Annlov AN-02 User manual

ANNLOV Barcode Scanner
User Manual
Mode:AN-02
Customer support:
ANNLOV is dedicated to offerthe best service.
To reach ANNLOV customersupport.Please email:
[email protected]

◄ dH·IW@tttl~f\i!·I·OOil:l:l,]M
VIP CLUB
Dear customer,
Thanks for buying ANNLOV brand products.
All ANNLOV products offer one yearwarranty.
If you have
any problem with our products, please contact us
by the
following way.
Technical Support
Email:
English: [email protected]
Website:
https://www.annlov.net
iWl&@ftl
l'l@ANNLOV
l! ◄ i:13Mtl
If you are satisfied with ANNLOV products and you are willing share
ANNLOV products to your facebook, youtube, twitter, etc, you will
have the chance to be
our VIP.
What's the welfare for our VIP
1. Extended Warranty: The warranty of ANNLOV products will be
extended by 180 days for VIP.
2. Free Priority Trial Qualification: Free priority trial qualification for
you when new products come out.
3. VIP Discounl:10-20% discount for your future order.
More information aboutVIP club,
please visit ourwebsite:www.annlov.net

Precautions
Features&Technical Parameter
Shape Description
Battery & Charging
Buzzer & Indicator Light State
FAQS & Troubleshooting
Restore Factory Defaults Setting & Version Number
Pairing Mode Setting
Upload Mode Setting
IOS Pull up and Hid Keyboard
Language Setting
Communication Mode Switching
Beep&Vibration Setting
Identity Barcode Type
Barcode Setting
Sleep Time Setting
Bluetooth Name Change Setting
End Character Setting
Capital & Lowercase
Hide front and back characters
Set Prefix and Suffix
Appendix A
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
◄ 39·1Wiffi@~tl,1·i·%1ii:i:l=lM
Contents
............................................ 01
..· ·· · ·-··-··-··-··-··-··01-02
.
..................................... 03
...................................... 04
. ......................... 05
. .............................. 06
.... 07
.
.................................. 07-09
·-·-· ·· ···· ·· ·· ·-·-··· ·· ···· ·· ·-·-· 10-11
. ........................ 12
·
..................................... · 13
. ...................... 14
. ................................ 15
.
................................. 16
.
..................................... 16-18
.
.................................... 19
.
...................... 20
.................................. 21
. .................................. 21
. ........................ 22
. .................................. 23
.......................................... 24-34

138·1W@ffi:fif+I·00¥1,l,l,i
In order to correctly use the barcode scanner, please read
the instruction carefully and do notarbitrarily scan the
settings code, otherwise, some settings may not be
available temporarily.
Please keep this instruction for reference in the future.
If you have any question or concern about the operation of
the scanner, please contact us at the following Email:
http://www.www.annlov.net
[email protected]
All our ANNLOV brand product can offer a one-year
warranty and lifelong tech support.
You are suggested to write down the model & the specific
scenario and consult the maintenance person should you
find the scanner abnormal.

ri33•1
1
d#tffi-f:lif·l·i1+1,i,IJM
1.Precautions
1.Please read the user manual carefully before using this
barcode scanner.
2.The working voltage
of this barcode scanner is 3.3V, charging
voltage
5V. Please use our original USB cable and AC power
adapter to ensure the scanner is working properly.
3.Copyright and Patent Notice Ourcompany reserves the
copyright, software copyright and sufficient patents
of the
barcode scanner and its accessories(including firmware, MR
Configurator,illustration documents, appearance and so on. )
4.Ourcompany reserves all rights reserves the right to make any
changes to the product to improve its reliability, function
or
design.Our company shall not be liable for applications or use
of any product or circuit with ourscanner, or any liability arising
therefrom
or in connection with any other applications
described herein.
2.Features&Technical Parameter
ittiUIJ4:M
*Wired and wireless dual mode freely switching.
*One-click matching with various PCs
*Outdoor 30 meters visual transmission distance (Bluetooth
transmission mode).
*Large capacity storage, safe and reliable.
*In storage mode stores barcodes more than 50,000pcs.
*Support normal mode, storage mode and switch freely.
*SupportWindowsXP, Win7, Win8, Win10, operating
system PC&Android devices and iOS devices.
*Support Bluetooth HID protocol, SPP protocol and BLE
protocol (Bluetooth Transmission Mode).
*Unit power management system, ultra-long standby time.
*Rich symbologies supported.
*Adopting imported trigger button, long life, fitting perfectly in
your
*Hand for comfortable use.
-- 01 --

