Olympus DS-5000 User manual

Thank you for purchasing an Olympus
Digital Voice Recorder.
Please read these instructions for information
about using the product correctly and safely.
Keep the instructions handy for future reference.
To ensure successful recordings, we recommend that you
test the record function and volume before use.
INSTRUCTIONS
EN
INSTRUCTIONS
FR
MODE D’EMPLOI
ES
INSTRUCCIONES
DIGITAL VOICE
RECORDER
DS-5000
DS-5000iD
EN

2
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Macintosh is a trademark of Apple Inc.
Intel and Pentium are registered trademarks of Intel Corporation.
SD and microSD are a trademark of SD card Association.
SDHC and microSDHC are a trademark of SD card Association.
Other product and brand names mentioned herein may be the trademarks or registered
trademarks of their respective owners.
●The contents of this document may be changed in the future without advanced notice.
Contact our Customer Support Center for the latest information relating to product names
and model numbers.
●The utmost care has been taken to ensure the integrity of the contents of this document. In
the unlikely event that a questionable item, error, or omission is found, please contact our
Customer Support Center.
●Any liability for passive damages or damage of any kind occurred due to data loss incurred
by a defect of the product, repair performed by the third party other than Olympus or an
Olympus authorized service station, or any other reasons is excluded from the Olympus’s
liability.
Trademarks
Introduction
Introduction

3
1
2
3
5
7
4
Table of Contents
Table of Contents ...................................... 3
Safe and Proper Usage ............................ 4
General Precautions ................................. 5
1 Getting Started
Main Features .......................................... 9
Memory Card ......................................... 10
Identification of Parts ............................. 12
Installing Batteries ................................. 14
Charging Battery Pack .......................... 16
Using the Battery Pack .......................... 18
Using the AC Adapter ............................ 19
Turning ON the Recorder ...................... 20
Power Save Mode ................................. 20
Inserting and Ejecting a SD card .......... 21
Setting Time/Date (Time & Date) .......... 22
Setting Recording Destination
(Card Select) ................................... 24
2 Basic Operations
Recording .............................................. 25
Playing ................................................... 29
Erasing ................................................... 31
3 Advanced Operations
Menu List ............................................... 35
Learning to Use the Menu ..................... 39
Selecting Folders and Files ................... 40
Displaying File Information .................... 41
Device Lock Function ............................ 42
Setting Priority Levels (Priority) ............ 45
Setting the Author ID and Work Type.... 46
Verbal Comment .................................... 49
Index Marks ........................................... 50
Inserting and Ejecting a microSD card .... 51
Formatting the Card (Format) ............... 52
Customizing the Recorder ..................... 54
4 Managing Files on Your PC
DSS Player Software ............................. 55
Installing DSS Software ........................ 57
Uninstalling DSS Software .................... 58
Using Online Help ................................. 59
Connecting Recorder to PC .................. 60
Running DSS Player ............................. 62
5 Other Information
Alarm Message List ............................... 63
Troubleshooting ..................................... 64
Accessories (Optional) .......................... 65
Specifications ........................................ 66
Technical Assistance and Support ........ 67

4
Convention Used In this Manual
•The word “card”is used to refer to the SD
card and microSD card.
•The word “DSS Player”is used to refer to
the DSS Player Pro R5 Dictation Module
in Windows environment and DSS Player
in Apple Macintosh environment.
•The Notes at the bottom of a page are
used for additional information,
exceptions, or related events.
•Words in uppercase form such as PLAY
or REC are used to describe a function,
button, or switch position on the recorder.
Safe and Proper Usage
Before using your new recorder, read this
manual carefully to ensure that you know
how to operate it safely and correctly. Keep
this manual in an easily accessible location
for future reference.
Important Safety Precautions
Certain symbols are used in the user’s
manual and on this product to help protect
users, their surroundings, and their
property from possible injury or damage.
Please familiarize yourself with the
following definitions and meanings for each
symbol before reading the precautions.
Symbols prohibiting a specific action
Prohibited Do not
disassemble
Symbols requiring a specific action
Mandatory Unplug from
power outlet
Signifies danger which
may result in serious
injury or death.
Indicates items or actions
which may cause serious
injury or death.
Indicates items or actions
which may result in
damage or personal injury.
Danger
Warning
Caution

