NXP Semiconductors NCX3310 User manual

UM11737
NCX3310 evaluation board
Rev. 1.0 — 22 August 2022 User manual
Document information
Information Content
Keywords NCx3310, NFC TAG IC, Automotive, Secure Car Access
Abstract This document describes how to get started and evaluate the NCx3310 using
an NCX3310 Evaluation Board.

NXP Semiconductors UM11737
NCX3310 evaluation board
Rev Date Description
v.1.0 20220822 Initial version
Revision history
UM11737 All information provided in this document is subject to legal disclaimers. © 2022 NXP B.V. All rights reserved.
User manual Rev. 1.0 — 22 August 2022
2 / 16

NXP Semiconductors UM11737
NCX3310 evaluation board
IMPORTANT NOTICE
For engineering development or evaluation purposes only
NXP provides the product under the following conditions:
This evaluation kit is for use of ENGINEERING DEVELOPMENT OR
EVALUATION PURPOSES ONLY. It is provided as a sample IC pre-
soldered to a printed-circuit board to make it easier to access inputs,
outputs and supply terminals. This evaluation board may be used with any
development system or other source of I/O signals by connecting it to the
host MCU computer board via off-the-shelf cables. This evaluation board
is not a Reference Design and is not intended to represent a final design
recommendation for any particular application. Final device in an application
heavily depends on proper printed-circuit board layout and heat sinking
design as well as attention to supply filtering, transient suppression, and I/O
signal quality.
The product provided may not be complete in terms of required design,
marketing, and or manufacturing related protective considerations, including
product safety measures typically found in the end device incorporating the
product. Due to the open construction of the product, it is the responsibility of
the user to take all appropriate precautions for electric discharge. In order to
minimize risks associated with the customers’ applications, adequate design
and operating safeguards must be provided by the customer to minimize
inherent or procedural hazards. For any safety concerns, contact NXP sales
and technical support services.
UM11737 All information provided in this document is subject to legal disclaimers. © 2022 NXP B.V. All rights reserved.
User manual Rev. 1.0 — 22 August 2022
3 / 16

NXP Semiconductors UM11737
NCX3310 evaluation board
1 Introduction
This board provides an easy and quick evaluation and development environment
for NCx3310 enabled applications, especially for those leveraging I2C leader, I2C
follower, Bluetooth Pairing, Energy Harvesting use cases. A broad selection of software
packages is available, which are based on modular examples. A broad selection of
software packages is available. These packages are based on modular examples. These
examples can be easily extracted and reused on any other platform. The NCX3310
evaluation board can be stacked on single-board computer boards, MCU evaluation
boards, such as the NXP LPCXpresso Boards and NXP Freedom Boards, or be used
standalone.
Note: The antenna part can be broken off and replaced by any other antenna to fit the
desired application.
1.1 Potential applications
•BT and WiFi pairing
•Rear seat entertainment
•Personalization and diagnostics
•Connected keys for connected cars
•Originality check of auto parts
2 Finding kit resources and information on the NXP web site
NXP Semiconductors provides online resources for this evaluation board and its
supported device(s) on http://www.nxp.com.
The information page for the NCX3310EVB evaluation board is at https://www.nxp.com/
products/security-and-authentication/secure-car-access/nfc-forum-compliant-tag-ic-
with-ic-for-automotive:NCx3310. The information page provides overview information,
documentation, software and tools, parametrics, ordering information and a Getting
Started tab. The Getting Started tab provides quick-reference information applicable to
using the NCX3310EVB evaluation board, including the downloadable assets referenced
in this document.
3 Getting ready
NCX3310 evaluation board package includes:
UM11737 All information provided in this document is subject to legal disclaimers. © 2022 NXP B.V. All rights reserved.
User manual Rev. 1.0 — 22 August 2022
4 / 16

NXP Semiconductors UM11737
NCX3310 evaluation board
Figure 1. NCX3310 evaluation board PCB
The following information is provided per Article 10.8 of the Radio Equipment Directive
2014/53/EU:
(a) Frequency bands in which the equipment operates.
(b) The maximum RF power transmitted.
Part number RF Technology Frequency ranges Maximum transmitted power
NCX3310EVB NFC Type 5 Tag 13.54 MHz ± 423.75 KHz N/A
Table 1. NCX3310EVB evaluation board
Europeon Declaration of Conformity, simplified DoC per Article 10.9 of the Radio
Equipment Directive 2014/53/EU
This apparatus, namely NCX3310EVB, conforms to the Radio Equipment Directive
2014/53/EU. The full EU Declaration of Conformity for this apparatus can be found at this
location: https://single-market-economy.ec.europa.eu/sectors/electrical-and-electronic-
engineering-industries-eei/radio-equipment-directive-red_en
3.1 Getting to know the hardware
3.1.1 Connector PINOUT description
Figure 2. Locations of connectors (PINOUT)
UM11737 All information provided in this document is subject to legal disclaimers. © 2022 NXP B.V. All rights reserved.
User manual Rev. 1.0 — 22 August 2022
5 / 16