133·1:'@N+if+l·ii+l,l,i1
Technical Parameter
A dual-mode scanner wired and wireless, switch freelv.
Wireless transmission protocol Bluetooth 2.4G
Storage 16Mb
Decodino chip ARM Cortex 32 bits
Bluetooth module Bluetooth
4.1 Module
Codabar,Code11,Code93,MSI,
Code 128,UCC/EAN-128,
Support barcode 1D Code 39,EAN-8,EAN-13,
UPCA,ISBN,lndustrial25,
Interleaved 25,
Standard 25,2/5 Matrix
Indicator LED light, Buzzer, Vibration
Charging voltage /current 5V/1A
Time
of Endurance ContinuouslyWork 8 Hours
under Normal condition
Battery Capacity 1000mAh
Printing Contrast >25%
Scanning Angle Pitch:±65° Roll: 0-360°
Skew: ±60
Standby time >30 days
Working Temperature 32°F to 104°F1o·c to
4o•c
Storage Temperature -40°F to 140°F/-40°Cto
eo·c
Humidity 5% to 95% relative humidity
(no condensation)
Ruggedness Resist about 6 times drops from
1.5m to concrete ground
Under normal office and factory
Ambient Light Immunity ambient lighting conditions,
or
exposed to the sun won't take any
effect to it.
In line with 15KVair discharge
Electrostatic discharge and BKV contact discharge
requirements
In accordance with UL1950,CSA
Electrical safety C22.2 No.950,EN60950/IEC950
EMI/RFl:FCC Part 15 Class
B,European Union EMC
Directive Taiwan EMC
EnvironmentTerms In accordance with RoHS
directive 2002/95/EEC
-- 02 --

ft33·1','@fffi;1'1f!·l·i1+1,i,11M
3.Shape Description
Appearance Introduction
bluetooth
search scanning indicator
charge
indicator
ANNLOV
-- 03 --
switch
(press for3 seconds)

833·1't'ttffitffi+iiHlifi1i1H
4.Battery & Charging
The scanner is powered by 1000mAh chargeable
battery. please ensure that the scanner has
enough power before use.
During normal usage or start-up process, if the buzzer continuously
makes five times long sound (low frequency) ,then automatically
power off. It means the powercapacity is too low and need to be
charged before use
Insert one end
of the USB cable into the bottom of the scanner and
insert another end to computer USB interface
or 5V DC USB
interface power.
Charging indicator:
The red indicator light on the top
of the scannerwill light all the time
during charging and it will go offwhen the scanner is fully charged.
Note:
Please use computer USB interface
or special 5V DC power
adapter for charging, the abnormal power will cause permanent
damage to scanner and battery.
Battery Remaining
To know how much electricity remains, put the cursor in the blank
and then scan the flowing barcode.
1111111111111111111111111111111111111111111111
Electric Quantity Display
-- 04 --

93·1':'ittiM;f\;J.1·11¥1,1,\,iM
5.Buzzer & Indicator Light State
1-\IPJJ-l&
.
Sound Type Description
a long sound(First low then Means poweron
high frequency)
a long sound(First high then Means power
off
lowfrequency)
a short sound(lowfrequency) Means read barcode
a short sound(First low then Means data has been stored
high frequency)
a short sound(First high then Means scan the set-up barcode
lowfrequency)
Means wireless transmission
a short sound(lowfrequency) failed
or cache is full
LED Indicator light
light color Description
two blue lights flicker alternately Enter into HID pairing state
two blue lights flicker
at the same time Enter into BLE pairing state
blue light on the right flicker Enter into SPP pairing state
red light always on Charging state, afterfull,
it will be off
red light flickers Poor battery contact
green light on and off immediately Read barcode successfully
and make a short sound
-- 05 --

839·1Wmfttl:fii+I·OOil:l:I,]
6.FAQS & Troubleshooting
* What should I do if I can not pairscanner with Bluetooth
devices?
A. Please make sure that scanner is in the matching state under
corresponding Bluetooth protocol
B.
If the devices have connected successfully with other barcode
scanners via bluetooth,
or otherdevices. Please delete the
Bluetooth connection record before connecting.
C. The wireless module has been damaged. please contact the seller,
the email address is [email protected]
*Why do some symbologies fail to be read?
The scanning module does not support the symbology
or the
symbology has been turned
off, please contact with the sellerto tum
on the code system.
*Why scans fails to be uploaded to computer or smartphone?
A. Please make sure if they have been successfully paired, if yes, the
LED indicatorofthe bluetooth barcode scanner is blue.
B. Please check
if itis in "Storage Mode". (In "Storage Mode" scans
won't be uploaded automatically, please scan "Data Upload" setting
code manually to upload the scan is required)
C. Please switch to "Normal Mode" to scan and upload simultaneously.
D.The wireless module has been damaged, please contact the seller,
the email address is [email protected]
* Why the barcode content is not correct ?
Please make sure that the PC
or smartphone keyboard language is
the same as Barcode Scanner language.
*Why does the scanner cannot charge?
A. Please select correct charger.
B. The charging circuit
or battery has been damaged.
* How to change more scanning settings?
please contact the seller, the email address is [email protected]
-- 06 --

