OLIMEX MOD-VGA User manual

MOD-VGA and MOD-VGA-32
USER’S MANUAL
Revision A, October 2012
Designed by OLIMEX Ltd, 2012
All boards produced by Olimex LTD are ROHS compliant

OLIMEX© 01 MOD-VGA User's Manual
DISCLAIMER
© 01 Olimex Ltd. Olimex®, logo and combinations thereof, are registered trademarks of Olimex Ltd.
Other product names may be trademarks of others and the rights belong to their respective owners.
The inform tion in this document is provided in connection with Olimex products. No license, express
or implied or otherwise, to ny intellectu l property right is gr nted by this document or in connection
with the s le of Olimex products.
The Hardware project is released under the Creative Commons Attribution-Share Alike 3.0 United States
License. You may reproduce it for both your own personal use, and for commertial use. You will have to
provide a link to the original creator of the project http://www.olimex.com on any documentation or website.
You may also modify the files, but you must then release them as well under the same terms. Credit can be
attributed through a link to the creator website: http://www.olimex.com
The software is released under GPL.
It is possible that the pictures in this manual differ from the latest revision of the board.
The product described in this document is subject to continuous development and improvements. All
particulars of the product and its use contained in this document are given by OLIMEX in good faith.
However all warranties implied or expressed including but not limited to implied warranties of
merchantability or fitness for purpose are excluded. This document is intended only to assist the reader in the
use of the product. OLIMEX Ltd. shall not be liable for any loss or damage arising from the use of any
information in this document or any error or omission in such information or any incorrect use of the
product.
This evaluation board/kit is intended for use for engineering development, demonstration, or evaluation
purposes only and is not considered by OLIMEX to be a finished end-product fit for general consumer use.
Persons handling the product must have electronics training and observe good engineering practice
standards. As such, the goods being provided are not intended to be complete in terms of required design-,
marketing-, and/or manufacturing-related protective considerations, including product safety and
environmental measures typically found in end products that incorporate such semiconductor components or
circuit boards.
Olimex currently deals with a variety of customers for products, and therefore our arrangement with the user
is not exclusive. Olimex assumes no liability for applications assistance, customer product design, software
performance, or infringement of patents or services described herein.
THERE IS NO WARRANTY FOR THE DESIGN MATERIALS AND THE
COMPONENTS USED TO CREATE MOD-VGA. THEY ARE CONSIDERED
SUITABLE ONLY FOR MOD-VGA.
Page of 3

OLIMEX© 01 MOD-VGA User's Manual
Table of Contents
DISCLAIMER ............................................................................................................. 2
CHAPTER 1: OVERVIEW ........................................................................................ 5
1. Introduction to the ch pter ....................................................................................................... 5
1.1 Fe tures ..................................................................................................................................... 5
1.2 T rget m rket nd purpose of the bo rd .............................................................................. 6
1.3 Org niz tion ............................................................................................................................. 6
CHAPTER 2: SETTING UP THE MOD-VGA BOARD .........................................
2. Introduction to the ch pter ....................................................................................................... 7
2.1 Electrost tic w rning ............................................................................................................... 7
2.3 Requirements ........................................................................................................................... 7
2.4 Powering the bo rd .................................................................................................................. 8
2.5 Running n ex mple using Olimex OLIMEXINO-328 ........................................................ 8
CHAPTER 3: MOD-VGA BOARD DESCRIPTION .............................................. 9
3. Introduction to the ch pter ....................................................................................................... 9
3.1 L yout (top view) ..................................................................................................................... 9
3.2 L yout (bottom view) ............................................................................................................. 10
CHAPTER 4: The XILINX SPARTAN-3 XC3S200 FPGA .................................. 11
4. Introduction to the ch pter ..................................................................................................... 11
4.1 The XILINX SPARTAN-3 XC3S200 FPGA ....................................................................... 11
CHAPTER 6: CONNECTORS, HARDWARE, PINOUTS ................................... 13
6. Introduction to the ch pter ..................................................................................................... 13
6.1 FPGA progr mming options ................................................................................................ 13
6.1.1 SPI_PGM pinholes .............................................................................................................. 13
6.1.2 JTAG pinholes ..................................................................................................................... 13
6.2 UEXT connector .................................................................................................................... 14
6.3 Audio connector ..................................................................................................................... 15
6.4 VGA video connector ............................................................................................................. 15
6.5 Arduino shield connector ...................................................................................................... 16
6.6 Keybo rd connector .............................................................................................................. 17
6.7 Jumper description ................................................................................................................ 17
6.7.1 5V/3V .................................................................................................................................... 17
6.7.2 SJ1 ........................................................................................................................................ 17
CHAPTER 8: SCHEMATICS .................................................................................. 18
8. Introduction to the ch pter ..................................................................................................... 18
8.1 E gle schem tic ...................................................................................................................... 18
8.2 Physic l dimensions ............................................................................................................... 20
Page 3 of 3

