OEM CX12 User manual

OEM AUDIO
CX SERIES OPERATIONS GUIDE
CX10 CX12 CX15
CX12M CX15M
18SUB 218SUB

Warning:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
Caution:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT
REMOVE THE COVER. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO A QUALIFIED SERVICE PROFESSIONAL
Unpacking your unit
IMPORTANT NOTE: Your OEM Audio CX Series product was originally
packaged in a specially designed carton and included special packing
materials. Please save these items. They should be used when you
return your OEM Audio CX Series product for repair. Please inspect
the shipping carton - If the packaging seems damaged please return
this item to the shipper.
WARNING!
RISK OF ELECTRIC SHOCK
The lightning flash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) in the literature
accompanying this device.
Important Safety Instructions
Read these instructions.
Keep these instructions
Heed all warnings.
Follow the instructions.
Do not use this apparatus near water.
Clean only with a dry cloth.
Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus that produce heat.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
Object and Liquid entry: Never push any foreign objects of
any kind into the openings as they may touch dangerous
voltage points that could result in fire or electric shock. The
apparatus shall not be exposed to dripping or splashing and
no objects filled with liquids such as a beverage shall be
placed on top.
When the apparatus exhibits a distinct change in
performance this indicates a need for service.
There are NO USER SERVICABLE PARTS
Refer servicing to all qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way or liquid has been spilled or objects have fallen into
the apparatus or the apparatus has been exposed to rain
or moisture, does not operate normally or has been
dropped.
Connecting: When you connect the Speaker Unit to other
equipment, turn off the power and unplug all of the equipment
from the supply source. Failure to do so may cause an electric
shock and serious personal injury. Read the User's Manual of the
other equipment carefully and follow the instructions when
making the connections.
Sound Volume: Reduce the volume to minimum before you turn
on the amplifier to prevent sudden high levels of noise which may
cause hearing or speaker damage.
SpeakON connectors: WARNING: SpeakON connectors marked
with the lightning flashes indicate high voltages that are
potentially life threatening. Wiring to these terminals requires
installation by an instructed person and the use of ready-made
leads or cords.
Custom wiring should only be carried out by qualified
personnel.
To prevent electric shock, do not operate the product with any of
the conductor portion of the speaker wire exposed.
NOTE: For reasons of safety and performance, use only high-
quality fully insulated speaker cables of stranded copper wire.
Use the largest wire size that is economically and physically
practical, and make sure the cables are no longer than
necessary.

EC Declaration of Conformity in accordance to EC Directives
The CX Series speakers covered by this manual can be used for portable P.A. applications or for fixed
installation in an indoor environment where they will not be exposed to rain, direct moisture, extended
periods of sunlight or extreme temperature changes. Moisture can cause deterioration of electrical
contacts and metal parts in addition to damaging the speaker cone and surround. Avoid getting them
wet. Also, avoid direct sunlight. The sun and heat can dry out the driver suspension prematurely
negatively impacting performance.
PRECAUTIONS
Suspension of Loudspeaker System: Before attempting to suspend your LIGWA loudspeakers, read
and understand the following safety information.
IMPORTANT SAFETY WARNING!
THE FOLLOWING INFORMATION HAS BEEN GATHERED FROM DOCUMENTED ENGINEERING DATA AND IS
INTENDED FOR INFORMATIONAL PURPOSES ONLY. NONE OF THE INFORMATION IN THIS SECTION
SHOULD BE USED WITHOUT FIRST OBTAINING EXPERT ADVICE REGARDING THE ACTUAL
CIRCUMSTANCES PERTAINING TO YOUR DESIRE TO SUSPEND THESE SPEAKERS. NONE OF THE
INFORMATION PRESENTED HERE IS INTENDED AS AN EXEMPLIFICATION OR A WARRANTY ON
THE PART OF SONEGY. ANYONE MAKING USE OF THIS INFORMATION ASSUMES ALL LIABILITY
THAT RESULTS FROM SUCH USE. ALL INFORMATION PRESENTED HERE IS BASED UPON
STANDARD PRACTICES AND PRODUCTS COMMON TO NORTH AMERICA. THE INFORMATION MAY
NOT APPLY TO OTHER COUNTRIES LOCAL REGULATIONS, SYSTEMS OF MEASUREMENT,
SPECIFICATIONS OR DIFFERENT MATERIALS. USERS IN AREAS OUTSIDE OF NORTH AMERICA SHOULD
CONSULT WITH ENGINEERS AND LOCAL REGULATORY AUTHORITIES FOR SPECIFIC GUIDELINES. USING
SUSPENSION HARDWARE CORRECTLY IS REQUIRED FOR SAFELY SECURING SYSTEMS THAT ARE HANGING.
MAKE SURE THAT ALL COMPONENTS ARE USED WITHIN THEIR WORKING LOAD LIMITS BEFORE
THE SPEAKER IS SUSPENDED. USE ONLY LOAD-RATED HARDWARE WHEN SUSPENDING SONEGY
LOUDSPEAKER MODELS.
NEVER EXCEED THE MAXIMUM RECOMMENDED LOAD RATINGS.
BEFORE SUSPENDING ANY SPEAKER SYSTEM, ALWAYS INSPECT ALL COMPONENTS (ENCLOSURE,
EYEBOLTS, ETC.) FOR DAMAGE
IF YOU NOTICE DAMAGE OR ANY ANOMALY, DO NOT SUSPEND THE SPEAKER UNTIL THE
PROPER CORRECTIVE ACTION HAS BEEN TAKEN.