5
General Precautions
●Do not leave the recorder in hot, humid
locations such as inside a closed
automobile under direct sunlight or on the
beach in the summer.
●Do not store the recorder in places exposed
to excessive moisture or dust.
●Do not use organic solvents such as
alcohol and lacquer thinner to clean the
unit.
●Do not place the recorder on top of or near
electric appliances such as TVs or
refrigerators.
●Avoid recording or playing back near
cellular phones or other wireless
equipment, as they may cause interference
and noise. If you experience noise, move
to another place, or move the recorder
further away from such equipment.
●Avoid sand or dirt. These can cause
irreparable damage.
●Avoid strong vibrations or shocks.
●Do not disassemble, repair or modify the
unit yourself.
●Do not operate the unit while operating a
vehicle (such as a bicycle, motorcycle, or
go-cart).
●Keep the unit out of the reach of children.
<Warning regarding data loss>
Recorded content in memory may be
destroyed or erased by operating mistakes,
unit malfunction, or during repair work.
It is recommended to back up and save
important content to other media such as a
computer hard disk.
Batteries/Rechargeable Battery Pack
Danger
•Do not solder lead wires or terminals directly
onto a battery or modify it.
•Do not connect the =and -terminals
together.This may cause fire, overheating or
electric shock.
•When carrying or storing the battery, be sure
to put it in the provided case to protect its
terminals. Do not carry or store the battery
with any metal objects (such as key rings).
If this warning is not followed, fire,
overheating or electric shock may occur.
•Do not connect the batteries directly to a
power outlet or a cigarette lighter of an
automobile.
•Do not insert the batteries with their =and
-terminals reversed.
•If any liquid from a battery gets into your
eyes, promptly wash it off with clean water
and consult your doctor at once.
•There is a hole from which gas escapes on the =
terminal. Do not cover or block it.
Warning
•Batteries should never be exposed to flame,
heated, short-circuited or disassembled.
•Do not attempt to recharge alkaline, lithium
or any other non-rechargeable batteries.
•Never use any battery with a torn or cracked
outer cover.
•Keep batteries out of the reach of children.

6
Cradle
Danger
•Never disconnect the AC adapter
or power cord with a wet hand.This
may cause electric shock or injury.
•Only use the included AC adapter
with the cradle. Using it in
combination with other AC
adapters may cause overheating,
fire, or malfunction.
Warning
•Never disassemble, modify, or
repair the recorder yourself. This
may cause fire, electric shock, or
injury.
•Never use it in locations where it
might come into contact with water
(such as a bathroom). Getting the
recorder wet may cause fire or
electric shock.
•Do not drop the recorder or allow
it to suffer a shock.This may cause
damage, fire, or electric shock.
•Do not insert metal wires or similar
objects. This may cause fire,
overheating or electric shock.
•Keep out of the reach of children.
Do not let children use this product
without adult supervision.
•If you notice anything unusual when
using this product such as abnormal
noise, heat, smoke, or a burning odour:
1remove the batteries immediately while
being careful not to burn yourself, and;
2call your dealer or local Olympus
representative for service.
•Do not expose the rechargeable batteries to
water. Do not allow water to contact the
terminals.
•Do not remove or damage the battery
insulating sheet.
•Do not use the batteries if you find
something wrong with them such as leakage,
color change or deformity.
•Unplug the charger if the charging is still
incomplete after the specified time it should
take.
•Should any battery liquid get on skin or
clothing, promptly wash it off with clean
water.
•Keep batteries away from fire.
Caution
•Rechargeable batteries are exclusively for
use with Olympus digital voice recorder DS-
5000/5000iD. Do not use them in combination
with other equipment.
• Do not subject batteries to strong shocks.
•Do not use batteries of different types, voltages,
and/or brand names.
•When using rechargeable batteries or battery
pack, make sure they are charged at the same
time.
•When using rechargeable batteries or
battery pack that have not been used for a
while, be sure to recharge them before use.
General Precautions
Do not
disassemble

