Ohme Cable User manual

v1.0 1
Ohme Cable
Product Manual

v1.0 2
Contents
Safety Precautions...............................................................................................................................3
Product Specification...........................................................................................................................4
Product Description.............................................................................................................................4
Installation...........................................................................................................................................4
Instructions for Use .............................................................................................................................6
Grid-sympathetic Charging ..................................................................................................................7
Indicator Lights ....................................................................................................................................7
Troubleshooting ..................................................................................................................................7
Cleaning...............................................................................................................................................8
Maintenance........................................................................................................................................8
Standards Compliance .........................................................................................................................9
Disposal ...............................................................................................................................................9
Contact Details ..................................................................................................................................10
Manufacturer’s Warranty..................................................................................................................10
Limitation of Liability .........................................................................................................................11

v1.0 3
Safety Precautions
This document contains important safety information relating to your Ohme Cable. Please retain
this document for future reference.
Please read the document fully before using the Ohme Cable. Not following the safety instructions
can result in electric shock, fire, serious injury or death.
Do not use the Ohme Cable with extension leads or multi-plug adaptors
The cable should be inspected periodically to check for damage to the cabling and the
enclosure. Do not use if the product is defective or appears damaged. Contact the
Ohme support centre for advice
Do not attempt to open, repair, tamper or modify the Ohme Cable in any way. There
are no user-serviceable parts
We strongly recommend that a competent person (e.g. qualified electrician) installs
and/or inspects the installation to check for safety and supply adequacy before use
The overall installation should be in accordance with the IET Wiring Regulations and the
IET Code of Practice for Electric Vehicle Charging Equipment
Do not disconnect the Ohme Cable from the wall socket/power supply when charging.
Always disconnect from the vehicle first
Handle the Ohme Cable with care. Do not expose any part of the cable to severe forces,
impact or sharp objects
The Ohme cable is weatherproof –it can withstand heavy rain –however, do not
submerse any part of the Ohme Cable in water. For example, check that the Ohme
Cable will not rest in a puddle during inclement weather
The Ohme Cable is only intended for vehicles that do not require ventilation during
charging
You may clean the Ohme Cable, when unplugged, with a soft damp cloth. Do not use
solvents or abrasives

v1.0 4
Product Specification
Voltage
220 –250 V
Frequency
50 / 60 Hz
Power output
3-pin: 10 Amps
Commando: 32 Amps
Type 2: 32 Amps
Operating Temperature
-25⁰C to 45⁰C
Storage Temperature
-40⁰C to 85⁰C
Cable length
5 metres
Residual current function
Type A 30mA
DC 6mA
Overcurrent protection
Not fitted
Ingress protection
IP54 + partial immersion
Product Description
The Ohme Cable is an Electric Vehicle (EV) charging cable, comprising:
•Power input connector
•Charge controller, including residual current protection device
•Charging cable
•Vehicle connector
The Ohme Cable is supplied in various connection formats to make installation and use as easy as
possible.
All Ohme Cables are to be used with single phase electricity supplies (most UK houses are single
phase).
The cable is paired with the Ohme smartphone app, which allows users to control their charging to
minimise cost, minimise carbon content of their energy use and maximise battery life of their
vehicle.
The product conforms to the latest safety standards including functions to disconnect the power
supply if AC or DC current leakage occurs.
Installation
The Ohme Cable comes in three power input connector types:

v1.0 5
•3-pin plug (BS1363)
•32A Commando plug (IEC 60309)
•Type 2 (IEC62196)
3-pin Plug
The Ohme Cable can be plugged into any household socket to charge your vehicle. We recommend
that your electrical system is inspected by a competent electrician to ensure the circuit is safe for
the continuous demands of EV charging.
For frequent charging, we recommend that an external dedicated socket is installed by a competent
electrician to avoid any risks of overload to existing household electrics.
It is not necessary to inform your local DNO (Distribution Network Operator) that a charge point has
been installed.
Do not use multi-plug adaptors or extension leads with the Ohme Cable. Many of these are not
suitable for the continuous, high loads drawn by electric vehicle charging.
Commando Socket
Commando sockets are widely used in industry to power small industrial appliances, similar to the
sockets you would see at a caravan park. They make great, simple, inexpensive connectors for your
Ohme Cable. They are readily available rated at 32 Amps / 7.4 kW to fast charge your EV.
For use in a domestic environment, “interlocked” Commando sockets are recommended. These are
fitted with a switch so the power can be isolated before the connector is removed. Your electrician
will be familiar with these sockets.
Included with the Ohme Cable is a short “Guide for Electricians” document, which will make sure
your electrician knows exactly what you need them to do.
Type 2
The Type 2 Ohme Cable has been developed to “upgrade” an existing charge point to smart. This
cable simply plugs into a Type 2 untethered charge point. There is no additional installation
necessary.
The Ohme Cable will “talk to” your charge point and make sure that it does not charge above the
rating of your unit. It is therefore safe to use a 32 Amp Ohme Cable, for instance, with a 16A charge
point.

v1.0 6
Instructions for Use
Starting a charge session
Firstly, connect the Ohme Cable to the power supply socket or the charge point. The Ohme Cable
will automatically initialise, check for faults and initialise and connect to the Ohme cloud service.
Secondly, connect to the vehicle. The vehicle will begin charging. Once the cable has connected to
the Ohme service, a charging profile will be sent to the cable based on your requirements and
preferences.
Stopping a charge session
Disconnect the cable from the vehicle first in the normal way. If required, then remove from the
power supply socket.
Getting the App
Download the smartphone app by searching for “Ohme” from the Android or Apple App Store.