SUSPENSION SAFETY INSTRUCTIONS
General use:
Speakers can be heavy. Use a hand cart or some other device to move the speakers from one location to
another.
When pole or suspension mounting, always have at least one other person to assist.
Do not stand directly in front of the speakers while in operation as this may result in hearing damage or
hearing loss.
Suspending speakers: Things you need to know
You are liable for damages to property and injuries to individuals if a loudspeaker enclosure fails.
Know the rules for safe rigging. Improper practices can lead to great bodily harm including death.
Educate yourself at a safe rigging seminar. In North America, professionals like Rigging SeminarsTM or ATS
have classes which will educate you to these important practices. A quick internet search for “safe rigging
seminars” will yield several options.
Meet and establish a relationship with a local licensed mechanical or structural engineer. Get in the habit
of asking them questions instead of guessing about their answers. Learn from what they tell you.
Make certain you have the proper insurance coverage.
Research and understand the codes, practices, and requirements in the venues where you intend to
operate your sound system.
General Hardware Information
Any hardware used in an overhead suspension application must be load rated for the intended use. Local
hardware stores do not usually stock these products. Generally, this type of hardware is available
from rigging supply houses, industrial supply catalogs and specialized rigging distributors. Hardware that
is intended for overhead suspension will comply with ASME B30.20. The correct hardware will be
identified with a working load limit (WLL) and a manufacturing code that allows it to be traced should
there be a manufacturing lot that does not meet guaranteed specifications. Remember, when consulting
with a licensed and bonded rigger be sure to ask about the hardware and demand that the hardware
meet all minimum load and regulatory requirements.
Attachment to Structures
A licensed and bonded Mechanical or Structural Engineer must approve the location and means of
attachment to the structure before you suspend anything, including speakers. They will know the
building and/or safety codes and will help you ensure a safe suspension of the loudspeaker.
Safety first! Anything suspended without safety in mind can result in serious injury or death.

