Omniaire 1000V User manual

Operation and Maintenance Manual
1000V
HEPA Air Filtration Machine

CONFORMS TO UL STD 507
CERTIFIED TO CAN/CSA STD
C22.2 NO. 113-M1984
WARNING
Do not use with combustible or explosive material. Do not expose to water or rain. Connect
only to grounded outlet with GFCI device. Disconnect power for cleaning and servicing.
This equipment to be operated only by trained personnel.
Safety Warning Instructions:
READ AND SAVE THESE INSTRUCTIONS
This equipment to be operated only by trained personnel.
Do not use with combustible or explosive material.
Do not expose to water or rain.
Connect only to grounded outlet with GFCI device.
Disconnect power for cleaning and servicing.
Do not operate if cord or plug is damaged. Contact a authorized service facility for examination and/or repair.
Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Arrange cord away
from traffic areas and where it is not a tripping hazard.
Avertissement de sécurité Instructions:
LIRE ET CONSERVER CES INSTRUCTIONS
Cet équipement doit être utilisé que par un personnel formé.
Ne pas utiliser avec des matières combustibles ou explosives.
Ne pas exposer à l’eau ou à la pluie.
Connectez uniquement à une prise mise à la terre avec un dispositif GFCI.
Coupez l’alimentation électrique pour le nettoyage et l’entretien.
Ne pas utiliser si le cordon ou la fiche est endommagé. Contactez un centre de service autorisé pour examen et / ou
réparation.
Ne pas passer le cordon sous un tapis. Ne pas couvrir le cordon avec des carpettes, les coureurs, ou revêtements simi-
laires. Éloigner le cordon des endroits passants et où il n’est pas un risque de déclenchement.

The OmniAire 1000V is a compact, lightweight air scrubber with variable airflow. It is used for removal of toxic mold,
asbestos and lead dust during renovation and abatement projects, and for purifying air in commercial, factory sites
and medical facilities. This popular, mid-sized machine is made of strong aircraft- grade aluminum housing with
smooth surfaces, for easy sanitation. It can be used with multiple filter options such as HEPA, Activated Carbon plus
MERV 9 primary/secondary filter. Additional accessories include intake manifold, flex ducting and quick clamps.
Application Examples
OmniAire 1000V Specifications
Airflow: 300 - 900 CFM
Power Requirements: 115VAC/60 Hz/4.4 Amp (OA1000V); also available 230VAC/60Hz (OA1000V230)
Filtration: HEPA filter 99.97% 0.3μ; MERV 9 primary/secondary filter. Optional: MERV 11 Pleated Filter; OdorGuard 600
activated carbon filter; HEPA filter 99.99% 0.3μ
Controls: speed selector switch - HIGH/Speed Control; variable speed controller; hour meter; 0-3” WC pressure gauge
Housing: aircraft grade aluminum; silicone sealed before riveting; 10” outlet; (2) rubber grip handles; (4) 3” hospital
grade locking casters.
Size/Weight with Filters: 19”W x 23”H x 34”L; 75 lbs.
Receiving Instructions
Visually inspect the unit for damage. Remove the primary/secondary filter and ensure that the HEPA filter has not been
dislodged during shipping. The HEPA filter should be sitting on the filter guides and the filter tabs that hold the HEPA
filter in place should be tight.
If the filter is not seated correctly then remove the filter tabs, reposition the filter, and reinstall the filter tabs before
operation to ensure that there is no bypass around the filter. If the filter tabs are loose verify that the filter is in the
correct position and re-tighten the filter tab nuts.
Operations
For Asbestos and mold abatement, the machine must be operated with a HEPA filter in place. Also, it is recommended
to use the primary/secondary filer and replace it frequently to extend the life of the HEPA.
contaminated
containment area
positive pressure
clean contained area
clean
ltered
air
sealed contaminated
containment area
sealed
clean room
clean
ltered
air
recirculation
sealed contaminated
clean
ltered
air
contaminated
air
negative pressure
sealed contaminated
sealed
clean room
clean
ltered
air
negative pressure
contaminated room
clean
ltered
air
contaminated
air
contaminated
air
contaminated
air
contaminated
containment area
positive pressure
clean contained area
clean
ltered
air
sealed contaminated
containment area
sealed
clean room
clean
ltered
air
recirculation
sealed contaminated
clean
ltered
air
contaminated
air
negative pressure
sealed contaminated
sealed
clean room
clean
ltered
air
negative pressure
contaminated room
clean
ltered
air
contaminated
air
contaminated
air
contaminated
air
To create NEGATIVE PRESSURE inside the containment,
more air has to be exhausted out than leaks into the
containment. Place the machine inside the containment
and hook a flexible duct to the outlet ring of the
machine exhausting to outside the containment.
(See Above) All of the air being exhausted has been
treated by the HEPA filter so no contaminants are being
exhausted from the containment.
To create POSITIVE PRESSURE inside the containment,
more air has to be pumped in than leaks out of the
containment. Place the machine outside the containment
and hook a flexible duct to the outlet ring of the machine
ducting the exhaust into the containment. (See Above)

