OLT RB63T User manual

Outdoor Living Today www.outdoorlivingtoday.com [e-mail]
Thank you for purchasing a 6’ x 3’
Raised Garden Bed Trellis/Lid Kit.
Please take the time to identify all
the parts prior to
assembly.
Please use Safety Eyewear and Gloves
while assembling. Be sure to read and
follow all operating instructions for any
tools used during assembly.
Remember- NO SAW CUTTING IS
REQUIRED!
Safety Points and Other Considerations
Please follow this instruction manual when
assembling your Raised Garden Bed and
retain the manual for future maintenance
purposes.
6’X3’ Garden in a Box
Trellis / Lid Kit
Page 1
Revision #3
March 19th, 2018
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Trellis/Lid Dimensions:
A: Width = 72"
B: Height with Lid Closed = 35”
C: Height to top of Trellis = 71”
Estimated Assembly Time for the
Lid/Trellis Option = 1/2 Hour.
A
B
C
Item# RB63T
Licensed Under U. S. PATENT No. RE44055

Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 2
Part A 2 - Trellis/Lid Panels
36” wide x 37 1/2” high
Part B 4 - Plastic Hinges
Part C 2 - Trellis/Lid Arms
3/4” t x 1 1/2” w x 26” l
Part D 1 - Rear Trellis Cleat
3/4” t x 2 1/2” w x 33” h
B
C
Exploded View and Parts List for Trellis/Lid Kit
Hardware Kit (Provided)
Safety Glasses Work Gloves
Safety Equipment Required (Not Provided)
Screw Gun/Drill Tape Measure Level
Tools Required (Not Provided)
1/8” Drill Bit
Parts List
2”
AA
D
B
x 12 pcs
3/4”
Black
x 24 pcs
Wood Clamp
Trellis/Lid Arm Spacer x 2

Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 3
1. Orientate Trellis/Lid Panels - Part A (screen down) as illustrated below on flat level ground.
Align so vertical framings are tight together. Use wood clamp to hold framings together.
2. Screw panels together with 4 - 2” Screws as shown above.
A
A
Tight together
3. Place completed Trellis/Lid on top of raised bed framing as shown above.
Rear
Important - If Raised Bed is not square and level, Trellis/Lid may not fit and align correctly.
Before positioning, measure and align bed framing as square as possible.

6. To complete Trellis/Lid installation, lift lid up and position in an upright position. You will have to
hold in this position until Trellis/Lid arms are installed so an assistant would be helpful.
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 4
Rear
5. Complete attachment of 1st hinge by screwing 3 - 3/4” Black Screws into the lid framing as shown
above. Evenly space remaining hinges and attach as described previously.
4. With Trellis/Lid evenly positioned on raised bed framing, locate 4 Black Plastic Hinges - Part B and 24
- 3/4” Black Screws. Align 1st hinge with counter sunk holes facing up. Position hinge approx. 5” from
end. Attach to top framing of 6x3 raised bed with 3 - 3/4” Black Screws per hinge. Pre-drill shallow hinge
holes first with 1/8” drill bit to prevent wood from splitting. Do not over screw with cordless screw gun!
Flush
Trellis/Lid
5”
Lid Frame

Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 5
8. At the bottom of arm, attach a 2” screw to a 1” depth in previously
marked location. Arm notch will rest on screw and prevent Trellis/Lid from
closing.
9. Complete remaining Trellis/Lid Arm (C) as per Steps 7 & 8.
16”
17”
7. To install Trellis/Lid Arms (C), measure 16” up from
bottom and 17” from the rear of panel. Pre-drill shallow
1/8” hole 3/8” from top of framing to help you position arm.
Locate Trellis/Lid Arm Spacer and position next to framing.
Screw top of arm to Trellis/Lid panel with 1 - 2” screw.
Do not overtighten.
Spacer

10. If required, locate Rear Trellis Cleat (D). Center on 6x3 Raised Bed center framing and
Trellis/Lid panel framing. Attach with 4 - 2” screws slighly offset from the center. At the end of your
gardening season, carefully remove screws from cleat and store to use again for the next year.
We hope your experience constructing our 6’x3’ Raised Garden Bed Trellis/Lid Kit has been both
positive and rewarding. We value your feedback and would like to hear back from you on how well
we are doing in the following areas:
1. Customer Service
2. On Time Shipping
3. Motor Freight Delivery
4. Quality of Materials
5. Assembly Manual
6. Overall Satisfaction.
Please call, write or email us at:
Page 6
The materials contained in this Assembly
Manual may be downloaded or copied
provided that ALL copies retain the
copyright and any other proprietary
notices contained on the materials. No
material may be modified, edited or
taken out of context such that its use
creates a false or misleading statement
or impression as to the positions,
statements or actions.
Canadian Address
9393 287th Street
Maple Ridge, British Columbia
Canada V2W 1L1
United States Address
P.O. Box 96
Sumas, Washington
USA 98295
Toll Line: 1.888.658.1658 | Fax: [phone] | [e-mail]
Note; Rear Trellis Cleat is only required when
you plan to use Trellis in the up position for an
extended period of time. Not required of you
plan on opening and closing your lid often.
