LPC-P11C24
CORTEX-M0 Development board
USER’S M NU L
Revision C, March 2013
Designed by OLIMEX Ltd, 2012
All boards produced by Olimex LTD are ROHS compliant
2 / 27
2 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
DISCL IMER
© 013 Olimex Ltd. Olimex®, logo and combinations thereof, are registered trademarks of Olimex Ltd.
Other product names may be trademarks of others and the rights belong to their respective owners.
The information in this document is provided in connection with Olimex products. No license, express
or implied or otherwise, to any intellectual property right is granted by this document or in connection
with the sale of Olimex products.
It is possible that the pictures in this manual differ from the latest revision of the board.
The product described in this document is subject to continuous development and improvements. All
particulars of the product and its use contained in this document are given by OLIMEX in good faith.
However all warranties implied or expressed including but not limited to implied warranties of
merchantability or fitness for purpose are excluded. This document is intended only to assist the reader in the
use of the product. OLIMEX Ltd. shall not be liable for any loss or damage arising from the use of any
information in this document or any error or omission in such information or any incorrect use of the
product.
This evaluation board/kit is intended for use for engineering development, demonstration, or evaluation
purposes only and is not considered by OLIMEX to be a finished end-product fit for general consumer use.
Persons handling the product must have electronics training and observe good engineering practice
standards. As such, the goods being provided are not intended to be complete in terms of required design-,
marketing-, and/or manufacturing-related protective considerations, including product safety and
environmental measures typically found in end products that incorporate such semiconductor components or
circuit boards.
Olimex currently deals with a variety of customers for products, and therefore our arrangement with the user
is not exclusive. Olimex assumes no liability for applications assistance, customer product design, software
performance, or infringement of patents or services described herein.
THERE IS NO W RR NTY FOR THE DESIGN M TERI LS ND THE
COMPONENTS USED TO CRE TE LPC-P11C24. THEY RE CONSIDERED
SUIT BLE ONLY FOR LPC-11C24.
Page of 6
3 / 27
3 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
Table of Contents
DISCL IMER ...............................................................................................................
CH PTER 1: OVERVIEW ..........................................................................................
1. Introduction to the chapter .........................................................................................................
1.1 Features .......................................................................................................................................
1.2 Target market and purpose of the board .................................................................................
1.3 Organization ...............................................................................................................................
CH PTER 2: SETTING UP THE LPC-P11C24 BO RD ........................................
2. Introduction to the chapter .........................................................................................................
2.1 Electrostatic warning .................................................................................................................
2.2 Requirements .............................................................................................................................
2.3 Powering the board ....................................................................................................................
2.4 Prebuilt software and bootloader .............................................................................................
CH PTER 3: LPC-P11C24 BO RD DESCRIPTION ..............................................
3. Introduction to the chapter .........................................................................................................
3.1 Layout (top view) .......................................................................................................................
CH PTER 4: THE LPC11C24 MICROCONTROLLER .........................................
4. Introduction to the chapter .........................................................................................................
4.1 The microcontroller ...................................................................................................................
CH PTER 5: CONTROL CIRCUITY .......................................................................
5. Introduction to the chapter .........................................................................................................
5.1 Reset ............................................................................................................................................
5.2 Clocks ..........................................................................................................................................
5.3 Power supply circuit ..................................................................................................................
CH PTER 6: CONNECTORS ND PINOUT ..........................................................
6. Introduction to the chapter .........................................................................................................
6.1 SWD debug connector ...............................................................................................................
6.2 UEXT connector .........................................................................................................................
6.3 Proto area pads ..........................................................................................................................
6.4 RS232 ..........................................................................................................................................
6.5 PWR Jack ...................................................................................................................................
6.8 C N interface .............................................................................................................................
6.12 Jumper description ..................................................................................................................
6.12.1 PIO1_LOW ............................................................................................................................
6.12.2 PIO3_LOW ............................................................................................................................
6.12.3 PIO1_RS and RST_E ...........................................................................................................
6.12.4 SILENT/NORM L ..............................................................................................................
6.12.5 5V_DIS ...................................................................................................................................
Page 3 of 6
4 / 27
4 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
6.12.6 C N_T ...................................................................................................................................