Inspection & Maintenance
Annual inspections of approved suspensions in a fixed location should be done once a year. All elements need
to be checked for structural integrity and application specific deployment.
Stand mounting safety precautions
CX Series speakers can generate considerable energy and may move due to its acoustical energy output. Be
conscious of the surfaces on which you place the speaker and make sure to place stands away from the edge
of the stage or stairs.
Some CX Series models are equipped with a 35mm receptacle cup. This allows for pole mounting and
stand mounting. If you are going to use a stand or pole please think about the following advice:
Make sure that stand is rated to handle the weight of the speaker.
Place the stand on a flat surface paying special attention to balance.
Make sure that the stand’s legs are not in a traffic area and that the cables are routed in such a
way as to avoid tripping and knocking over the speaker. Gaffer’s tape, brightly colored
professional wire management devices or carpets will go a long way to ensuring the highest
degree of safety.
Make sure the stand is in good working order before you place the speaker on the stand.
Only place 1 speaker per pole or stand.
Be extremely cautious when wind is present. Place sandbags on the stand legs. Never place a
banner on the stand as it will become a sail and increase the chances of the speaker toppling
over.
Ask for help when deploying a speaker on a stand or pole.
Hearing damage, prolonged exposure to excessive SPL
CX SERIES loudspeakers can get loud enough to cause permanent hearing damage to humans within a
close proximity. Don’t prolong yourself to exposure to any sounds that exceed 90dB.
For technical specifications, block diagrams and other valuable information refer to the appropriate
cut sheet
Operation
1. Unpack the unit and inspect for any damage
2. Place the unit in its intended location i.e. on a stand, table or attached to the suspension cables*
(see above)
3. Using high quality speaker cable (unshielded) terminated in Neutrik NL4 connectors, connect the
speaker to the power amplifier by inserting the male end of the cable into the female jack on the
cabinet. Gently twist the connector until you feel it snap into place.
4. Gradually raise the system volume until the desired loudness has been achieved.
5. Enjoy the beautiful sound

CX10
10” Two Way, 375W, Passive
Coaxial Loudspeaker
Technical Specifications
Freq. Response1(±3 dB): 65 Hz -
19 kHz
Freq. Range1(-10 dB): 59 Hz - 20 kHz On-
axis Sensitivity: 94 dB (1W/1m)
Cont./Program/Peak Power2: 375W/750W/1500W
Continuous/Peak SPL: 120 dB/126 dB
Coverage Angle: 90° Horiz. x 90° Vert.
Crossover Frequency: 2.8 kHz
Nominal/Min Impedance: 8 0/6.2 0
Connections: (2) NL4
Cabinet Construction: Multi-Ply Baltic Birch
(all panels)
Cabinet Surface: Ultra Tough Polyuria
Grille: 16 Gauge Powder
Coated Steel with
Backing Screen
Handles: Powder Coated Steel
Mounting Points: (10) M10
Net Dimensions (H x W x D): 483 x 308 x 329 (mm)
19.0 x 12.1 x 12.9 (in)
Gross Dimensions (H X W X D): 600 x 432 x 408 (mm)
23.6 x 17 x 16 (in)
Net Weight: 16.0 kg (35.2 lbs.)
Shipping Weight: 19.1 kg (42.1 lbs.)
1 - Half Space Measurement
2 - AES band limited pink noise for two hours
CX10 FEATURES
High Definition Coaxial Transducer
1.75” Edge Wound Voice Coil Compression Driver
3” Edge wound Voice Coil Woofer
Hi-QTM Dynamic Crossover Network
90° x 90° Coverage
Adjustable Angle Pole Mount Socket
High Durability Polyuria Finish
Product Description
The CX10 is an extremely compact high power, high definition,
coaxial 2-way passive loudspeaker designed for both portable and
fixed installation applications. It is part of OEM’s full line of CX Series
premium loudspeakers which are designed to provide unmatched
sonic quality at very high sound pressure levels.
OEM Audio has designed the CX10 with a 10” cast frame coaxial
transducer with a 3” edge wound voice coil woofer for maximum
heat transfer and efficiency. The coaxially mounted compression
driver (1” exit) incorporates an edge wound 1.75” aluminum wire
voice coil with a high strength aluminum dome and a specially
designed Mylar surround structure.
The Hi-Q crossover network provides superior overload protection yet
preserves its sound character even when the CX10 is driven with
highly dynamic program material. This results in remarkable clarity
and consistency of the CX10 even when driven at very high levels.
Two NL4 connectors are provided for input and loop output which are
mounted into the enclosure’s recessed rear plate.
The CX10 comes with a pole socket integrated into the bottom of the
cabinet. To accommodate a variety of mounting applications, the CX10
is equipped with ten threaded M10 mounting points.
The enclosure is made of void-free Baltic birch plywood with
optimized bracing to minimize resonances and improve damping.
Cabinet surfaces are finished in a highly durable two-part polyuria
coating. The CX10 enclosure provides the strength and durability
needed for a high degree of safety and reliability whether it is used
in portable or fixed installation applications.
A cutaway handle is conveniently located in the rear of the cabinet for
easy lifting and moving of the CX10.
The CX10 addresses a wide range of applications from live sound
to commercial installations due to its compact size and flexible
mounting hardware. It can be pole mounted on OEM’s 18SUB
subwoofer for full range performance. The CX10 is sonically
matched with the other CX loudspeaker models for perfect
integration into complete sound systems.

