OctiveTech 300AH User manual

▒▓ www.OctiveTech.com Operating Instructions
1
OctiveTech 300AH
HANDHELD OXIMETER
OPERATING
INSTRUCTIONS
Octive Technologies U.S.A.
www.OctiveTech.com
▒▓ www.OctiveTech.com Operating Instructions
2
Contents
CHAPTER1
INTRODUCTION............................................................3
1.1 Brief Introduction .........................................................................................3
1.2 Safety Information............................................................................................…3
1.3 Electromagnetism interference ..........................................................................4
1.4 Conception of Warning，Caution and Note.....................................................4
CHAPTER 2 OVERVIEW of SYSTEM ...................................... 6
2.1 Summary...............................................................................................................6
2.2 Specifications .......................................................................................................6
CHAPTER 3 OPERATION GUIDE.......................................... 7
3.1 Appearance ..........................................................................................................7
3.2 Display...................................................................................................................7
3.3 Operation ..........................................................................................................8
3.4 Power Supply .................................................................................................15
CHAPTER 4 USE GUIDE .............................................. 16
4.1 The necessary setup before operation .......................................................16
4.2 SPO2 (Arterial oxygen saturation) Monitor ................................................16
4.3 Alarm ...............................................................................................................19
CHAPTER 5 MAINTENANCE and REPAIR............................. 20
5.1 Maintenance ...................................................................................................20
5.2 Trouble Shooting............................................................................................21
5.3 Warranty and Repair .....................................................................................21

▒▓ www.OctiveTech.com Operating Instructions
3
CHAPTER 1 INTRODUCTION
1.1 Brief Introduction
Thank you for using the handheld pulse oximeter. The main functions of this device
are to measure SPO2 and PR, visual and audio alarm, sensor off alarm, data storage
and replay etc. Please read the operator’s manual carefully before operating it.
Application range: The device is used to monitor patient’s arterial oxygen saturation
and pulse rate continuously.
1.2 Safety Information
!
●The handheld pulse oximeter is to be operated by qualified personnel only.
Before using, carefully read this manual, directions for using of accessory, all
precautions, and all specifications. The user must check that the equipment
functions safely and ensure that it is in proper working condition before being
used.
●The is intended for use only as an adjunct in patient assessment. It must be
used in conjunction with clinical signs and symptoms.
●To avoid an electrical hazard, never immerse the unit in any fluid or attempt to
clean it with liquid cleaning agents. Always take out the batteries before
cleaning.
●If oximeter becomes accidentally wet during use, stop operation of the oximeter
until all affected
components have been cleaned and permitted to dry completely. Contact your
local representative if additional information is required.
●If any parameters displayed on oximeter is not accurate, adopt the other
methods to diagnosis patient.
●The medical equipment must be manipulated by personnel who have already
gotten the relative training of operation.
●For safe and accurate operation, use only recommended accessories. Request
for the special children or infant accessories, when monitoring infant or
▒▓ www.OctiveTech.com Operating Instructions
4
children.
●Do not use the oximeter in the presence of a flammable anesthetic mixture with
air, oxygen or nitrous oxide
●Alarm must be set up according to different situation of individual patient. Make
sure that audio sound can be activated when alarm occurs.
● For proper equipment maintenance, perform the service procedures at the
recommended intervals as described in the manual.
●Do not use the oximeter during Magnetic Resonance Imaging (MRI) scanning.
Induced current could potentially cause burns. The oximeter may affect the
MRI image, and the MRI unit may affect the accuracy of oximeter measurements.
● The oximeter can monitor only one patient synchronously.
●As to the other points for attention, please carefully read the relevant chapter in
this instruction.
1.3 Electromagnetism interference
The oximeter is low power consumption device. It will not interference
surrounding people, device and environment. Nevertheless, if there is strong
electromagnetic interference near the equipment, it may result in harmful
interference, even makes performance inactivate. Therefore, if any the warp of
anticipated effect appears, you should firstly prevent, identify and solve the
adverse electromagnetic interference, then proceed to use the device.
To reduce possible problems caused by electromagnetic interference, we
recommend the following:
1. Interference from adjacent radio or mobile phone.
If the radio is the interference source, install the equipment in other place. If the
mobile phone is the source, make it far away from the equipment.
