Okina SEDX-761AI-B User manual

SEDX-761AI-B 12V DC, Black
SEDX-761AI-W 12V DC, White
SEDX-761AI-BD 12V DC / 24V AC, Black
SEDX-761AI-WD 12V DC / 24V AC, White
3-AXIS Varifocal Dome Camera - Effio-E
User Manual
Thanks for purchasing our product. Before operating the unit, please read the
instructions carefully and keep this manual for future reference.

Copyright © 2010. All Rights Reserved.
www.okinausa.com i REV122010-V17
Safety Warnings
1. Read this manual carefully before installing the unit
Please read this manual first for correct installation and operation.
2. Never install the camera on a ceiling that cannot hold its weight
The product may fall down and cause damages.
3. Never install the camera near electric or magnetic fields
Install the camera away from TV, radio transmitter, magnet, electric motor,
transformer, audio speakers since the magnetic fields generate from above
devices would distort the video image.
4. Never install or use the camera in areas exposed to water, oil or gas
The water, oil or gas may result in operation failure, electric shock or fire. Do
not use this unit near water-for example, near a bath tub, wash bowl, kitchen
sink, or laundry tub, in a wet basement, near a swimming pool, in an
unprotected outdoor installation, or any area which is classified as a wet
location.
5. Never face the camera toward the sun
Direct sunlight or severe ray may cause fatal damage to sensor and internal
circuit.
6. Power Cord Protection
Touching the wet power cord with hands or touching the power cord with wet
hands may result in electric shock. Power supply cords should be routed so
that they are not likely to be walked on or pinched by items placed upon or
against them, playing particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Attachments
Do not use attachment not recommended by the product manufacturer as
they may cause hazards.
8. Object and Liquid Entry
Never push objects of any kind into this product through openings as they
may touch dangerous voltage points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any kind onto the product.
9. Do not operate the camera in environments where the temperature,
humidity or power source is beyond the specified ones
Use the camera in suitable environments where the temperature is within
-10°C~50°C and humidity below 90%. Use the input power source as the
specifications listed.

Copyright © 2010. All Rights Reserved.
www.okinausa.com ii REV122010-V17
10.Cleaning
Unplug the unit from the outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
11. Never disassemble the camera nor put impurities in it
Disassembly or impurities may result in trouble or fire.
12.Stop using when the product emits smoke or abnormal heat
13.Servicing
Do not attempt to repair this unit yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
14.Retain Instructions
THE SAFETY AND OPERATING INSTRUCTIONS SHOULD BE RETAINED
FOR FUTURE REFERENCE.
Warranty
OKINA USA Products are covered under warranty for one year from the date of
purchase. The warranty will automatically be voided if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any information
regarding when and where the product was purchased. We have no other way to
verify the purchase record without the serial number on the camera sticker;
therefore, it should not be removed.
2. Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not described in this
manual, the warranty will be voided immediately. It is the customer’s responsibility
to keep the camera in good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered with. Cutting or
modifying of the cables will result in termination of the warranty.
NOTICE:
The information in this manual was up-to-date when published. The manufacturer
reserves the right to revise and improve its products. All specifications are therefore
subject to change without notice.