CX12
12” Two Way, 600W, Passive Coaxial
Loudspeaker
Technical Specifications
Freq. Response1(±3 dB): 65 Hz - 19 kHz
Freq. Range1(-10 dB): 59 Hz - 20 kHz
On-axis Sensitivity: 95 dB (1W/1m)
Cont./Program/Peak Power2:
600W/1200W/2400W Continuous/Peak SPL:
121 dB/127 dB Coverage Angle: 90° Horiz. x
90° Vert. Crossover Frequency: 1.8 kHz
Nominal/Min Impedance: 8 0/6.8 0
Connections: (2) NL4
Cabinet Construction: Multi-ply Baltic birch
Cabinet Surface: Ultra-Tough Polyuria
Grille: 16 Gauge Powder Coated
Steel with Backing Screen
Handles: Powder Coated Steel
Mounting Points: (12) M10
Net Dimensions (H x W x D): 420 x 420 x 430 (mm)
16.5 x 16.5 x 16.9 (in)
Gross Dimensions (H x W x D): 560 x 534 x 525 (mm)
22 x 21 x 20.7 (in)
Net Weight: 26.3 kg (58 lbs.)
Gross Weight: 30 kg (66 lbs.)
1 - Half Space Measurement
2 - AES band limited pink noise for two hours
CX12 FEATURES
High Power Edge Wound 4” Voice Coil Woofer
3” Edge Wound Voice Coil Compression Driver
Hi-QTM Dynamic Crossover Network
90° x 90° Coverage
Pole Mount Socket
High Durability Polyuria Finish
Product Description
The CX12 is a high power, high definition, coaxial, compact 2-way
passive loudspeaker designed for both portable and fixed install
applications. It is part of OEM’s full line of CX Series premium
loudspeakers which are designed to provide unmatched sonic quality
at very high sound pressure levels.
OEM Audio has designed the CX12 with a compliment of premium
quality transducers including a 12” cast frame woofer with a 4” edge
wound voice coil for maximum heat transfer and efficiency. The 3”
compression driver (2” exit) incorporates an edge wound aluminum
wire voice coil with a high strength aluminum dome and a specially
designed Mylar surround structure.
The Hi-Q crossover network provides superior overload protection yet
preserves its sound character even when the CX12 is driven with
highly dynamic program material. This results in remarkable clarity
and consistency of the CX12 even when driven at very high levels.
Two NL4 connectors are provided for input and loop output which are
mounted into the enclosure’s recessed rear plate.
For pole mounting, a pole socket is integrated into the bottom of the
cabinet. To accommodate a variety of mounting applications, the CX12
is equipped with twelve threaded M10 mounting points.
The enclosure is made of void-free multi-ply Baltic birch with
optimized bracing to minimize resonances and improve damping.
Cabinet surfaces are finished in a highly durable two-part polyuria
coating. The CX12 enclosure provides the strength and durability
needed for a high degree of safety and reliability whether it is used
in portable or fixed installation applications.
Heavy duty, powder-coated steel handles are integrated into the sides
of the enclosure at its center of gravity to lower the effort of
transporting and mounting the CX12s.
The CX12 addresses a wide range of applications from live sound to
commercial installations due to its compact size and flexible
mounting hardware. It can be pole mounted or stacked with OEM’s
18SUB subwoofer for full range performance. The CX12 is sonically
matched with the other CX loudspeaker models for perfect
integration into complete sound systems.

