NXP Semiconductors MIMXRT1010-EVK User manual

Quick Start Guide
i.MX RT1010 Evaluation Kit

2
GET TO KNOW THE i.MX RT1010 EVK
Quick Start Guide
Figure 1: Front side of MIMXRT1010-EVK
TABLE 1: BOOT OPTIONS
BOOT_MODE[1:0](SW8-3 SW8-4) BOOT Type
00 Boot From Fuses (The boot ROM code uses the boot eFUSE settings only)
01 Serial Downloader(Download a Program Image to the chip over USB or UART)
10 Internal Boot (Execute the boot code from the internal boot ROM)
11 Reserved
SW8-1 SW8-2 SW8-3 SW8-4 Boot Device
OFF OFF ON OFF QSPI FLASH
Audio Jack
Boot Mode
Select
User button
POR Pin
reset
Debug USB
QSPI Flash
ON/OFF
USB OTG
i.MXRT1010
Power On
Reset
JTAG
Arduino and motor control interfaces

3
www.nxp.com
HOW TO GET STARTED
1
The evaluation kit is shipped with a
MIMXRT1010-EVK and a USB cable
(Micro B).
2
Connect the MIMXRT1010-EVK board
to a PC using the included micro USB
cable to USB connector J41.
The MIMXRT1010 EVK comes
preprogrammed with a demo which
flashes the LED on the board.
3
Explore more out-of-box demos and
download software and tools on
www.nxp.com/MIMXRT1010-EVK/
startnow.
4
Enjoy your design freedom with the
MIMXRT1010-EVK.

SUPPORT
Visit www.nxp.com/support for a list
of phone numbers within your region.
WARRANTY
Visit www.nxp.com/warranty for
complete warranty information.
www.nxp.com
NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of
their respective owners. © 2019 NXP B.V.
Document Number: IMXRT1010EVKQSG REV 0
Agile Number: 926-45852 Rev A
Get Started
Download installation
software and documentation
at www.nxp.com/MIMXRT1010-EVK.
