Office Line Hoganas Plus User manual

Höganäs Plus
www.officeline.se
Sit upright
Sit in a balanced position
Recline backwards
Stretch out your body
Höganäs Plus
Allow yourself a couple of minutes
to work with your chair’s settings in
order to achieve carefully selected
positions for the seat, back and
armrests. Adjust the firmness of
the recline setting and leave the
seat loose. Then, without having to
move a lever, you can:

7.
1. Backrest height adjustment
The backrest can be raised or lowered when this button is
pressed. The backrest should be set so that the protruding
section provides complete support for your lower back.
2. Backrest angle setting
If you pull the lever upwards and apply pressure to the
backpad, its angle will change.
3. Adjust the firmness of the recline setting
Turn the rubber knob to the left or to the right to set the
recline mechanism to fit your body weight.
4. Seat height adjustment
Move the lever that controls the seat height upwards to
raise the seat position or press with the help of your body
weight to lower it.
5. Recline mechanism lock
Press the lever in order to lock the recline mechanism in
an upright sitting position.
6. Seat angle lock
Pull the lever forwards in order to release the lock. If you
pull the lever backwards, you can lock the seat angle in any
desired position.
7. Lumbar support (optional extra)
If you need more support in the lumbar region, more air
can be pumped into the backrest using the pump. Air is
let out by pressing the button next to the pump. The air
cushion has two air chambers in order to ensure that the
pressure is equally distributed.
8. Seat depth adjustment
There is a lever at the front edge of the seat that regulates
the seat depth. Loosen the seat by pushing the lever up
towards the seat, move the seat forwards/backwards to
achieve the desired depth, then release the lever, which locks
in a number of fixed positions.
9. Armrest 40 adjustment
The armrests can have their height, width, depth and angle
adjusted.
Height: Press the button on the side
Width: Loosen the snap fitting on the bottom of the arm-
rest attachment. Or move the armrest pad sideways.
Depth: Move the armrest pad forwards or backwards.
Angle: There is a small locking lever located on the bottom
of the armrest pad. The armrest pad can be twisted
when this lever is pointing downwards.
10. Neck rest setting (optional extra)
The height and depth of the neck rest can be adjusted.
Adjust the neck rest to the desired height by pulling it up or
down. Adjust its depth by rolling it forwards/backwards.
1.
3.
2. 4.
6.
9.
5.
8.
7. 7. 7.
