OBD2 V317 User manual
USER MANUAL
AUTOMOBILE OBD DIAGNOSTIC INSTRUMENT
QUICK OPERATION MANUAL
V317
CONTENT
1. Product introduction
1
This is a gasoline car code reader，which supports nine standard
protocols of OBD II/EOBD. Plug and play, can quickly read the car's fault
information and vehicle parameters, is a more comprehensive function of
the fault diagnosis instrument. Please read the product manual carefully
before using this product, thank you.
2. Matters needing attention
1. Do not use abrasive cleaners to clean this product.
2. Do not let this product be heated or close to the source of the fire.
3. Do not expose this product to direct sunlight for a long time.
4. Do not try to disassemble this product to make any modifications,
because it does not contain any maintenance components.
5. Do not use this product in the room.
6. If you do not plan to use this product for a long time, please store it in
a dry environment to avoid extreme temperature and dust.
3. Product appearance and function key introduction
3.1 Tool description
1
2
2
3
1.
45
6
6
The OBD plug is connected to the OBD connector of the vehicle.
2. 2.8 color display screen, resolution: 240*320
3. Press the button to the right or page up
4. Confirm key
4. Product parameters and accessories
4.2 Product accessories
4.3 Support Agreement:
4.1 Product parameters
3
4.
5.
6.
ESC to return.
Press the button to the left or next page
Green light: support the vehicle detection
Yellow light: It is read that the vehicle is faulty
Red light: The product is energized normally
Working voltage: DC9～16V
Working current: about 50mA
Operating environment: -20～65℃
Storage temperature: -30～80℃
Dimensions: 168*89*25mm
Eight languages: English, German, Italian, Dutch, French, Spanish,
Chinese, Russian.
Accessories Host *1 Manual *1
1. SAE J1850 PWM (41.6Kbaud)
2. SAE J1850 VPW (10.4Kbaud)
3. ISO9141-2(5 baud init, 10.4Kbaud)
4. ISO14230-4 KWP (5 baud init, 10.4 Kbaud)
5. ISO14230-4 KWP (fast init, 10.4 Kbaud)
6. ISO15765-4 CAN (11bit ID, 500 Kbaud)
7. ISO15765-4 CAN (29bit ID, 500 Kbaud)
8. ISO15765-4 CAN (11bit ID, 250 Kbaud)
9. ISO15765-4 CAN (29bit ID, 250 Kbaud)
5. Product operation instructions
4.4 Main functions
4
Support nine standard protocols of OBD II/EOBD.
Support car battery voltage test.
Support gasoline model reading, clearing vehicle fault code, reading
data stream, freezing frame information, checking MIL status, reading
vehicle information, oxygen sensor test, fuel evaporation system
(mode 8) test.
Support fault code information query.
Support data stream playback function, view/delete fault code, data
stream, and freeze frame information.
Support eight languages English, German, Italian, Dutch, French,
Spanish, Chinese, Russian.
When you need to inspect a car, directly plug this product into the
car’s OBD connector to start the inspection.
6. Page menu introduction
6.1 Car inspection menu
5
After connecting the vehicle, go to the home page, select the
"OBD/EOBD" menu, press the OK button to enter the test function
page, this menu has 9 test functions, you can use the up/down
function keys to turn pages.
6.2 Read data stream
After connecting to the vehicle, go to the homepage, select the "Date
Stream" menu, and press OK to enter the data stream view pag
Data Stream
Vehicle Information
FUELSYS2
LOAD_PCT(%)
ETC(℃)
SHRTFT1(%)
LONGFT1(%)
SHRTFT2(%)
CL
59.6
40
1.6
-46.4
-43.0
1/13
6.3 Fault code query
6.4 I/M ready state
6
After connecting the vehicle, go to the home page, select the "DTC
Lib" menu, press the OK button to enter the fault code query page,
support the query of the vehicle fault code, and explain the reason.
After connecting the vehicle, enter the home page, select the "I/M"
menu, and press the OK button to enter the setting page. This menu
has 2 functions, and you can use the up/down function keys to turn
pages.
I/M Readiness
Since DTCs Cleared
This Drive Cycle
1/2
DTC Lookup
P2100
The 1st range:P,C,B,U
The 2nd range:0,1,2,3
Others from 0 to F
6.5 Voltage test
6.6 Product settings
7
After connecting the vehicle, go to the home page, select the "Voltage"
menu, press the OK button to enter the voltage test page, and check the
voltage value.
After connecting the vehicle, go to the home page, select the "Setup"
menu, and press the OK button to enter the setting page. This menu has
2 setting functions, and you can use the up/down function keys to turn
pages.
System Setup
Language
Unit Of Measure
1/2
Voltage
12.1V
7. Matters needing attention
8. Disclaimer
8
The product is not compatible with new energy vehicles, hybrid vehicles,
and models that do not comply with the OBD2 protocol.
We are committed to providing customers with unparalleled customer
support before and after sales. The following provides our products with
our exemption conditions:
If any of the following conditions are met, the customer shall not enjoy
the policies within the scope of this limited warranty:
a) Abnormal use of the product, abnormal conditions, improper storage,
exposure to moisture or humidity, unauthorized modification, unautho-
rized maintenance, misuse, negligence, abuse, accident, alteration,
improper installation or other actions that are not malfunctions, Including
damage caused by transportation.
b) The product is damaged due to external reasons (such as collision
with objects) or fire, flood, sand, dust, storm, lightning, earthquake or
weather conditions, irresistible acts of natural disasters or battery
leakage, theft and damage, blown fuse, Our company is not responsible
for any product damage caused by incorrect use of any power supply.
3/8
Language
Deutsch
Dutch
English
Español
Français
Italiano