OLIMEX© 01 MOD-VGA User's Manual
CHAPTER 9: REVISION HISTORY AND SUPPORT ........................................ 21
9. Introduction to the ch pter ..................................................................................................... 21
9.1 Document revision ................................................................................................................. 21
9.2 Bo rd revision ........................................................................................................................ 21
9.3 Useful web links nd purch se codes ................................................................................... 22
9.3 Product support ..................................................................................................................... 23
Page 4 of 3

OLIMEX© 01 MOD-VGA User's Manual
CHAPTER 1: OVERVIEW
1. Introduction to the chapter
Thank you for choosing the MOD-VGA video shield from Olimex! This document provides a
user’s guide for the Olimex MOD-VGA. As an overview, this chapter gives the scope of this
document and lists the board’s features. The document’s organization is then detailed.
The MOD-VGA development board enables code development of applications running on the
FPGA from the SPARTAN-3 family, manufactured by XLINIX.
MOD-VGA is an open-source, open-hardware project and all documentation is available to the
customer. It is tested and working with OLIMEX AVR boards.
1.1 Features
Gameduino is a game adapter for the Arduino - or anything else with an SPI interface - built as a
single shield that stacks up on top of the Arduino and has plugs for a VGA monitor and stereo
speakers. The board is based on the open-source, open-hardware GAMEDUINO project by
excamera. For more information on the original project please visit
http://excamera.com/sphinx/gameduino/.
Video output is 400x300 pixels in 51 colors
•all color processed internally at 15-bit precision
•compatible with any standard VGA monitor (800x600 @ 7 Hz)
•background graphics
•51 x51 pixel character background
•56 characters, each with independent 4 color palette
•pixel-smooth X-Y wraparound scroll
•foreground graphics
•each sprite is 16x16 pixels with per-pixel transparency
•each sprite can use 56, 16 or 4 colors
•four-way rotate and flip
•96 sprites per scan-line, 1536 texels per line
•pixel-perfect sprite collision detection
Audio output is a stereo 1 -bit frequency synthesizer
Page 5 of 3

OLIMEX© 01 MOD-VGA User's Manual
•64 independent voices 10-8000 Hz
•per-voice sine wave or white noise
•sample playback channel
1.2 Target market and purpose of the board
The board follows the Arduino shield connector platform and can be mounted on Arduino boards. It
works out-of-the-box with Arduino IDE (after importing the library and the examples provided on
our web-site in Arduino).
The board is tested and working with our OLIMEXINO-3 8:
https://www.olimex.com/dev/olimexino-3 8.html.
The board has hardware compatibility with Maple boards, Duinomite boards, and basically every
board that follows the Arduino shield connector platform. However, the software support for all
boards except for the Arduino-compatible AVR ones is not still implemented and might require
extended software knowledge to be implemented.
Customers have full access to the technical documentation of the board. The software is released
under General Purpose License and the board is considered open-hardware.
1.3 Organization
Each section in this document covers a separate topic, organized as follow:
–Chapter 1 is an overview of the board usage and features
–Chapter provides a guide for quickly setting up the board and software notes
–Chapter 3 contains the general board diagram and layout
–Chapter 4 describes the component that is the heart of the board: the XILINX Spartan-3
FPGA
–Chapter 5 is an explanation of the control circuitry associated with the microcontroller to
reset. Also shows the clocks on the board
–Chapter 6 covers the connector pinout, peripherals and jumper description
–Chapter 7 shows the memory map
–Chapter 8 provides the schematics
–Chapter 9 contains the revision history, useful links and support information
Page 6 of 3

