Omni Skydrate Operating instructions
USER & MAINTENANCE GUIDE
™
2
3
TABLE OF CONTENTS
CONTENTS
Table of Contents........................................................................................ 3
Important Safety Information ................................................................... 4
System Components .................................................................................. 5
Quickstart..................................................................................................... 6
Control Unit Kit............................................................................................ 8
Control Unit ................................................................................................. 9
Charger & Batteries .................................................................................. 10
Hose Switch ............................................................................................... 11
Removable Hoses ..................................................................................... 12
Collection Bag............................................................................................ 13
Male Cup .................................................................................................... 14
Undergarment........................................................................................... 15
Male System Overview ............................................................................. 16
Charging the System ................................................................................ 17
Donning the System ................................................................................. 18
Prepping the System ................................................................................ 21
Male System Operation............................................................................ 22
After Mission ............................................................................................. 23
Care, Maintenance and Storage.............................................................. 24
Troubleshooting........................................................................................ 25
Technical Specications ........................................................................... 26
Warranty .................................................................................................... 27
4
1. Always follow instructions when operating the device.
2. The batteries must be fully recharged at least once every 6 months.
3. The batteries must be left in fully charged state when they are not
going to be used for more than 2 months.
4. Do not submerge Control Unit under water.
5. Do not use liquid cleaners (bleach, vinegar, alcohol, ammonia, etc.)
or aerosol cleaners. Clean using a warm water (or a solution of 3%
hydrogen peroxide) and a damp cloth.
6. Use only the type of power supply provided with the Skydrate™
System.
7. Do not attempt to service this product yourself, as opening or
removing covers may damage the device and void your warranty.
8. Refer all servicing to Omni Service Technicians under the following
conditions:
• When the power-supply cord or plug is damaged.
• If the product does not operate.
• If the product has been dropped or damaged in any way.
• When the product exhibits a distinct change in performance.
9. All servicing should be done by a certied Omni Service Technician.
Unauthorized component substitutions may result in re, electric
shock, or other hazards.
10. This product should be kept away from heat sources such as
radiators, heat registers, stoves, or other products that produce
heat.
IMPORTANT SAFETY INFORMATION
Before using the Skydrate™ System in a mission
setting, familiarize yourself with the components
and operation of the system. Practice using the
Skydrate™ in a chair or ight simulator before
using it in an aircraft.
5
SYSTEM COMPONENTS
Male Cup
Collection Bag
Control Unit
Male Hose
(Cup Side)
Male Hose
(Control Unit Side)
Hose
Switch
Battery Charger &
Battery
Skydrate Personal Aircrew Flight Equipment
The Skydrate is a fully automatic, hands free bladder relief system
designed for use in xed and rotary wing aircraft. The system was
designed to allow pilots to be hydrated during mission (in accordance
with mandatory regulation for aircrew of military aircraft) and to
remain fully clothed and secure in their seat harness at all times.
QUICKSTART
How Does The Skydrate Work?
The Skydrate system is simple to use. Worn discretely beneath the
ight suit, the collection cup hose connector contains sensors that will
detect urine once the user begins to urinate. The external control unit
will automatically activate, evacuating the urine from the cup and into
the attached collection bag. The Gen 3 Hose Switch has a push button
for manual activation of the control unit without waiting for sensors.
Cup worn discretely beneath
the ight suit.
Gen 3 System Conguration
66
7
QUICKSTART
MALE SYSTEM OPERATION PROCEDURE
OVERVIEW
DON THE SYSTEM
1. Don the Boxer Briefs.
2. Connect the removable hose to the cup. Insert the cup into place
within the briefs.
3. Insert the penis through the hole in the Briefs, into the cup via the
Foam Ring.
4. Don the rest of the ight ensemble. If using the Through Suit
Connector (TSC), connect the hose to the inside TSC port. If not,
make sure that the cup hose is accessible via the ight suit's zipper.
BEFORE TAKE OFF
1. Ensure that the control unit is fully charged (all green lights)
2. Ensure that the system is fully connected.
3. Ensure that the collection bag drain is closed.
SYSTEM OPERATION
1. Before urinating, ensure that the cup is in the correct position and
connect the hose to the control unit.
2. The system is now activated, and will automatically drain urine
into the collection bag as soon as the aircrew begins to urinate.
3. The system can remain connected for the duration of the ight.
8
CONTROL UNIT KIT
• 1 Control Unit
• 1 Charger
• 2 Battery Packs
• 1 Wall Power Adaptor
• 1 User Manual
KIT CONTENTS
Gen 3 Control Unit with QR Code for easy access to
Omni's Training and Supply App.
Charger with 2 Battery Packs.
Batteries are shipped in sleep mode.
Wall Power Adapter
9
CONTROL UNIT
Bag Release
Battery Status
Indicator
(Green LEDs)
GREEN Push Button
(Manual Activation)
Sensor
Pins
Hose Ports
Battery
Release
Latch
10
CHARGER & BATTERIES
Fully charged, the battery lasts for up to 12 uses within a 16 hour
period.
Long Term Storage: Batteries are shipped in sleep mode. Once the
battery is taken out of sleep mode (charged for the rst time), the
batteries must be fully recharged every 6 months.
The battery charger is only for use with the Skydrate™ rechargeable
battery packs. It must only be used with the supplied power supply.
