OMEZ LIGHTING TitanBeam 2R User manual

TitanBeam™ 2R
User
Manual
132W Moving Head
Beam
Introduction
Thank you for purchasing the OMEZ TitanBeam™2R. This moving head
fixture, characterizedby its exceptional bright light beam, is a new product
in the Titan Series. This light weight fixture is CE compliant and has a
perfect combination of advanced electronic controlling technology with
standard DMX 512 control. Programing is a breeze on the fixture’s touch
screen panel.
TheOMEZ TitanBeam™2R has a 132 watt discharge lamp with reflector
thatprojectsahighqualitylongrangebeamof light. With 5 high quality step
motors you can pan, tilt, and focus with fast smooth precision.
TheOMEZTitanBeam™2R features; one color wheel with 13 colors plus
open and one gobo wheel with 14 static patterns plus open. The OMEZ
TitanBeam™2R is a small, lightweight fixture designed for easy transport
for mobile DJ’s,VJ’s, KJ’s, mobileentertainers and Production companies.
TheOMEZTitanBeam™2Ris the industry standard in T.V., reality shows,
Arenas,Concerthalls,Banquet halls, Performing arts theaters, Nightclubs,
Entertainment venues.
Omez Guarantee
ThisOMEZTitanBeam™2Rhas met all quality control requirements when
testedin our factory and is known to be in perfect condition when shipped
to our warehouse in El Monte, California. In order to guarantee the
conditionof this fixture, we conductfinal QC inspectionsuponarrivalto our
facility before deeming the product salable. In order to ensure the safe
operationof this OMEZTitanBeam™2R, it is absolutely necessary for the
user to followthe safetyinstructions and warning notes written in this user
manual.

Contents
Introduction/Omez Guarantee …….…...………………..1
Safety information …………………….………..2
Included in package ………………………………3
Features ..…………………….……….4
Control panel ……………………………….5
DMX Channels .………………………………6
Installation ...…………………………….7
Cleaning & maintenance .……………………………….8
(Before plugging in the fixture, please the read manual)
2 SafetyInformation

3. Included In Package
Thisbox includes items listed below
Item
QTY
UNIT
User manual
1
PCS
Warrantycard
1
PCS
Suspensionfasteners
2
SET
DMX cable
1
PCS
 4. Features

Modes:16 Channels
Luminous:78700k@ 15m
Lamp Type:132WattDischargeLamp
ColorTemperature: 92000K
BeamAngle: 0-3.8°
0-100%LinearDimming
StrobeSpeed:1-13 FPS
13 DichroicColors
14 StaticGobos
8 FacetRotatingPrism
Pan/Tilt540/270
8 bit/16bit
LED TouchScreenDisplay
PowerSupply:100-240V~,50/60Hz
Frost 0-100%Linear Frost Adjustment
Ratedpower:140W
Size: 400*330*475mm
Net weight:14.5kg
CE Compliant

Option
Instruction
Invert
Invert Pan & Tilt
Display
DisplayReverse/ LCD Light
5. Control panel
5.1 PanelInstructions
Functions
Fromthehomescreentoget to themenu screenpushthe
Knob(enter),Inthemain menu screenyouhavesubmenus:
Setup,Options,Information,ManualControl,Reset,Factory
Default,&Return.
Scrollthroughthesubmenus,pressingtheknobwill enterthe
highlightedfield
5.3 Set Up Tab
Option
Instructions
Operation
Mode
DMX
Set DMX Channel
Return
Backto previousmenu
5.4 Option Tab
5.2 Home Screen
Thehome screenwill alwaysdisplayDMXchannelfixture is
addressedto.
5.5 Information Tab
Option
Instruction
SystemVersion
DisplayVersion
Fixture Hours
Total/Current
Lamp Hours
Total/Current
Time Clear
Clear Lamp/PowerTime
Fan Motors
Fan SpeedTime
DMX Values
ControlFixture Manually
Return
ReturnBack Tomain menu