OLIMEX© 01 MOD-VGA User's Manual
CHAPTER 2: SETTING UP THE MOD-VGA BOARD
2. Introduction to the chapter
This section helps you set up the MOD-VGA development board for the first time. Please consider
first the electrostatic warning to avoid damaging the board, then discover the hardware and software
required to operate the board.
The procedure to power up the board is given, and a description of the default board behavior is
detailed.
2.1 Electrostatic warning
MOD-VGA is shipped in a protective anti-static package. The board must not be exposed to high
electrostatic potentials. A grounding strap or similar protective device should be worn when
handling the board. Avoid touching the component pins or any other metallic element.
2.3 Requirements
In order to set up the MOD-VGA optimally, the following items are required (separated in hardware
and software requirements).
Hardware:
- Host board with Arduino platform connectors (For example OLIMEXINO-3 8 or OLIMEXINIO-
3 U4)
- VGA monitor
- PS keyboard
- Audio output device
Software:
- Arduino-IDE
- A library that needs to be imported in Arduino-IDE and can be found at our web-site at MOD-
VGA's page
Page 7 of 3

OLIMEX© 01 MOD-VGA User's Manual
2.4 Powering the board
The board gets powered when mounted on compatible Arduino board either by 5V (default) or 3.3V
depending on position of the 5V/3V jumper.
2.5 Running an example using Olimex OLIMEXINO-328
First place properly the library for Arduino that can be found on the device's web page:
https://www.olimex.com/Products/Modules/Interface/MOD-VGA/
Then start Arduino and open the corresponding to OLIMEXINO-3 8 board configuration:
Tools -> Bo rd -> Arduino Duemil nove w\ATmeg 328
Then program for example:
Files -> Ex mples -> G meduino -> Audio -> pl yer
We should see a graphic and there should be audio.
Page 8 of 3

OLIMEX© 01 MOD-VGA User's Manual
CHAPTER 3: MOD-VGA BOARD DESCRIPTION
3. Introduction to the chapter
Here you get acquainted with the main parts of the board. Note the names used on the board might
differ from the names used below to describe them. For the actual names check the MOD-VGA
board itself.
3.1 Layout (top view)
Page 9 of 3

OLIMEX© 01 MOD-VGA User's Manual
3.2 Layout (bottom view)
Note the base MOD-VGA version doesn't have the additional memory present on the picture of
MOD-VGA-3 .
Page 10 of 3

OLIMEX© 01 MOD-VGA User's Manual
CHAPTER 4: The XILINX SPARTAN-3 XC3S200 FPGA
4. Introduction to the chapter
In this chapter is located the information about the heart of MOD-VGA – its controller. The
information is a modified version of the datasheet provided by its manufacturers.
4.1 The XILINX SPARTAN-3 XC3S200 FPGA
Low-cost, high-performance logic solution for high-volume, consumer-oriented applications
✔43 0 logic cells
SelectIO™ interface signaling
✔173 I/O pins
✔6 + Mb/s data transfer rate per I/O
✔18 single-ended signal standards
✔8 differential I/O standards including LVDS, RSDS
✔Termination by Digitally Controlled Impedance
✔Signal swing ranging from 1.14V to 3.465V
✔Double Data Rate (DDR) support
✔DDR, DDR SDRAM support up to 333 Mbps
Logic resources
✔Abundant logic cells with shift register capability
✔Wide, fast multiplexers
✔Fast look-ahead carry logic
✔Dedicated 18 x 18 multipliers
✔JTAG logic compatible with IEEE 1149.1/153
SelectRAM™ hierarchical memory
✔16 Kbits of total block RAM
✔30 Kbits of total distributed RAM
Digital Clock Manager (up to four DCMs)
✔Clock skew elimination
✔Frequency synthesis
✔High resolution phase shifting
Eight global clock lines and abundant routing
✔Fully supported by Xilinx ISE® and WebPACK™ software development systems
Page 11 of 3