6.13 dditional hardware components ..........................................................................................
CH PTER 7: BLOCK DI GR M ND MEMORY ...............................................
7. Introduction to the chapter .........................................................................................................
7.2 Processor block diagram ...........................................................................................................
7.3 Physical memory map ...............................................................................................................
CH PTER 8: SCHEM TICS ......................................................................................
8. Introduction to the chapter .........................................................................................................
8.1 Eagle schematic ..........................................................................................................................
8.2 Physical dimensions ...................................................................................................................
CH PTER 9: REVISION HISTORY ND SUPPORT ............................................
9. Introduction to the chapter .........................................................................................................
9.1 Document revision .....................................................................................................................
9.2 Board revision ............................................................................................................................
9.3 Useful web links and purchase codes .......................................................................................
9.3 Product support .........................................................................................................................
Page 4 of 6
5 / 27
5 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
CH PTER 1: OVERVIEW
1. Introduction to the chapter
Thank you for choosing the LPC-P11C 4 development board from Olimex! This document
provides a user’s guide for the Olimex LPC-P11C 4 board. As an overview, this chapter gives the
scope of this document and lists the board’s features. The document’s organization is then detailed.
The LPC-P11C 4 development board enables code development of applications running on the
microcontroller LPC11C 4, manufactured by NXP Semiconductors.
1.1 Features
MCU: LPC11C 4 Cortex-M0, up to 50 Mhz, 3 kB Flash, 8kB SRAM, CAN,UART RS-
485, two SSP, I C/Fast+, ADC
Power supply circuit
Power-on led
CAN interface
RS 3 interface
Debug interface – SWD (Serial Wire Debug)
UEXT connector
Two user leds
Two user buttons
Reset button
Prototype area
Variable input voltage
FR-4, 1.5 mm, soldermask, component print
Dimensions: 9 x7 mm (3.6 x .8")
1.2 Target market and purpose of the board
The LPC-P11C 4 is a development board with prototyping area. It is suitable for hobbyists in the
fields of ARM development.
The strong points of the board are the CAN interface, the built-in bootloader, the proto area and the
low price.
The software for the boards is released under General Purpose License.
Page 5 of 6
6 / 27
6 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
1.3 Organization
Each section in this document covers a separate topic, organized as follows:
–Chapter 1 is an overview of the board usage and features
–Chapter provides a guide for quickly setting up the board and software notes
–Chapter 3 contains the general board diagram and layout
–Chapter 4 describes the component that is the heart of the board: the LPC11C14
microcontroller
–Chapter 5 is an explanation of the control circuitry associated with the microcontroller to
reset. Also shows the clocks on the board
–Chapter 6 covers the connector pinout, peripherals and jumper description
–Chapter 7 shows the memory map
–Chapter 8 provides the schematics
–Chapter 9 contains the revision history, useful links and support information
Page 6 of 6
7 / 27
7 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
CH PTER 2: SETTING UP THE LPC-P11C24 BO RD
2. Introduction to the chapter
This section helps you set up the LPC-P11C 4 development board for the first time. Please consider
first the electrostatic warning to avoid damaging the board, then discover the hardware and software
required to operate the board.
The procedure to power up the board is given, and a description of the default board behavior is
detailed.
2.1 Electrostatic warning
LPC-P11C 4 is shipped in a protective anti-static package. The board must not be exposed to high
electrostatic potentials. A grounding strap or similar protective device should be worn when
handling the board. Avoid touching the component pins or any other metallic element.
2.2 Requirements
In order to set up the LPC-P11C 4 optimally, the following items are required:
- 7V to 9V source of power with 1A maximum amperage.
- Personal Computer with RS 3 port
- RS 3 -RS 3 cable
- TRACE/SWD interface programmer for custom code
Code can be loaded via the RS 3 -RS 3 interface and the bootloader, however it is highly
recommended to have a SWD/TRACE programmer at your disposal.
Note that OpenOCD OLIMEX programmers + SWD adapter at the moment of writing are
supported only in Rowleys Crossworks for ARM.
Page 7 of 6
8 / 27
8 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
2.3 Powering the board
The board is powered via the PWR jack by 7 to 9 volts (preferably closer to the upper limit if you
use all peripherals and GPIOs).