Copyright © 2010. All Rights Reserved.
www.okinausa.com iii REV122010-V17
Table of Contents
1. INTRODUCTION............................................................................................................................ 1
1.1 MAIN FEATURES....................................................................................................................... 1
1.2 CONTENT LIST ......................................................................................................................... 1
1.3 SPECIFICATIONS....................................................................................................................... 2
2. CAMERA OVERVIEW.................................................................................................................... 3
2.1 DIMENSIONS ............................................................................................................................ 3
2.2 DESCRIPTION OF CAMERA PARTS .............................................................................................. 4
3. OSD OPERATION ......................................................................................................................... 4
3.1 OSD CONTROL BUTTONS ......................................................................................................... 5
3.2 OSD OPERATION ..................................................................................................................... 6
4. CONFIGURATION ......................................................................................................................... 7
4.1 LENS ..................................................................................................................................... 7
4.1.1 AUTO IRIS.................................................................................................................. 7
4.2 SHUTTER/AGC ..................................................................................................................... 9
4.2.1 AUTO SETUP ............................................................................................................. 9
4.2.2 MANUAL SETUP ...................................................................................................... 10
4.3 NR ........................................................................................................................................11
4.4 WHITE BAL (WHITE BALANCE) .............................................................................................. 12
4.4.1 ATW (Auto Trace White Balance).............................................................................. 13
4.4.2 PUSH........................................................................................................................ 13
4.4.3 USER1...................................................................................................................... 13
4.4.4 USER2...................................................................................................................... 14
4.4.5 MANUAL WB (Manual White Balance)...................................................................... 14
4.4.6 PUSH LOCK ............................................................................................................. 14
4.5 ATR...................................................................................................................................... 15
4.5.1 ATR ON..................................................................................................................... 15
4.6 BACKLIGHT ........................................................................................................................ 16
4.7 DAY/NIGHT ......................................................................................................................... 17
4.7.1 B/W........................................................................................................................... 17
4.7.2 DAY/NIGHT............................................................................................................... 18
4.8 PICT ADJUST ...................................................................................................................... 19
4.9 MOTION DET (MOTION DETECTION)...................................................................................... 20
4.9.1 MOTION DET ON ..................................................................................................... 20
4.10 PRIVACY ............................................................................................................................. 22
4.10.1 PRIVACY ON............................................................................................................ 22
4.11 CAMERA ID ......................................................................................................................... 24
4.11.1 CAMERA ID ON........................................................................................................ 24
4.12 LANGUAGE......................................................................................................................... 26
4.13 CAMERA RESET................................................................................................................. 27
4.14 SAVE ALL ............................................................................................................................ 27
4.15 EXIT..................................................................................................................................... 27

Copyright © 2010. All Rights Reserved.
www.okinausa.com 1 REV122010-V17
1. Introduction
SEDX-761AI-B / SEDX-761AI-W / SEDX-761AI-BD / SEDX-761AI-WD are built
with Sony’s latest image processor. This super-wide dynamic camera has the
capability of achieving resolutions of over 610 TVL. The features include 2D
noise reduction, spot removal, strong-light suppression, intelligent motion, face
detection and OSD functions. SEDX-761AI-B / SEDX-761AI-W /
SEDX-761AI-BD / SEDX-761AI-WD reproduces nearly perfect images like no
other.
1.1 Main Features
1/3" Sony 760H Super HAD CCD II
Sony Effio-E DSP
Color: 610 TVL, B/W: 630 TVL
Color: 0.15 Lux @ F1.2, B/W: 0.1 Lux @ F1.2
Multi-Language OSD Control
ATR Digital Powerful 128x WDR (52dB)
Anti-Headlight (HLC)
2D Noise Reduction
High Contrast Images
Ideal for Backlight Environments
Mosaic Privacy Mask
Advanced Motion Detection Function
Picture Quality Adjustable (Contrast/Sharpness/Hue/Gain)
Built-in Varifocal Lens & Unique 3 Axis Gimble Mechanism
SEDX-761AI-B / SEDX-761AI-W: 12V DC, 2.3W
SEDX-761AI-BD / SEDX-761AI-WD: 12V DC / 24V AC, 2.3W
1.2 Content List
One (1) SEDX-768AI-B or SEDX-768AI-W or SEDX-768AI-BD or
SEDX-768AI-WD camera with video/power cable
Two (2) Mounting Screws
One (1) DC Male Connector
One (1) Cleaning Cloth
One (1) Warning Sign Sticker
One (1) User Manual
One (1) CD
*For any returns, please include all components listed above with original packaging in
Resalable Condition. Absolutely No Returns will be accepted if any component is
missing/damaged or if any cable is cut or tampered with.

