CONGRATULATIONS ON YOUR NEW NYMI BAND™!
We want to make sure you have the absolute best experience with your Nymi
Band! If you have any questions or comments, we are here for you. Email, phone,
or send us some old fashioned snail mail.
[email protected] 1-855-781-9655 Nymi Inc, 82 Peter Street
Toronto, ON, Canada, M5V 2G5
TO GET STARTED, GO TO:

In the Box
Adjusting your Nymi Band
Lengthen
Shorten
Using Windows PC with your Nymi Band
First-Time Use
Daily Activation of your Nymi Band
Authorizing Applications to your Nymi Band
Charging your Nymi Band
Check the Status of your Nymi Band
Taking Care of your Nymi Band
Troubleshooting
Resetting your Nymi Band
Legal Information
1
3
3
4
5
7
9
11
12
13
14
15
17
19
TABLE OF CONTENTS

12
IN THE BOX
Bottom Sensor
Core
Band
Contact Pins
Lights
Cover
Top Sensor Nymi Connector
USB End
Charging Cable
Reset Hole

34
CAUTION ! TIGHT ON YOUR WRIST?
You should adjust your Nymi
Band to t comfortably around
your wrist. It should not be
worn too loose or too tight.
1ADJUST TO LENGTHEN
Hold the Nymi Core in your hand
with the bottom sensor facing you.
Using your other hand, pull the band
to adjust to your desired length.
Stop pulling when the band locks up.
2
Pulling the band beyond
the point where it locks
up will result in damage
to the band.
!LOOSE ON YOUR WRIST?
You should adjust your Nymi
Band to t comfortably around
your wrist. It should not be
worn too loose or too tight.
1ADJUST TO SHORTEN
Hold the Nymi Core in your hand
with the bottom sensor facing you.
Using your thumb, push down and
feed the band through the Nymi
Core to your desired length.
2CAUTION
Do not cut your Nymi
Band due to electronics
within the band.
LENGTHEN YOUR NYMI BAND™ SHORTEN YOUR NYMI BAND™

56
!
HOW DO I USE IT?
Plug it into your computer’s USB
port and keep it there. Do not use
a USB hub as this may interfere with
the module’s functionality.
!HOW DO I GET MORE?
If you have more than one Windows
computer that you would like to use
with your Nymi, you can order more
modules at [email protected].
!
For all other platforms,
enable Bluetooth on your
device to connect to your
Nymi Band.
USING WINDOWS PC WITH YOUR NYMI BAND
WHAT IS A NYMI-COMPATIBLE BLUETOOTH DONGLE?
The BLED112 Bluetooth® Smart Module is the buddy for your
Nymi Band™, if you have a Windows® computer. You need it in
order to use the Windows version of the Nymi Companion or
any Nymi-Enabled Applications.
WHY DO I NEED IT?
The Bluetooth module passes data between your computer and
your Nymi Band, because the default way that Windows handles
Bluetooth does not work well with the Nymi. You need the
module for all Windows computers - regardless of whether or
not it already has Bluetooth. Bluegiga’s BLED112 Bluetooth Smart
Module is the only dongle that is Nymi-compatible.
Contact [email protected] for more info

78
Once clasped onto your wrist,
your Nymi Band’s lights will pulse
twice indicating the battery level
of your band.
DOWNLOAD NYMI COMPANION
1WEAR YOUR NYMI BAND
Clasp your Nymi Band onto your
wrist with the lights facing you. It
will light up. If not, unclasp and
reclasp your Nymi Band.
3
ENABLE BLUETOOTH
Turn on Bluetooth® on your device. For
Windows® PC, you need to use a Nymi-
compatible Bluetooth module. If you don’t
have one, contact [email protected].
2BATTERY LEVEL
4APP SEARCH MODE
Your Nymi Band will place itself
into search mode. If you do not
see the above light sequence
appear, unclasp and reclasp your
Nymi Band.
5LAUNCH NYMI COMPANION
The Nymi Companion will guide you
through setting up your Nymi Band.
6
IMPORTANT - Consult Safety Instructions Before Use.
FIRST-TIME USE
Pick one device that you would like to
use to activate your Nymi Band daily
(mobile device is recommended). Go to
got.nymi.com to download the Nymi
Companion onto it.

910
BATTERY LEVEL
Once clasped onto your wrist,
your Nymi Band’s lights will pulse
twice indicating the battery level
of your band.
2APP SEARCH MODE
Your Nymi Band will place itself
into search mode. If you do not
see the above light sequence
appear, unclasp and reclasp your
Nymi Band.
3
WEAR YOUR NYMI BAND
Clasp the Nymi Band onto your wrist
with the lights facing you. You will
need to activate your Nymi Band every
time you put it on. Once activated, it
will stay activated until you unclasp it.
1LAUNCH NYMI COMPANION
Have your Nymi Companion open
on your phone or computer so it can
search for your Nymi Band.
4ACTIVATE YOUR NYMI BAND
Place one nger on the top sensor
of your Nymi Band for your heart’s
electrocardiogram to be read.
5ONCE ACTIVATED, CLOSE APP
Your Nymi Band will stay activated as
long as it stays clasped on your wrist.
Now it can interact with Nymi-Enabled
Applications.
6
DAILY ACTIVATION OF YOUR NYMI BAND™

11 12
OPEN NYMI-ENABLED APP
To use your Nymi Band with
applications like phone unlock,
you need to authorize the
application to your Nymi Band.
1AUTHORIZE THE APP
When asked to put your Nymi Band
in pairing mode, quickly tap the top
of your Nymi Band four times.
2PAIRING MODE
Your Nymi Band will indicate
that it is looking for nearby
applications when the above
light sequence appears.
3LOW BATTERY
If the Nymi Band vibrates
and then one light appears,
this means it is low battery
and needs to be charged.
1CONNECT THE CHARGER
A pulsing light indicates that your
Nymi Band is charging. If you do
not see the lights, your charger
may be on backwards.
2FULL CHARGE
A full charge takes approximately
two hours when you use a wall
outlet or your computer’s USB port.
3
AUTHORIZE APPLICATIONS TO YOUR NYMI BAND™ CHARGING YOUR NYMI BAND™

13 14
CHECK STATUS
CHECK THE STATUS OF YOUR NYMI BAND™
! !
!
WATER RESISTANT DESIGN
The Nymi Band is water resistant,
but not waterproof. Do not shower
or swim with your Nymi Band on. If
water is splashed on it, dry it o as
soon as possible.
TEMPERATURE
Do not heat, microwave, or freeze
your Nymi Band. Do not store it with
direct sunlight exposure. Do not
leave your Nymi Band in a hot car.
CLEANING YOUR NYMI BAND
Use only a clean, damp cloth to
clean your Nymi Band. Do not use
chemicals.
TAKING CARE OF YOUR NYMI BAND™
INACTIVE
Your Nymi has not been
activated yet. Activate it
with the Nymi Companion.
!READY
Your Nymi Band is
activated and ready
to go!
!BUSY
Your Nymi Band is currently
connected to an application,
and unable to connect to
another one.
!
Whenever your Nymi
Band is idle, you can
check its status by
double tapping it.
!
