OLIGHT SR51 User manual

SR 92说明书
铜版纸
单色，过光油
1/1
TM
TM
SR51 Intimidator
SR51 Intimidator World-class CREE XM-L U2 LEDs, output up to 900 lumens
max(OTF).
700 meters long throw, smooth light spot
The highest efficient synchronous buck circuit enable
power save, Max. 11 hours continual runtime
One key for control operation
Rugged indestructible aluminum body with anti-scratching
type-III hard anodization. Engineered anti-slip knurling for
tightly firm grip
Firm stainless steel bezel
Water proof IPX-8
MIL-SPEC.: MIL-STD-810F
Memory function ( Exclude strobe mode)
Lock function and unlock function
As to those exceed 24 months of the purchase date, Olight will
still provide with warranty service. Labor is free but cost of
parts will be charged. This warranty covers parts and labor
only as specified above. Freight and transit costs are the
responsibility of the user/owner; not the factory or dealer.
TM
Olight warrants its products to be free from defects in
materials and workmanship. Within 30 days of receipt,
any defective lights will be offered repair or replacement
TM
by the retailer where the product was purchased. Olight will
repair or replace, at its option and without charge, any product
or part which is found to be defective under normal use and
service within 24 months counting from the date of purchasing
with proof of purchase, Such repair or replacement shall be the
purchaser’s sole and exclusive remedy under this warranty,
This warranty does not cover normal maintenance and service
and does not apply to any products or parts which have been
subject to modification, misuse, negligence, accident,
TM
improper maintenance or repair by anyone other than Olight .
There is no other express warranty. Olight hereby disclaims any
and all implied warranties, including but not limited to fitness for
a particular purpose.
Olight shall not be liable for incidental, consequential,
or special damages arising out of, or connection with, product
use or performance.
Olight Technology Co., Limited
www.olightworld.com
Tel: [phone]
Fax: [phone]
Email: [e-mail]
SR51 is one member of high power LED flashlights series
made by Olight, it mounts latest in CREE XM-L U2 LED and
drives LED to maximum capability, output luminous flux up
to 900 lumens maximum, orange peer reflector enables
smooth and wide light spot.
Suitable for outdoor adventure, hunting, searching and
rescuing.
Introduction
Specification
LED
Reflectors: Orange peel surface, aluminum alloy
Battery: 6xCR123A/RCR123 or 2x18650 ( Use matched
battery carrier for different battery type)
Operate Voltage: 4.5~8.4V
Output Luminous Flux/Runtimes:
--- : 900 lumens /110 minutes
---Low Level: 250 lumens /10 hours
---Strobe: 10Hz (frequency)
Dimension: Head: D63mm(2.48in) Body: D43.8mm(1.85in )
Length: 190mm(7.48in)
Material: Aluminum alloy body with type-III hard anodization
Weight: 400g
Color: Black
Accessories: Lanyard x 1, Diffuser x 1, O-ring x 2, 18650
battery carrier x1(optional)
: CREE XM-L U2 COOL WHITE
High Level
Features
Warranty
Warranty Limitation
1. Power on/off the light
To power on the light, click power switch.
To shut off the output, click power switch.
2. Switch output mode
Under on state, press and hold power switch, the output
switches between high level and low level, choose expected
level then release the switch.
To enter into strobe mode, double click power switch under
on state.
Under strode mode, click power switch will shut off the
output, but press and hold power switch will enter into either
high level or low level.
3. Lock and unlock
To lock the light, under on sate, press and hold power switch
until the output shut off automatically. Under lock state,
press the power switch will not power on the light. Usually
we use lock function when we make transportation with
batteries.
To unlock the light, quickly click the power switch 3 times
within 1 second.
HOT SURFA CE
Battery Installation
After you unfold the package, unscrew the tail and fetch out
the battery carrier, then install batteries as above 1 (Please
install the batteries toward right polarity) and insert the
installed battery carrier into the body, then screw the tail.
When you don't need to use the flashlights for long time,
please fetch out the battery carrier and uninstall batteries as
above 2 and 3(push the batteries upwards along the battery
slot then fetch them out).
power switch
tail-cap
stainless steel bezel
Operation Introduction
www.DrMemory.com/OLight