Copyright © 2010. All Rights Reserved.
www.okinausa.com 2 REV122010-V17
1.3 Specifications
PIC D-233 D-234 D-239 D-240
Model SEDX-761AI-B SEDX-761AI-W SEDX-761AI-BD SEDX-761AI-WD
Base Color Black White Black White
Image Sensor 1/3" Sony 760H Super HAD CCD II
Total Pixels NTSC: 811(H)x508(V) / PAL: 795(H)x596(V)
Resolution ; DSP Color: 610 TVL, B/W: 630 TVL ; Sony Effio-E
Minimum Illumination Color: 0.15 Lux @ F1.2, B/W: 0.1 Lux @ F1.2
Wide Dynamic Range ATR Digital WD (ATR: Adaptive Tone-curve Reproduction) ;
128x Normal Camera (52dB)
Video Output ; Connector 1.0Vp-p Composite, 75Ω; BNC 1.0Vp-p Composite, 75Ω; BNC
RCA Service Monitor Output
Signal Noise Ratio More than 52dB (AGC off, Weight on)
Gamma Correction 0.45
Menu OSD Control
Title TITLE (LOCATION)
Synchronizing System INTERNAL
Digital Day&Night Mode COLOR / B&W / AUTO
Electronic Shutter
AUTO (1/50(60)~1/100,000sec.) /
MANUAL: 1/50(60), FL 1/120(100), 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000,
1/10,000sec.
Automatic Gain Control AUTO (4 Steps)
White Balance ATW / PUSH / USER1 / USER2 / ANTI CR /
MANUAL / PUSH LOCK
Back Light Compensation HLC / BLC / OFF
Flickerless ON / OFF
Dynamic Noise Reduction 2D
Language ENGLISH / JAPANESE / GERMAN / FRENCH / RUSSIAN / PORTUGUESE /
SPANISH / SIMPLIFIED CHINESE
Motion Detection ;
Privacy
ON / OFF (24x16 Zones, Alarm) ;
ON / OFF (8 Zones Programmable, Mosaic)
Automatic IRIS ;
Connector DC
Lens Mount Built-in DC Auto IRIS Lens
Lens, Angle of View(H) f2.8 mm~10.5mm / F1.2
Aspherical Auto Iris Lens/ 99.5°~27.4°
Power Input ;
Consumption 12V DC ; 2.3W 12V DC / 24V AC Internal 12V DC Only ; 2.3W
Operation ; Storage
Temperature 14˚F~122˚F ; -4˚F~140˚F / -10˚C~50˚C ; -20˚C~60˚C
Operation ; Storage
Humidity Maximum:RH80% ; RH90%
Dimensions 4.88”(DIA) x 3.78”(H) / 124(DIA) × 96(H)mm
Net Weight 0.71 lbs / 320g
* Specifications are subject to change without notice
PAL version also available

Copyright © 2010. All Rights Reserved.
www.okinausa.com 3 REV122010-V17
2. Camera Overview
2.1 Dimensions

Copyright © 2010. All Rights Reserved.
www.okinausa.com 4 REV122010-V17
2.2 Description of Camera Parts
(1) FAR/NEAR
To adjust the lens focus for near and far.
(2) WIDE/TELE
To adjust the lens angle for wide and tele.
(3) OSD Control Buttons
ENTER button
UP & DOWN button
LEFT & RIGHT button
(4) VIDEO Connector
This is an output for BNC connection to a video monitor, etc (75Ω).
(5) Power Input Terminal
Connect the power input of 12V DC for SEDX-761AI-B / SEDX-761AI-W.
(6) Power Input Terminal
Connect the power input of 12V DC / 24V AC for SEDX-761AI-BD /
SEDX-761AI-WD.
(7) 12V DC Input (Available for SEDX-768AI-BD / SEDX-768AI-WD only)
(8) RCA Service Monitor Output (Available for SEDX-768AI-BD / SEDX-768AI-WD only)
4
6
4
5
Dual Power
SEDX-761AI-BD
SEDX-761AI-WD
12V DC
SEDX-761AI-B
SEDX-761AI-W
7 8

Copyright © 2010. All Rights Reserved.
www.okinausa.com 5 REV122010-V17
3. OSD Operation
3.1 OSD Control Buttons
① U (UP)
Use this button to move the cursor upwards to the desired item.
② R (RIGHT)
Use this button to move the cursor to the right to select or to adjust the
parameters of the selected item. The parameter increases when the right
button is pressed.
③ D (DOWN)
Use this button to move the cursor downwards to the desired item.
④ L (LEFT)
Use this button to move the cursor to the left to select or to adjust the
parameters of the selected item. The parameter decreases when the left
button is pressed.
⑤ ENTER
Use this button to display the main menu, to confirm and to enter the
submenus when they’re available. Items with the symbol “<┘” in the end
contain sub-menus. For further settings of those items, select the desired
item with the button cor dand press the ENTER button to bring up the
sub-menu and edit.
U
RL
ENTER
D