When powered by 9V the current measured is around 40mA. The red, green and yellow leds (PWR
LED, LED1 and LED ) turn on.
2.4 Prebuilt software and bootloader
The prebuilt software is a bootloader and a simple LEDs and buttons test. When you power the
board initially all LEDs will be on. If you press and hold the B1 button LED should start blinking.
If you press and hold WAKE_UP button LED1 should start blinking. Upon releasing the buttons the
LEDs should return to their initial “always on” state.
In order to connect with the bootloader you should close PIO1_RS and RST_E jumpers. You will
also need RS 3 cable and RS 3 computer port. After that you can use NXP's FlashMagic
software to check if the board is connected successfully. You can also load binary files via the
RS 3 using the FlashMagic.
Page 8 of 6
9 / 27
9 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
CH PTER 3: LPC-P11C24 BO RD DESCRIPTION
3. Introduction to the chapter
Here you get acquainted with the main parts of the board. Note the names used on the board might
differ from the names used below to describe them. For the actual names check the LPC-P11C 4
board itself.
3.1 Layout (top view)
Page 9 of 6
10 / 27
10 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
CH PTER 4: THE LPC11C24 MICROCONTROLLER
4. Introduction to the chapter
In this chapter is located the information about the heart of LPC-P11C 4 – its microcontroller. The
information is a modified version of the datasheet provided by its manufacturers.
4.1 The microcontroller
System:
✔ARM Cortex-M0 processor, running at frequencies of up to 50 MHz.
✔ARM Cortex-M0 built-in Nested Vectored Interrupt Controller (NVIC).
✔Serial Wire Debug.
✔System tick timer.
Memory:
✔3 kB on-chip flash program memory.
✔8 kB SRAM data memory.
✔In-System Programming (ISP) and In-Application Programming (IAP) via on-chip
bootloader software.Flash ISP commands can be issued via UART or C_CAN.
Digital peripherals:
✔General Purpose I/O (GPIO) pins with configurable pull-up/pull-down resistors.
✔36 GPIO pins on the LPC11C 4 parts.
✔GPIO pins can be used as edge and level sensitive interrupt sources.
✔High-current output driver ( 0 mA) on one pin.
✔High-current sink drivers ( 0 mA) on two I C-bus pins in Fast-mode Plus.
Four general purpose counter/timers with a total of four capture inputs 1 match outputs.
Programmable WatchDog Timer (WDT).
✔Analog peripherals:
✔10-bit ADC with input multiplexing among 8 pins.
Serial interfaces:
✔UART with fractional baud rate generation, internal FIFO, and RS-485 support.
✔Two SPI controllers with SSP features and with FIFO and multi-protocol capabilities.
✔I C-bus interface supporting full I C-bus specification and Fast-mode Plus with a data
rate of 1 Mbit/s with multiple address recognition and monitor mode.
✔C_CAN controller. On-chip C_CAN and CANopen drivers included.
✔On-chip, high-speed CAN transceiver.
Clock generation:
Page 10 of 6
11 / 27
11 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
✔1 MHz internal RC oscillator trimmed to 1 % accuracy that can optionally be used as a
system clock.
✔Crystal oscillator with an operating range of 1 MHz to 5 MHz.
✔Programmable watchdog oscillator with a frequency range of 7.8 kHz to 1.8 MHz.
✔PLL allows CPU operation up to the maximum CPU rate without the need for a high-
frequency crystal. May be run from the system oscillator or the internal RC oscillator.
✔Clock output function with divider that can reflect the system oscillator, IRC, CPU
clock, or the Watchdog clock.
Power control:
✔Integrated PMU (Power Management Unit) to minimize power consumption during Sleep,
Deep-sleep, and Deep power-down modes.
✔Three reduced power modes: Sleep, Deep-sleep, and Deep power-down.
✔Processor wake-up from Deep-sleep mode via a dedicated start logic using 13 of the GPIO
pins.
✔Power-On Reset (POR).
✔Brownout detect with four separate thresholds for interrupt and forced reset.
Unique device serial number for identification.
Single 3.3 V power supply (1.8 V to 3.6 V).
Available as 48-pin LQFP package.
For comprehensive information on the microcontroller visit the Freescale’s web page for a
datasheet.