OLIMEX© 01 MOD-VGA User's Manual
✔MicroBlaze™ and PicoBlaze™ processor, PCI®, PCIExpress® PIPE Endpoint, and
other IP cores
✔Pb-free packaging options
✔Automotive Spartan-3 XA Family variant
For comprehensive information on the microcontroller visit the Xilinx’s web page for a datasheet.
At the moment of writing the microcontroller datasheet can be found at the following link:
http://www.xilinx.com/support/documentation/data_sheets/ds099.pdf
Page 1 of 3

OLIMEX© 01 MOD-VGA User's Manual
CHAPTER 6: CONNECTORS, HARDWARE, PINOUTS
6. Introduction to the chapter
In this chapter are presented the connectors that can be found on the board all together with their
pinout and notes about them. Jumpers functions are described. Notes and info on specific
peripherals are presented. Notes regarding the interfaces are given.
6.1 FPGA programming options
There are couple of options provided for programming the Xlinx FPGA. Both of them are located
near the DIGITAL connector from the Arduino platform. Note that both of them lack headers. The
SPI_PGM and JTAG are discussed below.
6.1.1 SPI_PGM pinholes
The SPI_PGM interface lacks connector. You can mount for instance WU06S for easier interfacing.
SPI_PGM
PIN# SIGNAL NAME
1FLASH_SO
2FLASH_SI
3FLASH_SCK
4#FLASH_CS
5GND
6+3.3V
6.1.2 JTAG pinholes
The JTAG interface lacks connector. You can mount for instance WU06S for easier interfacing.
Page 13 of 3

OLIMEX© 01 MOD-VGA User's Manual
JTAG
PIN# SIGNAL NAME
1+3.3V
2TCK
3TDO
4TMS
5TDI
6GND
6.2 UEXT connector
Note that the signals on the UEXT connector are multiplexed with the respective header pins from
the Arduino shield connector.
Note that the SPI interface can also be found on the Arduino shield connector.
For more info on the UEXT connector please visit:
https://www.olimex.com/Products/Modules/UEXT/
UEXT connector
Pin # Signa Name Processor Pin #
1+3.3V -
2GND -
3Not Connected -
4INT 78
5Not Connected -
6INT 78
7U XT_MISO 86
8U XT_MOSI 85
9U XT_CLK 84
10 U XT_SS L 88
Page 14 of 3

OLIMEX© 01 MOD-VGA User's Manual
6.3 Audio connector
Standard audio jack and phone jack are mounted for the audio interfacing.
Headphones/Audio out connector
Pin# SIGNAL NAME Processor Pin#
1LIN _OUT_L 99
3LIN _OUT_R 98
2GND GND pins
The headphones resistance is 16 Ohms!
6.4 VGA video connector
The female DB15 connector is used for video output on a monitor.
Note that there is also a row of pinholes near the DB15 named VGA_CON – it gives access to the
used signals only. Check the tables below for pinout of both the DB15 and the VGA_CON.
VGA_CON
PIN# SIGNAL
1VGA_R
2VGA_G
3VGA_B
4H_SYNC
5V_SYNC
6+5V
7GND
8+3.3V
Page 15 of 3

OLIMEX© 01 MOD-VGA User's Manual
VGA DB15 connector
GPIO Pin# Signa Name GPIO Pin# Signa Name
1VGA_R 2VGA_G
3VGA_B 4Not Connected
5GND 6GND
7GND 8GND
9GND 10 GND
11 Not Connected 12 Not Connected
13 VGA_HSYNC 14 VGA_VSYNC
15 Not Connected 16 Not Connected
6.5 Arduino shield connector
Pad Name Signa Pad Name Signa
POW R ANALOG
RST Not connected A0 Not connected
3V3 3V3 A1 Not connected
5V 5V A2 Not connected
GND GROUND A3 Not connected
GND GROUND A4 Not connected
VIN Not connected A5 Not connected
DIGITAL #1 DIGITAL #2
D0 Not connected D8 Not connected
D1 Not connected D9 U XT_SS L
D2 INT D10 SPI_CS
D3 Not connected D11 SPI_MOSI
D4 Not connected D12 SPI_MISO
D5 Not connected D13 SPI_CLK
D6 PS2_DATA GND Not connected
D7 PS2_CLK AREF Not connected
Page 16 of 3