7
Caution
•Do not use or store the Cradle in/
on an unstable place, such as a
television set, etc. If it falls, it may
cause injury or break.
•Unplug the AC adapter or power
cord from the cradle and AC outlet
when not using for extended
periods of time. If this precaution
is not followed and the cradle is
damaged then fire may occur.
AC Adapter
Danger
•Be sure to use the AC Adapter with
the proper voltage (AC 100 - 240 V).
Using it with other voltage levels
may cause fire, explosion,
overheating, electric shock or
injury.
•For safety, be sure to unplug the
AC Adapter from the outlet before
performing maintenance or
cleaning. Also, never plug in or
disconnect the power plug with a
wet hand. This may cause electric
shock or injury.
Warning
•Do not attempt to disassemble, repair or
modify the AC adapter in any way.
•Keep foreign objects including water, metal,
or flammable substances from getting inside
the product.
•Do not moisten the AC adapter or touch it
with a wet hand.
•Do not use the AC adapter in the vicinity of
flammable gas (including gasoline, benzine
and lacquer thinner).
Unplug from
power outlet
General Precautions
Unplug from
power outlet
In case
•... the internal parts of the AC adapter are
exposed because it has been dropped or
otherwise damaged:
•... the AC adapter is dropped in water, or if
water, metal flammable substances or other
foreign objects get inside it:
•... you notice anything unusual when using
the AC adapter such as abnormal noise, heat,
smoke, or a burning odour:
1do not touch any of the exposed parts;
2immediately disconnect the power supply
plug from the power outlet, and;
3
call your dealer or local Olympus representative
for servicing. Continued use of the AC adapter
under these circumstances could result in
electric shock, fire or injury.
Caution
•Do not use the AC Adapter if the
power plug is damaged or the plug
is not completely connected to the
outlet. This may cause fire,
overheating, electric shock, short
circuit or damage.
•Unplug the AC Adapter from AC outlet
when not using. If this precaution is
not followed, fire, overheating or
electric shock may occur.
•Make sure to hold the plug when
removing the power plug from the
outlet. Do not bend the cord
excessively or put a heavy object on
it. This may cause fire, overheating,
electric shock or damage.
Unplug from
power outlet

8
General Precautions
•If something appears to be wrong
with the AC Adapter, unplug the AC
Adapter from the outlet and consult
your nearest service center. Using
the AC Adapter may cause fire,
overheating, electric shock or
injury.
•Do not use or keep the AC Adapter
in very hot places, such as in direct
sunlight, in a closed car on a sunny
day, near a heater, on an electric
carpet, etc. Do not use the AC
Adapter if something is covering it
(such as a blanket).This may cause
fire, explosion, leakage or
overheating.

9
1
1 Getting Started
1 Getting Started
Main Features
Main Features
●Slide switch operation for ease of use and
fast response.
●Supports two types of memory: SD card and
microSD card (☞P.10).
●Three Programmable smart buttons F1,F2
and F3 (☞P.54).
●Recording and storing voice in Digital
Speech Standard Pro (DS2 format).
●Two recording modes, QP (Quality
Playback) mode or SP (Standard Playback)
mode (☞P.37).
●Data encryption function for securing
recordings on the device.
●The recorder’s Ni-MH Rechargeable Battery
Pack can be charged in the recorder using
the USB cable or the AC adapter (☞P.16,
17).
●Supports USB 2.0. High-Speed, which
enables high-speed data transmission from
the recorder to your computer.
●Five folders and up to 200 files/folder, for a
maximum of 1000 recordings (☞P.25).
When using DSS Player, it is possible to create
up to a maximum of seven folders (1,400 files) (☞
P.54, 55).
●Large LCD screen with backlight.
●Device Lock function to prevent
unauthorized access to device (☞P.42).
Authentication system via password or
fingerprint scan (☞P.42, 43). (DS-5000iD only)
●IndexMark function which is useful to search
particular points in the dictation (☞P.50).
● Verbal comment function which allows
transcriptionists to instantly search and play
back instructions on their computer (☞P.49).
●Priority Setting (☞P.45).
●DSS Player software included (☞P.55).
It is possible to customize the recorder in a number
of ways.

