Nyle e360 User manual

NOT TO BE USED FOR INSTALLATIONNOT TO BE USED FOR INSTALLATION
NOT FINAL DRAFTNOT FINAL DRAFT
Rev. IM-E360-051223

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523 HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Introduction
2
Thank you for your purchase of an
e-Series Heat Pump Water Heater! With
this purchase, you now own one of the
most ecient and reliable large-volume
water heaters available in the world
today. This unit will produce potable hot
water from a highly ecient and capable
heat pump, helping end users reach
their carbon reduction, electrification,
eciency, and operating cost reduction
goals.
The e-Series heat pumps feature R-513a
refrigerant, which meets the EPA’s SNAP
guidelines for Global Warming Potential
(GWP). Units are capable of providing
single-pass water heating to appropriate
external storage vessels with up to 160°F
water, and can perform at outdoor temperatures as low as 10°F. Models
are available for 230v and 460v 3-phase power, include internal power
quality monitoring, and all units are ready to be integrated into BMS
systems.
Nyle’s e-Series units are not intended for primary space conditioning,
nor for multi-pass water heating configurations. When installed in
suitable conditioned spaces, they can provide supplemental cooling
and/or dehumidification benefits.
Introduction

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Table of Contents
3
TABLE OF CONTENTS
Safety Information...............................................................................................................................
General Description............................................................................................................................
Performance Specifications & Requirements........................................................................
Expanded Performance Data.......................................................................................................
Physical Specifications & Clearances.......................................................................................
Before Ordering Your Heat Pump...............................................................................................
Cold Climate Installation Considerations.................................................................................
Unit Diagram & Key Components.................................................................................................
Installation
Required Tools & Materials.................................................................................................
Rough-In Checklist..................................................................................................................
Transportation, Placement, Mounting............................................................................
WaterPiping................................................................................................................................
Condensate Piping..................................................................................................................
PowerWiring...............................................................................................................................
Control Wiring............................................................................................................................
Optional Ducting & Ventilation...........................................................................................
Configuration..............................................................................................................................
Pre-Startup Checklist........................................................................................................................
Startup Procedure...............................................................................................................................
Initial Troubleshooting.......................................................................................................................
Routine Maintenance.........................................................................................................................
Warranty...................................................................................................................................................
4
6
8
10
11
14
15
17
18
19
20
28
32
34
37
40
43
46
49
52
56
58

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523 HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Safety Information
4
SAFE INSTALLATION, USE AND SERVICE
The proper installation, use and servicing of this commercial heat pump water
heater is extremely important to your safety and the safety of others.
Many safety-related messages and instructions have been provided in this manual
and on your own heat pump water heater to warn you and others of a potential
injury hazard. Read and obey all safety messages and instructions throughout this
manual. It is very important that the meaning of each safety message is understood
by you and others who install, use, or service this heat pump water heater
All safety messages will generally tell you about the type of hazard, what can
happen if you do not follow the safety message, and how to avoid the risk of injury.
The California Safe Drinking Water and Toxic Enforcement Act requires the
Governor of California to publish a list of substances known to the State of
California to cause cancer, birth defects, or other reproductive harm, and requires
businesses to warn of potential exposure to such substances.
This product contains a chemical known to the State of California to cause
cancer, birth defects, or other reproductive harm. This appliance can cause low
level exposure to some substances listed in the Act.
This is the safety alert symbol. it is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER Indicates an imminently hazardous situation which, if not
avoided, will result in injury or death
WARNING Indicates a potentially hazardous situation which, if not
avoided, could result in injury or death
CAUTION Indicates a potentially hazardous situation which, if
not avoided, could result in minor or moderate injury or property
damage

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Safety Information
5
GENERAL SAFETY INFORMATION
PRECAUTIONS
**DO NOT USE THIS APPLIANCE IF ANY PART HAS BEEN UNDER WATER.**
Immediately call a qualied service agency to inspect the ap-
pliance and make a determination on what steps should be
taken next.
If the unit is exposed to the following, do not operate heater
until all corrective steps have been made by a qualied service
agency.
1. External re.
2. Damage.
3. Running without water .
GROUNDING INSTRUCTIONS
This heat pump water heater must be grounded in accordance
with the National Electrical Code and/or local codes. These
must be followed in all cases. Failure to ground this water
heater properly may also cause erratic control system operation.
This heat pump water heater must be connected to a ground-
ed metal, permanent wiring system; or an equipment ground-
ing conductor must be run with the circuit conductors and
connected to the equipment grounding terminal or lead on
the water heater.

