OHAUS 5000 User manual

Guardian 5000 Series
Hotplate-Stirrer, e-G51HSRDM
Hotplate-Stirrer, e-G51HS07C
Hotplate, e-G51HP07C
Stirrer, e-G51ST07C
Hotplate-Stirrer, e-G51HS10C
Instruction Manual
EN
ES
FR
DE
IT
PT
SE
NL
DA
FI
NO
PL
CZ
HU
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

Guardian 5000 Series EN-1
Table of Contents
1INTRODUCTION...................................................................................................................................................2
1.1. Safety Information......................................................................................................................................2
1.2. Intended Use .............................................................................................................................................2
1.3. Package Contents .....................................................................................................................................3
1.4. Installation..................................................................................................................................................3
1.5. Overview....................................................................................................................................................4
1.5.1 Dimensions ............................................................................................................................................4
1.5.2 Device Setup..........................................................................................................................................9
1.5.3 Display (Hotplate-Stirrers)....................................................................................................................13
1.5.4 Display (Hotplate) ................................................................................................................................14
1.5.5 Display (Stirrer)..................................................................................................................................155
2OPERATION.....................................................................................................................................................166
2.1 Getting Ready........................................................................................................................................166
2.2 Standby Mode........................................................................................................................................166
2.3 Controlling the Stirrer.............................................................................................................................177
2.4 Controlling the Top Plate Heater ...........................................................................................................188
2.5 Using the External Probe.........................................................................................................................20
2.6 The Settings Menu...................................................................................................................................21
2.6.1 Accessing / Exiting.............................................................................................................................221
2.6.2 Features.............................................................................................................................................221
2.6.3 Structure & Defaults.............................................................................................................................22
2.7 Using the Single Point Calibration Feature..............................................................................................23
2.8 Enabling / Disabling the Beeper ..............................................................................................................27
2.9 Changing the Power Recovery Setting....................................................................................................28
2.10 Reset to Factory Default Settings............................................................................................................29
3MAINTENANCE................................................................................................................................................331
3.1 Troubleshooting.....................................................................................................................................331
3.2 Service Information..................................................................................................................................32
4TECHNICAL DATA .............................................................................................................................................32
5COMPLIANCE.....................................................................................................................................................33
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

EN-2 Guardian 5000 Series
1. INTRODUCTION
This manual contains installation, operation and maintenance instructions for the Ohaus Guardian 5000 Series.
Please read the manual completely before using.
1.1. Safety Information
Safety notes are marked with signal words and warning symbols. These show safety issues and warnings. Ignoring
the safety notes may lead to personal injury, damage to the instrument, malfunctions and false results.
WARNING
For a hazardous situation with medium risk, possibly resulting in severe injuries or death if not
avoided.
CAUTION
For a hazardous situation with low risk, resulting in damage to the device or the property or in loss
of data, or minor or medium injuries if n
ot avoided.
ATTENTION
For important information about the product. May lead to equipment damage if not avoided.
NOTE
For useful information about the product.
Warning Symbols
General
hazard
Caution, hot
surface
Electrical shock
hazard
Safety Precautions
WARNING! DO NOT use the Hotplate-Stirrer / Hotplate / Stirrer in explosive atmospheres or with
materials that could cause a hazardous environment from processing. Keep in mind the material flash
point relative to the target temperature that has been set. Also, the user should be aware that the
protection provided by the equipment may be impaired if used with accessories not provided by the
manufacturer.
Always operate unit on a level surface for best performance and maximum safety.
DO NOT lift unit by the top plate.
CAUTION! To avoid electrical shock, completely cut off power to the unit by disconnecting the power
cord from the wall outlet. Disconnect unit from the power supply prior to maintenance and servicing.
Spills should be removed promptly after the unit has cooled down. DO NOT immerse the unit for
cleaning. Alkalis spills, hydrofluoric acid or phosphoric acid spills may damage the unit and lead to
thermal failure.
CAUTION! The top plate can reach 500°C; DO NOT touch the heated surface. Use caution at all times.
Keep the unit away from explosive vapors and clear of papers, drapery, and other flammable materials.
Keep the power cord away from the heater plate.
CAUTION! The rear panel of the 10x10-120V unit runs hot to the touch. Avoid contact during operation.
Allow unit to cool before touching the rear panel.
DO NOT operate the unit at high temperatures without a vessel/sample on the top plate.
DO NOT operate the unit if it shows sign of electrical or mechanical damage.
WARNING! Units are NOT explosion proof. Use caution when heating volatile materials.
Earth Ground –Protective Conductor Terminal. Protective earthing of the equipment is achieved via
connection of the provided power cord to a compatible grounded power outlet.
Alternating Current
1.2. Intended Use
The Ohaus Hotplate-Stirrer / Hotplate / Stirrer are intended for general laboratory use. Safety cannot be
guaranteed if used outside of the intended use.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

