Oblica FOCUS SERIES User manual

GYROFOCUS:
INSTALLATION AND
USER MANUAL
1. TECHNICAL DATA 2
2. PRE-INSTALLATION 3
3. INSTALLATION 5
4. OPERATION 11
5. TESTING 12
Keep for future use
OBLICA
200 Argyle St
Fitzroy VIC 3065
03 9416 0400

PAGE 2
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
1. TECHNICAL DATA
DETERMINED UNDER TEST CONDITIONS:
Nominal thermal output 6kW
Efficiency 57,8%
WEIGHT AND DIMENSIONS:
Firebox diameter 1250mm
Firebox weight 92Kg
Flue diameter 219mm
Flue weight 16Kg/meter
Standard bracket weight 20Kg
External flue kit Triple skin 200/250/300mm
ø219 mm
FLUE
ø1250 mm
500 mm
FIREBOX

PAGE 3
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
2. PRE-INSTALLATION
Congratulations on your purchase of the GyroFocus. This appliance should be installed and checked by a qualified
professional. Ensure you have read the operation guidelines thoroughly prior to first use. For any questions or concerns
please contact Oblica on 03 9416 0400.
The installation process is outlined below:
– Determine position of firebox and flue carefully observing the clearances described within this section
– Install the suspension bracket
– Install the external flue
– Install the internal flue and engage the firebox
– Ensure the floor has adequate protection
CAUTION:
Using components or parts other than those provided by the manufacturer or modifying the specification of components
may result in inferior or unsafe operation. If such action is necessary, consult the manufacturer in the first instance.
WARNING:
• The appliance and flue-system must be installed in accordance with AS/NZS 2918 and the
relevant building code or codes.
• Any modification of the appliance that has not been approved in writing by the testing authority
will be in breach of the approval granted for compliance with AS/NZS 4013.
• Once the flue has been installed and approved by a professional installer, the flue must not be
modified in any way.

PAGE 4
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
MINIMUM CLEARANCE – INTERNAL
2.1 Clearance from non-combustible surfaces
(eg masonry)
100mm minimum clearance is required from fully
non-combustible surfaces.
100
100
520
520
Non Combustible
Non Combustible
1200
1200
Combustible
FULLY ROTATING
Combustible
Combustible
FIXED
Combustible
500
500
Glass
(frameless or aluminium frame)
Glass
(frameless or aluminium frame)
2.2 Clearance from glass
500mm minimum clearance is required from normal
non-combustible glass.
350mm minimum clearance is required from
toughened glass.
100
100
520
520
Non Combustible
Non Combustible
1200
1200
Combustible
FULLY ROTATING
Combustible
Combustible
FIXED
Combustible
500
500
Glass
(frameless or aluminium frame)
Glass
(frameless or aluminium frame)
2.3 Clearance from combustible surfaces
(eg timber joist & plasterboard)
1200mm minimum clearance is required on all sides
when the GyroFocus can rotate 360˚ .
100
100
520
520
Non Combustible
Non Combustible
1200
1200
Combustible
FULLY ROTATING
Combustible
Combustible
FIXED
Combustible
500
500
Glass
(frameless or aluminium frame)
Glass
(frameless or aluminium frame)
520mm minimum clearance is required if the rotation
of the GyroFocus is locked at 120˚ or 90˚ away from the
wall. Locking the GyroFocus so that the opening is fixed
is an option available on purchase.
100
100
520
520
Non Combustible
Non Combustible
1200
1200
Combustible
FULLY ROTATING
Combustible
Combustible
FIXED
Combustible
500
500
Glass
(frameless or aluminium frame)
Glass
(frameless or aluminium frame)
Clearances may be reduced with the application of
heat shielding to walls in accordance to the Australian
Building Code.
For information on heat shielding please contact our
office on 03 9416 0400 or email [email protected].
IMPORTANT:
Frames must also be considered. Timber window
frames must be treated as combustible surfaces
(see 2.3). Aluminium frames can be treated as
non-combustible surfaces (see 2.2).
2. PRE-INSTALLATION (CONTINUED)

PAGE 5
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
3. INSTALLATION
LOWER FLUE 219mm dia.
CONNECTOR
SUSPENSION BRACKET
CEILING FLANGE
CROSS BAR SET IN-BETWEEN RAFTERS
RUBBER FLASHING
TRIPLE SKIN FLUE
200 X 250 X 300
(8’ x 10’ x 12’)
CHINAMAN HAT
(Anti-Down-Draft device)
Insulative pad
( Plaster Ceiling Minimum Gap)
150 250
40
12
25
3.1 Installing the suspension bracket
• The bracket must be structurally secured within the roof as shown in the diagram below.
• The largest cylinder must project down from the ceiling by at least 150mm (BCA requirement) unless
the ceiling is made from a non-combustible material such as concrete.
• You must leave a 25mm clearance gap between the bracket and the ceiling. This gap will be covered by
the ceiling Flange.
• 12mm ventilation gap between the plasterboard and the ceiling flange
• 25mm minimum clearance from the triple skin flue to any combustible material within the roof space
• 40mm minimum overlap of the stainless steel 8” flue into the connector
TYPICAL FLAT ROOF INSTALLATION

PAGE 6
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
3. INSTALLATION (CONTINUED)
Custom Length & Angle
12
25
150
PITCHED ROOF INSTALLATION (CUSTOM MADE BRACKET)