Speed Control
The air flow can be regulated from 300 to 900 cfm by using the HIGH/VARIABLE speed selector switch and the SPEED
CONTROL knob.
Start the Machine
To start the machine in high speed, set the rocker switch HIGH/VARIABLE speed to the HIGH position. In this position
the SPEED CONTROL is disabled.
To start the machine in VARIABLE SPEED, set the rocker switch to the VARIABLE SPEED position and rotate the SPEED
CONTROL knob clockwise to obtain the desired airflow. As the filters fill with dust, the efficiency of the filters are
maintained, but the airflow will decrease and the vacuum reading will increase. Change the primary/secondary filter
frequently to protect the HEPA and to get more air flow and prolong the life of your HEPA. When the vacuum gauge
reached about 2.0” CC, with a clean per-filter in place, the HEPA filter will have to be replaced. Accessories such as
an optional intake manifold can be used on the suction side of the unit providing 12” connection for the flex duct. The
discharge side of the unit has a 12” diameter ring for a flex duct.
Maintenance
The blower and motor do not require any maintenance when the machine is operated with the HEPA filter in place.
Pr-Filter Replacement
The primary/secondary filter should be changed when the orange side shows it is loaded with dust. Changing the
filter can be done while the machine is running. Ensure that the orange side of the prefilter is facing the HEPA filter.
HEPA Filter Replacement
During your projects, your HEPA filter purifies the air and gradually becomes loaded with
sub-micron particulates. Even when the HEPA filter is fully loaded, the filter is still removing
particulates from the air at the rated efficiency yet at a reduced airflow. This will affect the
ability of the machine to provide positive or negative pressure within the containment.
To replace the HEPA filter unplug the machine and remove the screen/manifold to remove
the prefilter. You will see 4 filter tabs holding the HEPA filter in place (see photo). These tabs
are secured with 1/4-20 Nylock nuts, which require a 7/16” wrench or socket. Remove all 4
filter tab retaining nuts and remove the filter tabs and set aside. Slide the HEPA filter out
along the filter guides and remove it from the machine. ALWAYS TREAT THE USED HEPA
FILTER AS HAZMAT AND PROCESS IT ACCORDING TO YOUR ESTABLISHED HAZMAT PROCEDURES.
To replace the HEPA filter ensure that the gasket on the HEPA filter faces inwards toward the flange, slide the filter
in place along the filter guides and re-install the filter tabs and filter tab securing nuts. The nuts should initially be
tightened to where the stud is flush with the end of the nut. This will compress the gasket on the filter approximately 1/2
of the thickness. This allows for the filter to be reseated and tightened at a later time if necessary.
Troubleshooting
Your Omnitec Design machine is designed and engineered to provide years of trouble free service. Occasionally
problems occur. Here are some helpful tips and solutions
The machine does not start
1. Check that the unit is plugged in and there is 115VAC available. Select either LOW or HIGH speed to turn the machine
on. If the red indicator light comes on, power is coming to the unit from the outlet.
2. Call Omnitec technical support to troubleshoot further.
filter tab

The machine just hums when turned on
1. Unplug the unit.
2. Remove the HEPA filter and push the blower wheel by hand. If it does not move freely or if you hear a grinding/
scrapping noise as you spin it, then the blower wheel is touching the side of the blower housing. This may be due to an
impact of some kind and the motor mounts have been bent. Remove the motor/blower assembly and replaced the
bent motor mounts.
3. If the blower spins freely, check the capacitor. With the HEPA filter still removed from the machine, insure that the
wiring connected to the capacitor is plugged in and not broken. Re-plug the unit into the power outlet keeping the
switch in the OFF position. Then push the blower wheel and as it is spinning, turn the speed selector switch to HIGH. If
the machine keeps running, the capacitor needs to be replaced.
The machine will run for a few minutes then turn off
1. The machine must have a HEPA filter installed to operate properly. If you are trying to run it without a filter in place,
the motor will overheat within a few minutes and the thermal overload will engage and shut it down. Let he motor
cool off for 30 minutes, install the filter and try running the machine again.
2. If the filter is in pace and the machine still shuts off after a few minutes then the motor is faulty. Replace the motor.
The machine vibrates excessively when running
1. This is an indication that the motor bearings are worn out. If the machine continues running, at this point the
vibration will cause the center hub of the blower wheel to separate from the wheel requiring replacement of both the
motor and blower. Replace the motor.
2. If the machine does require electrical servicing of the motor or switches the following page contains a wiring
diagram to aid in repair or troubleshooting.