2. Direct and indirect electrostatic discharge:
Before using equipment, make sure operator and patient who touch the
equipment have no direct or indirect electrostatic power. Damp room is helpful to
remit such problem.
1.4 Conception of Warning, Caution and Note
Warning, Caution and Note
The Warning, Caution and Note in the manual are special information to draw the
operator’s attention.
●Warning

▒▓ www.OctiveTech.com Operating Instructions
5
Tell you about something that could hurt patient or operator.
●Caution
Remind user to pay more attention to error operation, which may induce the
possibility of the patient’s hurt and death, includes abnormal function, crash,
damaged equipment and other property.
●Note
Tell you other important information like suggestion, requirement and supplement
CHAPTER 2 OVERVIEW OF OXIMETER
2.1 Summary
Our new-type handheld pulse oximeter can monitor SPO2 and PR.
▒▓ www.OctiveTech.com Operating Instructions
6
2.2 Specifications
Display
Size: 55mm*27.5mm
Resolution: 128*64
DisplayingWaveform: SPO2, pulse column
Data: SPO2%,PR
Others: Connection status of probe, time and remaining
batteryenergy
Alarm
Alarm: SPO2%,probeoff
Alarm mode: audio alarm, visual alarm (flash the value) and
information
Alarm switch: turn on or off alarm
SPO2
Display range: 0%~100%
Resolution: 1%
Accuracy: 2%(70-100%) Unspecified (0-69%)
Pulse Rate
Display range : 0~254bpm
Measurement range: 30~254 bpm (zero is ---)
Resolution: 1bpm
Accuracy: 2bpm or2%
Operation Environment
Operating temperature: 5℃~40 ℃
Relative humidity: ≤80%
Atmosphere pressure: 86kPa～106kPa
Power supply: 4 AA Ni-MH batteries or AC-DC 6V
Working time: work for 24 hours continuously
Trend
Recall 24 hours trend graph of SpO2 and PR
Store and replay
Store and replay more than 24 hours parameters of SPO2%, PR. The
time interval is 1 minute.
CHAPTER 3 Operation Guide
3.1 Appearance
SPO2 socket

▒▓ www.OctiveTech.com Operating Instructions
7
Fig 3.1(Front) Fig 3.1(Back)
3.2 Display
The handheld pulse oximeter uses graphic dot matrix LCD to display. It can display
the value and the waveform synchronously or display the value only by selecting
menu. Please refer to Fig 3.2ٛ3.3.
Fig 3.2
Fig 3.3
Instruction：
SPO2: SPO2 value（displaying value is 98% now）
PR：Pulse rate（displaying value is 156bpm now）
Technical alarm: Probe off: indicate SPO2 probe off;
Current time
Pulse column
SPO2 waveform
Visual and audio
alarm
Lock of ke
y
board
Low power
Visual alarm
Current time
SPO2
Pulse rate
Button Batteries cover
Indicate light
Indicator of power
consum
p
tion
▒▓ www.OctiveTech.com Operating Instructions
8
No Finger: indicate SPO2 probe does not detect finger
12:37:56: Current time is 12:37:56 now
Low power: When displays on the screen, it means the power is low and
you should change batteries promptly.
3.3 Operation
3.3.1 Power on/off the oximeter
The oximeter can work orderly after putting on batteries and enter the default
display automatically. If you want to power off the oximeter, press the “ON/OFF”
button for several seconds.
3.3.2 Function buttons
Right button Enter main menu from normal display and change the
setting value
Left button Enter main menu from normal display and change the
setting value
Up button Menu selection
Down button Menu selection
Enter button Confirm the operation and return the previous menu
F1 The button is useless now.
LOCK Lock keyboard
ON/OFF Power switch
3.3.2.1 Use of the “LOCK” button
In the main interface showed as Fig 3.2, pressing the “LOCK” button, “press ENTER
to lock keyboard” will be presented on the display, then press “ENTER” button, the
keyboard is locked, displays on the screen. In that case, any buttons is useless
unless releasing “LOCK”, press the “LOCK” button and “press ENTER to unlock
keyboard” shown on the display, press “ENTER” button.
3.3.2.2 Use of the “ON/OFF” button
When the oximeter is powered on, press the “ON/OFF” button for several seconds to
power off; when the oximeter is powered off, press the “ON/OFF” button for several
seconds to power on.