10
1
SD card
1Card Lock
SD card is equipped with a lock function.
When the lock function is used, important
data is protected by preventing it from being
accidentally overwritten or erased.
When the lock function is set will
appear on the display.
2Index area
For writing down information identifying card
or content.
3Contact area
Comes into contact with the recorder’s
signal read contacts.
microSD card
1Contact area
Comes into contact with the recorder’s
signal read contacts.
Memory Card
Memory Size QP Mode SP Mode
512MB 38 hr. 45 min. 79 hr. 30 min.
1GB 77 hr. 40 min. 159 hr. 05 min.*2
2GB 157 hr. 55 min.*2323 hr. 35 min.*2
4GB 310 hr. 10 min.*2635 hr. 25 min.*2
8GB 631 hr. 15 min.*21293 hr. 15 min.*2
The above are the standard times, and the available
recording time will vary depending on the card.
*1: Available recording time for one continuous file.
Available recording time may be shorter if many short
recordings are made.
*2:Total recording time of several files. The maximum
recording time per file is 99 hours 59 minutes.
Memory Card
This recorder uses dual memory in the form of
SD card memory and built-in memory
(microSD card), allowing you to record to the
selected memory.
A removable microSD card is used for the built-
in memory thus allowing you to remove your
recording from the recorder safely in case of
recorder malfunction or failure.
Check the latest operating information on the
Olympus homepage (http://www.olympus.com/)
when using cards other than the included card.
In addition, refer to the following pages as well
when handling the card.
•Inserting and Ejecting a SD card (☞P.21)
• Inserting and Ejecting a microSD card (☞P.51)
•Setting Recording Destination (Card Select) (☞P.24)
•Formatting the Card (Format) (☞P.52)
Memory Sizes of Cards and
Approximate Recording Times*1
Compatible Cards
The recorder supports cards with memory
capacity between 512 MB to 8 GB.
Settings and operating environment
relating to the card
SD card
2
3
1
microSD card
1

11
1
Memory Card
Memory Card
Warning
• Do not touch the card contacts.
That may damage the card.
• Do not place the card in locations
with static electricity.
• Store the card in a location that is
out of the reach of children. In case
of accidental ingestion, consult a
physician immediately.
Check Card Information (Card Info.)
Information such as the memory capacity and
remaining memory for installed cards can be
displayed on the recorder (☞P.36).
Notes
•When initializing (formatting) a card, confirm that
no necessary data is stored on the memory card
beforehand. Initialization completely erases the
existing data on the card.
•In some cases cards which have been formatted
(initialized) by another device, such as a computer,
cannot be recognized. Be sure to format them with this
recorder before using.
•The card has a service life. When reaching the end of
its life, writing or erasing data on the card will be
disabled. In this case, replace the card.
•If you use a PC card adapter compatible with the card
to save or delete some data on the card, the maximum
recording time on the card may be decreased. To
recover the original recording time, initialize/format the
card in the recorder.
•Olympus will not be held liable for any data corruption
or loss due to misuse of the media card.
BACK EXIT
Card Info.
SD
micro SD
mSD
Remain
Capacity
Remain
Capacity
540MB
1024MB
250MB
512MB