At the moment of writing the microcontroller datasheet can be found at the following link:
http://www.nxp.com/documents/data_sheet/LPC11CX _CX4.pdf
Page 11 of 6
12 / 27
12 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
CH PTER 5: CONTROL CIRCUITY
5. Introduction to the chapter
Here you can find information about reset circuit and quartz crystals locations, the power supply
circuit is discussed.
5.1 Reset
LPC-P11C 4's reset circuit includes R49 (33Ω), R48 (10kΩ), and a RESET button.
5.2 Clocks
1 MHz quartz crystal Q1 is connected to pins 6 and 7 of the LPC11C 4 processor.
5.3 Power supply circuit
The power supply circuit of LPC-P11C 4 allows flexible input supply from 7V to 9V. This means a
wider range of power supplies, adapters, converters are applicable. The maximum amperage
recommended is 1A by default.
After initial power-up the board consumes 40mA @ 9V.
Page 1 of 6
13 / 27
13 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
CH PTER 6: CONNECTORS ND PINOUT
6. Introduction to the chapter
In this chapter are presented the connectors that can be found on the board all together with their
pinout and notes about them. Jumpers functions are described. Notes and info on specific
peripherals are presented. Notes regarding the interfaces are given.
6.1 SWD debug connector
The TRACE interface is used to program and debug the board.
JTAG/SWD interface
Pin # Signal Name Pin # Signal Name
1+3.3V 11 GND
2+3.3V 12 GND
3Not connected 13 Not connected
4GND 14 GND
5Not connected 15 RST
6GND 16 GND
7SWD 17 GND
8GND 18 GND
SWCLK 1 +5V_JTAG
10 GND 20 GND
Notice the orientation of the cut on the connector in the picture above.
Page 13 of 6
14 / 27
14 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
6.2 UEXT connector
LPC-P11C 4 board has a UEXT connector and can interface Olimex's UEXT expansion modules.
For more information on UEXT please visit:
https://www.olimex.com/Products/Modules/UEXT/
UEXT connector
Pin # Signal Name
1+3.3V
2GND
3TXD
4RXD
5SCL
6SDA
7MISO1
8MOSI1
SCK1
10 SSEL1
Notice the orientation of the cut on the connector in the picture above.
6.3 Proto area pads
The proto area allows easier and safer analyzing of signals on the board and also provides easier
access to free processor pins. In the table below the pads are listed with their corresponding
processor pins. When a name of signal is available and written before the processor pin this means
the pad is used for the peripheral of the board and provides debug interface. If you wish to use such
a pad as GPIO probably you would have to disable some of peripherals on the board.
The pad names are written on the board and the names are above the corresponding pads.
Page 14 of 6
15 / 27
15 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
GPIO connector hardware
Pad
name [Name], Processor pin# Pad name [Name], Processor pin#
0_0 RST, 3 0_1 IS _E, 3
0_2 10 0_3 IO0_3, 14
0_4 SCL, 15 0_5 SDA, 16
0_6 23 0_7 B1, 24
0_8 27 0_9 28
0_10 SWCLK, 29 0_11 32
1_0 33 1_1 34
1_2 35 1_3 SWD, 39
1_4 40 1_5 WAKE_U , 45
Name Processor pin# Name Processor pin#
1_6 RXD, 46 1_7 TXD, 47
1_8 9 1_10 LED2, 30
1_11 LED1, 42 2_0 SSEL1, 2
2_1 SCK1, 13 2_2 MISO1, 26
2_3 MOSI1, 38 2_6 1
2_7 11 2_8 12
2_10 25 2_11 31
3_0 36 3_1 37
3_2 43 3_3 CAN_MODE, 48
VIN_1 EXTERNAL SU LY, CAUTION GND30 GND
There are also 3.3V row of pads on the top of the proto area, +5V row of pads under the 3.3V one.
At the bottom of the proto area there is GND row of pads.
Page 15 of 6
16 / 27
16 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
6.4 RS232
RS 3 's RXD and TXD can be found on the UEXT, on the processor's pins 46 and 47 and on the
proto area P1_6 and P1_7.