3.3.3 Main menu
Press or can enter main menu. Sometimes the monitored parameters
can not be displayed synchronously in one screen, press or to rotate the
screen.

▒▓ www.OctiveTech.com Operating Instructions
9
The menu is shown as Fig3.4
Fig 3.4
In the main menu, press or to highlight the item you want to select, then
press enter the submenu or press to cancel the selection, return the
normal interface. You can also press the “ENTER” button to return the normal
interface.
3.3.4 Display Type
Enter the “Display Type” submenu from main menu, there are two selections shown
as the Fig3.5. Press or to highlight the Data or Waveform, press the
“ENTER” button to return the main menu.
Fig 3.5
Attention: the oximeter only displays the approximate waveform.
3.3.5 Alarm Set：
Enter the “Alarm set” submenu from main menu. The setup of the alarm includes
DisplayType
Data
WaveandData
0DisplayType
1AlarmSet
2DataManage
Cancel Select
3TimeSet
4DateSet
5PulseAudio
Cancel Select
6LanguageSet
7 Backlight Set
8About
Cancel Select
▒▓ www.OctiveTech.com Operating Instructions
10
on/off, the setup of alarm limit. Please refer to Fig 3.6
Fig 3.6
Press or to highlight the submenu, press to enter the submenu. Enter the
Alarm Type submenu shown as Fig 3.7, now you can press or to select the
items of submenu. Press the “ENTER” button to return the main menu.
Attention: There are three selections for the Alarm Type. The first is “Visual Alarm”,
when you select this item, only visual alarm is responded when alarm event happens,
the audio alarm is mute, displays on the left top corner of the screen; The second
is “visual and audio”, when you select this item, the visual and audio alarm are
activated when new alarm occurs, displays on the left top corner of the screen.
The last one is “off”, when you select this item, the visual and audio alarm are
inactivated. No alarm is responded when the alarm event happens, displays on the
left top corner of the screen. Press the “ENTER” button to return the previous menu.
When the value and waveform are displayed on the screen, pressing “ENTER” button
can switch and .
Fig 3.7
Select “SPO2 Limit Set” item in the menu shown as Fig 3.6 and press to enter
the submenu shown as Fig 3.8. Pressing or to select “Upper Limit” or “Lower
Limit”. Pressing or to set the limits. Press the “ENTER” button to restore the
previous menu.
Fig 3.8
Select “PR Limit Set” item in the menu shown as Fig 3.6 press to enter the
submenu shown as Fig 3.9. Pressing or to select “Upper Limit” or “Lower
Limit”. Pressing or to set the limits. Press the “ENTER” button to return the
AlarmSet
Alarm Type
SPO2LimitSet
PR LimitSet
AlarmType
LightAlarm
Sound And Light
Off
SPO2LimitSet
UpperLimit：99
LowerLimit：90

▒▓ www.OctiveTech.com Operating Instructions
11
previous menu.
Fig 3.9
3.3.6 Data Management
Select the “Data Management” item in the main menu shown as Fig 3.4 and enter the
“Data Management” submenu shown as Fig 3.10. You can adjust the display and
management of historic data. Sometimes the monitored parameters can not be
displayed synchronously in one screen, you can press or to change the
screen.
Press or to highlight the item you want to set, then press to enter the
submenu. Press the “ENTER” button to return the main menu.
3.3.6.1 Data Browse
Highlight the “Data Browse” shown as Fig 3.10 then press to enter the “Data
Browse” shown as Fig 3.11
Fig 3.11
In the interface shown as Fig 3.11, press or to change the interval. The
longest interval is 10 minutes, press or to change the screen to view the data,
press the “ENTER” button to return the previous menu.
3.3.6.2 SPO2 Trend
PRLimitSet
UpperLimit：100
LowerLimit：50
DataManage
DataBrowse
SPO2Trend
PRTrend
DataManage
SPO2Trend
PRTrend
ClearData
Fig 3.10
▒▓ www.OctiveTech.com Operating Instructions
12
Highlight the “SPO2 Trend” shown as Fig 3.10 to display the SPO2 trend graph
shown as Fig3.12
Fig 3.12
The ordinate shown as Fig 3.12 represents the value of SPO2, the abscissa
represents the time. 60 points can be displayed synchronously in one screen at most,
the trend for one hour. Each time on the abscissa matches with SPO2% monitored at
that time. The “SPO2” displayed on the left top corner of the screen means SPO2
trend graph. “01 hour” means one-hour trend graph. “01/24”means there are 24
pages in all and this is the first page.