OLIMEX© 01 MOD-VGA User's Manual
6.6 Keyboard connector
The key board connector is a standard PS one requiring MINI-DIN cable connector.
6. Jumper description
Please note that both jumpers on the board are SMT type. If you feel insecure of your
soldering/cutting technique it is better not to try to adjust the jumpers.
6. .1 5V/3V
Those jumpers control the shield power operating mode.
The default position is 5V.
6. .2 SJ1
SJ1 jumper controls whether SPI SSEL that is lead on the UEXT is also connected to Digital D9 on
the Arduino shield connector. If the jumper is connected then the mentioned multiplexing is present.
The default position is closed.
Page 17 of 3

OLIMEX© 01 MOD-VGA User's Manual
CHAPTER 8: SCHEMATICS
8. Introduction to the chapter
In this chapter are located the schematics describing logically and physically MOD-VGA.
8.1 Eagle schematic
The EAGLE schematic is situated on the next page for quicker reference. It can also be found on
the web-page of the device. The schematic and board files are released under the Creative
Commons Attribution-Share Alike 3.0 United States License. You may reproduce it for both your
own personal use, and for commercial use. You will have to provide a link to the original creator of
the project (https://www.olimex.com) on any documentation or website.
Page 18 of 3

OLIMEX© 01 MOD-VGA User's Manual
Page 19 of 3
U3
default-5V_closed
JACK-3PINSCJ325P00XG0B02G
100n
100n
100n
100n
100n
NA 100n)
100n
100n
10uF/6.3V 47uF/6.3V 100n
100n
100n
100n
100n
100n
100n
10n 10n
10n
100n
2 2 u F/ 6 . 3 V
100n
2 2 u F /6 . 3 V
100n
25MHz
WU06S NA)
+5V
1.2V
1.2V
1.2V
1.2V
1.2V
+5V
+5V
MD6R MINI-DIN
240R
NA 47
47
3.9k
470
1k
1.8k
47
47
3.9k
3.9k
10k 10k
240R
470
1k
1.8k
240R
NA 10k)
22
470
1k
1.8k
5.1k 5.1k
NA
NA
close
WU06S NA)
2*PN1x6_8,5/11mm+2*PN1x8_8,5/11mm
NA K6R4016V1D)
XC3S200A-4VQ100C
AT45DB041D-SU
K4S561632C-TC/L75
BH10R
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
NA
LM1117IMPX-ADJ
XD[0..15]
#FLASH_CS
#FLASH_CS
#FLASH_CS
25MHZ
25MHZ
B1
B1
B2
B2
B3
B3
FLASH_SCK
FLASH_SCK
FLASH_SCK
FLASH_SI
FLASH_SI
FLASH_SI
FLASH_SO
FLASH_SO
FLASH_SO
G1
G1
G2
G2
G3
G3
HSYNC
HSYNC
INT
INT
INT