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523 HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
General Description
6
Purpose:
e-Series units are air-to-water Commercial Heat Pump Water Heaters
(CHPWHs) using R-513a refrigerant in a closed and factory charged circuit. A
double wall heat exchanger provides heat to a potable water circuit. Potable
water is piped to the heat pump in a loop to and from external storage tanks.
Circulation is provided by the integral circulator in the heat pump.
Usage:
the e-series of water heaters are designed to provide hot water in a “Single
Pass” configuration; meaning that water is delivered at full usable temperature
to the potable storage tank in one pass. This allows for faster recovery of usable
water temperatures than in traditional “Multi-Pass” configurations. This system
is not an “on demand” heater and does require external and stratified storage to
operate eectively. Building recirculation loops must be returned to a separate
“swing tank” to preserve this stratification.
Ease of Installation:
The enclosure is designed to minimize its footprint, and to simplify placement
considerations for multiple-unit installations. As a “monobloc” style heat pump,
the unit arrives ready to connect to electrical, condensate, optional ducting, and
potable water infrastructure in the field.
It features onboard defrost heaters and heat tracing for cold climate usage, an
integral circulator and control valve, and an internal condensate drain pan with
a pipe connection point. The system is coated to resist salt spray corrosion for
coastal environments. While typically installed outdoors, interior locations with
adequate and consistent ventilation or heat gain can also house the unit, such
as large server rooms or parking garages. e-Series heat pumps can also be
fully ducted, allowing installation indoors in rooms that would not otherwise be
suitable for the heat pump.
General Description

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
General Description
7
Controls and Electrical:
The e-Series line is available in 208-230 and in 440-480 3 phase variants. Units
require a main power feed and a secondary 120v power feed for the onboard
freeze protection, controls, and circulator. It is strongly recommended that the
120v power feed come from a power source with a backup generator if the unit
is installed in a location that experiences freezing conditions, allowing freeze
protection to continue during a power outage. Optionally, a Unified Power
Package accessory can be ordered and installed to bring all power in through a
single primary voltage power feed.
All e-Series units are MODBUS and BACNET capable, ready to be integrated
into BMS systems by 3rd party integrators using Bacnet/IP and MSTP protocols.
All units also ship with internet accessibility for observation, alarms, and
troubleshooting on Nyle’s Nimbus online portal.
All e-Series units have a CTA-2045 port for power utility demand management
and are certified UL 1995.
For more information:
Please refer to the Performance Specifications for appropriate operating ranges
and requirements. If more detailed information is required than is available in this
manual, please contact Nyle Water Heating Systems for additional assistance.

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523 HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Performance Specifications & Requirements
8
Performance Specifications and Requirements
Heating and
Cooling
Heating Capacity at 70 F ** 287,000 BTUs/hr
Heating Capacity at 10 F ** 98,000 BTUs/hr
Cooling Capacity at 70 F * 211,000 BTUs/hr
Recovery Rate *** 380 Gallons/hr
Outdoor Temperature Operating Range 10-120 Deg. F
Water Inlet Operating Range 35-115 Deg. F.
Water Outlet Operating Range 80-160 Deg. F.
Mechanical
Water Side Maximum Flow 16 GPM
Available External Pressure Drop for Piping 15 Ft. Hd.
Maximum Water Side Pressure 150 PSIG
Minimum Tank Cycle Volume **** 157 Gallons
Design Air Side Flow 16,000 CFM
Available External Static for Ducting 1.5 In. W.C.
Refrigerant R513a
Typical Refrigerant Pressure High Side 130-395 PSIG
Typical Refrigerant Pressure Low Side 5-87 PSIG
Max Sound Pressure (Front/Left/Right/Rear) ***** 78.5/70.2/70.7/79 dBA
Quiet Mode Sound Pressure ***** 70.4/64.1/65.8/71.7 dBA
Salt Spray resistance Cabinet/Evap 9000/1000 hours
Table 1: Performance Specifications
*Note: Cooling is incidental to heating operation and should typically be considered supplemental, not primary space cooling.
**Nominal heating performance is outdoor air at 50% RH, 140 Deg.F. outlet and 50 Deg.F. inlet water temps.
***Recovery Rate assumes 70 Deg. F. outdoor temp, 140 Deg.F. storage temp and 50 Deg.F. inlet water temp.
****Minimum Tank Cycle Volume is the min volume between tank sensor and and heat pump inlet pipe, in the storage tank.
*****Sound Pressure measured 3’ away 3’ from ground, at max and quiet mode fan speeds, with ductless cowl installed.