CX15 FEATURES
High Power Edge Wound 4” Voice Coil Woofer
3” Edge Wound Voice Coil Compression Driver
Hi-QTM Dynamic Crossover Network
90° x 40° Coverage

Pole Mount Socket/Suspension Points

High Durability Polyuria Finish
Product Description
The CX15 is a high power, high definition, 2
-
way passive loudspeaker
designed for both portable and fixed installation a
pplications. It is part
of OEM
’s full line of CX Series premium loudspeakers which are
designed to provide unmatched sonic quality at very high sound
pressure levels.
OEM Audio
has designed the CX15 with a compliment of premium
qual
ity transducers including a 15” cast frame woofer with a 4” edge
wound voice coil for maximum heat transfer and efficiency. The 3”
compression driver (2” exit) incorporates an edge wound aluminum
wire voice coil with a high strength aluminum dome and a spe
cially
designed Mylar surround structure.
The Hi
-Q
crossover network provides superior overload protection yet
preserves its sound character even when the CX15 is driven with
highly dynamic program material. This results in remarkable clarity
and consistency of the CX15 even when driven at very high levels.
Two NL4 connectors are provided for input and loop output which
are mounted into the enclosure’s recessed rear plate.
For pole mounting, a pole mount socket is integrated into the bottom
of
the cabinet. To accommodate a variety of mounting applications,
the CX15 is equipped with twelve threaded M10 mounting points.
The enclosure is made of void
-
free, multi
-
ply Baltic birch with
optimized bracing to minimize resonances and improve damping.
Cabinet surfaces are finished in a highly durable two-part
polyuria
coating. The CX15 enclosure provides the strength and durability
needed for a high degree of safety and reliability whether it is used in
portable or fixed installation applications.
Heavy duty, powder
-
coated steel handles are integrated into the sides
of the enclosure at its center of gravity to lower the effort of
transporting and mounting the CX15s.
The CX15 addresses a wide range of applications from live sound to
commercial
installations due to its compact size and flexible
mounting hardware. It can be pole mounted or stacked with OEM
’s
18SUB subwoofer for full range performance. The CX15 is sonically
matched with the other CX loudspeakers for perfect integration into
complete sound systems.
CX15
15” Two Way, 600W, Passive
Loudspeaker
Technical Specifications
Freq. Response
1
(±3 dB): 73 Hz
-
19 kHz
Freq. Range
1
(
-
10 dB): 49 Hz
-
20 kHz
On
-
axis Sensitivity: 96 dB (1W/1m)
Cont./Program/Peak Power2: 600W/1200W/2400W
Continuous/Peak SPL: 124 dB/130 dB
Coverage Angle: 90° Horiz. x 40° Vert.
Crossover Frequency: 1.7 kHz
Nominal/Min Impedance: 8 0/6.5 0
Connections: (2) NL4
Cabinet Construction: Multi
-
ply Baltic Birch
Baltic Birch
Cabinet Surface:
Ultra
-
Tough Polyuria
Grille: 16 Gauge Powder
Coated Steel with
Backing Screen
Handles: Powder Coated Steel
Mounting Points: (12) M10
Net Dimensions (H x W x D): 740 x 457 x 470 (mm)
29.1 x 18 x 18.5 (in)
Gross Dimensions (H x W x D): 876
x 566 x 566 (mm)
34.5 x 22.3 x 22.3 (in)
Net Weight: 37.3 kg (82.2 lbs.)
Gross Weight: 42.2 kg (93 lbs.)
1
-
Half Space Measurement
2
-
AES band limited pink noise for two hours