LINE_OUT_L
LINE_OUT_R
PS2_CLK
PS2_CLK
PS2_DATA
PS2_DATA
R1
R1
R2
R2
R3
R3
RAM_#CS
RAM_#CS RAM _ # CS
SPI_CLK
SPI_CLK
SPI_CS
SPI_CS
SPI_MISO
SPI_MISO
SPI_MOSI
SPI_MOSI
TCK
TCK
TDI
TDI
TDO
TDO
TMS
TMS
UEXT_CLK
UEXT_MISO
UEXT_MOSI
UEXT_SSEL
VSYNC
VSYNC
XA0
XA0
XA0 XA0
XA1
XA1
XA1 XA1
XA2
XA2
XA2 XA2
XA3
XA3
XA3 XA3
XA4
XA4
XA4 XA4
XA5
XA5
XA5 XA5
XA6
XA6
XA6 XA6
XA7 XA7
XA7
XA7
XA8
XA8
XA8 XA8
XA9
XA9
XA9 XA9
XA10
XA10
XA10 XA10
XA11
XA11
XA11 XA11
XA12
XA12
XA12 XA12
XA13
XA13
XA13 XA13
XA14
XA14
XA14
XA14
XA15/SDRA M_CLK XA15/SDRAM_CLK
XA15/SDRAM_CLK
XA15/SDRAM_CLK
XA16/#RASXA16/#RAS
XA 16/#RA S
XA16 /# RA S
XA17/#CAS
XA17/#CAS
XA 17/#CA S
XA17 /# CA S
XD0
XD0 XD0
XD0
XD1
XD1 XD1
XD1
XD2
XD2 XD2
XD2
XD3
XD3 XD3
XD3
XD4
XD4 XD4
XD4
XD5
XD5 XD5
XD5
XD6
XD6 XD6
XD6
XD7
XD7 XD7
XD7
XD8
XD8 XD8
XD8
XD9
XD9 XD9
XD9
XD10
XD10 XD10 XD10
XD11
XD11 XD11 XD11
XD12
XD12 XD12
XD12
XD13
XD13 XD13
XD13
XD14
XD14 XD14
XD14
XD15
XD15 XD15
XD15
XOE
XOE
XOE
XWE
XWE
XWE XWE
1
2
3
5V/3V
AUDIO
C1
C2
C3
C4
C5
C7
C8 C9
C10 C11 C12
C13
C14
C15
C16
C17
C18
C19 C20
C21
C22 C23 C24 C25 C26
1
3
4
2
CD
1
2
3
4
5
6
JTAG
11
22
33
44
55
66
NC1
NC2
SHIEL D
PS2_KEYBOARD
R1
R2 R3
R4
R5
R6
R7
R8
R9
R10
R11
R12
R13 R14
R15
R16
R17
R18
R19
R20
R21
R22
R23
R24
R25 R26
R27
R28
1 2
SJ1
1
2
3
4
5
6
SPI_PGM
3V3
5V
A0
A1
A2
A3
A4
A5
AREF
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
GND
GND
GND
RST
VIN
U1
BHE
40
BLE
39
CS
6
OE
41
WE
17
A0
1
A1
2
A2
3
A3
4
A4
5
A5
18
A6
19
A7
20
A8
21
A9
22
A10
23
A11
24
A12
25
A13
26
A14
27
A15
42
A16
43
A17
44
I/O0 7
I/O1 8
I/O2 9
I/O3 10
I/O4 13
I/O5 14
I/O6 15
I/O7 16
I/O8 29
I/O9 30
I/O10 31
I/O11 32
I/O12 35
I/O13 36
I/O14 37
I/O15 38
NC 28
VDD1 11
VDD2 33
VSS1 12
VSS2 34
U2
DONE 54
GND
8
GND
14
GND
18
GND
42
GND
47
GND 58
GND 63
GND 69
GND 74
GND 80
GND 87
GND 91
GND 95
IO_0/GCLK11 90
IO_2/MOSI/CSI_B
46
IO_L01N_0 78
IO_L01N_1 57
IO_L01N_2/M0
25
IO_L01N_3
4
IO_L01P_0/VREF_0 77
IO_L01P_1 56
IO_L01P_2/M1
23
IO_L01P_3
3
IO_L02N_0/GCLK5 84
IO_L02N_1/RHCLK1 60
IO_L02N_2/CSO_B
27
IO_L02N_3
6
IO_L02P_0/GCLK4 83
IO_L02P_1/RHCLK0 59
IO_L02P_2/M2
24
IO_L02P_3
5
IO_L03N_0/GCLK7 86
IO_L03N_1/TRDY1/RHCLK3 62
IO_L03N_2/VS2
29
