Omega DRG-AR-DC User manual

DESCRIPTION
The DRG-AR-DCisaDINrailmount,
DCvoltageorcurrentinputlimitalarm
with dual setpoints and two contact
closureoutputs. Thefieldconfigurable
inputandalarmfunctionsofferflexible
setpointcapability. Inputvoltagespans
from10mVto200Vandinputcurrent
spansfrom1mAto100mAcanbefield
configured. Bipolar inputs are also
accepted.
TheDRG-AR-DCisconfigurableasa
singleordualsetpointalarm,withHIor
LO trips and failsafe or non-failsafe
operation. Also included are adjust-
able deadbands (0.25 to 5% of full
scaleinput)foreachsetpoint,a24VDC
voltage source (isolated from line
power) for transducer excitation, and
a flexible DC power supply which ac-
cepts any voltage between 9 and
30VDC.
DIAGNOSTICLEDS
The DRG-AR-DC is equipped with
three front panel LEDs. The green
LED is a dual function LED labeled
INPUT. ThisLEDindicateslinepower
and input signal status. Active DC
power is indicated by an illuminated
LED. If this LED is off, check DC
power and wiring connection. If the
input signal is more than 110% of the
fullscalerange,theLEDwillflashat8
Hz. Below 0%, the flash rate is 4 Hz.
TworedLEDsindicatetherelaystate
for each setpoint. An illuminated red
LED indicates the tripped condition.
OUTPUT
TheDRG-AR-DCisequippedwithtwo
SPDT(formC)relays,ratedat120VAC
or28VDCat5amperes. Eachofthese
relays is independently controlled by
the field configurable setpoint and
deadband.
OPERATION
The field configurable DRG-AR-DC
limitalarmsetpointscanbeconfigured
for HI or LO, failsafe or non-failsafe
operation. Each of the setpoints has
arespectiveHIorLOdeadband. Ina
tripped condition, the setpoint is ex-
ceeded and the appropriate red LED
will illuminate. The trip will reset only
when the process falls below the HI
deadband or rises above the low
deadband(seeFigure1). For proper
deadband operation, the HI setpoint
must always be set above the LO
setpoint. In failsafe operation, the
relayisenergizedwhentheprocessis
belowtheHIsetpointorabovetheLO
setpoint(oppositefornon-failsafe). In
the failsafe mode, a power failure
results in an alarm state output.
DYNAMICDEADBAND
LSI circuitry in the DRG-AR-DC pre-
vents false trips by repeatedly sam-
plingtheinput. Theinputmustremain
beyond the setpoint for 100 millisec-
onds, uninterrupted, to qualify as a
validtripcondition. Likewise,theinput
must fall outside the deadband and
remain there for 100 milliseconds to
return the alarm to an untripped con-
dition. This effectively results in a
“dynamic deadband” —based on
time— in addition to the normal
deadband.
Figure1:Limitalarmoperation
andeffectofdeadband(s).
CONFIGURATION
Unlessotherwisespecified,the
factory presets the Model
DRG-AR-DCasfollows:
Input: Current
Range: 0-20mA
Output: Dual,SPDT
Trip: A:HI, B:LO
Failsafe: No
Deadband: A, B: 0.25%
The DC power input accepts any DC
sourcebetween9and30V,typicallya
12V or 24VDC source is used.
For other I/O ranges, refer to Table 1
and Figure 4. Reconfigure switche
SW1forthedesiredinputtype,range
and function.
1. With DC power off, set positions 9
and10of switch“SW1”forcurrent or
voltage.
2.Setposition1through position 4 of
input range switch “SW1” for the de-
sired input range (see Table 1).
3.Set position5 ofinput rangeswitch
“SW1” to ON for unipolar (e.g. zero
based, 0-20mA) range or OFF for
bipolar (e.g. -100% offset,
-20 to 20mA) range (see Figure 4).
4. Set position 6 and 7 of input
rangeswitch“SW1”toONforaHItrip
setpoint or OFF for a LO trip setpoint
(see Figure 4).
5. Set position 8 of input range
switch “SW1” to ON for non-failsafe
operation or OFF for failsafe
operation (e.g. alarm trips upon
power failure).
WARNING: Do not attempt to
change any switch settings with power
applied. Severe damage will result!
50
100
Process (% of Span)
Time
Relay Trips
(LED Red)
Relay Trips
(LED Red)
Relay returns to its
untripped condition
(LED Off)
Relay returns to its
untripped condition
(LED off)
} 10% Deadband
} 10% Deadband
Setpoint
Illustrating HI Setpoint
Illustrating LO Setpoint
DRG-AR-DC
DC Input, Field Configurable Limit Alarm
Instruction Sheet M2399/0796
Inputs
VoltageInput
Range:10mVto+200V
Impedance:>100KΩ
Overvoltage:200Vrms,max.
CurrentInput
Range:1mAto+100mA
Impedance:20Ω,typical
Overcurrent: 170mA rms, max.
Overvoltage:60VDC
(protectedbyselfresetting fuse)
CommonMode(InputtoGround):
1800VDC,max.
LEDIndicators
InputRange(Green)
>110%input:8Hzflash
<0%input:4Hzflash
Setpoint(Red)
Tripped:Solidred
Safe:Off
LimitDifferentials(Deadbands)
>50mV/5mA:0.25%to5%ofspan
<50mV/5mA:1% to5%of span
Response Time
DynamicDeadband:Relaystatus
willchangewhenproper
setpoint/processconditionexists
for 100msec.
NormalMode(analogfiltering):
<250mSec,(10-90%)
Setpoints
Effectivity:Setpointsareadjustable
over100%oftheselectedinput
span.
Repeatability(constanttemp.):
>50mV/5mA:0.1%offullscale
<50mV/5mA:0.2%offullscale
Stability
Temperature:+0.05%offull
scale/°C, max.
ExcitationVoltage
24VDC,20mA,maximum
Common Mode Rejection
DCto 60Hz:120dB
Isolation
1800VDCbetweencontacts,input
andpower
EMC Compliance (CE Mark)
Emmissions:EN50081-1
Immunity:EN50082-2
Safety:EN50178
Humidity(Non-Condensing)
Operating:15to95%(@45°C)
Soak:90%for24hours(@65°C)
Temperature Range1
Operating:0 to55°C (32to131°F)
Storage:-25 to70°C (-13to158°F)
Power
Consumption:1.5Wtypical,
2.5W max.
SupplyRange:9to30VDC,
inverterisolated
In-rushCurrent:300mA,max.
RelayContacts
2 SPDT (2 form C) Relays
1Relaypersetpoint
CurrentRating(resistive)
120VAC:5A
240VAC:2A
28VDC:5A
Material:Silver-CadmiumOxide
ElectricalLife:105operations
atratedload
Note:External relaycontact
protectionisrequiredforuse
withinductiveloads(see
Figures 2 & 3).
MechanicalLife:107operations
WireTerminations
Screwterminations for12-22AWG
AgencyApprovals
CSAcertifiedperstandardC22.2,No.
0-M91 and 142-M198 (File
No.LR42272)ULrecognizedperstan-
dard per standard UL508 (File
No.E99775). CE conformance per
EMC directive 89/336/EEC and Low
Voltage 73/23/EEC (Input<75VDC,
only).
Mounting
32mm and 35mm DIN Rail
PIN CONNECTIONS
11 N.O.RelayB
12 Com. Relay B
13 N.C.RelayB
21 DC Power (+)
22 DC Power (-)
23 NoConnection
41 AnalogInput(+)
42 AnalogInput (-)
43 (+)24VDCExcitation