Press or you can select one hour, eight hours and 24hours trend graph.
“60Dot” means the actual points displayed on the screen now.
You can press or to change the screen to view the trend graph when more than
one screen points (60 points) to be displayed on the screen.
3.3.6.3 PR Trend
Highlight the “PR Trend” shown as Fig 3.10 to display the PR trend graph Shown as
Fig3.13
Fig 3.13
The ordinate shown as Fig 3.13 represents the value of pulse rate, the abscissa
represents the time. 60 points can be displayed synchronously in one screen at most,
the trend for one hour. Each time on the abscissa matches with PR monitored at that
time. The “PR” displayed on the right top corner of the screen means PR trend graph.
“01 hour” means one-hour trend graph. “01/24” means there are 24 pages in all and
this is the first page.

▒▓ www.OctiveTech.com Operating Instructions
13
Press or you can select one hour, eight hours and 24hours trend graph.
“60Dot” means the actual points displayed on the screen now.
You can press the or to change the screen to view the trend graph when more
than one screen points (60 points) to be displayed on the screen.
3.3.6.4 Clear Data
Highlight the “Clear Data” shown as Fig 3.10 and enter the interface Shown as Fig3.14
Fig 3.14
Press or to select “Cancel” or “Sure” then press the “ENTER” button to confirm,
return the previous menu.
3.3.7 Time Set
Highlight the “Time Set” in main menu shown as Fig 3.4 then you can see the “time
set” submenu shown as Fig 3.15.
Fig 3.15
Press or to highlight the item you want to set, then press or to adjust
the item you selected. Press the “ENTER” button to return the previous menu.
3.3.8 Date Set
Highlight the “Date Set” in main menu shown as Fig 3.4 then you can see the “Date
set” submenu shown as Fig 3.16.
g 3.16
ClearData
Cancel
Sure
TimeSet
15 Second
19Minute
17Hour
DateSet
15Day
12Month
2004 Year
▒▓ www.OctiveTech.com Operating Instructions
14
Fig 3.16
Press or to highlight the item you want to set, then press or to
adjust the item you selected. Press the “ENTER” button to return the previous
menu.
3.3.9 Pulse Audio
Highlight the “Pulse Audio” in the main menu shown as Fig 3.4, then you can enter
the “pulse audio” submenu shown as Fig 3.17. Pressing or to select on or
off for pulse audio. Press the “ENTER” button to return the previous menu.
Fig 3.17
3.3.10 Language Set
Highlight the “Language Set” in the main menu shown as Fig 3.4, then you can
enter the “Language Set” submenu shown as Fig 3.18. Pressing or to
select language. Press the “ENTER” button to return the previous menu.
Fig 3.18
3.3.11 Backlight Set
Highlight the “Backlight Set” in the main menu shown as Fig 3.4 and enter the
“Backlight Set” Submenu shown as Fig 3.19.Press or to select “Always on” or
the time you want the backlight to last. “Always on” means the backlight will always
be on, press or to change the time how long the backlight will be lit, the unit
is second. Press the “ENTER” button to return the main menu.
PulseAudio
ON
OFF
Language Set
English
Chinese

▒▓ www.OctiveTech.com Operating Instructions
15
Fig 3.19
3.3.12 System Setting
Enter the submenu from the main menu, where it shows the system information and
the version shown as Fig3-20
Fig 3.20
3.4 Power Supply
The oximeter uses 4 AA Ni-MH rechargeable batteries, which can work 24 hours
continuously.
CHAPTER 4 Use Guide
4.1 Necessary Setup before Operating
BacklightSet
AlwaysOn
15 Second
▒▓ www.OctiveTech.com Operating Instructions
16
4.1.1 Adjusting date and time
Once the oximeter being powered on, the current time will be displayed on the right top
corner. Check whether the time is exact, if not please adjust it. As for detailed
operation, please refer to the time setup in Chapter 3 operation guide.