IO_L03N_3/LHCLK1
10
IO_L03P_0/GCLK6 85
IO_L03P_1/RHCLK2 61
IO_L03P_2/RDWR_B
28
IO_L03P_3/LHCLK0
9
IO_L04N_0/GCLK9 89
IO_L04N_1/RHCLK7 65
IO_L04N_2/VS0
31
IO_L04N_3/IRDY2/LHCLK3
13 IO_L04P_0/GCLK8 88
IO_L04P_1/IRDY 1/RHCLK6 64
IO_L04P_2/VS1
30
IO_L04P_3/LHCLK2
12
IO_L05N_0 94
IO_L05N_1 71
IO_L05N_2
33
IO_L05N_3/LHCLK7
16
IO_L05P_0 93
IO_L05P_1 70
IO_L05P_2
32
IO_L05P_3/TRDY2/LHCLK6
15
IO_L06N_0/PUDC_B 99
IO_L06N_1 73
IO_L06N_2/D6
35
IO_L06N_3
20
IO_L06P_0/VREF_0 98
IO_L06P_1 72
IO_L06P_2/D7
34
IO_L06P_3
19
IO_L07N_2/D4
37 IO_L07P_2/D5
36
IO_L08N_2/GCLK15
41 IO_L08P_2/GCLK14
40
IO_L09N_2/GCLK1
44 IO_L09P_2/GCLK0
43
IO_L10N_2/D3
49 IO_L10P_2/INIT_B
48
IO_L11N_2/D1 52
IO_L11P_2/D2
50
IO_L12N_2/CCLK 53
IO_L12P_2/D0/DIN/MISO 51
IP_0 97
IP_0/VREF_0 82
IP_1/VREF_1 68
IP_2/VREF_2
39
IP_3
21
IP_3/VREF_3
7
PROG_B 100
TCK 76
TDI
2
TDO 75
TMS
1
VCCAUX
22
VCCAUX 55
VCCAUX 92
VCCINT
17
VCCINT
38
VCCINT 66
VCCINT 81
VCCO_0 79
VCCO_0 96
VCCO_1 67
VCCO_2
26
VCCO_2
45
VCCO_3
11
/CS/
4
/RESET/
3
/WP/ 5
GND 7
SCK
2
SI
1SO 8
VCC 6
U4
A0
23
A1
24
A2
25
A3
26
A4
29
A5
30
A6
31
A7
32
A8
33
A9
34
A10/AP
22
A11
35
A12
36
BA0
20
BA1
21
CAS
17
CKE
37 CLK
38
CS
19
DQ0 2
DQ1 4
DQ2 5
DQ3 7
DQ4 8
DQ5 10
DQ6 11
DQ7 13
DQ8 42
DQ9 44
DQ10 45
DQ11 47
DQ12 48
DQ13 50
DQ14 51
DQ15 53
DQMH
39 DQML
15
NC1
40
RAS
18
VDD1 1
VDD2 14
VDD3 27
VDDQ1 3
VDDQ2 9
VDDQ3 43
VDDQ4 49
VSS1 28
VSS2 41
VSS3 54
VSSQ1 6
VSSQ2 12
VSSQ3 46
VSSQ4 52
WE
16
U5
UEXT-1
UEXT-2
UEXT-3
UEXT-4
UEXT-5
UEXT-6
UEXT-7
UEXT-8
UEXT-9
UEXT-10
1
2
3
4
5
6
7
8
VGA_CON
VGA_DB15-F_1
VGA_DB15-F_2
VGA_DB15-F_3
VGA_DB15-F_4
VGA_DB15-F_5
VGA_DB15-F_6
VGA_DB15-F_7
VGA_DB15-F_8
VGA_DB15-F_9
VGA_DB15-F_10
VGA_DB15-F_11
VGA_DB15-F_12
VGA_DB15-F_13
VGA_DB15-F_14
VGA_DB15-F_15
ADJ/GND
IN OUT
MOD-VGA-32MB_Rev_B
OLIMEX LTD BULGARIA
http://www.olimex.com/dev
1-L
2
3-R
+
VDD
VSS OUT
E/D
IO
NA
GN
5V
CK
NA
POWERANAL O GDIGITALDIGITAL
ARDUINO: SH PLATFORM
KeyBoard
UEXT
VGA
SPI FLASH
AUDIOJTAG & CLOCK
SRAM
SDRAM

OLIMEX© 01 MOD-VGA User's Manual
8.2 Physical dimensions
Note that all dimensions are in mil.
The two highest elements on the board are: VGA connector – 500mil; KEYBOARD connector -
500mil
Page 0 of 3