Guardian 5000 Series EN-3
1.3. Package Contents
•Hotplate-Stirrer / Hotplate / Stirrer Unit
•Power Cord (pre-attached for 10x10-120V units)
•Stir Bar (40 x 8 mm)
1.4. Installation
Upon receiving the Ohaus Hotplate-Stirrer / Hotplate / Stirrer check to ensure that no damage has occurred during
shipment. It is important that any damage that occurred in transport is detected at the time of unpacking. If you do
find such damage, the carrier must be notified immediately.
After unpacking, place the Hotplate-Stirrer / Hotplate / Stirrer on a level bench or table, away from explosive
vapors. Ensure that the surface on which the unit is placed will withstand typical heat produced by the unit and
place the unit a minimum of six (6) inches from vertical surfaces. Do not position the equipment such that it is
difficult to disconnect the power cord during use. Always place the unit on a sturdy work surface.
The Hotplate-Stirrer / Hotplate / Stirrer is supplied with a 3 conductor, grounded power cord that should be plugged
into a matching standard grounded outlet. If the cord supplied does not meet your needs, please use an approved
power cord that has ratings equal or exceeding those of the originally provided cord and that complies with the
local/national regulations of the country in which the equipment is to be used. Replacement of the plug must be
made by a qualified electrician.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

EN-4 Guardian 5000 Series
1.5. Overview
1.5.1 Dimensions
Round Top Hotplate-Stirrer
Note: + 2” diameter center of top plate
++ 800 mL of water in 1 L flask, 38 mm stir bar, 150 rpm and 50°C, 23°C ambient, 8” (20 cm) SS probe
Overall dimensions (L x W x H)
26.7 x 17.3 x 12.7 cm
(10.5 x 6.8 x 5”)
Top plate dimensions:
Ø 13.5 cm (5.3”)
Top plate material:
Aluminum
Electrical (50/60 Hz):
120 volts ±10%: 8.3 amps
230 volts ±10%: 4.6 amps
Fuses:
10A time-delay, 5x20mm, 250VAC
Temperature range:
Ambient +5° to 380°C
Temperature stability of top plate+:
± 3% > 100°C, ± 2% ≤100°C
Temperature stability with temperature probe++:
± 1% > 100°C, ± 1°C ≤100°C
Stir capacity:
20 L
Speed range:
60 to 1600 rpm
Speed stability:
± 2%
Weight capacity:
Up to 19.9 kg (44 lbs)
Ship weight:
2.8 kg
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

Guardian 5000 Series EN-5
7h
h
7Hotplate-Stirrer
Overall dimensions (L x W x H)
30.7 x 22.4 x 12.2 cm
(12.1 x 8.8 x 4.8”)
Top plate dimensions:
17.8 x 17.8 cm (7 x 7”)
Top plate material:
Ceramic
Electrical (50/60 Hz):
120 volts ±10%: 10.0 amps
230 volts ±10%: 6.0 amps
Fuses:
10A time-delay, 5x20mm, 250VAC
Temperature range:
Ambient +5° to 500°C
Temperature stability of top plate+:
± 3% > 100°C, ± 2% ≤100°C
Temperature stability with temperature probe++:
± 1% > 100°C, ± 1°C ≤100°C
Stir capacity:
15 L
Speed range:
60 to 1600 rpm
Speed stability:
± 2%
Weight capacity:
Up to 14.5 kg (32 lbs)
Ship weight:
2.8 kg
Note: + 2” diameter center of top plate
++ 800 mL of water in 1 L flask, 38 mm stir bar, 150 rpm and 50°C, 23°C ambient, 8” (20 cm) SS probe
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