Channel
Standard mode
1CH
ColorWheel
2CH
Shutter/Strobe
3CH
Dimmer
4CH
Gobo
5CH
Prism
6CH
PrismRotate
7CH
8CH
Frost
9CH
Focus
10CH
Pan
11CH
Pan Fine
12CH
Tilt
13CH
TiltFine
14CH
Pan/TiltSpeed
15CH
Reset
16CH
Lamp Control
5.6 ManuelTab 6.
DMX Channels
5.7 Reset Tab
Option
Instruction
Reset
SystemReset
Pan & TiltReset
Effect Reset
Return
5.8 Factory Default
Option
Instruction
Lamp
Lamp On / Off
Return
BackTo MainMenu
Option
Instruction
FactoryDefault
Use Jog WheelToEnterPassword
Pass
1111

Channel
Function
Value
Description
1
Color
0-4
Open
5-9
Open/DarkRed
10-13
Dark Red
14-18
Dark Red/Darkyellow
19-22
Dark Yellow
23-27
Dark Yellow/Aquamarine
28-31
Aqua Marine
32-36
Aquamarine/DarkGreen
37-41
Dark Green
42-45
DarkGreen/Olivine
46-50
Olivine
51-54
Olivine/Pink
55-59
Pink
60-63
Pink/Yellow
64-68
Yellow
69-73
Yellow/Magenta
74-77
Magenta
78-82
Magenta/Cyan
83-86
Cyan
87-91
Cyan/GoldenYellow
92-95
GoldenYellow
96-100
GoldenYellow/Amber
101-105
Amber
106-109
Amber/CTO
110-114
CTO
115-118
CTO/Fluorescent
119-123
Fluorescent
124-127
Fluorescent/Open
128-191
ColorScrollRev.
192-225
ColorScrollForward
Channel
Function
Value
Description
2
Strobe
0-3
Close
4-7
ShutterOpen
8-97
StrobeSlow ToFast
98-101
ShutterOpen
102-126
Pules FromSlowTo Fast
127-151
Pules FromFast ToSlow
152-155
ShutterOpen
156-180
RandomPulesSlow ToFast
181-205
RandomPulesFast ToSlow
206-209
ShutterOpen
210-249
RandomStrobeSlowToFast
250-255
ShutterClosed
3
Dimmer
0-255
Turn Lamp On Or Off

Channel
Function
Value
Description
4
StaticGobo
174-180
GoboShake3
181-187
GoboShake4
188-194
Gobo Shake5
195-201
Gobo Shake6
202-207
Gobo Shake7
208-214
GoboShake8
215-221
Gobo Shake9
222-228
GoboShake10
229-235
GoboShake11
236-242
Gobo Shake12
243-249
GoboShake 13
250-255
GoboShake14
5
Prism
0-127
No Prism
128-255
Prism
6
Rotating
prism
0-63
No Rotation
64-127
Rev. Rotation
128-191
Fwd. Rotation
192-207
90°Shake
208-223
180° Shake
224-239
270° Shake
240-255
360°Shake
255
FastRotation
7
No Function
Channel
Function
Value
Description
4
StaticGobo
0-4
Open
5-9
Gobo1
10-14
Gobo2
15-19
Gobo3
20-23
Gobo4
24-28
Gobo5
29-33
Gobo6
34-38
Gobo7
39-43
Gobo8
44-47
Gobo9
48-52
Gobo10
53-57
Gobo11
58-62
Gobo12
63-67
Gobo13
68-71
Gobo14
72-115
Gobo Scroll Rev.
116-159
Gobo Scroll Fwd.
160-166
Gobo 1 Shake
167-173
Gobo2Shake