ftdd·i','@®:f, \ i1·I·tii+l:l:l = iM
7.Restore Factory Defaults
Settin & Version Number
During usage, if you scan other set-up barcodes by mistake and the
scanning cannotperfonn
as normal way, you can scan the "Reset
Configuration
to Defaults" barcode to revert.
Ill IIIII III I IIIII II Il lIIIIll 11 1 11111 1 111111111
initialization setting
If you want to know theversion ofthis barcode scanner, you can
scanthe "Version lnfonnation"
Ill IIIII III I IIIII II II IIIII ll 11 1 11 1 1111111 1 1111
version Information display
a.Pairing Mode Setting
Several methods of usage
A: When using2.4G feature, you can match desktop PCs or PC
terminals that do not supportBluetooth. Scannersupports systems
such
as XP, Win7, Wln8 , Win10,elc.(Please referto the next page
for specific pairing steps)
B:When using Bluetooth, you can matchAndroid, IOS mobile phones,
or PC terminals with bluetooth capabililies.(Pleaserefer to the next
page forspecificpairingsteps)
C:Plug in the data cable with the USB end connected to the computer,
you
can charge the scannerand use It as wired scanner
synchronously
-- 07 --

139·1':'iiffi@+iiHiiii:i:H
Bluetooth Pairing Steps:
Pairwith operating system(lncluding Andro, ios, win system)
that with Bluetooth function:
Method 1:
A: Start the scanner and long press for 8 seconds to enterthe
Bluetooth search mode
B:Turn on Bluetooth in
your device to detect Bluetooth device named
with "Barcode Scanner HID".
If pair successfully, you will heara
beep. Note: When the scanner enters the state
of matching and it
does not pairwith Bluetooth successfully within 1 minute, there is 2
times long low sound indicated failing match and return to scanning
mode.(Or triggertwice to exit match mode and revert to scanning
state)
Method 2:
A: Start the scanner and scan the "Bluetooth pairing setup barcode" to
enterthe Bluetooth search mode
Iii iiliillliiilili i iii! Ii Iii ilili i Iii! lliillil
Bluetooth HID Pairing Mode
B:Turn on Bluetooth in
your device to detect Bluetooth device named
with "Barcode Scanner HID".
If pair successfully, you will heara
beep. Note: When the scanner enters the state
of matching and it
does not pairwith Bluetooth successfully within 1 minute, there is 2
times long low sound indicated failing match and return to scanning
mode.(Or triggertwice to exit match mode and revert to scanning
state)
-- 08 --

CCD Wireless Barcode Scanner
2.4G Pairing Steps：
PC terminals ,like desktop computer, which is not equipped
with Bluetooth, need to pair with Dongle, Dongle Pairing Steps
as follow:
A: Scan Dongle Setup Barcode
Ill I Ill lllll llllll I Ill I II Ill 111111111111111111
B: Scan"Compulsory Pairwith Dongle Setup Barcode" so that
enter into pairing state. The blue light
on the left flickers
quickly.
Ill I Ill lllll llllll I Ill I II Ill 111111111111111111
Compulsory Pair with Dongle Setup Barcode
C: Plug the receiver, If pair successfully, you will hear a beep.
The blue light
on the right will always be bright
Note: When the scanner enters the state
of matching and it
does not detect the receiver successfully within 1 minute, there
is 2 times long low sound indicated failing match and return to
scanning mode.(Ortrigger twice to exit match mode and revert
to scanning state)
-- 09 --

ld3·1Wffitffi=blii·i·ii¥1,l,ii
9.Upload Mode Setting
Normal Mode
In normal mode, the scans are uploaded directly to the computer via
USB cable
or wireless connection. If succeeds, barcode scanner will
make a low-frequency shorttone.
If it fails, there will be three
low-frequency short tones to alarm.
In normal mode, iffails, the data
will be lost.
To set the scanner to upload barcode instantly, scan the following
code.
Ill lllllllllllllllI lllllllll 111111111111111111
Normal Mode
Transmission Speed Setup
Selectthe corresponding transmission speed according to PC
receiving speed.
Ill llll lllll llllll I Il lI II Ill 111111111111111111
Fast
Ill llllllllll lllll I IIII II Ill 111111111111111111
Medium
Ill llllllllll lllll I IIII II Ill 111111111111111111
slow
Ill llll lllll llllll I Il lI II Ill 111111111111111111
Very Low
-10 -

