nwvox SIP-T29G User manual

Every call matters.
2216 36th Street |Suite 100 |Everett, WA 98201
1.877.208.9710 [e-mail]
GATEKEEPER
QUICK START GUIDE
Gigabit Color IP Phone
SIP-T29G

2nwvox.com
The following items are included in your package. If you find anything missing, contact
Northwest Vox.
IP Phone Overview
What’s in the box
Connect the handset and optional headset:
2
Handset Quick Start
Guide
Power Adapter
(Optional)
IP Phone
Handset Cord Ethernet Cable Stand
Wall Mount
Bracket
(Optional)
Continued
Note: The headset, Bluetooth USB dongle BT40 and wireless headset adapter EHS36 should be purchased
separately. The EXT port can also be used to connect the expansion module EXP39. For more information
on how to use the EHS36, EXP39 and BT40, refer to Yealink EHS36 User Guide, Yealink EXP39 User
Guide and Yealink Bluetooth USB Dongle BT40 User Guide.
Desk Mount Method
B
A
Note: You can aslo mount the phone to a wall.
For more information on how to attach the wall
mount bracket, refer to Yealink Wall Mount Quick
Installation Guide for Yealink IP Phones.
Assembling the Phone:
Attach the stand:
1

3nwvox.com
Assembly continued
Connect the network and power:
You have two options for network and power connections. Northwest Vox will
advise you on which one to use.
3
B
PoE (Power over
Ethernet)Option
A
AC Power
Option
PC Connection
(Optional)
PC Connection
(Optional)
Power Adapter
(DC 5V)
IEEE 802.3af compliant
PoE Hub/Switch
Note: If inline power (PoE)
is provided, you do not
need to connect the power
adapter. Make sure the
Ethernet cable and hub/
switch are PoEcompliant.
Startup
After the IP phone is connected to the network and supplied with
power, it automatically begins the initialization process. After startup,
the phone is ready for use. You can configure the phone via web user
interface or phone user interface.
Check with Northwest Vox if any error appears during the registration
process or a specific condition is required for your registration.
Register status icons on the LCD screen:
(Green)Registered (Gray)Register Failed (Yellow)Registering