Channel
Function
Value
Description
8
Frost
0-255
No Frost ToFrost
9
Focus
0-255
No FocusTo Focus
10
Pan
0-255
0-540°
11
Pan Fine
0-255
0-1.8°
12
Tilt
0-255
0-270°
13
Tiltfine
0-255
0-1.8°
14
MotorSpeed
0-255
Pan/TiltSpeed
15
Reset
0-13
UnusedRange
26-76
EffectReset
77-127
Pan/TiltReset
128-255
CompleteReset
16
Lamp control
32-63
Lamp PowerReduction
160-191
Lamp Off (5sec.)
224-255
Lamp On (5sec.)
7. Installation
Mountingthe fixture in areas away from reach by unauthorized
personnelis always recommended. Before mounting the fixture
make surethat the area you are using can hold a minimumload
of 5x the Fixtures weight. You must always use a secondary
safety attachment, such as a safety cable. The OMEZ
TitanBeam™2R is fully operational in any install position,
including:hanging upside down on a truss or by setting it on a
flat level surface. Always make sure that all fixture are kept at
least 0.5m away from any flammable materials.
8. Cleaning & Maintenance
For best results OMEZ TitanBeam™ 2R requires routine cleaning
and maintenance. Excessive dust, smoke fluid, and particulate
buildup will degrade the performance and will cause the fixture to
overheat. The damage from this is not is not covered in the
manufacture warranty. Always make sure you unplug the fixture
before openingany coversfor cleaning.Optical components should
be cleaned carefully and do not use any harmful solvents to avoid
damage. Remember to keep all air ventsclean and free from clutter
that will prevents constant air flow.
When resetting fixture please allow an average of 20 sec. for the fixture to reset all
sensors and motors. Fixture will continue where it left off. The lamp will stay on so
there is no cool off wait time. Always remember if the light bulb turns of at any time
during operation there is a 5-10 minute cool down period before bulb ignites.

OMEZ
Omez Lightingreservesthe right to make changes and/or improvements in
designuponits productswithoutanyobligationto include these changes to
any products theretofore manufactured. Please check our website,
www.OmezLighitng.com,regularly for any updates to manuals.
Warraty
Omez Lighting isdedicated to providing quality, affordable lighting products around the world.
We stand behind all of our products and offera 3 year warranty. Please read below for the
terms and conditions of our warranty.
Omez Lighting, hereby warrants that this products shall be free of manufacturing defects in
material and workmanship for a period of 3 years from the date of purchase. This warranty
shall be valid onlyif the product is purchased from an authorized Omez Lighting dealer. Please
contact OMEZ Lighting directly for all warranties. It is the purchaser’s responsibility to provide
acceptable proof of purchase that includes date and location of purchase.
For Warranty service please contact OMEZ lighting to obtain a Return Merchandise
Authorization number (RMA#). You must include the RMA# when shipping product back to
Omez. To contact the Omez Lighting Service Department, please email [e-mail]
or call 888-683-OMEZ. All shipping charges must be prepaid. If the requested repairs or
services (including parts replacement) are within the terms of this warranty, Omez Lighting will
pay return shipping charges (within the United States).Products must be shipped in the
original package. It is recommended that accessories not be shipped with the product. Should
any accessories arrive with the product, Omez Lighting is not liable for loss of or damage.
The warranty will be considered voidif:
• There appears to be any tampering, altering, or removal of the original serial number;
• The product is modified or altered in any way, including the removal or covering of the Omez
Branding;
• Any modifications are made that affects the reliability of the product;
• The product has been repaired or serviced by anyone other than Omez (unless prior written
authorization by Omez);
• Or if the product is damaged because improper maintenance as set forth in the instruction
manual.
Omez Lighting will replace or repair defective parts with new or refurbished parts, and will
cover expenses forwarranty services and repair caused by defects in material or
workmanship. The responsibility of Omez Lighting underthis warranty shall be limited to the
repair or replacement of the product, including parts, at the sole discretion of Omez Lighting.
Omez Lighting reserves the right to make changes and/or improvements in design upon its
products without any obligation to include these changes to any products theretofore
manufactured. This warranty is the only written warranty applicable to Omez Lighting
Products and supersedes all prior warranties and written descriptions of warranty terms and
conditions heretofore published.