33·1','@f#i+lB · I·i1+i,l,IJM
Storage Mode:
If the transferrange Is beyond Bluetooth wireless transferrange,
storage mode
Is suggested, In which scans arastored In Internal
storage after being scanned
In storage mode, Wa barcode Is scanned, the scannerwill makea
shorttone and the scanned
data areautomaticallystored in the
scanne~s internal storage.
If the internal storageIs full, the scannerwill emit three low-frequen-
cy shorttones to alarm.
*To convert scanner from
11
normal mode to nstorage mode", scan the
following barcode' storage mode'.
I ll lllllllllllllllIIII IIII II IIIII I III IIIIII Ill
Storage Mode
*Upload the stored data by scanning the "Data Upload"barcode.
After the data
is uploaded, the barcode stored inthe barcode
scanner
won't be automaticallydeleted. The user can upload the
storeddata multiple times
by scanning 'Data Upload" barcode.
Ill lllllllllllllllIl ll llllll 1111 1 1111111111111
Data Upload
Note: When uploading data, please ensure thewireless
signal Is perfect,
or upload after connecting with USB cable
*By scan "Total amount of stored barcode" barcode, to check the
total amount of scannedbarcodes in storage:
1 11 11111111 1 1111111 1 1111 11 11 IIIII 1111 111 111111
Total amount of stored barcode
*By scanning 'Clear Data' to clearthe scans in storage, the cleared
scans won't
be uploaded once cleared. Please confirm whetherthe
scans have been uploadedbefore clearthem.
Il lI Ill I III IIIIIIII Ill IIII ll I11 11111111 111 11 11
ClearData
-- 11 --

133·1W@tffi:fli1·1·00¥1,l,11
10.10S Pull up and Hid Keyboard
Method 1:
*it you need pull up the 10S keyboard, you can double click the scan
button.
*if you need hid 10S keyboard, you can double click the scan button
too.
Method 2:
*it you want pull up and hid 10S keyboard, you can also scan the
barcode
as followings:
Ill I Ill lllll llllll I Ill I II Ill 111111111111111111
Pull up and Hide 10S Keyboard
111111111111111 II II II II II Ill lllll llll Illllllll
Triggertwice to pull up iOS keyboard
Ill lllllllllllllll I lllllllll 111111111111111111
Trigger twice to disable iOS keyboard
- 12 -

i3·1W¥@+il+l·ilfi,i:liM
11.Language Setting
1111111 1 11111 1 1111 I II I II I III IIIII IIIII I IIIII II
English
111 1 11 11 111 1 111111 II ll III Ill lll ll llll II ll lll ll
German
Il l lll l llllll l llll 111 1 111111 1 1111111 1 1111111 11
French
Ill lll l lllll llllll I Ill I II Ill 11111 1 11 1 1111111 11
Spanish
111 1 11 11 1111111111 I II I IIII IIIIIII III I 111 1 111 11
Italian
111111111111111 I ll I Ill I II Ill I IIII IIIIII II IIIII
Japanese
1111111 1 1111111111 I Ill I II Ill lllll llllllllllll
Only apply for PC and output by American Keyboard
-13 -

lk3·Jlti@M+iih¥1¥i,i,iJ
12.Communication Mode Switching
Select the Bluetooth protocal you demand
Ill lllllllllllllllI IIIIII Ill 111111111111111111
Bluetooth HID Mode
Ill I Ill lllll llllll I Ill I II Ill 111111111111111111
Bluetooth SPP Mode
111111111111111111 I Ill I II Ill lllll II III II Ill Ill
Bluetooth BLE Mode
Note: Scan above barcode to enter the Bluetooth searching state
-14 -

183·1
1
,'1@@-f,ii!·l · tti+l:l:l,JE
13.Beep & Vibration Setting
Scan one of the following barcode to select the decoding beep &
Vibration mode
IllI Ill lllll lllll lI Ill I II Il l 1111111111111111 11
tum off the sound
Illll ll l lllll l lll lI lllllll ll 11 1 11111111 1 1111 11
tum on the sound
1111 1 111111 1 111 111 1111 11111 111 1 11 1 111111111 Ill
Intermediate volume
Ill lllllllll l lllll 111 1 1111 1 111 111 111111 1 1111 11
High volume
Ill I Ill lllll llllll 1111111111111111111111111111
vibration off(optional)
111111111111111111 I Ill I II Ill lllll llllllll II Ill
vibration on (optional)
-15 -

++··i
1
f5: :,. ... , .... ::
14.IdentltyBarcode Type
-of111e...,_lla\o•lf-....tt-,_,,._
,_, __ ..._w. ... _,.., ____ ..,_
~
15.BarcodllS.tting
II I1 11111 1 111 1 11111 1 11111
Pio..eyon
I ll II11 11 1 111 1 111 111 111 11
Pf9886Yoff
-,s-