CX12M FEATURES
High Definition Coaxial Transducer
3” Edge Wound Voice Coil Compression Driver
4” Edge wound Voice Coil Woofer
Hi-QTM Dynamic Crossover Network
90° x 90° Coverage
High Durability Polyuria Finish
Product Description
The CX12M is a compact high output, high definition, coaxial
2
-
way
passive loudspeaker designed for floor monitor a
pplications. It is part
of OEM
’s full line of CX Series premium loudspeakers which are
designed to provide unmatched sonic quality at very high sound
pressure levels.
OEM Audio has designed the CX12M
with a 12” cast frame coaxial
transducer with a 4” edge wound voice coil woofer for maximum heat
transfer and efficiency. The coaxially mounted compression driver
incorporates an edge wound 3” aluminum wire voice coil with a high
strength aluminum dome an
d a specially designed Mylar surround
structure.
The Hi
-Q
crossover network provides superior overload protection yet
preserves its sound character even when the CX12M is driven with
highly dynamic program material. This results in remarkable clarity
and consistency of the CX12M even when driven at very high levels.
Two NL4 connectors are provided for input and loop output which
are mounted into the enclosure’s recessed rear plate.
The specially designed shape of the CX12M provides the optimum
angle for use as a professional stage monitor. Because of its
symmetrical coverage angle as a coaxial, it can also be used a side fill
or other full range uses when setup on its side panel.
The enclosure is made of multi
-
ply, void free Baltic birch with
optimized bracing to minimize resonances and improve damping.
Cabinet surfaces are finished in a highly durable two-part
polyuria
coating. The CX12M enclosure provides the strength and durability
needed for a high degree of safety and reliability whether
it is used in
portable or fixed installation applications.
A cutaway handle is located in the front of the cabinet for easy
lifting and moving of the CX12M.
The CX12M addresses a wide range of live sound applications from
portable to commercial ve
nues due to its compact size and multiple
use positions. The CX12M is sonically matched with the other CX
loudspeaker models for perfect integration into complete sound
systems.
CX12M
12” Two Way, 600W, Passive Coaxial
Floor Monitor Loudspeaker
Technical Specifications
Freq. Response
1
(±3 dB): 70 Hz
-
19 kHz
Freq. Range
1
(
-
10 dB): 68 Hz
-
20 kHz
On
-
axis Sensitivity: 95 dB (1W/1m)
Cont./Program/Peak Power
2
: 600W/1200W/2400W
Continuous/Peak SPL: 122 dB/128 dB
Coverage Angle: 90°
Horiz. x 90° Vert.
Crossover Frequency: 2.1 kHz
Nominal/Min Impedance: 8 0/7.1 0
Connections: (2) NL4
Cabinet Construction: Void
-
free Baltic
Birch (all panels)
Cabinet Surface: Ultra
-
Tough Polyuria
Grille: 16 Gauge Powder
Coated
Steel with
Handles: Cut away handle
Net Dimensions (H x W x D): 483 x 365 x 415 (mm)
19.0 x 14.4 x 16.3 (in)
Gross Dimensions (H x W x D): 653 x 462 x 435 (mm)
25.7 x 18.1 x 17.1 (in)
Net Weight: 24.2 kg (53.4 lbs.)
Gross Weight: 27.7
kg (61 lbs.)
1
-
Half Space Measurement
2
-
AES band limited pink noise for two hours