v1.0 7
Grid-sympathetic Charging
The Ohme platform is designed to help reduce power demand in times of stress to the local and
regional electricity networks. As the adoption of EVs progresses, these features will become more
important to avoid expensive and disruptive upgrades to electricity networks.
To facilitate this, charging demand may be limited in times of extreme stress to the electricity
network to prevent power outages. This will always be done in a way to limit the effect on users of
the platform. We understand that EV drivers are reliant on their vehicles. If you have any queries or
concerns, please contact us for more information.
Indicator Lights
The Ohme Cable has an LCD display and LED charge indicator lights.
Waiting, ready to connect to the car
Connected to the car, not charging
Charging
Smart charging
Electrical Fault
EV Fault
Troubleshooting
Issue
Possible Cause
Ohme Cable does not power up
Check electrical supply to the Ohme Cable or
separate chargepoint. Supply MCB or RCD
may have tripped.
1
2
3
Flash
Flash
Flash
Flash
Flash

v1.0 8
Issue
Possible Cause
Ohme is powered up but vehicle does not
charge
Check cable is fully inserted. Possible earth
impedance issue as some vehicles do not
charge if earth impedance is high. Try in a
different location. Contact Ohme Support.
No communications to the Ohme Cable
Possible poor mobile phone signal. If
persistent, it is possible to use the Ohme
Cable with mobile phone signal repeaters.
Contact Ohme Support for further
information.
Cannot link the Ohme Cable to the app
The cable can be remotely linked to the app.
Contact Ohme Support for assistance.
If there are any queries or issues regarding using the Ohme Cable, please contact Ohme Support via
email: [e-mail], telephone [phone], or send a direct message on Twitter to
@OhmeEV.
Cleaning
The Ohme cable can be cleaned with a soft damp cloth. Avoid the use of cleaning agents and
solvents.
Maintenance
The Ohme Cable is maintenance free. If the cable is defective or damaged, please discontinue usage
and contact the Ohme Support Centre for advice.

v1.0 9
Standards Compliance
The Ohme Cable is classed as an IC-CPD (In-Cable Control and Protection Device) as described in
IEC62752:2016.
The product complies with:
•IEC62752:2016 In-cable control and protection device for mode 2 charging of electric road
vehicles (IC-CPD)
•EN61000-6-3 Electromagnetic compatibility (EMC). Generic standards. Emission standard for
residential, commercial and light-industrial environments
•EN61000-6-1 Electromagnetic compatibility (EMC). Generic standards. Immunity standard for
residential, commercial and light-industrial environments
•IEC62196-1 Plugs, socket-outlets, vehicle connectors and vehicle inlets
•IEC60309-2 Plugs, sockets and couplers for industrial purposes
•BS 1363-1 13 A plugs, socket-outlets, adaptors and connection units. Specification for
rewirable and non-rewirable 13 A fused plugs
Disposal
Information on Disposal for Users of Waste Electrical & Electronic Equipment
(private households)
This symbol on the product and accompanying documents means that used electrical
and electronic products should not be mixed with general household waste. For
proper treatment, recovery and recycling, please take this product to designated collection points
where it will be accepted free of charge.
Alternatively, in some countries you may be able to return your products to your local retailer upon
purchase of an equivalent new product.
Disposing of this product correctly will help save valuable resources and prevent any potential
negative effects on human health and the environment, which could otherwise arise from
inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with your national
legislation.
For business users in the European Union:

v1.0 10
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for
further information.
Information on Disposal in other Countries outside the European Union:
This symbol is only valid in the European Union. If you wish to discard this product please contact
your local authorities or dealer and ask for the correct method of disposal.
Further information on disposal and general recycling can be found at www.complydirect.com/the-
recylcing-room.
Contact Details
Ohme Support can be contacted at:
Address: Ohme Technologies Ltd.
Unit 74
Penrose Wharf
Penrose Quay
Cork
Ireland
T23 HF51
Email: [email protected]m
Telephone: [phone]
Manufacturer’s Warranty
The Ohme Cable is protected by a manufacturer’s warranty for 12 months from the date of
purchase or delivery, whichever is later.
The warranty covers any defects in materials or workmanship under normal use. During the
warranty period, Ohme will refund, repair or replace, at its discretion, at no charge, products or
parts of the product which prove defective because of improper materials or workmanship under
normal use and maintenance.
Ohme will either repair the product using new or refurbished replacement parts or replace the
product with new.

v1.0 11
A replacement product assumes the remaining warranty period of the original product or for 180
days from the date of the replacement or repair, whichever is longer.
The warranty does not cover any issues that are caused by conditions, malfunctions, or damage not
resulting from defects in materials or workmanship. The warranty does not cover damage or
malfunction directly or indirectly caused by normal wear and tear, abuse, misuse, negligence,
accident, lack of or improper use, including but not limited to:
•Failure to follow the instructions and warnings provided in the product literature
•The environment or “Acts of God” such as fire, earthquake, flood
•General appearance of the product such as damage to paint, labels, scratches, dents and
cracks
•Any repair, alteration or modification to the product other than those authorised by
Ohme
You may have other legal rights under local laws in addition to the rights under this manufacturer’s
warranty. Contact Ohme in the first instance to discuss your options.
To initiate a service from Ohme under the manufacturer’s warranty, it is necessary to contact Ohme
first to assist in determining the most appropriate solution.
Limitation of Liability
No liability will be accepted for any loss, costs or damage as a consequence of using or misusing the
product except, and only to the extent, where this is caused by our negligence.
Terms & Conditions
For Terms & Conditions of the product please visit our website at www.ohme-ev.com.