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Performance Specifications & Requirements
9
Do not install e-Series heat pumps such that they would need to be operated in conditions
outside of these performance specifications. Units may stop compressor operation outside
of ambient temperature limits. In cold climates, freeze protection measures will remain active
when the compressor is turned o.
Table 2: Electrical Specifications
Standard Power Package Unied Power Package
Model: e360-230v e360-460v e360-230v e360-460v
Main 3-Phase Power Feed: 208-230/3/60 460/3/60 208-230/3/60 460/3/60 Volt/Phase/Hz
Min. Circuit Ampacity (MCA) 123 63 129 66 Amps
Max. Overcurrent Protecon (MOCP) 222 113 228 116 Amps
Running Load Amps (RLA) 110 57 110 57 Amps
Power Factor 0.86 0.86
Short Circuit Current Rang (SCCR) 100 100 kA
Internal Component Data:
Fan Motor Full Load Amps (FLA) 10.1 6 10.1 6 Amps
Fan Horsepower (HP) 5.1 6.02 5.1 6.02 HP
Compressor Locked Rotor Amps (LRA) 294 245 294 245 Amps
Internal Pump Full Load Amps (FLA) On Backup Feed 2.1 Amps
Compressor Horsepower (HP) 30 30
Backup Circuit Single Phase Power Feed: 120/1/60 Volt/Phase/Hz
Min. Circuit Ampacity (MCA) 14 14 Amps
Full Load Amps (FLA) 11.3 11.1 Amps
Max. Overcurrent Protecon (MOCP) 25 20 Amps
Internal Pump Full Load Amps (FLA) 2.1 2.1 Amps
Circuit Power 1360 1330 Was
Short Circuit Current Rang (SCCR) 100 kA

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523 HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Expanded Performance Data
10
Expanded Performance Data: 140 Leaving Water Temp.
e360 Performance Data: 70 Deg F. Entering Water
Ambient Heating Cap. Cooling Cap. Heat COP Cool COP Flow
10 Deg. F. 98 kBTU/hr 68 kBTU/hr 2.6 1.8 4.2 GPM
24 Deg. F. 126 kBTU/hr 93 kBTU/hr 2.9 2.1 5.5 GPM
30 Deg. F. 141 kBTU/hr 107 kBTU/hr 3.0 2.3 6.2 GPM
40 Deg. F. 171 kBTU/hr 133 kBTU/hr 3.3 2.6 7.4 GPM
50 Deg. F. 205 kBTU/hr 165 kBTU/hr 3.8 3.1 9.3 GPM
60 Deg. F. 241 kBTU/hr 202 kBTU/hr 3.9 3.3 10.5 GPM
70 Deg. F. 287 kBTU/hr 242 kBTU/hr 4.1 3.5 12.3 GPM
80 Deg. F. 333 kBTU/hr 282 kBTU/hr 4.4 3.7 14.0 GPM
90 Deg. F. 351 kBTU/hr 327 kBTU/hr 4.9 4.6 15.9 GPM