CX15M FEATURES
High Definition Coaxial Transducer
3” Edge Wound Voice Coil Compression Driver
4” Edge wound Voice Coil Woofer
Hi-QTM Dynamic Crossover Network
90° x 90° Coverage
High Durability Polyuria Finish
Product Description
The CX12M is a compact, very high output, high definition, coaxial 2
-
way passive loudspeaker designed for floor monitor a
pplications. It is
part of OEM
’s full line of CX Series premium loudspeakers which are
designed to provide unmatched sonic quality at very high sound
pressure levels.
OEM Audio
has designed the CX15M with a 15” cast frame coaxial
transducer with a 4” edge wound voice coil
woofer for maximum heat
transfer and efficiency. The coaxially mounted compression driver
incorporates an edge wound 3” aluminum wire voice coil with a high
strength aluminum dome and a specially designed Mylar surround
structure.
The Hi
-Q crossover ne
twork provides superior overload protection yet
preserves its sound character even when the CX15M is driven with
highly dynamic program material. This results in remarkable clarity
and consistency of the CX15M even when driven at very high levels.
Two N
L4 connectors are provided for input and loop output which
are mounted into the enclosure’s recessed rear plate.
The specially designed shape of the CX15M provides the optimum
angle for use as a professional stage monitor. Because of its
symmetrical
coverage angle as a coaxial, it can also be used a side fill
or other full range uses when setup on its side panel.
The enclosure is made of void
-
free, multi
-
ply Baltic birch (18 mm
side, top and bottom panels) with optimized bracing to minimize
resonan
ces and improve damping. Cabinet surfaces are finished in a
highly durable two-part
polyuria coating. The CX15M enclosure
provides the strength and durability needed for a high degree of
safety and reliability whether it is used in portable or fixed
installation applications.
A cutaway handle is located in the front of the cabinet for easy
lifting and moving of the CX15M.
The CX15M addresses a wide range of live sound applications from
portable to commercial venues due to its compact size and
multiple
use positions. The CX15M is sonically matched with the other CX
loudspeaker models for perfect integration into complete sound
systems.
CX15M
15” Two Way, 600W, Passive Coaxial
Floor Monitor Loudspeaker
Technical Specifications
Freq.
Response
1
(±3 dB): 90 Hz
-
15 kHz
Freq. Range
1
(
-
10 dB): 77 Hz
-
18 kHz
On
-
axis Sensitivity: 98 dB (1W/1m)
Cont./Program/Peak Power
2
: 600W/1200W/2400W
Continuous/Peak SPL: 126 dB/132 dB
Coverage Angle: 90° Horiz. x 90° Vert.
Crossover
Frequency: 1.8 kHz
Nominal/Min Impedance: 8 0/6.8 0
Connections: (2) NL4
Cabinet Construction: Multi
-
ply Baltic Birch (all
panels)
Cabinet Surface: Ultra
-
Tough Polyuria
Grille: 16 Gauge Powder Coated
Steel with Backing Screen
Handles: Powder Coated Steel
Net Dimensions (H x W x D): 550 x 445 x 460 (mm)
21.7 x 17.5 x 18.1 (in)
Gross Dimensions (H x W x D): 763 X 540 X 489 (mm)
30 x 21.25 x 19.25 (in)
Net Weight: 28.3 kg (62.4 lbs.)
Gross Weight: 32.5 kg (71.6 lbs.)
1
-
Half Space
Measurement
2
-
AES band limited pink noise for two hours

18SUB FEATURES
High Output/Low Distortion Woofer with a 4”
Voice Coil and Kevlar Reinforced Cone
750W AES
Ultra Rugged Premium Birch Plywood Cabinet
High Durability Polyuria Finish
Product Description
The 18SUB is a high output, high definition, passive subwoofer
designed for both portable and fixed installation applications requiring
very high output at the lowest frequencies while maintaining low
distortion. It is part of OEM
’s full line of CX Series premium
loudspeakers which are designed to provide unmatched sonic quality
at very high sound pressure levels.
OEM Audio
has designed the 18SUB with a high quality 18” long
excursion cast frame woofer with a 4” edge wound high
temperature resistant voice coil. This enables the 18SUB to produce
sustained high levels of low frequency output while efficiently
dissipating heat
to improve long term reliability and reduce power
compression. Additionally, the 18SUB woofer has a specially
designed Kevlar reinforced cone which provides consistent sonic
performance when driven at even the highest levels.
Two NL4 connectors are prov
ided for input and loop output which
are mounted into the enclosure’s recessed rear plate.
The 18SUB has an integrated threaded M20 pole plate for solid and
easy installation of top cabinets in full range applications. The
cabinet design of the 18SUB
allow for quick and easy transportation
and setup.
The enclosure is made of Void
-
free, multi
-
ply Baltic birch plywood
with optimized bracing to minimize resonances and improve
damping. The 18SUB enclosure provides the strength and
durability needed for
a high degree of reliability whether it is used
in portable or fixed installation applications.
Heavy duty, powder
-
coated steel handles are integrated into the sides
of the enclosure at its center of gravity to lower the effort of
transporting and setting up the 18SUB.
The 18SUB addresses a wide range of subwoofer applications from
live sound to commercial installations due to its high reliability and
excellent sonic characteristics. It can be used with any of the CX full
range loudspeaker models to
create a variety of complete and
sonically matched sound systems.
18SUB
18” 750W Passive Subwoofer
Technical Specifications
Freq. Response
1
(±3 dB): 40 Hz
-
250 Hz
Freq. Range
1
(
-
10 dB): 35 Hz
-
250 Hz
On
-
axis Sensitivity: 96 dB (1W/1m)
Cont./Program/Peak Power
2
: 750W/1500W/3000W
Continuous/Peak SPL: 125 dB/131 dB
Nominal/Min Impedance: 4 0/3.2 0
Connections: (2) NL4
Cabinet Construction: Baltic Birch Ply (all
sides)
Cabinet Surface: Ultra
-
Tough Polyuria
Grille: 16 Gauge Powder
Coated Steel
with
Backing Screen
Handles: Powder Coated Steel
Pole Mount: Steel: Threaded M20
Net Dimensions (H x W x D): 808 x 565 x 502 (mm)
31.8 x 22.3 x 19.8 (in)
Gross Dimensions (H x W x D): 923 x 609 x 672 (mm)
36.3 x 24 x 26.5 (in)
Net
Weight: 42.5 kg (93 lbs.)
Gross Weight: 47.9 kg (105.6 lbs.)
1
-
Half Space Measurement
2
-
AES band limited pink noise for two hours