DO NOT submerge batteries in water.
DO NOT leave batteries discharged.
Battery Status
Indicator Light
11
HOSE SWITCH
The Hose Switch allows for one handed operation
of the system.
Note: Tan color Code to Cup Side Hose Connector
ON/OFF Switch
Puts the system into Automatic mode (ON) or
disconnects it (OFF).
Manual Button
Manually activates the liquid
pump while held.
Removable Hose Control Unit Side
Note: Black Connector is Color Coded to the
Hose Switch
Removable Hose Cup Side
Note: Tan Connector is Color Coded to the
Hose Switch
It can be used to manually activate the system,
as well as to completely deactivate the system
without disconnecting any hoses.
Note: Black Color Code to Control Unit Side Hose
Connector
12
REMOVABLE HOSES
Nomex Covered
Hose
Control Unit
Connector
Cup Connector
With Sensors
Hose Switch
Connector
Cup Side
Hose Switch
Connector
Pump Side
The removable hoses connect the cup to the hose switch and/or
control unit. These hoses are reusable and should be inspected and
tested before each ight - replace after 25 ights.
Hose
Lengths:
18”/24"
Hose
Lengths:
12"/18”/24"
13
COLLECTION BAG
DO NOT OVERFILL THE COLLECTION BAG
The Collection Bag has a one-time emergency 1000mL over-capacity safety
factor and must be replaced after overlling.
Standard Reusable Bag
Filled with 1200mL
Filled with 2200 mL
The Collection Bag is manufactured from durable, medical-grade
urethane. The standard bags have a capacity of 1200mL. While not
recommended, in an emergency it can withstand up to 2200mL.
Air Vent
Odor Proof
Hydro Block
Control Unit
Connection Clip
Drainage Valve
Clockwise to
tighten DisposableReusable
14
MALE CUP
The Male Cup has a removable hose which attaches to the bottom of
the cup. It is designed for optimal use in all aircraft, including aircraft
with the 5-point harness. The cup is reusable, at the user’s discretion,
for up to 20 ights or 30 days with proper cleaning.
Soft Foam Ring
Medical Grade
Latex-Free
Hose
Connector
Polyurethane Cup
Medical-Grade
Latex-Free
Removable hose
connects to the
bottom of the cup.
15
UNDERGARMENT
UNDERGARMENT
The undergarments are used to hold the Cup in place. They should be
sized for a snug t.
Features:
• No-melt, no-drip construction
• Lightweight and Breathable
• Machine washable
MALE GARMENT
MG-XX-MF
WAIST
32-34”
36-38”
40-42”
44-46”
SIZE
S
M
L
XL
16
MALE SYSTEM OVERVIEW
The Male System consists of the Male Cup, Male Hose, In-Line Hose
Switch, Control Unit, and Collection Bag. They are connected
together as pictured below. These are the only components required
on a mission. Additional batteries and bags may be taken as needed.
Green Status LEDs will Flash Battery Status continuously
when system is ON, activated and ready for use.
17
CHARGING THE SYSTEM
Connect a Rechargeable
Battery to the Charger.
Connect the cord from the
Power Supply to the Charger.
The battery pack must be charged prior to the rst use.
It make take up to 2.5 hours.
A solid GREEN light indicates that
the battery is charged.
A ashing YELLOW light indicates
that the battery is charging.
A ashing RED light indicates
that the battery is completely
discharged.
If it does not change to yellow after an
hour, the battery must be replaced.
18
Attach Hose
Attach the hose to
the cup. Ensure
that the hose snaps
securely in place.
Rotate hose for
desired location.
Position Hose
The hose exits the
garment at the
bottom, and can be
positioned as desired.
Insert Cup
Place the cup into
the garment pocket
and insert the male
anatomy through the
foam ring. Secure the
pocket.
Alignment Flaps
If necessary, the alignment aps can
be cut o and discarded to provide a
more comfortable t.
Depending on which provides a better
t, future supplies can be ordered
with or without aps as desired.
DONNING THE MALE SYSTEM (REMOVABLE HOSE)
Connect to System
Leave hose accessible via
garment zipper or other
access point. Connect
to Skydrate Control Unit
and Bag for use.
19
DONNING THE MALE SYSTEM
The Cup may be inserted into the Undergarment
either before or after donning.
Insert the Male Cup (with hose
attached) into the cup pocket ,
making sure that the foam ring is
aligned with the hole.
If the garment is currently donned,
insert the penis through the hole in
the fabric and through the foam ring
of the cup.
Open the cup pocket aps on the
front of the Male garment.
While keeping the cup in place,
fasten the pocket aps shut with the
Velcro strip.
Make sure that the cup is secure in
the cup pocket.
20
DONNING THE MALE SYSTEM
After the cup has been placed into the boxer
briefs, insert the penis through the foam ring
of the cup while donning the boxer briefs.
The boxer briefs should be a
comfortable, snug t to properly
hold the Male Cup in place.
Ensure that the hose can be
retrieved through the bottom
zipper after donning ight gear.
Once seated in aircraft, adjust the cup for comfort and ensure that the
tip of the cup is down and between the legs.
After entering the aircraft, but before securing the harness, retrieve
the hose and zip the ight suit to capture the hose. Ensure that the
hose is not kinked, crimped or pinched.
Table of contents