4640 Campus Place, Suite 100
T. 425.290.3922 | F. 425.290.3964
Wiring Diagram
DRAWN BY: REV
SCALE DAT E SHEET
A. Briceno A
Not to Scale Nobember 9, 2018
MODEL
Diagram Legend
Terminated (Capped) Wire
Wiring Connector
Red LED Light
R
Green LED Light
G
Amber LED Light
A
OA1000V
1 of 1
115
VAC
60Hz 0.5 HP
MOTOR
20 μF
CAPACITOR
SPEED
CONTROLLER
ON
ON
HOUR
METER
WHITE
BLACK
GREEN
BLACK
BLUE
WHITE
GREEN
GREEN
Ordering Info Part #
OmniAire 1000V OA1000V
Primary/Secondary Two-Stage Filters (box of 20) OAP1818
MERV 11 Pleated Filter OPF1616
HEPA Filter 99.99%, 0.3μ (metal frame) OAH1616G
HEPA FILTER 99.97%, 0.3μ (pb frame) OAH1616
OdorGuard 600 Carbon Filter OG1616
Intake Manifold Kit (Manifold, Clamp & 3’ Duct) OAIM1000-10KIT
ABS Plastic Intake Manifold, 10” Dia. OAIM10
Quick Clamp, 8”-10” Dia. QCW12
Flexible Duct, 10” Dia. x 25’ L OAD10
Flexible Duct, Wire & Fiber Reinforced OAD10R

LIMITED WARRANTY REGISTRATION
The undersigned has read and understood the above Warranty and Limitation of Warranty and Limitation of Remedy.
PRODUCT # SERIAL #
PURCHASED FROM DATE
CUSTOMER INFORMATION
COMPANY PHONE
STREET
CITY STATE ZIP CODE
BY DATE
PLEASE SEND TO:
Omnitec Design 4640 Campus Place Ste. 100 Mukilteo, WA 98275
Omnitec Design LIMITED WARRANTY
Omnitec Design warrants, for a period of twelve (12)
months from the date of purchase, that all Products,
component parts and accessories, excluding filters,
will be free from defects in material and workmanship
under normal use and service.
THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY
UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR
REPLACEMENT OF DEFECTIVE PARTS F.O.B., Omnitec
Design 4640 Campus Place Ste. 100, Mukilteo, WA 98275
Phone: [phone]
In order to keep this warranty in effect for the
aforementioned twelve-month period, the purchaser
must (i) promptly, i.e., immediately upon discovery,
inform Omnitec Design’s customer service of any
defects, and (ii) properly use and maintain the Product
prior to the discovery of any defect.
This warranty does not cover normal wear and tear or
defects caused by (i) improper or negligent handling or
unauthorized modifications; (ii) defective or improper
premises, chemical, or electrical influences; or (iii)
weather or other forces of nature.
In order to provide the best customer service possible,
Omnitec Design requests that purchaser completes the
enclosed LIMITED WARRANTY REGISTRATION FORM
and returns it to Omnitec Design within 30 days of
purchase date.
LIMITATIONS OF WARRANTY
THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL
OTHER WARRANTIES AND OBLIGATIONS OF Omnitec
Design OR ITS SUPPLIERS, EXPRESS OR IMPLIED,
AND Omnitec Design EXPRESSLY DISCLAIMS ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR
ANY PARTICULAR PURPOSE.
LIMITATION OF REMEDY
Under no circumstances shall Omnitec Design or
any supplier of Omnitec Design be liable for any
loss or damage, including, but not limited to, loss or
damage arising out of the failure of the Products to
operate for any period of time, inconvenience, the use
of rental or replacement equipment, loss of profits or
other economic loss, or general, direct, special, indirect,
incidental or consequential damages or property
damages.
PRODUCT SUITABILITY
Many states and localities have their own varied
codes and regulations governing sales, construction,
installation, and/or use of Products for certain
purposes. While Omnitec Design attempts to assure
that its Products comply with such codes, it cannot
guarantee compliance, and cannot be responsible for
how the Products are installed or used. Omnitec Design
recommends that, before purchasing and using a
Product, purchasers review the Product application, and
federal, state and local regulations, to be sure that the
Products, installation, and use will comply with them.