218SUB FEATURES
Dual High Output/Low Distortion Woofer with 4”
Voice Coils and Kevlar Reinforced Cones
1500W AES
Ultra Rugged Premium Birch Plywood Cabinet
High Durability Polyuria Finish
Product Description
The 218SUB is a very high output, high definition, passive subwoofer
designed for both portable and fixed installation applications requiring
very high output at the lowest frequencies while maintaining low
distortion. It is part of OEM’s full line of CX Series premium
loudspeakers which are designed to provide unmatched sonic quality
at very high sound pressure levels.
OEM Audio has designed the 218SUB with a two high quality 18” long
excursion cast frame woofers with 4” edge wound high temperature
resistant voice coils. This enables the 218SUB to produce sustained
high levels of low frequency output while efficiently dissipating heat to
improve long term reliability and reduce power compression.
Additionally, the 218SUB woofers have specially designed Kevlar
reinforced cone which provides consistent sonic performance when
driven at even the highest levels.
Two NL4 connectors are provided for input and loop output which are
mounted into the enclosure’s recessed rear plate.
The cabinet design of the 218SUB allow for quick and easy
transportation and setup. Four sets of 1/4-20 threaded inserts are
located on the rear of the cabinet in each of its four corners for
mounting casters or other transportation hardware.
Four heavy duty, powder-coated steel handles are integrated into the
sides of the enclosure at its center of gravity to lower the effort of
transporting and setting up the 218SUB.
The enclosure is made of void-free, multi-ply Baltic birch plywood with
optimized bracing to minimize resonances and improve damping. The
218SUB enclosure provides the strength and durability needed for a
high degree of reliability whether it is used in portable or fixed
installation applications.
The 218SUB addresses a wide range of subwoofer applications from
live sound to commercial installations due to its very high output, high
reliability and excellent sonic characteristics. It can be used with any
of the CX full range loudspeaker models to create a variety of
complete and sonically matched sound systems.
218SUB
Dual 18” 1500W Passive Subwoofer ,
Technical Specifications
Freq. Response1(±3 dB): 35 Hz - 250 Hz
Freq. Range1(-10 dB): 24 Hz - 250 Hz
On-axis Sensitivity: 99 dB (1W/1m)
Cont./Program/Peak Power2: 1500W/3000W/6000W
Continuous/Peak SPL: 131 dB/137 dB
Nominal/Min Impedance: 4 0/3.3 0
Connections: (2) NL4
Cabinet Construction: Multi-ply Baltic Birch (all
sides)
Cabinet Surface: Ultra Tough Polyuria
Grille: 16 Gauge Powder Coated
Steel with Backing Screen
Handles: Powder Coated Steel
(Two Per Side)
Transportation Mounts: (4) sets of 4 1/40-20
threaded inserts on rear
Net Dimensions (H x W x D): 559 x 1245 x 660 (mm)
22.0 x 49.0 x 26.0 (in)
Gross Dimensions (H x W x D): 678 x 1363 x 776 (mm)
26.7 x 53.7 x 30.6 (in)
Net Weight: 76.4 kg (168 lbs.)
Gross Weight: 86.9 kg (1187.2 lbs.)
1 - Half Space Measurement
2 - AES band limited pink noise for two hours

OEM AUDIO
www.oemaudio.uk