12
1
Identification of PartsIdentification of Parts
Identification of Parts
1SD card slot
2Built-in microphone
3NEW button
4Slide (REC/STOP/PLAY/REV)
switch
5POWER (ON/OFF) switch
6ERASE button
7EAR (Earphone) jack
8MIC (Microphone) jack
9Record/Play indicator light
0Display (LCD panel)
!VOLUME (+) button
@Fast Forward (9) button
#OK/MENU button
$Programmable smart button
(F1,F2,F3)
%Rewind (0) button
^VOLUME (
- ) button
&Built-in speaker
*Battery removal tape
(Fingerprint sensor*
)Battery cover
-PC (USB) terminal
=Cradle connector
qPower jack
wBattery cover release button
emicroSD card cover
*DS-5000iD only
0
7
8
9
&
1
2
3
4
5
$
^
%
!
@
#
6
w
q
=-
)
(
*
e

13
1
Identification of PartsIdentification of Parts
Identification of Parts
Display in the recording mode Display in the playback mode
VERBAL DISPLY INDEX
MIKE 025
/030
QP DICT
EF
00M 10s
15H22M30s
1
2
8
6
9
3
4
5
0
7 INSERT SPEED INDEX
MIKE 025
/030
QP DICT VCVA
02 M 50 s
12 M 0 5 s
!
#
@
Display Status Indicators
1Record mode indicator
2Current folder
3Memory remaining indicator
(E/F bar)
4Recording elapsed time
5Remaining recording time
6Level meter indicator
7Button guide display
8Microphone sensitivity indicator
9Current file number
0Total number of files in the folder
!Playback position bar indicator
@Current Playback time
#
Total recording time of the selected
file
Author ID indicator
Battery indicator
SD card indicator
mSD microSD card indicator
VCVA VCVA (Variable Control Voice
Actuator) indicator
Pending indicator
Card Lock indicator
Encryption indicator
Priority indicator
Erase Lock indicator

14
1
Installing Batteries
Ni-MH Rechargeable Battery Pack
(included)
1
Lightly press down on the battery cover
release button and open the battery
cover, as shown in the illustration below.
2
Insert the Ni-MH Rechargeable Battery
Pack, observing the correct polarity as
shown in the illustration below, and then
close the battery cover.
Installing Batteries
Installing Batteries
When pulling on the tape the battery pack may
suddenly pop out, so be sure to press down
lightly the battery pack with your finger while
pulling.
The battery pack needs to be fully charged in
the recorder before initial use.
Recharging Battery Pack
The battery indicator on the display changes
as the battery pack lose power.
→→
When appears on the display, charge the
battery pack as soon as possible.
When the battery pack charge is low, the
recorder shuts down and [ Battery Low]
appears on the display.
Notes
•Removing the battery pack while the recorder is in use
may corrupt the file.
•If power runs out during recording, current file will be
lost or corrupted!.
•It is crucial to charge the battery pack once you see
one hash mark on the LCD battery indicator.
•Remove the battery pack if you are not going to use
the recorder for an extended period of time.
This recorder can be used with either Ni-MH
Rechargeable Battery Pack or AAA Alkaline
Batteries.
When using the Ni-MH Rechargeable Battery
Pack, insert it so that the flat surface with the
polarities is facing down as shown in the
illustration below. Exercise caution, as the
directions inscribed inside the battery
compartment apply to AAA batteries only.
In addition, when inserting the battery pack, insert
them so that the tape is under the battery pack,
as shown in the illustration. The battery pack can
then be removed easily by pulling up the tape.