Copyright © 2010. All Rights Reserved.
www.okinausa.com 6 REV122010-V17
3.2 OSD Operation
1. Start to operate the OSD menu
Press the ENTER button to bring up the OSD main menu to start operating
OSD menus.
2. Select items with the cursor buttons
yUse buttons cand dto move the cursor up and down.
yUse buttons eand fto switch the modes or to adjust the parameters or
the values of the settings.
3. Switch to the sub-menu
Items with the symbol “<┘” in the end contain sub-menus. For further settings
of those items, select the desired item with the button cor dand press the
ENTER button to bring up the sub-menu and edit.
4. Return to the previous page
Select RETURN and press the ENTER button to return to the previous page.
5. Exit the OSD menu
Select EXIT with the button cor dand press the ENTER button to exit the
OSD menu.
SETUP MENU
LENS AUTO<┘
SHUTTER/AGC AUTO<┘
NR <┘
WHITE BAL ATW<┘
ATR OFF
BACKLIGHT OFF
DAY/NIGHT AUTO<┘
NEXT<┘
EXIT<┘SAVE ALL<┘
Main Menu
AUTO IRIS
TYPE DC
MODE AUTO
SPEED ||||
|
||||||||||| 080
RETURN<┘
Sub-Menu
SETUP MENU
LENS AUTO<┘
SHUTTER/AGC AUTO<┘
NR <┘
WHITE BAL ATW<┘
ATR OFF
BACKLIGHT OFF
DAY/NIGHT AUTO<┘
NEXT<┘
EXIT<┘SAVE ALL<┘
U
RL
ENTER
D

Copyright © 2010. All Rights Reserved.
www.okinausa.com 7 REV122010-V17
4. Configuration
4.1 LENS
When the SETUP MENU is displayed on the screen, use buttons cand dto
select the LENS and press the ENTER button to do further settings.
Select to set the mechanical iris of the lens.
Function Option
LENS MANUAL
AUTO<┘
yMANUAL
Auto electronic shutter
yAUTO<┘
Auto electronic shutter + Mechanical auto IRIS
When AUTO<┘is selected, click ENTER to bring up the AUTO IRIS
sub-menu for further settings.
4.1.1 AUTO IRIS
Adjust the settings of the AUTO IRIS.
Function Option
TYPE DC
VIDEO
MODE
OPEN
CLOSE
AUTO
SPEED 000 – 255
yTYPE
Select to set the type of the mechanical iris.
- DC: DC Lens.
- VIDEO: VIDEO Lens.
Main Menu
AUTO IRIS
TYPE DC
MODE AUTO
SPEED ||||
|
||||||||||| 080
RETURN<┘
Sub-Menu
SETUP MENU
LENS AUTO<┘
SHUTTER/AGC AUTO<┘
NR <┘
WHITE BAL ATW<┘
ATR OFF
BACKLIGHT OFF
DAY/NIGHT AUTO<┘
NEXT<┘
EXIT<┘SAVE ALL<┘

Copyright © 2010. All Rights Reserved.
www.okinausa.com 8 REV122010-V17
yMODE
Select to set the type of control to be exercised over the mechanical
iris.
- OPEN: The mechanical iris is fixed to open.
- CLOSE: The mechanical iris is fixed to close.
- AUTO: The mechanical iris is controlled automatically.
ySPEED
Select to set the convergence speed of the mechanical iris.

Copyright © 2010. All Rights Reserved.
www.okinausa.com 9 REV122010-V17
4.2 SHUTTER/AGC
When the SETUP MENU is displayed on the screen, use buttons cand dto
select the SHUTTER/AGC and press the ENTER button to do further settings.
Select to set Auto exposure or Manual exposure.
Function Option
SHUTTER/AGC AUTO<┘
MANUAL<┘
yAUTO<┘:
When AUTO<┘is selected, click ENTER to bring up the AUTO SETUP
sub-menu for further settings.
yMANUAL<┘:
When MANUAL<┘is selected, click ENTER to bring up the MANUAL
SETUP sub-menu for further settings.
4.2.1 AUTO SETUP
Adjust the settings of the AUTO SETUP.
Function Option
HIGH
LUMINANCE
MODE SHUT+AUTO IRIS
AUTO IRIS *
BRIGHTNESS 000 – 255
LOW
LUMINANCE
MODE OFF
AGC
BRIGHTNESS x0.25 ; x0.50 ; x0.75 ; x1.00
yHIGH LUMINANCE
- MODE
Select to specify AE control on the medium- and high-brightness
side.
SHUT + AUTO IRIS: Auto electronic shutter + Mechanical auto IRIS
AUTO IRIS: Shutter fix + Mechanical auto IRIS
NOTICE:
If MANUAL has been selected as the LENS function setting, SHUT will be
displayed, and the settings made in this section will not take effect.
SETUP MENU
LENS AUTO<┘
SHUTTER/AGC AUTO<┘
NR <┘
WHITE BAL ATW<┘
ATR OFF
BACKLIGHT OFF
DAY/NIGHT AUTO<┘
NEXT<┘
EXIT<┘SAVE ALL<┘