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Physical Specifications and Clearances
11
D1-Dimensional Information
FRONT LEFT
WATER OUT
1-1/4" FPT
WATER IN
1-1/4" FPT
POWER
ACCESS
CONDUIT
SERVICE PANELS
ELECTRICAL
ENCLOSURE
CONTROL
ACCESS
CONDUIT
62 5
8
" O.D.
36"
4 1
2
"
2"
72 7
8
" O.D.
REAR
INTAKE DUCT
COLLAR
3/4" CONDENSATE DRAIN
72"
81 1
8
"
7"
1 5
8
"
101 1
4
"
5 1
2
"
FRONT
2 1
2
"
24"
36"
41 1
8
"
0"
2 5
8
"
5 3
4
"
9 1
4
"
15 3
8
"
TOP
CLEARANCE
CLEARANCE
40"
1 3
8
"
44 5
8
"
1 5
8
"
7"
AIR FLOW
LEFT
FRONT LEFT
WATER OUT
1-1/4" FPT
WATER IN
1-1/4" FPT
POWER
ACCESS
CONDUIT
SERVICE PANELS
ELECTRICAL
ENCLOSURE
CONTROL
ACCESS
CONDUIT
41 3
4
"
7
8
"
43 1
2
"
0" 11 1
2
"
15 3
4
"
56 1
2
"
60 3
4
"
BOTTOM
62 5
8
" O.D.
36"
4 1
2
"
2"
72 7
8
" O.D.
REAR
INTAKE DUCT
COLLAR
3/4" CONDENSATE DRAIN
1
2
" 4 1
4
"
2"
1
2
"
37 5
8
" O.D.
67 1
2
" O.D.
TOP
DISCHARGE DUCT
COLLAR
1 OF 1
10/17/2022
4/21/2023
GH
UNLESS OTHERWISE SPECIFIED:
1:30
TITLE:
NAME
DATE
CHECKED
DRAWN
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/16"
DECIMAL
0.02"
ANGULAR MACH
1/2°
ANGULAR BEND
1°
PROPRIETARY AND CONFIDENTIAL:
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
NYLE SYSTEMS LLC. ANY REPRODUCTION
IN PART OR AS A WHOLE WITHOUT THE
WRITTEN PERMISSION OF NYLE SYSTEMS
LLC IS PROHIBITED.
DEPT:
WEIGHT (lbs): SCALE:
SHEET:
SECTION:
PART REVISION:
SHEET SIZE:
B
RM
RB
2105.7690978
EDITED
GH
4/21/2023
E360 MARKETING
SHEET1

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523 HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Physical Specifications & Clearances
12
2 1
2
"
24"
36"
41 1
8
"
0"
2 5
8
"
5 3
4
"
9 1
4
"
15 3
8
"
TOP
CLEARANCE
CLEARANCE
1
2
" 4 1
4
"
2"
1
2
"
37 5
8
" O.D.
67 1
2
" O.D.
TOP
DISCHARGE DUCT
COLLAR
40"
1 3
8
"
44 5
8
"
1 5
8
"
7"
AIR FLOW
LEFT
41 3
4
"
7
8
"
43 1
2
"
0" 11 1
2
"
15 3
4
"
56 1
2
"
60 3
4
"
BOTTOM
D1-Dimensional Information
Clearance Note 1:
Unit is designed to be installed with zero side clearance, and all typical service items are serviceable from the front.
However, defrost heaters would need to pull out to the side if replaced. Units may be installed with successive
units oset 6” to the rear to allow the evaporator mounted heaters to pull from the unit right side, or in the unlikely
event of element failure the unit could be temporarily disconnected and moved.
Clearance Note 2:
Bottom clearance to the ground varies by project requirements, and is driven by height required for any necessary
condensate drain pitch. Free discharge (unpiped) condensate applications are not generally recommended.
See “Water and Condensate Piping” section for more information about piped and free discharge condensate
applications.
Clearance Note 3:
If vibration transmission and/or seismic activity is a concern for your installation, account for the additional height
of vibration isolation or seismic measures as recommended by a qualified engineer.
Clearance Note 4:
Top clearance required for fan installation/removal. If fans are installed prior to mounting and unit can be moved to
replace fans in the event of failure, this can reduce to 1” clearance.