4.1.2 Clearing the old record
The measured records are not cleaned away automatically. We advise user to clear
the previous data before operation.
4.1.3 Setup of alarm limit
The default high/low alarm limit of the oximeter have been set when ex work, but user
can also set the new alarm limits according to the patient’s conditions for realizing the
best performance of oximeter.
As for the detailed operation, please refer to the alarm setting of Chapter 3 Operation
Guide.
4.2 SPO2 (Arterial oxygen saturation) Monitor
4.2.1 Chief introduction
What is SpO2 Monitoring?
SpO2 plethysmogram measurement is employed to determine the oxygen
saturation of hemoglobin in the arterial blood，that is the percentage of hemoglobin
molecules and oxygen molecules。For example, 97% hemoglobin molecules in the
red blood cells of arterial blood combine with oxygen, then the blood has a Spo2
oxygen saturation of 97%，the Spo2 numeric on the monitor will read 97%.The Spo2
numeric shows the percentage of hemoglobin molecules that have combined with
oxygen molecules to form oxhemoglobin. SpO2 /PLETH parameter can also
provide a pulse rate signal and a plethysmogram wave.
How do the SpO2/PLETH parameters work?
Arterial oxygen saturation is measured by a method called pulse oximetry. It is a
continuous, no-invasive method. It measures how much light, sent from light
sources on one side of the sensor, is transmitted through patient tissue to a
receiver on the other side.
The amount of light transmitted depends on many factors, most of which are
constant. However, one of these factors is blood flow in the arteries varies with
time, because it is pulsating. By measuring the light absorbing
during the pulsation, it is possible to get the oxygen saturation of arterial blood.
Detecting the pulsation gives a PLETH waveform and pulse rate signal.
Spo2 value is shown in the form of numerical value, PLETH waveform is shown in
the form of graph on the screen.

▒▓ www.OctiveTech.com Operating Instructions
17
Warning：If there is carbon oxygen hemoglobin, high iron hemoglobin or dye
dilution agent on the sensor, it would lead to inaccurate Spo2 value.
4.2.2 Monitoring Spo2%/Pluse rate
Warning：Do not tangle with SpO2 cable with the wires of ES(Electro surgery)
equipment.
Warning：Do not put the sensor on extremities with arterial catheter or
venous syringe.
Caution ：Do not perform SpO2 measuring and NIBP measuring in same arm
at one time, because obstruction of blood flow during NIBP
measuring may adversely affect the reading of SpO2 value.
SpO2 plethysmogram measurement
 Select the appropriate type and size sensor
 Attach the sensor to the appropriate site of the patient finger
 Plug the connector of sensor into SpO2 socket on the top panel of pulse
oximeter.
Fig 4.1 placement of the sensor
4.2.3 Limitation for measurement
In operation, the accuracy of oximetry readings can be affected by the following
factors.
4.2.3.1 Whether the performance of measurement is content or not depends on the
pulsant in the artery. The measurement would not be performed if the following
instances come across in operation:
 Shock
 Low temperature of hand
 Have taken vascular activity medicine
 Anemia
4.2.3.2 Whether the performance of measurement is content or not also depends
on the absorption of oxyhaemoglobin and deoxyhemoglobin for special wavelength.
▒▓ www.OctiveTech.com Operating Instructions
18
If there are substances absorbing the same wavelength, which would induce false
or low SpO2 value, for examples:
 carboxyhemoglobin
 methemoglobin
 methylene blue
 Indigo carmine
4.2.3.3 Extreme illumination would affect the Spo2 measurement, using
nontransparent cover to shield the sensor would get the better performance.
Note：Pulse sensor should obviate the light source, e.g. radial lamp or
infrared lamp.
Prolonged and continuous monitoring may increase jeopardy of unexpected
change of dermal condition such as abnormal sensitivity, rubescence,
vesicle, repressive putrescence, and so on. It is especially important to check
the sensor placement of neonate and patient of poor perfusion or immature
dermogram by light collimation and proper attaching strictly according to
changes of the skin. Check per 2~3 hours the sensor placement and move it
when the skin deteriorates.
4.2.3.2 Whether the performance of measurement is content or not also depends
on the absorption of oxyhaemoglobin and deoxyhemoglobin for special wavelength.