EN-6 Guardian 5000 Series
7x7 Hotplate
Overall
dimensions (L x W x H)
30.7 x 22.4 x 12.2 cm
(12.1 x 8.8 x 4.8”)
Top plate dimensions:
17.8 x 17.8 cm (7 x 7”)
Top plate material:
Ceramic
Electrical (50/60 Hz):
120 volts ±10%: 10.0 amps
230 volts ±10%: 6.0 amps
Fuses:
10A time-delay, 5x20mm, 250VAC
Temperature range:
Ambient +5° to 500°C
Temperature stability of top plate+:
± 3% > 100°C, ± 2% ≤100°C
Temperature stability with temperature probe++:
± 1% > 100°C, ± 1°C ≤100°C
Weight capacity:
Up to 14.5 kg (32 lbs)
Ship weight:
2.8 kg
Note: + 2” diameter center of top plate
++ 800 mL of water in 1 L flask and 50°C, 23°C ambient, 8” (20 cm) SS probe
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

Guardian 5000 Series EN-7
7x7 Stirrer
Overall dimensions (L x W x H)
30.7 x 22.4 x 12.2 cm
(12.1 x 8.8 x 4.8”)
Top plate dimensions:
17.8 x 17.8 cm (7 x 7”)
Top plate material:
Ceramic
Electrical (50/60 Hz):
120 volts ±10%: 1.0 amps
230 volts ±10%: 0.5 amps
Fuses:
5A quick-acting, 5x20mm, 250VAC
Stir capacity:
15 L
Speed range:
60 to 1600 rpm
Speed stability:
f2%
Weight capacity:
Up to 14.5 kg (32 lbs)
Ship weight:
2.8 kg
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

EN-8 Guardian 5000 Series
10X10 Hotplate-Stirrer
Overall dimensions (L x W x H)
42.2 x 28.6 x 12.2 cm
(16.6 x 11.25 x 4.8”)
Top plate dimensions:
25.4 x 25.4 cm (10 x 10”)
Top plate material:
Ceramic
Electrical (50/60 Hz):
120 volts ±10%: 11.2 amps
230 volts ±10%: 7.0 amps
Fuses:
120 volts: 15A quick-acting, 6.3x32mm, 125VAC
230 volts: 10A time-delay, 5x20mm, 250VAC
Temperature range:
Ambient +5° to 500°C
Temperature stability of top plate+:
± 3% > 100°C, ± 2% ≤100°C
Temperature stability with temperature probe++:
± 1% > 100°C, ± 1°C ≤100°C
Stir capacity:
18 L
Speed range:
60 to 1600 rpm
Speed stability:
± 2%
Weight capacity:
Up to 14.5 kg (32 lbs)
Ship weight:
5.4 kg
Note: + 2” diameter center of top plate
++ 800 mL of water in 1 L flask, 38 mm stir bar, 150 rpm and 50°C, 23°C ambient, 8” (20 cm) SS probe
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

Guardian 5000 Series EN-9
1.5.2 Device Setup
Hotplate-Stirrer (Round Top, 7x7, 10x10-230V)
A. Display Screen
B. Standby Indicator
C. Left Knob:
Controls temperature and settings
menu
D. Right Knob:
Controls speed
E
. External RTD Probe Port
F. Fuse
G
. Power Entry Module (PEM)
H
. Threaded Knob for Accessory Rod
I. Standby Switch
J
. Feet: Not adjustable