NXP Semiconductors UM11737
NCX3310 evaluation board
Number Net name Description
J1:6 ED_PU Event detection pin. Open drain. Pulled up to Vcc by R22 (4.7 kΩ).
J1:7 HPD_PD Hard-power-down pin. Pulled down to GND by R24 (10 kΩ).
J2:7 GND Ground
J2:9 SDA Multiplexed pin: I2C SDA data line / GPIO1. Can be optionally pulled up to Vcc
by switch SW3:2 on position, R26 (4.7 kΩ).
J2:10 SCL Multiplexed pin: I2C SCL data line / GPIO0. Can be optionally pulled up to Vcc
by switch SW3:1 on position, R25 (4.7 kΩ).
J3:4 P1V8_3V3_BRD Lower-voltage source from underlaying board (e.g. MCU board), usually 3.3 V.
J3:5 P5V0 Higher-voltage source from underlaying board (e.g. MCU board), usually 5 V.
J3:6 GND Ground
J3:7 GND Ground
Table 2. OM2NTP5332 pinout description
3.1.2 Switches and other components description
Figure 3. Locations of switches and other components
Number Net name / Options Description
1-6: PU_EN_SCL With ON position, Pullup R25 engaged.
2-5: PU_EN_SDA With ON position, Pullup R26 engaged
SW3
3-4: VOUT With ON position, NCx3310's VOUT connected to VCC (a must for energy
harvesting)
SW1 HPD_VCC When HPD is pulled to VCC, NCx3310 enters High Power-down mode. When
released, NCx3310 exits from HPD mode. Can be used as NCx3310 reset.
1.8 - 3.3 VSW6
5 V
VCC chooser. It only connects voltage from underlaying board or source to the
NCx3310 and whole PCB.
D1 D1 Green LED
JP1 GND Jumper for easy access to GND.
Table 3. OM2NTP5332 switches and other components description
UM11737 All information provided in this document is subject to legal disclaimers. © 2022 NXP B.V. All rights reserved.
User manual Rev. 1.0 — 22 August 2022
6 / 16

NXP Semiconductors UM11737
NCX3310 evaluation board
3.1.3 Schematics
The schematic of the evaluation board can be seen below.
aaa-047744
C5
0603
27 pF
J91 1
2
1
2
1
2
HDR 1X2
PCB Antenna
54x27 mm
NPC Antenna
54x27 mm
C4
0603
120 pF
C19
0603
100 pF
TP3
VOUT
C20
0603
470 nF
R2
0603
0 Ω
R1
GND_P
0603
0 Ω1
2
1
2
1
6
C8
0603
1 µF
R24
0603 - 5%
10 kΩ
R27
D1
Diode
0603
0603
220 Ω
1
1 2
3
1
2
3 4
2
4 3
LA_TX
LA
G
N
D
LB
LA_C
LB_C
LB_TX
16
1
15
14
13
NC2
SDA
NCx3310
HVQFN SCL
SDA
SCL
ED
ED_PU
5
6
7
8
J9
HDR 1X2
J7
HDR TX 1X3
DNP
DNP
J8
HDR TX 1X3
JP1
GND_P GND_B
GND_P
GND_P
VCC
VCC
VCC
VCC
VCC
Layout Notes: C8 to be placed as close as possible
to NCx3310 DC
SW1
Arduino connectors
G
N
D
_
T
X
2
V
C
C
_
T
X
3
N
C
1
4
1 2 3
321
3 2
21
SJ3
SolderJ
GND_B GND_P
12
SJ2
SolderJ
GND_B
GND_S 12
A C
1
V
O
U
T
12
G
N
D
11
H
P
D
10
GND_P
VCC
P5V0_BRD
R28 - DNP
0603 - 5%
4.7 kΩ
R3
0603 - 5%
4.7 kΩ
GND_P
GND_1
J1 SKT 1x8
J4
SW6
SPDT
SKT 1x6
GND_P
V
C
C
H
P
D
_
P
D
9
VOUT
VCC
HPD_VCC
611-KMR221NGLFS
SW3C
SW DIP 3 POS
SW3A
SW DIP 3 POS
2
5
R4
0603 - 5%
4.7 kΩ
R22
0603 - 5%
4.7 kΩ
VCC
SW3B
SW DIP 3 POS
VCC
TP2
TP1
5476854321
J2 SKT 1x10
7 69 810
64 52 31
J3 SKT 1x8
SJ1
SolderJ
GND_B
12
6
P1V8_3V3_BRD
4 5 872
SCL
SDA GND
HPD_PD
HD_PU
31
Figure 4. NCX3310 evaluation board schematic
The board layout and bill of materials for the NCX3310EVB evaluation board are
available at www.nxp.com/NCX3310EVB.
4 Optional hardware that is supported for development
This section lists optional supported hardware that are not included in the board. This
hardware eases evaluation and enables faster integration or portation to other similar
devices. Optional hardware is ordered separately.
Item 1 Item 2 Item 3 Item 4
Description NFC mobile RF (ISO15693) reader MCU development board NFC Door handle
reference design
Table 4. Supported optional hardware (NOT included in the board). Needs to be ordered separately.
UM11737 All information provided in this document is subject to legal disclaimers. © 2022 NXP B.V. All rights reserved.
User manual Rev. 1.0 — 22 August 2022
7 / 16

