Omega Altise ODE10 User manual

ODE10
10 Litre Dehumidifier
Instruction
Manual

omega altise
2
Important Safety Instructions
1. Read all instructions.
2. Disconnect the power plug before dismantling, assembling or before cleaning.
3. Avoid touching mobile parts of the unit.
4. Make sure the unit is on a dry and even surface.
5. Never insert fingers, pencils or any other objects though the guards whenever
the power plug is connected, especially while running.
6. The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervised or instruction concerning
use of the appliance by a responsible person for their safely.
7. Young children or infirm persons should be supervised to ensure that they do not
play with the appliance.
8. Do not use the appliance for any other purpose than its intended use.
9. The unit must not be used if the guards are not fastened according to
instructions.
10. When the power cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
11. Do not use your appliance with an extension cord unless it has been checked
and tested by a qualified electrician or electrical supplier.
12. Return to Hagemeyer or authorised service agent.
13. Leave the unit to stand for one hour before connecting to the mains supply after
transport or when it has been tilted (e.g. during cleaning).
Read all instructions before using this unit. Keep them for future reference.

omega altise
3
Specifications
Model no. ODE10
Power supply 230-240V~, 50Hz
Test condition DB 30oC, RH 80%
Dehumidification capacity 10 L/day
Power consumption 260 W
Air volume (max.) 70m3/h
Compressor Reciprocating
Refrigerant R134a
Working range 5 ~ 32oC
Water tank 3.6 L
Size (w x d x h) 342 x 245 x 492 mm
N.W. 11.5 kg

omega altise
4
How a Dehumidifier works
This product is a dehumidifier. It controls relative humidity by passing the air through
the unit, forcing the excess moisture to condensate over the cooling elements.
Contact with this cold surface causes the moisture in the air to condense. This
condensed water then drains safely into the water tank. The dried air then passes
through the condenser where it is slightly warmed and re-enters the room at a
slightly elevated temperature.
Where to position the unit
Excess moisture will travel throughout your home, in the same way that cooking
smells waft to every room in the house. For this reason, the dehumidifier should be
positioned, so that it can draw this moist air towards it from all over the home.
Alternatively, if you have a serious problem in one area you can begin by positioning
the dehumidifier close to this area and later moving it to a more central point.
When positioning the dehumidifier, ensure that it is placed on a level surface and
that there is a minimum of 10 cm (4") of space on either side of the unit to allow for
efficient airflow.
This dehumidifier is fitted with castors for extra mobility, if you move the unit, it
should first be switched off and the water tank emptied.
We do not recommend the use of an extension lead, so please try to ensure that the
unit is sufficiently close to a fixed mains socket. If it is necessary to use an extension
lead, please ensure the diameter of the wires of the cable are at least 1mm2.
When the dehumidifier is in operation, outside doors and windows should be closed
when necessary for most efficient use.

omega altise
5
Parts List
Front
1. Control panel
2. Air inlet
3. Filter (inside the unit
4. Water tank
5. Castor
6. Handle for water tank
7. Handle for the unit
Rear
8. Air outlet
9. Hole for continuous drainage
10. Power cable
Control Panel
11. Water full indicator
12. Operation indicator
13. On/off humidistat controller

omega altise
6
Operating Instructions
1. Plug the unit into a correct mains socket.
2. To turn the unit on turn the humidistat control
clockwise.
3. The humidistat (humidity controller) also
controls the required humidity level. The
intensity of humidity extraction is increased
clockwise
4. For continuous working, set the humidistat to
position 'MAX'.
5. To turn off the unit turn the humidistat to OFF position.
Drainage
Whenever the water tank is full, or the water tank is not positioned properly, the
compressor will stop and the water full indicator will turn red.
To remove the water tank, use the handle to pull the tank out squarely from the unit.
After empting, replace the water tank. The tank will need to be properly positioned in
order for the 'water full' sign to cancel and your dehumidifier will start operating.

omega altise
7
Continuous Drainage
When the dehumidifier is operated at very high humidity levels, the water tank will
require more frequent drainage. In this situation, it may be more convenient to set
the unit up for continuous drainage with the following procedures:
1. Pull out the stopper from the
drain hole A at the rear of the
machine ( see FIG. 1) and
connect the drain hole A with a
water tube of inner diameter 12
mm. (FIG.2)
* Please note, the water tube is
not supplied with the unit.
2. Pull out the water tank. Use the
stopper taken from Hole A to
stick into drain Hole B (FIG. 3).
3. Ensure the water will always
drain away freely and the tube
will remain in right place. Note!
In very cold weather conditions,
precautions should be taken to
prevent the water tube from
freezing.
4. Put the water tank back to its
position (FIG. 4).
Hole A

omega altise
8
Care and Maintenance
lways disconnect the cord from the electrical outlet when cleaning the unit.
LEANING THE BODY e the unit clean.
LEANING THE AIR FILTER
2. m cleaner or tap the filter
3. irty, use warm water
4. ry before
5. r to sunlight.
torage
you do not use the unit for an extended period of time, please turn the unit off,
A
C
1. Use a soft cloth to wip
2. Do not use volatile chemicals, gasoline,
detergents, chemically treated cloths or
other cleansing solutions as they could
possibly damage the unit.
C
1. Remove the water tank and extract the
filter holder
Use a vacuu
lightly for easy cleaning.
If the filter is particularly d
with a small amount of detergent.
Make sure the filter is completely d
placing into position.
Do not expose the filte
S
If
unplug and tidy power cord, completely empty the water tank and wipe it clean.
Cover the unit and store where it will not receive direct sunlight.

omega altise
9
Trouble Shooting
The unit does not operate:
• Is the unit plugged in?
• Is the house electricity on?
• Is the room temperature below 5oC or above 32oC? If so,
then it is out of the working range of the unit.
• Ensure the humidistat (or ON/OFF switch) is turned on.
• Check the water tank is positioned properly in the unit and
it is not full.
• Make sure the air inlet and outlet are not obstructed.
The unit seems to do nothing:
• Is the filter dusty, contaminated?
• Is the air intake or outlet blocked up?
• Is the room humidity already quite low?
The unit seems to do little:
• Are too many windows or doors open?
• Is there something in the room producing lots of humidity?
The unit is too noisy:
• Check whether the unit is sitting on a level surface.
The unit is leaking:
• If you are not using continuous drainage, make sure the
rubber plug (at the bottom of the unit) is in its position.
CAUTION! Do not immerse the unit in water or allow water to drip into
the interior of the unit housing as this could create a fire or electric
shock hazard.
WARNING! Do not attempt to repair the unit yourself. Doing so could
void the warranty and cause damage or personal injury.
Omega Altise products are distributed in Australia by MEA,
(A Division of Hagemeyer Brands Australia Pty Ltd)
ABN 28 001 375 686
Locked Bag 4013, Kingsgrove NSW 2208
Phone: [phone]
Fax: [phone]
Email: [email protected]
Web: meaappliances.com.au
