OEM 24FE+2GE+2G SFP User manual

User Guide
24FE(PoE)+2GE+2G SFP
24FE +2GE+2G SFP PoE Switch
PoE Port 1-4: Max 60W,PoE Port5-16/20: Max 32W

- 2 -
Package Contents
Check the following contents of your package:
 PoE Switch x 1
 User’s Manual x 1
 Power Cord x 1
 Accessories(hanging ears*2, Rubber Feet*4, screw*8)
If any part is lost and damaged, please contact your local agent immediately.
1. Introduction
24FE+2GE+2G SFP PoE switch is 16/ 24-port 10/100Mbps PoE switch with 2-port 10/100/1000Mbps and 2
Gigabit SFP Slots. The PoE ports can automatically detect and supply power to IEEE802.3af/at compliant
Powered Devices (PD). Among them port1-4 supports IEEE802.3bt，The electrical power and data
transmission on the same cable can expand your network to the places where no power lines or outlets,
where you can install devices such as APs, IP cameras, or IP phones etc
The LCD not only can display the PoE work status, accurate judgment port of load, can also help customer
and engineer timely discover and solve the network failure,improve work efficiency and quality.
Port Feature
Model
10/100Mbps
RJ45 Port
Gigabit RJ45
Port
Gigabit SFP
Port
LCD
Display PSE Port
24FE+2GE+2G SFP Port1~24 Port25~26 Port27~28
Support
Port1~20
2. Hardware Description
2.1 Front Panel
The Front Panel of the PoE Ethernet Switch Consists of Ethernet Ports. The LCD Display and LED indicators
are also located on the panel

- 3 -
LED indicator
LED Color Function
PWR Green Off: No Power supply.
Light: Indicates the switch has power.
LNK/ACT
Green
Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully
established at 10/100Mbps.
Blink: Indicates that the Switch is actively sending or
receiving data over that port.
PoE Orange
Off: No PoE powered device (PD) connected.
Light: There is a PoE PD connected to be port, which
supply power successfully.
Blink: Indicates port abnormal power supply.
Speed
Green Off: No connection or 10Mbps
Light: Indicates the link through established at 1000Mbps.
Orange Off: No connection or 10Mbps
Light: Indicates the link through established at 100Mbps.
Rear Panel

- 4 -
The rear panel of the PoE Switch indicates an AC inlet power socket, which accepts input power from
100 to 240V AC, 50/60HZ.
LCD Features
The PoE Switch with the fun on of the LCD display and PoE. The LCD can display the working
cond n of PoE port not only, s ll can accurately show the state of each port, such as: Output power,
Overload, Short circuit, Light load, Low voltage, Over voltage,High temperature, and so on...
Not only such visible on the basis of three generations in the second generation increases the color logo,
according to the menu button, switch mode, bandwidth display and warning, PD type, PSE power fine-tuning and
priority, PoE port switch control, LCD switch. Enhance the LCD viewing angles, smart fan control, language selection and
the function of the factory Settings, in turn, as shown in the figure below: See the operation instructions of the screen
concretely.

- 5 -
3. Installation the Switch
This part describes how to install your Ethernet Switch and make connec ons to it. Please follow the
following instru ns in avoid of incorrect installa on causing device damage and security threat.
Before cleaning the switch, unplug the power plug of the switch first. Do not clean the switch with wet
cloth or liquid;
Do not place the switch near water or any damp area. Prevent water or moisture from entering the
switch chassis;
Do not place the switch on an unstable case or desk. The switch might be damaged severely in case of a
fall;
Ensure proper ven la on of the equipment room and keep the ven vents of the switch free of
obstruc on;
Make sure that the opera ng voltage is the same one labeled on the switch;
Do not open the chassis while the switch is opera ng or when electrical hazards are present to avoid
electrical shocks.
3.1Desktop Installation
Install the Switch on a desktop, please attach these cushioning rubber feet provided on the bottom at
each corner of the Switch in case of the external vibration. Allow adequate space for ventilation
between the device and the objects around it.

- 6 -
3.2.RackmountableInstallation
The switch is rack-mountable and can be installed on an EIA-19 inch equipment rack. To do this, first,
please install the mounting brackets on the switch’s side panels (one on each side), secure them with
the included screws, and then use the screws provided with the equipment rack to mount the switch on
the 19 inch rack.

- 7 -
3.3 Turn on the switch
Please plug the power supply into the switch, the internal power system of the switch can Auto-regulate the
working power according to the actual input power. When the switch is power on, the power indicator will be
light on the front panel of the switch shines.

- 8 -
Note: Please confirm the voltage is correct before power on, otherwise the switch will be damaged.
(There is a power supply socket on the back panel of the PoE Ethernet switch. The power input is:
100V-240Vac, 50/60Hz.)
Specifications
Model 24FE+2GE+2G SFP
Standard IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3az, IEEE802.3x,
IEEE802.3af, IEEE802.3at, IEEE802.3bt
Network -
Media(Cable)
10BASE-T: UTP category 3,4,5 cable (≤100m)
100BASE-TX: UTP category 5 cable (≤100m)
1000BASE-T: UTP category 5e cable (≤100m)
1000BASE-X: MMF or SMF SFP module(Optional)
LCD Display Support
MAC Address Table 8K, Auto-learning, Auto-aging
Transfer mode Store-and-Forward
Frame Forward Rate 10Base-T: 14881pps/Port
100Base-TX: 148810pps/Port
1000Base-T/X: 1488095pps/Port
Switching Capacity 12.8G
Dimensions (L*W*H) 440*232*45 mm
Fan Fan
Power Input AC: 100~240V, 50/60Hz
Power output 55V/5.6A, 55V/7.2A(Optional)
PoE Port Port1~20
PoE Power on RJ45
4 Pair
Data Pairs
1/2(-),3/6(+)
Spare Pairs 4/5(+),7/8(-)
PoE Power Output Voltage: 55V DC Power: PoE Port 1-4: Max 60W,PoE Port5-16/20: Max 32W
PoE Power Budget 300W/380W(According to the power)
Power supply 330W/420W
Temperature Operating Temperature: -10°C ~ 60 °C (32 °F ~104°F )
Storage Temperature: -40 °C ~ 70 °C (-40 °F ~158°F )
Humidity Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
