Omneon MediaGrid ContentServer 1042C-DP User manual

Omneon MediaGrid ContentServer 1042C-DP
Quick Reference Guide
28-0255 Rev. COmneon Technical Support: 888 686-7781 (Americas), [phone] (Asia Pacific), + 44 1256 347 401 (EMEA), [phone] (Other)
1 Power Indicator/Wink
2 Air Vents
3 Status LEDs
1 Power Supplies (2)
2 Power Supply Status LED
3 Reset Button
4 Soft Power Button
5 Wink LED
6 Video Connector
7 Ethernet Ports (L=0, R=1)
Rear Panel Components
Front Panel Components

28-0255 Rev. C
Front Panel LEDs
Ethernet Port LEDs
Omneon Technical Support: 888 686-7781 (Americas), [phone] (Asia Pacific), + 44 1256 347 401 (EMEA), [phone] (Other)
(Solid) Online
Ethernet link problem
White
Red
Blue (Blink) ContentServer cannot download its
configuration file from ContentDirector
For the indicated Ethernet port
Off
(Blink) Active network port
Power off
(Solid) Normal state; disk online
Disk offline, may be unmounted or inactive;
drive failure
White
Red
For the indicated disk drives
Off
(Blink) Read/write activity
Power off
Ethernet Port 0
Disk 3
Disk 2
Ethernet Port 1
Disk 4
Disk 1
Activity (Right)
LED LED State NIC State
Link (Left) Off
Green (solid)
Amber (solid)
Power off, network cables unplugged
Power off, network cables plugged in; active connection at 100 Mb/s
Power on, network cables pugged in; active connection at 1 Gb/s
Off
Yellow (solid)
Yellow (blink)
Power off, network cables unplugged
Power on, active connection
Power on, network data being sent or received
Link
indicator
Activity
indicator
Port 0 Port 1