Copyright © 2010. All Rights Reserved.
www.okinausa.com 10 REV122010-V17
- BRIGHTNESS
Select to specify the high- and medium-brightness side reference.
The brightness changes depending on whether the ATR function is
ON or OFF, and whether the CRS mode has been selected as the
AWB function.
Please note that the brightness will change when ATR or WHITE
BAL is set to ANTI CR (CRS mode), etc., after BRIGHTNESS has
been set.
yLOW LUMINANCE
- MODE
Select to specify AE control on the low-brightness side.
OFF: OFF
AGC: Auto gain control
- BRIGHTNESS
Select to specify the low-brightness side reference.
4.2.2 MANUAL SETUP
Adjust the settings of the MANUAL SETUP.
Function Option
MODE SHUT+ AGC
SHUTTER 1/60* ; 1/100* ; 1/250 ; 1/500 ; 1/1000 ; 1/2000 ; 1/4000 ;
1/10000
AGC 6.00 ; 12.00 ; 18.00 ; 24.00 ; 30.00 ; 36.00 ; 42.00 ; 44.80
yMODE
"SHUT+AGC" is the only option available for the ME operation mode.
There are no other options.
ySHUTTER
Select to set the ME shutter speed (in fractions of a second).
yAGC
Select to set the AGC value for ME.

Copyright © 2010. All Rights Reserved.
www.okinausa.com 11 REV122010-V17
4.3 NR
This item is used to set the noise reduction.
Select to bring up the NR sub-menu for further settings.
Function Option
NR MODE
OFF
Y
C
Y/C
Y LEVEL 000-015
C LEVEL 000-015
yNR MODE
Select to set the 2D NR filter mode.
- OFF: Y and C filters OFF
- Y: Y filter ON
- C: C filter ON
- Y/C: Y and C filters ON
yY LEVEL
Select to set the Y filter strength.
yC LEVEL
Select to set the C filter strength.
SETUP MENU
LENS AUTO<┘
SHUTTER/AGC AUTO<┘
NR <┘
WHITE BAL ATW<┘
ATR OFF
BACKLIGHT OFF
DAY/NIGHT AUTO<┘
NEXT<┘
EXIT<┘SAVE ALL<┘

Copyright © 2010. All Rights Reserved.
www.okinausa.com 12 REV122010-V17
4.4 WHITE BAL (White Balance)
The screen color can be adjusted by using the WHITE BAL function.
1. Please use the cand dbuttons to WHITE BAL on the SETUP MENU and
press the ENTER button to do further settings.
2. Please select the desired item and press eand fbuttons to adjust the
settings.
Select to set the white balance Mode.
Function Option
WHITE BAL
ATW
PUSH
USER1
USER2
ANTI CR
MANUAL
PUSH LOCK
yATW (Auto Trace White balance)
When ATW<┘is selected, click ENTER to bring up the ATW sub-menu for
further settings.
yPUSH: All pull-in
Select to set the white balance mode to the PUSH mode.
yUSER1: Fluorescent light fixed gain (3200K)
When USER1<┘is selected, click ENTER to bring up the USER1 WB
sub-menu for further settings.
yUSER2: Outdoor fixed gain (6300K)
When USER2<┘is selected, click ENTER to bring up the USER2 WB
sub-menu for further settings.
yANTI CR: Color rolling suppression
Select to set the white balance mode to the ANTI CR mode.
yMANUAL: Manual white balance
When MANUAL<┘is selected, click ENTER to bring up the MANUAL WB
sub-menu for further settings.
SETUP MENU
LENS AUTO<┘
SHUTTER/AGC AUTO<┘
NR <┘
WHITE BAL ATW<┘
ATR OFF
BACKLIGHT OFF
DAY/NIGHT AUTO<┘
NEXT<┘
EXIT<┘SAVE ALL<┘

