Nyx NyxLite NGWY1010 User manual

Installation Guide for
NyxLite Gateway [NGWY1010]
Thank you for choosing NyxLite Gateway.
This product acts as a home controller for Nyx
Home Automation System.
The Box Contains- Gateway
Ethernet Cable
Installation Guide
Screws: 2 Nos.
Pin - To set DIP Switches
Technical Specifications
Operating voltage 230VAC, 50Hz
Active Current
Radio frequency 866Mhz
Radio operating
distance 50m line of sight
Operating
temperature
Dimension
Communication
ports 1 Ethernet port 10/100 Mbps
0 - 50°C
300 mA
100mm (H) x 70mm (D) x 52mm (W)
2. Connect 230V power to the gateway device.
3. Insert one end of Ethernet cable to the gateway
device and other end into one of the ethernet
port of router.
Product setup
Product setup
1. Ensure the DIP switches are set as per DIP
switch label.
A] Configuration with Wi-Fi router:
A] Configuration with Wi-Fi router:
DIP Switch
DIP
Switch
Label
4. Turn on NyxLite gateway, then PWR LED will
glow and “RUN” LED will start blinking. This
indicates that the device is working.
On-off
switch
B] Configuration using Jio Access Point:
1. To connect NyxLite gateway with Jio Access
point, you need additional Wi-Fi extender.
2. Turn on the Jio Access point and Wi-Fi
extender. (tested module viz.: MI3C).
3. Use mobile phone or computer to log-in to
the Wi-Fi extender by using its IP and
password (Generally printed on back side of
router).
B] Configuration using Jio Access Point:
Web: www.nyxhomeautomation.com
email: [email protected]
Revision04; June 2019
Configuration of Nyx devices to gateway:
1. Internet connection to the gateway is
recommended.
2. Download Nyx App on your mobile.
3. RUN the Nyx App and add the NyxLite
Gateway
Configuration of Nyx devices to gateway:
4. Give all the credentials and set-up a system.
5. Once gateway is set up, add the available
devices
Setting up additional hooter:
Setting up additional hooter:
4. Set the Wi-Fi extender to the amplifier mode
[Extend existing Wi-Fi].
5. Select existing Wi-Fi network to repeat and
enter its password. Here, existing wireless
network is Jio Access Point.
6. Now, connect Ethernet cable from NyxLite
gateway to the Wi-Fi extender.
EXT
HOOTER
Connector
Connection diagram with external hooter:Connection diagram with external hooter:
User can connect external hooter for larger
sound. Hooter can be connected to Gateway
is as shown below.
NyxLite Gateway
Input Power
Hooter
Recommended Specifications of Hooter:
Max Operating voltage: 230VAC
Max Operating current: 1Amp
Recommended Specifications of Hooter:
7.
.
8. LED indication status on Ethernet connector
of NyxLite Gateway:
GREEN: Continuous ON
Orange: Blink during router communication
Turn on NyxLite gateway. Then the “PWR”
LED will glow and “RUN” LED will start
blinking. This indicates that the device is
working
Pre-installation check list:
1. Install gateway at center location of home.

Node ID list for Dip switch configuration:
RF Two / Four Switch I/O module
Room Location Node ID ( DIP switch 8 to 12 )
8 9 10 11 12
Living 1 0 1 0 0 0
Living 2 1 1 0 0 0
Living 3 0 0 1 0 0
Master bedroom 1 1 0 1 0 0
Master bedroom 2 0 1 1 0 0
Master bedroom 3 1 1 1 0 0
Children bedroom 1 0 0 0 1 0
Children bedroom 2 1 0 0 1 0
Children bedroom 3 0 1 0 1 0
Kitchen 1 1 1 0 1 0
Kitchen 2 0 0 1 1 0
Dining / Study 1 0 1 1 1 0
Dining / Study 2 1 1 1 1 0
Lobby 1 0 0 0 0 1
Guest bedroom 1 0 1 0 0 1
Guest bedroom 2 1 1 0 0 1
Room Location Node ID ( DIP switch 8 to 12 )
8 9 10 11 12
Intrusion Detector
Motion Detector
Gas leak detector
Smoke detector
Remote
Entrance Door 0 1 0 0 0
Terrace 1 1 0 0 0
Balcony 0 0 1 0 0
Dry balcony 1 0 1 0 0
Back door 0 1 1 0 0
Entrance door 1 1 1 0 0
Back door 0 0 0 1 0
Terrace 1 0 0 1 0
Balcony 0 1 0 1 0
Dry balcony 1 1 0 1 0
01110
10110
11110
Single 15A switch module (AC)
Single Curtain Controller
Room Location Node ID ( DIP switch 8 to 12 )
8 9 10 11 12
Living AC-1 1 0 1 1 0
10001
Children AC 1 0 1 0 1
Guest AC 0 1 1 0 1
Master bed AC 0 0 1 0 1
Master bed geyser 1 1 1 0 1
Children Geyser 0 1 0 1 1
Guest Geyser 1 1 0 1 1
Living curtain-1 0 0 1 1 1
Living curtain-2 1 0 1 1 1
Master bed room 0 1 1 1 1
Living AC-2
curtain
Single 15A switch module (Geyser)
ON
1234567
Setting DIP switch for Living 1 of Four Switch I/O
Module:
1. Setting of 7 DIP switches of NyxLite Gateway as
per switch setting label on your Gateway is shown
below as an example.
Set as per given on
gateway unit
2. For living 1, set the DIP switch setting as per
table:
ON
123456789101112
Set as per given in table
Example:
Set as per given on
gateway unit
RF Four Switch I/O module
Room Location Node ID ( DIP switch 8 to 12 )
8 9 10 11 12
Living 1 0 1 0 0 0
DIP Switch setting for position 0:
DIP Switch setting for position 1:
How to set DIP switch to 1 or 0:
Four way RF Keypad
Pin Pad
Room Location Node ID ( DIP switch 8 to 12 )
8 9 10 11 12
Living 0 0 0 1 1
Master bedroom 1 0 0 1 1
11111