15
1
Installing Batteries
Installing Batteries
AAA Alkaline Batteries
1
Lightly press down on the battery cover
release button and open the battery
cover (☞P.14).
2
Insert two AAA batteries, observing the
correct polarity as shown in the illustration
below, and then close the battery cover.
Insert the batteries in the direction inscribed on
the inside of the recorder’s battery compartment.
In addition, when inserting the batteries, insert
them so that the tape is under the batteries, as
shown in the illustration. The batteries can then
be removed easily by pulling up the tape. When
pulling on the tape the batteries may suddenly
pop out, so be sure to press down lightly the
batteries with your finger while pulling.
The battery indicator on the display changes
as the batteries lose power.
Replacing Batteries
When appears on the display, replace the
batteries as soon as possible.
When the batteries are too weak, the recorder
shuts down and [ Battery Low] appears
on the display.
Installing Batteries
Notes
•Be sure to turn OFF the recorder before replacing
the batteries. Removing the batteries while the recorder
is in use may corrupt the card. If you are recording into
a file and the batteries run out, you will lose your
currently recorded file since the file header will not be
written. It is crucial to replace the batteries when one
hash mark in shown in the battery icon.
•Be sure to replace both batteries at the same time.
•Never mix old and new batteries, or batteries of
different types and/or brands.
•If it takes longer than 1 minute to replace dead batteries,
you may have to reset the time when you load new
batteries.
•Remove the batteries if you are not going to use the
recorder for an extended period of time.
Cautions Concerning the Battery
Warning
•Using batteries for which part or all
of the external coating (insulating
sheath) is peeling off or batteries
which have ruptured may cause fluid
leaks, overheating, and explosions.
For this reason such batteries should
absolutely not be used.
•Commercially available batteries for
which part or all of the external
coating (insulation sheath) has been
peeled off should absolutely not be
used.
Unusable batteries
Batteries for which the entire external coating
(insulating sheath) is peeled off (naked batteries),
or those where it has partially been peeled off.

16
1
Charging Battery Pack
Charging Battery Pack
Charge the Ni-MH Rechargeable
Battery Pack using the Cradle
The Ni-MH Rechargeable Battery Pack in the
recorder can be charged by connecting the AC
adapter or USB cable to the cradle with the
recorder set in it.
Charging using Cradle and AC Adapter
Connect the AC adapter to the cradle.
For connection procedures, see P.61.
When using the AC adapter for charging, connect the
power plug to the cradle AC connector (☞P.19).
Firmly press the recorder all the way into
the cradle as shown in the illustration.
CHARGE indicator light glows red and the charging
starts.
The light goes out when the charging is complete.
You can charge the Ni-MH Rechargeable
Battery Pack in the recorder using the cradle
in combination with the USB cable or AC
Adapter. Or by directly connecting the AC
Adapter or USB cable to the recorder.
Battery pack need to be fully charged before
first use.
Full charge time: Approximately 3 hours.
CHARGE indicator light
Charging using Cradle and USB Cable
Connect the USB cable to the cradle.
For connection procedures, see P.61.
Turn the recorder’s POWER switch OFF
(☞P.20) and firmly press the recorder all
the way into the cradle as shown in the
illustration.
CHARGE indicator light glows red and the charging
starts.
The light goes out when the charging is complete.
When the recorder is connected to a USB cable while
its POWER switch is turned OFF, only charging will
be performed, and the computer will not recognize it
as a drive.

17
1
Charging Battery Pack
Charging Battery Pack
Directly Charging Through the
Recorder
The Ni-MH Rechargeable Battery Pack in the
recorder can be charged by connecting an AC
adapter or USB cable to the recorder.
Charging using AC Adapter (no cradle)
Connect the AC adapter to the recorder.
For connection procedures, see P.19.
When using the adapter for charging, connect the
power plug to the cradle AC connector.
Charging using the USB cable (no cradle)
Connect a USB cable to the recorder while
its POWER switch is turned OFF.
When the recorder is connected to a USB cable while
its POWER switch is turned OFF, only charging will
be performed, and the computer will not recognize it
as a drive.
Notes
•Charge the battery pack often for first few uses. Battery
pack performs better after several full charge/discharge
cycles.
•Battery packs other than the supplied battery pack
cannot be charged.
•If you charge the battery pack right after charging is
complete, it will take only few minutes to charge the
battery pack.
•The PC must be ON when charging battery pack via
the USB cable connection.
•Charging battery pack via the USB cable connection
may not be successful depending on the power supply
capacity of your PC. Use the AC adapter instead.
•Do not set or remove the recorder from the cradle while
it is in operation.
•Do not charge the recorder with the USB hub connected.
•Do not attach or remove the rechargeable battery pack
if the AC adapter or USB cable is connected.

