OKIN BT-CB.02 User manual

BT‐CB.02UserGuide
Appearance
Specification
1.PartNumber:BT‐CB.02;
2.WorkingVoltage:18‐30V;
3.WorkingCurrent:5mA@29V;
4.OperationTemperature:‐20~55℃;
5.Storagetemperature:‐45~85℃;
6.RFFrequencyRange:2.402~2.480GHz;
7.RFModulation: GFSK;

8.RFTransmittedPower:-4.0dBm;
9.HousingMaterial:ABS765A,94V‐0;
InterfaceDescription
1. StatusIndication:onecolor,twodifferentstatus
Status1:Breathing lamp,whenpoweredon;
Status2:Blue,whenBluetoothislinkedbysmartphone;
StatusIndication
Main‐MFPINterface

Instructions
1. OpentheNewOreBedingapplication
2. Selectthecurrentcontrolboxisafewmotorsystems
http://www.pgyer.com/jbm0 ------Android mobile app download address
http://www.pgyer.com/Synergy369-ios------Iphone mobile app download address

3. GotothesetupinterfaceandpairtheBluetoothcontrolbox
3. SelectthesignalpairingfromthecurrentlyusedBluetoothcontrolbox
4.Aftersuccessfulpairing,operatethemaininterface,youcanoperatethecontrol
box

FCC：
AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliance
couldvoidtheuser’sauthoritytooperatetheequipment.
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo
conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustaccept
anyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.
ISEDRSSWarning:
ThisdevicecomplieswithInnovation,ScienceandEconomicDevelopmentCanadalicenceexempt
RSSstandard(s).Operationissubjecttothefollowingtwoconditions:(1)thisdevice
maynotcauseinterference,and(2)thisdevicemustacceptanyinterference,including
interferencethatmaycauseundesiredoperationofthedevice.
LeprésentappareilestconformeauxCNRd'ISEDapplicablesauxappareilsradio
exemptsdelicence.
L'exploitationestautoriséeauxdeuxconditionssuivantes:
(1)l'appareilnedoitpasproduiredebrouillage,et
(2)l'utilisateurdel'appareildoitacceptertoutbrouillageradioélectriquesubi,
mêmesilebrouillageestsusceptibled'encompromettrelefonctionnement.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment .This equipment should be installed and operated with minimum distance 20cm between
the radiator& your body.
ISED Radiation Exposure Statement:
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled
environment .This equipment should be installed and operated with minimum distance 20cm between
the radiator& your body. This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Le rayonnement de la classe b repecte IC fixaient un environnement non contrôlés.Installation et mise
en œuvre de ce matériel devrait avec échangeur distance minimale entre 20 cm ton corps.Lanceurs ou
ne peuvent pas coexister cette antenne ou capteurs avec d’autres.
