OEM RB-12 User manual

The Registered Bass 12" In-Floor Subwoofer was designed
to mount in standard construction frame floors. With proper
preparation it may also be mounted in ceilings. The
revolutionary and space saving design installs from above
the floor (or below the ceiling). In other words, installation
easily takes place from within the living space, not under the
floor.
A standard sized 6" x 14" HVAC register vent is used to
trim/dress the opening. No register is included with the unit.
The customer chooses a standard 6" x 14" sized register
vent (diffuser) to match the other registers in the house used
for the HVAC system.
RB-12 In-Floor Subwoofer
SE-80SWD
Dimensions:
Cut-out: 8 3/4" x 8 3/4" x 4" Deep
Overall: 10" x 10"
C-8SW
Dimensions:
Cut-out: 9" W x 13" H x 3 13/16" Deep
Overall: 10 1/2" W x 14 1/2" H
C-8SW & SE-80SWD In-Wall Subwoofers
Specifications:
 12" poly woofer with 2" voice coil, butyl surround, protected by stainless steel screen,
mounted to enclosure with stainless steel machine screws into stainless T-nuts
 Power Handling: 100 Watts nom. 150 Watts max.
 Frequency Response: 25 - 100 Hz
 Sensitivity: 90 dB @ 1 W/m
 Impedance: 8 Ohms nominal
 Net Weight: 18 lbs.
 Cut-out opening size: 14 1/4" x 6 1/8" x 16 1/2" Deep
 Top mounting flange inside dimensions: 14 3/16" x 6" x 1 5/16" Deep (Diffuser Opening)
 Top mounting flange outside dimensions: 15 1/4" x 7 1/16"
 8" Dual Voice Coil Carbon Fiber Subwoofers with on board cross-overs & switching for high pass output
 Frequency Response: 30 Hz - 120 Hz
 Power Handling: 50 Watts nom. 100 Watts max.
 Impedance: 8 Ohms
OEM Systems Company, Inc.
740 Freeport Blvd., #106
Sparks, Nevada 89431-6168
775 355-0405 Fax [phone]
www.oemsystems.com
[email protected]
Available in Single & Dual Voice Coil versions - RB-12SW & RB-12SWD