18
1
Using the Battery Pack
Using the Battery Pack
The battery pack is exclusively for use with
Olympus voice recorder DS-5000/5000iD.
Never use them in combination with other
equipment.
Discharging
Battery pack self-discharge while this is not in
use. Be sure to charge them regularly before
use.
Battery life
Over time, rechargeable battery packs
gradually wear down. If you charge you battery
pack regularly and you notice a decrease in
usage time, then it is probably time to purchase
a new battery pack.
Operating temperature
Rechargeable batteries, such as the battery
pack, are chemical products. Batteries
efficiency may fluctuate even when operating
within the recommended temperature range.
This is an inherent nature of such products.
Recommended temperature range for
use
Discharging (when using appliance):
0°C - 42°C/32°F - 107.6°F
Charging:
5°C - 40°C/41°F - 104°F
Storage:
–20°C - 30°C/–4°F - 86°F
Using the battery pack outside the above
temperature range may result in declining
efficiency and shorter battery life.
In order to prevent battery leakage or rust,
remove the battery pack from the products
when you will not be using them for a long time,
and store them separately.
Notes
•This recorder is designed to fully charge battery
pack regardless of their energy level. However, for
best results when charging newly purchased battery
pack or battery pack that have not been used for a
long time (more than one month), It is recommended
to fully charge the battery pack then discharge
repeatedly for 2 to 3 times.
• When disposing battery packs, always observe the local
laws and regulations. Contact you local recycling center
for proper disposal methods.
• If Ni-MH rechargeable battery pack is not fully
discharged, protect against short-circuiting (e.g. by
taping the contacts) before disposing.
For customers in Germany
Olympus has a contract with the GRS (Joint
Battery Disposal Association) in Germany to
ensure environmentally friendly disposal.

19
1
Using the AC Adapter
Using the AC Adapter
Use the AC adapter (Olympus Model A513,
included) in cases where battery
consumption is a concern, such as when
recording for extended periods of time.
Plug the AC adapter (Olympus Model A513
included) into a household power outlet and
connect the power plug to the recorder’s
power connector (DC 5V). Always turn off
the recorder before you connect power.
Refer to P.16-P.17 regarding supplying
power to the recorder and cradle with the
aim of charging the Ni-MH Rechargeable
Battery Pack (☞P.14).
If the recorder detects a DC power
voltage outside of the allowable voltage
(allowable voltage: 4.6 to 5.5 V), then
[Power Supply Error Remove Power
Plug] will appear on the display and all
operations will stop. The recorder will
not be operable while abnormal voltage
is detected. Use the included AC
adapter (A513).
Detecting abnormal voltage
AC
connector
The plug type varies
depending on the country
where sold.
AC adapter
AC cable
Power Supply
Error
Remove
Power Plug
Warning
• Always stop recording before
connecting or disconnecting
power.
• When the AC adapter is not in use,
disconnect the power supply plug
from the power outlet.
• Use only the correct power supply
voltage as indicated on the
adapter.
• Do not use the AC adapter when
connecting the recorder to the
USB port.

20
1
Turning ON the
Recorder
With the battery charged in the recorder and
the card inserted properly, the recorder is ready
to work.
While the POWER switch on the side of the
recorder is in the OFF position, none of the
buttons or switch on the recorder will be active.
Slide the power switch to the ON position to
activate the recorder.
Power Save Mode
When the recorder is ON but not in use for 10
minutes, by default, it will switch to power save
mode automatically. To reactivate the recorder
again, operate any button or the slide switch.
You can set the time to enter Power Save
mode from among [5 min.], [10 min.], [30
min.], [1 hour], and [Off] .
To exit power save, press any button.
The [Power Save] setting can be changed
from the Menu. For more details, refer to
“Menu List”(☞P.35) and “Learning to Use
the Menu”(☞P.39).
Power Save Setting (Power Save)
Turning ON the Recorder/Power Save Mode
BACK EXIT
Power Save
5min.
30min.
1hour
Off
10min.