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Physical Specifications & Clearances
13
Physical Specifications and Clearances
Water Side Pipe Connections 1-1/4” FPT
Condensate Pipe Connection 3/4” CTS Stub
Main Power Conduit Connection 1-1/2” Female Thread
120v Power Conduit Connection 3/4” Female Thread
Net Weight (Dry, no Fans) 2,300 Pounds
Net Weight (Shipping) 2,400 Pounds
Net Weight (Filled, w/Fans) 2,604 Pounds
Fan Unit Net Weight (Each) 140 Pounds
Refrigerant Charge 60.0 Pounds
Refrigerant Oil Charge 158.4 Ounces
Internal Water Volume 2.9 Gallons
Table 3: Physical Specifications

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523 HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Before Ordering Your Heat Pump
14
Before Ordering Your Heat Pump
Nyle Water Heating Systems recommends following this pre-order checklist, to
minimize the chances of costly mistakes and potentially lengthy project delays:
Be sure to thoroughly review this manual and familiarize yourself with the equipment’s
installation requirements. The manual has been organized to follow the general
sequence of most installations. If any details are not clear or questions are not
answered contact your Nyle representative to resolve them ahead of time.
Review performance specifications against your intended installed environment and
water temperature requirements, and ensure the unit will perform appropriately for
your conditions.
Review physical specifications to ensure the unit will have adequate installation
space, support, clearances, drainage support, and airflow. Familiarize yourself
with piping, condensate, wiring, and ducting connections to ensure all attached
infrastructure will be able to access the unit. Remember additional installation height
may be needed for condensate drain pitch requirements.
Evaluate the need for backup heat production, especially in cold climates. e-Series
units turn o the compressor at 10 degree F outdoor temperature, and capacity is
lower in cold weather.
Freeze protection measures require separate 120v power to operate, or the
installation of an optional unified power package accessory. Ensure 120v power
feed to the unit has a backup generator for any installation where the unit will be
exposed to freezing temperatures during power outages.
Be clear on your plan to deliver, transport, mount, and secure the unit.
Double check the voltage requirements of the unit you intend to order, to make sure it
is compatible with the available voltage on site.
Air to Water heat pumps are multidisciplinary installations that may require any or
all of the following trade specialties to support: site prep/structural, electrical,
plumbing, ducting, automation/controls, refrigeration, and duct/piping insulation.
Be sure that various specialties involved in your project are well informed as to their
role in the installation and are properly certified and qualified in their specialties in
accordance with all governing codes and regulations.
Be sure that qualified refrigeration technicians are available for installation
troubleshooting support and ongoing system maintenance. If this is in question,
contact your local Nyle representative to discuss support options.

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Cold Climate Installation Considerations
15
Cold Climate Installation Considerations
e-Series heat pumps are intended to operate in cold climates. However, freeze
protection is an important part of the installation and design planning for these
installations. One option is to install the unit in freeze protected spaces and duct
them to the outside. See the Optional Ducting section of this manual for details.
For exterior installations, additional measures are required.
IMPORTANT: Cold climate outdoor installations require close
attention to the following considerations. Failure to follow these
guidelines can result in equipment failure and/or severe water
damage to the property.
The heat pump has two steps of internal freeze protection for outdoor
applications:
1. First are the onboard, active heating measures: all internal water side
components are insulated and heat traced, which activate only when water
temperatures in the unit get too close to freezing. The condensate pan
has water sensing and pan heating, which activates when water is present
in the pan during freezing conditions.
2. In the event that active heating fails to keep water temperatures above
freezing, the heat pump will run its circulator to draw heat from the
attached storage tank as an emergency measure. It is imperative that
attached piping does not prevent this fluid exchange with the storage
tanks. Attached valves and components must allow free flow between
the heat pump and storage tank at all times: solenoid valves and other
automatic shutos are not recommended.
Considerations for Exterior Applications in cold climates:
1. All water and condensate piping that is exposed to freezing temperatures
must be insulated and heat traced as per local code and/or heat tracing
manufacturer’s requirements. It is recommended that this tracing be
thermostatically activated to run as needed, not always on. Self regulating
cable is recommended.

