Hset
Set your desired horizontal angle
by inputting ,but the angle should not
be greater than 360°
F4 1/2 Display the second page of the
soft key functions
2
F1 Hold Lock the horizontal angle
readings.
F2 Rep Repeat to measure the horizontal
angle
F3 V% Switch between Vertical angle
and slop
F4 2/3 Display the third page of the soft
key functions
F1 H-Bz
Set the beep on or off when the
horizontal angle is 0°, 90°,180°，
270°

16
F2 R/L Switch between HR (horizontal
right/ clockwise) and HL (horizontal
left/ anticlockwise) mode
F3 VA
Vertical Angle Mode (altitude
angle（Vh）, Zenith（Vz）
F4 3/3 Display the first page of the soft
key functions.
The key [★] is used to set contrast, light, compensator and
parameters of distance measurement . It can work under the
basic modes.
2.3.2 Distance measurement mode
Vz:
HR:
Mode
278°12′23″
159°54′05″
Meas
Save 1/2
F1 3F4F2 F3
SD: m
m
m
Vz:
HR:
m/f/i
278°12′23″
159°54′05″
S.O
Offset 2/2
F1 3F4F2 F3
SD: m
HD: m
m
VD:
[F4]
[F4]
HD:
VD:
Page
Soft key
Reference Function
1 F1 Save Start distance measurement and
record the measured data into the selected
files (measurement file ‗File(.MEA)‘ and
coordinate file ‗File(.COO)‘are selected
in
surveying function
).
F2 Meas Start Distance Mode
F3 Mode Switch between four distance
measurement mode (single accurate
measuring (sngl)/ repeated accurate
measuring (rept)/ continue accurate
measur
ing
(cont)/ tracking (track)
)
F4 P1/2 Display the second page of the soft key
functions
2
F1 Offset Start offset measurement (eccentric
measurement)
F2 Stake Start staking out
F3 m/f/i Switch distance units between meters,
feet, feet&inch.
F4 2/2 Display the first page of the soft key
functions

17
2.3.3 Coordinate measurement mode
Vz:
HR:
278°1223
159°5405
F1 3F4F2 F3
N : m
E :m
mZ :
Vz:
HR:
278°1223
159°5405
F1 3F4F2 F3
N : m
E : m
mZ :
Vz:
HR:
278°1223
159°5405
F1 3F4F2 F3
N : m
E : m
mZ :
[F4]
[F4]
[F4]
Page Soft key Reference Function
1
F1 Save Start coordinate measurement and record
the measured data into the selected files
(measurement file ‗File(.MEA)‘ or
coordinate file ‗File(.COO)‘ are selected
in surveying function).
F2 Meas Start coordinate measurement
F3 Mode Switch between four distance
measurement mode [single accurate
measurement (sngl)/ repeated accurate
measuring (rept)/ continue measuring
(cont)/ tracking (track)]
F4 1/3 Display the second page of the soft key
functions
2
F1
Setting
Set target height and instrument height
F2 BSS Set coordinates of BSS (back-sight point)
and back-
sight angle
F3 STA Set coordinates for station
F4 P2/3 Display the third page of the soft key
functions
3
F1 Offset Start offset measurement (eccentric
measurement)
F2 S.O Stake out coordinates
F3 Aver. Set the times of average measurement
F4 3/3 Display the first page of the soft key
functions

18
2.3.4 Explanation of saving data
If you have never selected the measurement file and your first
time to use the [Save] soft key, a dialogue box of ‗Select file‘ would
appear to the screen. Mention that this is a good chance for you to
select all files that the instrument may use.
When finishing single measurement, a dialogue box asks you to
save the measured point and you may rename and code the points or
set target height. The key ‗ENT‘ will save the coordinates into
measurement files, and the key [★] save the coordinates in the
measurement file and coordinate file at the same time (according to
the mention of the display).
If you choose not to edit points, the points would be saved with
the present name, elevation and code .After saving, the name of the
point is added by one.
2.4 Star key [★] mode
On the measurement interfaces, pressing the key [★](star key)
can lead to a page as shown below.
Reflect : NP
F1 3F4F2 F3
Contrast:
4
EDM Mode: Single ±
Settings from the star key(★) are as followed:
●EDM Mode : press [±] to set the work mode of EDM. These
modes are “Single”, “Rept”, “Cont”, “Track”.Adjust
contrast : press [▲] and [▼];
●Adjust background light of the screen : press [F1] to open
the backlight ,then press [◄] to adjust light;
●Comp.: press [F2] to enter the display of electric bubble ,
then setting the compensator off; pressing [◄] [►] can
adjust the light of laser plumb;
●Reflect: Press [►] to set the reflector. The options of
reflector are switched between Prism ,Non- prism(NP) and
reflector board(RB);
●Laser: press [F3] to on or off the laser;
●Para.: Press the key [F4] to select ‗parameters‘. You can set
settings of prism const, PPM value and temperature and