NXP Semiconductors UM11737
NCX3310 evaluation board
Item 1 Item 2 Item 3 Item 4
Purpose Developing Android-
based applications
Developing VCD (RF,
NFC) applications. Either
FW or higher software
layer.
Developing MCU based
I2C Follower, GPIO, PWM
use cases.
Evaluation of I2C leader,
Energy Harvesting use
cases
Picture pnev7462c reader
development board
LPCXpresso board for
LPC11U37H
FRDM-KW41Z
development board
Section in this
document
Section 4.1 Section 4.2 Section 4.3 DHRD FreeMASTER SW
Tool
Buying options Via NXP's distribution or
through nxp.com.
Via NXP's distribution or
through nxp.com.
Via nxp .com
Table 4. Supported optional hardware (NOT included in the board). Needs to be ordered separately. ...continued
4.1 Mobile NFC application development
Developing Android-based applications.
Hardware:
1. Device with integrated NFC.
Software:
1. TapLinx (Android only) (mifare.net)
2. NCx3310 Configuration over NFC Interface
3. Use cases examples (Bluetooth pairing, energy harvesting, I2C Leader mode) using
native Android NFC application.
Additional documentation:
•NCx3310 configuration from RF interface
•NFC Forum Type 5 Tag configuration
•NFC Forum NDEF
•I2C leader
•I2C follower
•Energy harvesting
•Event detection
•Protecting user memory and features, security
4.2 RF (ISO15693) reader development
Easy RF evaluation of NCx3310 features. Also for developing VCD (RF, NFC)
applications, either FW or higher layer software.
NCx3310 features that can be evaluated:
•NCx3310 configuration from RF interface
UM11737 All information provided in this document is subject to legal disclaimers. © 2022 NXP B.V. All rights reserved.
User manual Rev. 1.0 — 22 August 2022
8 / 16

NXP Semiconductors UM11737
NCX3310 evaluation board
•I2C leader
•I2C follower
•Pass-through mode
•PHDC data transfer
•Energy harvesting
•GPIO
•PWM
•Event detection
•Security
•NDEF
Hardware:
Figure 5. pnev7462c reader development board
Software:
•GUI
–RFIDDiscover (DocStore)
–NFCCockpit (nxp.com)
•Firmware: NFC Reader Library (DocStore)
•.NET: NXP Reader Library (DocStore)
Additional Documentation:
•NCx3310 configuration from RF interface
•I2C leader
•I2C follower
•Energy harvesting
•GPIO
•Event detection
4.3 LPC11U37H MCU based
Hardware:
UM11737 All information provided in this document is subject to legal disclaimers. © 2022 NXP B.V. All rights reserved.
User manual Rev. 1.0 — 22 August 2022
9 / 16

NXP Semiconductors UM11737
NCX3310 evaluation board
Figure 6. LPCXpresso v2 board with LPC11U37H MCU
Software:
•Use cases Code examples:
–GPIO
–Pass-through mode
•GUI - NTAG cockpit (easy I2C access)
Documentation:
•NTAG 5 configuration from I2C interface
•I2C leader
•I2C follower
•Energy harvesting
•GPIO
•Event detection
•NTAG 5 middleware porting guide
4.4 DHRD FreeMASTER tool
Easy I2C Leader mode evaluation of NCx3310. I2C Leader mode can be evaluated with
any I2C based sensor IC. Detailed description can be found in: UM-SCA1702 - NCx3320
Door Handle Reference Design User Manual.
UM11737 All information provided in this document is subject to legal disclaimers. © 2022 NXP B.V. All rights reserved.
User manual Rev. 1.0 — 22 August 2022
10 / 16
