Okina SHD4-7540DN-BP Quick start guide

SHD4-7540DN-B(W)_SSD4-7420-B(W) _rev03112008
Operational Manual
Day & Night Color Camera
1/3" Sony Super HAD CCD
540 TV Lines, HQ1 DSP SHD4-7540DN-B(W)
420 TV Lines SSD4-7420-B(W)
3.6mm Standard Lens
0.5 Lux @ F2.0 SHD4-7540DN-B(W)
0.3 Lux @ F2.0 SSD4-7420-B(W)
Auto White Balance & Auto Gain Control
12V DC
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this
may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling
could damage the camera.
3. Requires a proper operating environment
This camera is designed for indoor use. The allowable temperature
range for operation of this camera is between -10C ~ 50C and the
allowable humidity is 85%RH maximum.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned
before lens installation or whenever the lens is changed. Cleaning
should be done by using a chamois, a very fine soft cloth, lens
tissue, or cotton tipped applicator and ethanol to carefully remove
any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range.
(Camera must meet the specifications). Camera must be connected
to a surge protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may touch
dangerous voltage points of short out parts that could result in a fire
or electric shock. Never spill any kind of liquid on the video product.
7. Servicing
Do not attempt to service this video product by yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all service to qualified
servicing personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer
service to qualified servicing personnel under the following
conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
video product.
c. If the video product has been exposed to rain or water.
d. If the video product has been dropped or the cabinet
has been damaged.
e. When the video product exhibits a distinct change in
performance.
OKINA USA Products are covered under warranty for one year
from the date of purchase. The warranty will automatically be
voided if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to
confirm any information regarding when and where the
product was purchased. We have no other way to verify the
purchase record without the serial number on the camera
sticker; therefore, it should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner
not described in this manual, the warranty will be voided
immediately. It is the customer’s responsibility to keep the
camera in good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered
with. Cutting or modifying of the cables will result in
termination of the warranty.
One (1) SHD4-7540DN-B/SHD4-7540DN-BP,
SHD4-7540DN-W/SHD4-7540DN-WP,
SSD4-7420-B/SSD4-7420-BP, or
SSD4-7420-W/SSD4-7420-WP Camera with video/power
cable
Three (3) Mounting Screws
One (1) Operational Manual
SHD4-754ODN-B(W)
SSD4-742O-B(W)
SHD4-754ODN-BP(WP)
SSD4-742O-BP
(
WP
)
FEATURES
CAUTIONS
WARRANTY
Please read the Operational Manual
before attemptin
g
to use this product.
PACKAGE CON
T
ENTS

SHD4-7540DN-B(W)_SSD4-7420-B(W) _rev03112008
DC 12V Input Polarity
Model SHD4-7540DN-B(W) SHD4-7540DN-BP(WP)
TV System NTSC PAL
Image Sensor 1/3" Sony Super HAD CCD
DSP Sony HQ 1
Number of
Total Pixel 811(H) x 508(V) 795(H) x 596(V)
Video Output 1Vp-p Composite / 75 Ohm
Resolution 540 TV Lines
Minimum
Illumination
0.5 Lux @ F2.0
Color mode automatically switches to
B/W mode under 2.0 Lux
Signal to
Noise Ratio
More than 50dB
(AGC Off)
Synchronizatio
n System Internal
Electronic
Shutter Speed
Mode
Automatic
1/60~1/100,000 sec
Automatic
1/50~1/100,000 sec
Back Light
Compensation Automatic
Auto Gain
Control Automatic
White Balance AWB
Lead Free YES
Lens 3.6mm Standard Lens
Power Supply 12V DC / 150mA
Power
Consumption 1.8W
Operation
Temperature -10˚C ~ +50˚C
Storage
Temperature -20˚C ~ +60˚C
Operation
Humidity Maximum 85%RH
Dimension 112mm(D) x 70mm(H)
Weight 220g
Model SSD4-7420-B(W) SSD4-7420-BP(WP)
TV System NTSC PAL
Image Sensor 1/3" Sony Super HAD CCD
DSP Sony
Number of
Total Pixel 537(H) x 505(V) 537(H) x 597(V)
Video Output 1Vp-p Composite / 75 Ohm
Resolution 420 TV Lines
Minimum
Illumination 0.3 Lux @ F2.0
Signal to
Noise Ratio
More than 48dB
(AGC Off)
Synchronizatio
n System Internal
Electronic
Shutter Speed
Mode
Automatic
1/60~1/100,000 sec
Automatic
1/50~1/100,000 sec
Back Light
Compensation Automatic
Auto Gain
Control Automatic
White Balance ATW
Lead Free N/A
Lens 3.6mm Standard Lens
Power Supply 12V DC / 120mA
Power
Consumption 1.5W
Operation
Temperature -10˚C ~ +50˚C
Storage
Temperature -20˚C ~ +60˚C
Operation
Humidity Maximum 85%RH
Dimension 112mm(D) x 70mm(H)
Weight 220g
SPECIFICATIONS
DIMENSIONS (Unit: mm)