If there are substances absorbing the same wavelength, which would induce false
or low SpO2 value, for examples:
 carboxyhemoglobin
 methemoglobin
 methylene blue
 Indigo carmine
4.2.3.3 Extreme illumination would affect the Spo2 measurement, using
nontransparent cover to shield the sensor would get the better performance.
Note：Pulse sensor should obviate the light source, e.g. radial lamp or
infrared lamp.
Prolonged and continuous monitoring may increase jeopardy of
unexpected change of dermal
condition such as abnormal sensitivity, rubescence, vesicle, repressive
putrescence, and so
on. It is especially important to check the sensor placement of neonate
and patient of poor
perfusion or immature dermogram by light collimation and proper
attaching strictly according
to changes of the skin. Check per 2~3 hours the sensor placement and
move it when the skin
deteriorates.

▒▓ www.OctiveTech.com Operating Instructions
19
Do not immerse sensor completely in water, Do not immerse sensor completely in
water solvents or cleaning agent because the sensor and connector are not
waterproof.
If cable is damaged, please stop using it immediately
Cleaning：
Moisten the soft cloth or gauze with alcohol and use it to wipe the surface of
sensor, and then use the clean cloth to dry it .The same method can be used
to clean the light source and photo detector.
Cable can be disinfected by 3% of hydrogen-peroxide or 70% of isopropyl
alcohol. Do not immerse the connector into the liquid.
4.3 Alarm
There are three level alarms in oximeter:
High level: “DO-DO-DO---- DO-DO”indicates
 There are some problems with module, which can’t be used.
 The measured value exceeds the set limit, please pay attention to it.
Alarm sound: it is triggered once per 8 seconds. Alarm light: 2 times per
second, light on for half second,
light off for another half second.
Medium level: “DO-DO-DO” indicates:
 The value of the PR exceeds the alarm limit.
 Pleth waveform cannot be detected.
Alarm sound: once per five seconds. Alarm light: once per 2 seconds, light on for
one second, light off for another one second.
Low level: “DO-” indicates Probe off
Alarm sound: once per 5 seconds. Alarm light: once per 4 seconds, light on for
one second, light off for three seconds.
The setups of the audio and visual alarm can be alternated, please refer to the
Chapter 3 in details.
CHAPTER 5 MAINTENANCE and REPAIR
5.1 Maintenance
It is very important for user to make daily maintenance of oximeter and parts, which
▒▓ www.OctiveTech.com Operating Instructions
20
guarantees our company to perform the maintenance service. If user does not do
according to the below stipulations and lead to oximeter failure and possible health
damage, our company has right to change the warranty period.
a) Should make the effective maintenance plan for oximeter and reused parts.
This plan includes inspection and clearance, must comply with the policy issued
by the institution of epidemic control and Health Ministry in your country.
b) Please take out battery before cleaning the oximter.
c) Please clear the device regularly.(must comply with the policy issued by the
institution of epidemic control and Health Ministry in your country) The
appearance of oximeter can be cleared by not-denuded wet cloth.
Please use the following permitted solutions:
●Ammonia (diluted)
●Glutaraldehyde
●Javel bleacher (diluted)
●Mild soap water (diluted)
Please comply with the following regulations to avoid oximeter damage:
●Be sure to dilute the solution recommended by the manufacturer all the time.
●Wipe up all the solutions by dry cloth after clearance all the time.
●Don’t use the solution with wax.
●Don’t douse or spurt any clearance solution on oximeter or any slots of monitor.
●Don’t use the following agents:
○ Any kind of scrub solution or impregnant
○Acet
○Ketone
○Agent with alcohol
○Lycine
●If you want to clear displaying screen, please use the clean soft cloth
Don’t directly spurt agent on displaying screen, or use any alcohol and
medical disinfector to sterilize the monitor (Glutaraldehyde or lycine).
●Lead and cable can be cleaned by soft, wet cloth and soft soap water. Other
methods may shorten the lives of accessories.
d) Please note the items during operation:
●Should unmount the probe from the oximeter and care it well after operation.
●Please take the batteries out and remain it with plastic if the monitor would not
be used for long time.
●Don’t make the monitor get the agents.
If some abnormal cases happen, please stop using monitor immediately, and only
after inspection by technical person, it can be reused.