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523 HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Cold Climate Installation Considerations
16
2. e-Series units have a 120v power feed in addition to their primary 3
phase power feed. The 120v feed is intended to be connected to a power
source with a generator or battery backup. See Table 2 for electrical
specifications. Backup electrical support is important to protect the unit
in case of power failure on the main circuit, unless the main circuit is itself
backed up by a generator. For installations that do not require backup
power, the unified power package accessory can condense incoming
power to a single point electrical feed.
3. Water pipes in exterior space should pitch down toward the e-Series pipe
entry points, so if a manual drain down is necessary, all exterior piping can
drain to the dump valve within the heat pump.
4. Condensate pipes must pitch down to a freeze protected drain point or
to conditioned space for vents or condensate pumps for further handling.
Do not install vents or condensate pumps outside.
5. If filling the system in cold weather, ensure the 120v power circuit is active
BEFORE filling the circuit. See Pre-Startup and Startup procedures in this
manual for more information.

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Unit Diagram & Key Components
17
Unit Diagram and Key Components
INTAKE AIR INLET
(FAR SIDE OF
EVAPORATOR)
ELECTRONIC
EXPANSION
VALVE
PLUG FANS
DEFROST
HEATING
ELEMENT
EVAPORATOR
(HEAT EXCHANGER)
(AIR TO REFRIGERANT)
COMPRESSOR
ACCUMULATOR
RECEIVER
FLOW CONTROL VALVE
CIRCULATOR PUMP
WATER OUTLET
WATER INLET
CONDENSER
CONDENSATE PAN
WITH HEAT TRACE
MANUAL DUMP VALVE
(BEHIND ACCUMULATOR)
DISCHARGE AIR OUTLET
REVISIONS
REV. DESCRIPTION DATE APPROVED
8
B
1
36
C
D
B
3 16
1 OF 1
4/19/2023
GH
UNLESS OTHERWISE SPECIFIED:
1:16
TITLE:
NAME
DATE
CHECKED
DRAWN
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/16"
DECIMAL
0.02"
ANGULAR MACH
1/2°
ANGULAR BEND
1°
PROPRIETARY AND CONFIDENTIAL:
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
NYLE SYSTEMS LLC. ANY REPRODUCTION
IN PART OR AS A WHOLE WITHOUT THE
WRITTEN PERMISSION OF NYLE SYSTEMS
LLC IS PROHIBITED.
DEPT:
WEIGHT (lbs):
8 7 5 4 2
D
A
7 5 4 2
A
C
SCALE:
SHEET:
SECTION:
PART REVISION:
SHEET SIZE:
B
RM
2105.4573999
EDITED
GH
4/20/2023
E360 MANUAL
KEY COMPONENTS
D2-Key Components

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523 HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Installation: Required Tools & Materials
18
Installation: Required Tools and Materials
In addition to all standard tools and material required for any electrical or
plumbing installation, some of the other specialty tools required to support this
installation include:
1. Heat transfer compound such as Honeywell part number 107408 or
equivalent.
2. Electrical switch lock out devices
• used to secure disconnect switches/breaker panels while servicing.
3. Electronic thermometer with range of 10°F - 210°F (-12°C - 100°C)
including:
• Sensors capable of measuring surface temperatures on water or
refrigerant piping.
• Sensors capable of measuring ambient air temperature.
4. Volt-Ohm MultiMeter - capable of measuring:
• AC Voltage up to 600 VAC.
• DC Voltage up to 24 VDC.
• Ohms up to 2,000,000 ohms.
• Continuity.
• Amperage up to 200 amps.
5. Anemometer or other airflow measuring device.
6. Magnahelic or other pressure measuring device capable of reading 0.1” to
2” w.c.g.

HeatWater.com | [e-mail] | [phone] | Rev. IM-E360-060523
Installation: Rough-In Checklist
19
Installation: Rough-In Checklist
Infrastructure must sometimes be installed prior to the installation of the unit. Items
to consider for “Rough-In” installation include:
Potable water pipes to and from storage tanks, including pipe insulation and
heat tracing as necessary.
Primary power wiring.
Controls/freeze protection 120v power wiring, from a backed-up power source.
Condensate drain lines, including pipe insulation and heat tracing as necessary.
Ducting to or from remote locations, including insulation as necessary.
Control wiring for alarms, BMS interface, and external accessories. Nyle
recommends running a minimum of two 18/8 control wires and a CAT-5e/6
wire to ensure that all likely accessories and control functions could be utilized.
Site prep for mounting the heat pump.
Please refer to the appropriate sections of the manual for the specific details
associated with each item.
