OBDPROG MT301 User manual

OBDPROG User Manual
MT301 User Manual
Statement
This handbook is the manual of MT301. Without the
written permission from the manufacturer, any company or
individual shall not copy or backup it in any form (electronic,
mechanical, photocopying, recording or otherwise).This
manual is only operating instructions for MT301. If any result
caused by using it on other equipment, the company does not
assume any responsibility for it.
If not quality problems of MT301: such as equipment
failure caused by user abuse or misuse, unauthorized
disassembly, repair equipment yourself, not operate or
maintain by the instructions, lose it, the repair will not be
free. Other product names mentioned in this manual are in
order to describe how to use MT301, and their owners are still
the original company.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions(1) The
device may not cause harmful interference, and(2) this device
must accept any interference received, including interference
that may cause undesired operation.

OBDPROG User Manual
Content
Chapter 1 : Summary……………………………………………1
1.1 Features…………………………………………………1
1.1.1 Advantages…………………………………………1
1.1.2 Durability…………………………………………1
1.2 Introduction of the device………………………………2
1.2.1 The introduction of the main unit……………………2
1.2.2 Introduction of Accessories………………………3
1.3 Hardware technical specification………………………4
1.4 Functions Setting………………………………………4
1.4.1 Functions Selection………………………………5
1.4.1.1 Battery Test……………………………5
1.4.2 System Setting……………………………………6
1.4.2.1.Language………………………………6
1.4.2.2.Font……………………………………7
1.4.2.3 Metric/Inch……………………………7
1.4.2.4.Data Logging…………………………8
1.4.3 System Information………………………………8
1.4.4 Device Self-test…………………………………9
1.4.4.1 Keyboard Test……………………………9
Chapter 2: How to update software for OBDPROG MT301……10
2.1 Update Tool software Installation……………………10
2.2 Register ………………………………………………12
2.3 Software Updating……………………………………13

OBDPROG User Manual
1
Chapter1：Summary
1.1. Features
1.1.1. Advantages
Providing multi-language environment so it can be used
in different countries and regions.
The main unit system uses ARM high-speed chip to keep
it running fast, stable, and anti-jamming.
Modern design and high-definition true color screen
realize the integration of automotive industry and
electronic information technologies and make auto
diagnosis and key programming easier, practical and
economical.
1.1.2. Durability
Integrity structure design makes it crack resistance, shock
resistance and durable .
Industrial design ensures the tool work stably under tough
environment, as high and low temperatures.

OBDPROG User Manual
2
1.2 Introduction of the device
12.1 The introduction of the main unit
Number
Name
Instruction
①
Display Screen
Show information
②
Charging Interface
Connect with the charger
③
TF card slot
TF card storage
④
USB Interface
Connect with USB cable
⑤
Up
Up
⑥
F2
Keyboard input option key
⑦
F1
Keyboard input option key
⑧
Right
To right
⑨
Left
To left
⑩
Down
Down
⑪
ESC
Exit or give up
⑫
OK
OK
⑬
Testing cable port
Connect to the main test cable

OBDPROG User Manual
3
1.2.2 Introduction of accessories
OBD 16 pin testing lead (Connect to car diagnostic socket)
Double clamp battery testing lead (Connect to car
battery.( Red--positive/Black--negative)
User Manual

OBDPROG User Manual
4
1.3 Hardware technical specification
Dimension: 202mm(L)*106mm(W)*31.6mm(H)
CPU: ARM CORTEX M3
Power Supply:DC12V
Operation Power:DC12V
Operation Temperature: -10~60℃
Display Screen: 320×240 TFT
1.4 Functions Setting
Power on，and then press ENTER on the screen，then go to
the function setting, setting information as shown below:

OBDPROG User Manual
5
1.4.1 Vehicles
Press OK to confirm。The diagram below。
1.4.1.1 Battery Test
Press OK,press OK to confirm the entry.The diagram below：
Note: the number and function of different product configuration
software will be different ,Please contact the dealer for
confirmation of the number of software.

OBDPROG User Manual
6
1.4.2 System Setting
Select system setting, you can set the language,font,
metric/English system, data record, as shown below.
1.4.2.1 Language selection
This device supports simplified Chinese, traditional Chinese,
English, Russia, Greek, Spanish, Italian. In the language directory,
select required language by Up and Down and press ENTER to
confirm it.

OBDPROG User Manual
7
1.4.2.2 Font
Choose large or small fonts
1.4.2.3 Metric/Inch
Optional metric or English system

OBDPROG User Manual
8
1.4.2.4 Data Logging
Optional to close or open
1.4.3 System Information
The system information includes the product serial number,
the hardware version, the software version, the hair Cloth date,
registration password.

OBDPROG User Manual
9
1.4.4 Device Self-test
Liquid crystal self-check or keyboard self-check can be
selected.
1.4.4.1 Keyboard self-inspection
The machine self-check includes LCD display, keyboard test, such
as the lack of the display screen, keyboard malfunction, please
send MT301 to the manufacturer for maintenance

OBDPROG User Manual
10
Chapter 2: How to update software for MT301
2.1 Update Tool software installation
Login our website: http://www.obdprog.com and click “Click
a key to upgrade”.
Download the update tool and diagnostic software, double
click , then go to the next step:
Step1:Click “Next”
Step 2: Click “Next

OBDPROG User Manual
11
Step3: Click “Next”
Step 4: Click “Finish”

OBDPROG User Manual
12
2.2 Register
Click “Sign up” to fill in user information. Username can be
Chinese characters or the combination of alphabet and numbers.
Serial number and register password can be referred to System
information in the device.( Figure 1.4.3）

OBDPROG User Manual
13
2.3 Software Updating
Operation steps as following:
Step 1: Remove the TF card from your device.
Insert your TF card into computer.
Step 2: Open update tool and login
Step 3:Click the source menu, choose the program you want to
update, click it and confirm.
Step 4: Click and select all the software then click “update”
Step 5: Wait for several minutes then the updating finished
Note:For new update software and questions during
updating, please contact your distributor.