Copyright © 2010. All Rights Reserved.
www.okinausa.com 13 REV122010-V17
yPUSH LOCK
Select to set the white balance mode to the PUSH LOCK mode.
4.4.1 ATW (Auto Trace White Balance)
Adjust the settings of the ATW.
Function Option
SPEED 000-255
DELAY CNT 000-255
ATW FRAME x0.50 ; x1.00 ; x1.50 ; x2.00
ENVIROMENT INDOOR ; OUTDOOR
ySPEED
Select to adjust the pull-in speed of ATW.
yDELAY CNT
Select to set the time-based hysteresis of ATW.
yATW FRAME
Select to set the pull-in frame magnification.
yENVIROMENT
Select to set the pull-in frame (indoor/outdoor) of ATW.
4.4.2 PUSH
Select to allow the camera automatically adjust the white balance under
all conditions.
4.4.3 USER1
The gain values for the fluorescent light fixed mode are used as the
adjustment items of USER1 WB on the internal OSD menu.
yB-GAIN
Used for operating the B gain in the WB fixed gain mode.
yR-GAIN
Used for operating the R gain in the WB fixed gain mode.
Function Option
B-GAIN 000-255
R-GAIN 000-255

Copyright © 2010. All Rights Reserved.
www.okinausa.com 14 REV122010-V17
4.4.4 USER2
The gain values for the outdoor fixed mode are used as the adjustment
items of USER2 WB on the internal OSD menu.
yB-GAIN
Used for operating the B gain in the WB fixed gain mode.
yR-GAIN
Used for operating the R gain in the WB fixed gain mode.
4.4.5 MANUAL WB (Manual White Balance)
The B and R gain values for manual WB are set on this screen.
yLEVEL
Select to set the B and R gain values for MANUAL WB.
By incrementing or decrementing the B gain value, the R gain value is
also adjusted in tandem.
NOTICE:
The actual variable range is limited to the range from the low color temperature
(approx. 1800K) to the high color temperature (approx. 10500K) stored when the
pre-white balance was adjusted.
4.4.6 PUSH LOCK
To find the optimal setting for the current luminance environment in this
mode, point the camera towards a sheet of white paper and press the
ENTER button.
Whenever the condition changes, readjust it.
ATTENTION:
The white balance can not fully function under the following conditions. Please select
PUSH LOCK Mode when the following occurred.
<When there’s a higher temperature surrounded the object.
<When there’s darkness surrounded the object.
<When there’s a fluorescent light surrounded the object or where the light changes all
the time.
Function Option
B-GAIN 000-255
R-GAIN 000-255
Function Option
LEVEL 000-255

Copyright © 2010. All Rights Reserved.
www.okinausa.com 15 REV122010-V17
4.5 ATR
This item is used to set the Day/Night function.
Select to set ATR to OFF or ON.
yOFF
ATR OFF
yON
ATR ON
When ON<┘is selected, click ENTER to bring up the ATR sub-menu for
further settings.
4.5.1 ATR ON
yLUMINANCE
Select to set the extent of the luminance compression.
yCONTRAST
Select to set the extent of the contrast enhancement.
Function Option
LUMINANCE
LOW
MID
HIGH
CONTRAST
LOW
MIDLOW
MID
MIDHIGH
HIGH
SETUP MENU
LENS AUTO<┘
SHUTTER/AGC AUTO<┘
NR <┘
WHITE BAL ATW<┘
ATR OFF
BACKLIGHT OFF
DAY/NIGHT AUTO<┘
NEXT<┘
EXIT<┘SAVE ALL<┘

Copyright © 2010. All Rights Reserved.
www.okinausa.com 16 REV122010-V17
4.6 BACKLIGHT
This item is used to set the backlight compensation operation.
Select to set BACKLIGHT to OFF,BLC or HLC.
Function Option
BACKLIGHT
OFF
BLC
HLC
yOFF
Backlight compensation OFF.
yBLC
Backlight compensation ON.
yHLC
HLC(Headlight compensation) function ON.
SETUP MENU
LENS AUTO<┘
SHUTTER/AGC AUTO<┘
NR <┘
WHITE BAL ATW<┘
ATR OFF
BACKLIGHT OFF
DAY/NIGHT AUTO<┘
NEXT<┘
EXIT<┘SAVE ALL<┘