Pin # Signal Name
1Not Connected
2T OUT
3R1IN
4RST
5GND
6Not Connected
7R IN
8Not Connected
9Not Connected
6.5 PWR Jack
The power jack used is the typical .5mm one used by Olimex in most of our products. You should
provide between 7 and 9 volts @ 1A to the board.
in # Signal Name
1ower Input
2GND
More info about the power supply can be found in chapter 5 of this manual
Page 16 of 6
17 / 27
17 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
6.8 C N interface
There is a CAN connector for controller area network.
CAN
in# SIGNAL NAME rocessor in#
1GND -
2CANL (low) 18
3CANH (high) 19
6.12 Jumper description
Please note that the jumpers on the board are either PTH or SMD type. For setting the SMD
jumpers please consider that if you feel insecure of your soldering/cutting technique it is better not
to try to adjust those jumpers.
6.12.1 PIO1_LOW
When open starts user program after reset.
If closed starts the internal bootloader after reset.
The default position is open.
6.12.2 PIO3_LOW
When open PIO3 is high – UART bootloader is selected.
If closed PIO3 is low – CAN bootloader is selected.
The default position is open.
6.12.3 PIO1_RS and RST_E
When both open open UART RTS doesn't control PIO1 and UART DTR doesn't control reset.
When both closed UART RTS controls PIO1 (if PIO1_LOW is opened), UART_DTR controls
RESET.
The default position for both jumpers is open.
Page 17 of 6
18 / 27
18 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
6.12.4 SILENT/NORM L
Silent/Normal jumper alternatively switches the CAN operation mode. Either Silent T or Normal T,
you need CAN enabled.
The default position is jumper open.
6.12.5 5V_DIS
When open VR (5V) is enabled.
If closed disables VR (5V).
The default position is open.
6.12.6 C N_T
When closed CAN terminator ( x6 Ohm) is connected.
When open CAN terminator ( x6 Ohm) is disconnected.
The default position is closed.
6.13 dditional hardware components
The components below are mounted on LPC-P11C 4 but are not discussed above. They are listed
here for completeness:
Reset button - used for hardware reset of the board
B1 and W KE_UP - buttons
LED1 (Green) + LED2 (Yelow) + Power LED (Red)
Page 18 of 6
19 / 27
19 / 27
Distributor of Olimex LTD: Excellent Integrated System Limited
Datasheet of LPC-P11C24 - DEV BOARD FOR LPC11C24 CORTEX M0
OLIMEX© 01 LPC-P11C 4 user's manual
CH PTER 7: BLOCK DI GR M ND MEMORY
7. Introduction to the chapter
On the next page you can find a memory map for this family of processors. It is strongly
recommended to refer to the original datasheet released by NXP for one of higher quality.
7.2 Processor block diagram
The block diagram is taken from the original datasheet of LPC11Cx /Cx4.
Page 19 of 6
20 / 27
20 / 27
Table of contents
Other OLIMEX Motherboard manuals
OLIMEX
OLIMEX LPC-P11C24 User manual
OLIMEX
OLIMEX A13-OLinuXino-MICRO User manual
OLIMEX
OLIMEX OLIMEXINO-32U4 User manual
OLIMEX
OLIMEX IMX233-OLX-NANO User manual
OLIMEX
OLIMEX MOD-RTC User manual
OLIMEX
OLIMEX A20-OLINUXINO-LIME User manual
OLIMEX
OLIMEX MOD-WiFi User manual
OLIMEX
OLIMEX MSP430-CCRF User manual
OLIMEX
OLIMEX MOD-MAG User manual
OLIMEX
OLIMEX OLIMEXINO-STM32 User manual
OLIMEX
OLIMEX TMS320-XDS100-V3 User manual
OLIMEX
OLIMEX OLIMEXINO-5510 User manual
OLIMEX
OLIMEX MOD-VGA User manual
OLIMEX
OLIMEX STM32-P107 User manual
OLIMEX
OLIMEX STM32-P207 User manual
OLIMEX
OLIMEX PIC-MICRO-WEB User manual
OLIMEX
OLIMEX AVR-ISP500-ISO User manual
OLIMEX
OLIMEX AVR-ISP500-TINY User manual
OLIMEX
OLIMEX MOD-MP3-X User manual
OLIMEX
OLIMEX PIC32-HMZ144 User manual