PAGE 7
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
3. INSTALLATION (CONTINUED)
3.2 Installing the external flue
1. Place the connection piece inside the suspension bracket. This will join the single skin flue below the
bracket and the triple skin flue above the bracket which have different diameters.
2. Ensure the triple skin flue is installed as per Australian standards (see diagrams below).
The top of the flue must be 400mm higher than the highest point of the roof. Alternatively, there must be a
minimum distance of 3 meters from any higher section of roof.
> 40 cm
–> 40 cm
–> 40 cm
–
> 3 m
–
> 120 cm
–
> 3 m
–
> 120 cm
–
> 120 cm
–
> 40 cm
–> 40 cm
–> 40 cm
–
> 3 m
–
> 120 cm
–
> 3 m
–
> 120 cm
–
> 120 cm
–
The top of the flue must be 1200mm above the roofline. Alternatively, there must be a minimum distance of
3 meters from any higher section of roof.
PITCHED ROOF INSTALLATION
FLAT ROOF INSTALLATION (LESS THAN 5˚ PITCH)

PAGE 8
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
Black steel single skin lower flue
Thrust ball bearings
Washers
ø13/27
ø21/40
ep. 3mm
Bearing holder
M12 nuts
Safety split pin
3.3 Installing the internal flue
1. Position the single skin flue inside the suspension bracket and tighten the grab screws.
Ensure that the flue is perfectly vertical and the grab screws are tight.
2. Engage the firebox with the bolt bearings as per the diagram below.
3. INSTALLATION (CONTINUED)
Grab Screw

PAGE 9
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
3.4 Protecting the floor
• Any combustible floor beneath a fireplace must have a floor protector that extends 300mm beyond the
diameter of the firebox in all directions.
• If installed directly on combustible material, the floor protector must be made of a 20mm thick sheet of
material with a thermal conductivity of 0.21W/m.K. Non-combustible finishes can be applied to the floor
protector (tiles, steel sheet, light concrete, etc).
• If the combustible floor is installed on concrete, you can replace the combustible material with non-
combustible material laid directly onto the concrete.
Joist
300mm
300mm
Insulative board (20mm)
+ non combustible finish
Non combustible finish
(eg.tiles)
non combustible finish
Floor protector /
Concrete
300mm
FIREBOX
Combustible floor (eg. timber)
Combustible
floor (eg. timber)
Combustible
floor (eg. timber)
Joist
300mm Insulative board (20mm)
+ non combustible finish
Combustible
floor (eg. timber)
FLOOR PROTECTOR LAID ON TIMBER FLOOR
3. INSTALLATION (CONTINUED)
Joist
300mm 300mm
Insulative board (20mm)
+ non combustible finish
Non combustible finish
(eg.tiles)
non combustible finish
Floor protector /
Concrete
300mm
FIREBOX
Combustible floor (eg. timber)
Combustible
floor (eg. timber)
Combustible
floor (eg. timber)
Joist
300mm Insulative board (20mm)
+ non combustible finish
Combustible
floor (eg. timber)
FLOOR PROTECTOR LAID ON JOIST

PAGE 10
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
Joist
300mm
300mm
Insulative board (20mm)
+ non combustible finish
Non combustible finish
(eg.tiles)
non combustible finish
Floor protector /
Concrete
300mm
FIREBOX
Combustible floor (eg. timber)
Combustible
floor (eg. timber)
Combustible
floor (eg. timber)
Joist
300mm Insulative board (20mm)
+ non combustible finish
Combustible
floor (eg. timber)
Joist
300mm 300mm
Insulative board (20mm)
+ non combustible finish
Non combustible finish
(eg.tiles)
non combustible finish
Floor protector /
Concrete
300mm
FIREBOX
Combustible floor (eg. timber)
Combustible
floor (eg. timber)
Combustible
floor (eg. timber)
Joist
300mm Insulative board (20mm)
+ non combustible finish
Combustible
floor (eg. timber)
FLOOR PROTECTOR LAID ON CONCRETE
TOP VIEW
3. INSTALLATION (CONTINUED)

PAGE 11
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
4. OPERATION
4.1 What you should burn
• Untreated, air dried hardwood
• Split logs with a humidity content of less than 20%
4.2 Do not burn
• Trash
• Painted plastic
• Coated or preservative treated wood
• Waste or black coal
• Inflammable liquids
• Fire gels
• Moist wood with a residual humidity content of more than 20% (this may cause soothing of the chimney).
WARNING:
• Do not use flammable liquids or aerosols to start or rekindle the fire.
• Do not use flammable liquids or aerosols in the vicinity of the fireplace when operating.
• Do not store fuel within prescribed installation clearance distances.
• The use of some types of preservative-treated woods as a fuel can be hazardous.
IMPORTANT:
• Misuse may lead to unhealthy and environmentally harmful emissions and will void any warranty or guarantee.
• The maximum load capacity for the GyroFocus is 20kg of wood.
• Burning only seasoned hardwood helps to protect the environment and lower emissions.
For details of a wood supplier in your area please call our office on 03 9416 0400 or email [email protected].

PAGE 12
OBLICA | GYROFOCUS INSTALLATION AND USER MANUAL
TEST REPORT Nº ATL19-10
TESTING LABORATORY: AHHA Testing Laboratory
6/26 Stirling st
Thebarton, SA 5031
08 8351 8056
MANUFACTURER: Focus – Atelier Dominique Imbert
MODEL: GyroFocus open style fireplace
WORK REQUESTED: Measure CO2 levels as outlined in AS/NZS 4013:1999
to determine if appliance is excluded from full testing
to this standard.
TEST DATES: 21/05/2010
RESULTS: The maximum carbon dioxide output by the appliance
during the high burn rate prescribed in AS/NZS 4013:1999
was 4.54%.
CONCLUSION: This appliance meets the requirements of AS/NZS
4013:1999 section 1.2.3 (f) and is classified as an
excluded appliance.
5. TESTING
